Driving force analysis of carbon storage spatial-temporal variation in Xiaoxing'anling Mountains and its contribution to carbon emission reduction
-
摘要:
研究目的 生态系统在固碳释氧方面发挥着重要作用，可有效减缓气候变化。碳储量是衡量生态系统碳汇能力的重要指标，可为制定碳减排策略提供科学依据。但当前关于碳储分布的研究多聚焦于单一因素影响，对多因子协同作用及其空间分异规律的系统探讨相对较少，系统分析了中国小兴安岭地区碳储量的时空分布格局及其变化驱动机制，并评估了其对区域碳平衡管理与碳减排目标实现的潜在贡献。
研究方法 针对多因子对生态系统碳储量空间分异的作用机制，借助2000年、2010年、2020年土地利用数据，基于InVEST模型估算小兴安岭地区的碳储量及其空间分布特征，使用随机森林模型对地形、气象、土壤等重要变量进行筛选，并选择地理探测器探索驱动研究区碳储量空间分异的主要驱动因子，探究其驱动机制。
研究结果 ①研究区土地利用类型主要以林地（77%）、耕地（20%）为主，地类结构变化明显，表现为耕地、建设用地面积增加，林地、草地面积减少；②研究区近20年碳储总量提升14.72%，耕地与林地、草地的相互转化是碳储量减少的主要原因；③碳储量空间分异的主导因子为植被覆盖度（0.254~0.278）和土壤质地（0.146~0.168）。
结论 尽管小兴安岭地区近20年林草面积有所减少，削弱了生态系统的碳汇能力，但局部区域碳储量的增长掩盖了局部区域的减少，体现出研究区具有一定的生态恢复潜力。然而，人类活动导致区域碳汇能力承压变大，增加了碳排放控制的难度。因此，研究区虽然具有生态恢复能力，但为提升区域碳汇功能，缓解区域碳排放压力，应持续加强生态保护和恢复措施。
Abstract:Objective Ecosystems play an important role in carbon fixation and oxygen release, which can effectively mitigate climate change. Carbon storage is an important index to measure the carbon sink capacity of ecosystems, which can provide a scientific basis for formulating carbon emission reduction strategies. However, the current research on the distribution of carbon storage mostly focuses on the influence of a single factor, and there are relatively few systematic discussions on the multi-factor synergy and its spatial differentiation. Therefore, this study systematically analyzes the spatial and temporal distribution pattern of carbon storage in the Xiaoxing'anling region of China and its driving mechanism of change, and evaluates its potential contribution to regional carbon balance management and carbon emission reduction targets.
Methods Aiming at the mechanism of multi-factors on the spatial differentiation of ecosystem carbon storage, this study used the land use data of 2000, 2010 and 2020 to estimate the carbon storage and its spatial distribution characteristics in the Lesser Khingan Mountains based on the InVEST model. The random forest model was used to screen important variables such as topography, meteorology and soil, and the geographical detector was selected to explore the main driving factors driving the spatial differentiation of carbon storage in the study area and explore its driving mechanism.
Results ①The spatial distribution of carbon stocks in the study area is characterized by the following factors. The land use types in the study area are mainly dominated by forest land (77%) and cropland (20%), and the change of land structure is obvious, which is manifested in the increase of cropland and construction land area, and the decrease of forest land and grassland area; ②The total amount of carbon stock in the study area has increased by 14.72% in the last 20 a, and the mutual transformation of cropland and forest land and grassland is the main reason for the decrease of carbon stock; ③The dominant factors in the spatial differentiation of carbon stocks were vegetation cover (0.254~0.278) and soil texture (0.146~0.168).
Conclusions Although the area of forest and grass in the Xiaoxing'anling Mountains has decreased in the past 20 years, which has weakened the carbon sink capacity of the ecosystem, the increase of carbon storage in local areas has covered up the reduction of local areas, reflecting that the study area has certain ecological restoration potential. However, human activities have led to greater pressure on regional carbon sink capacity, increasing the difficulty of carbon emission control. Therefore, although the study area has the ability of ecological restoration, in order to enhance the regional carbon sink function and alleviate the pressure of regional carbon emissions, the ecological protection and restoration measures in the study area should be continuously strengthened.
-
Key words:
- carbon storage /
- driving factors /
- ecosystem service /
- interactive detection /
- random forest /
- Xiaoxing'an Mountains
-
-
表 1 数据来源及类型
Table 1. Data sources and types
数据源 空间分
辨率数据来源 土地利用数据（2000s、2010s、2020s） 1 km zenodo（ https://doi.org/10.5281/zenodo.4417810 ）数字高程模型（DEM） 30 m 国家地球系统科学数据中心( http://www.geodata.cn )归一化植被指数 1 km 年均气温 1 km 年均降水量 1 km 年均蒸散量 1 km 夜间灯光数据 1 km 土壤数据集(HWSD) 500 m 国家青藏高原科学数据中心( http://data.tpdc.ac.cn )人口密度数据 1 km WorldPop
（https://www.worldpop.org/ ）中国GDP空间分布公里网格数据集 1 km 中国科学院资源环境数据中心（ https://www.resdc.cn/ ）
下载: 导出CSV
表 2 不同土地利用碳密度
Table 2. Carbon density values of different land use types
t/ha 用地类型 地上碳密度 地下碳密度 土壤碳密度 死亡有机物碳密度 2000年 2010年 2020年 2000年 2010年 2020年 2000年 2010年 2020年 2000年 2010年 2020年 耕地 10.10 10.47 10.63 26.80 27.77 28.21 147.70 153.48 152.35 0.00 0.00 0.00 林地 41.88 43.40 44.08 31.32 32.46 32.97 173.90 180.71 179.38 2.25 2.33 2.37 草地 6.96 7.21 7.33 51.00 52.85 53.68 74.60 77.52 76.95 2.84 2.94 2.99 水域 8.72 9.04 9.18 2.21 2.29 2.33 23.01 23.91 23.73 0.00 0.00 0.00 建设用地 8.75 9.07 9.21 4.39 4.55 4.62 27.78 28.87 28.66 1.16 1.20 1.22 未利用地 10.03 10.39 10.56 0.00 0.00 0.00 44.79 46.54 46.20 0.00 0.00 0.00 湿地 0.65 0.67 0.68 0.32 0.33 0.34 28.43 29.54 29.33 0.38 0.39 0.40
下载: 导出CSV
表 3 交互作用类型
Table 3. Types of interactions
判断依据 类型 q(x1∩x2)<Min[q(x1),q(x2)] 非线性减弱 Min[q(x1),q(x2)]<q(x1∩x2)<Max[q(x1),q(x2)] 单因子非线性减弱 q(x1∩x2)>Max[q(x1),q(x2)] 双因子增强 q(x1∩x2)=q(x1)+q(x2) 独立 q(x1∩x2)>q(x1)+q(x2) 非线性增强
下载: 导出CSV
表 4 研究区1990—2020年土地利用面积
Table 4. The land use area of the study area from 1990 to 2020
ha 土地利用类型 2000年 2010年 2020年 耕地 2143093.32 2338291.08 2429273.16 林地 8267553.45 8146704.6 8028870.75 草地 204012.54 107879.22 109856.16 水域 41408.28 44268.75 43688.34 未利用地 333.27 220.05 418.86 建设用地 64975.86 86683.23 112958.73 湿地 6986.97 4316.76 3297.69
下载: 导出CSV
-
[1] Cao S X, Liu Y J, Su W, et al. 2018. The net ecosystem services value in mainland China[J]. Science China Earth Sciences, 61: 595−603. doi: 10.1007/s11430-017-9153-4
[2] Cheng J M, Cheng J, Yang X M, et al. 2012. Spatial distribution of carbon density in grassland vegetation of the Loess Plateau of China[J]. Acta Ecologica Sinica, 32(1): 226−237(in Chinese with English abstract). doi: 10.5846/stxb201011131626
[3] Cheng J, Huang W Q, Zhang S C, et al. 2023. Spatial distribution and influencing factors of topsoil organic carbon density in Fujian Province, China[J]. Journal of Agricultural Resources and Environment, 40(4): 805−816(in Chinese with English abstract).
[4] Cui X Y, Xu W T, Guan Q R. 2021. Estimation of organic carbon stocks in the East China Sea[J]. Infrared and Laser Engineering, 50(6): 110−121(in Chinese with English abstract).
[5] Dangullam M, Manaf L A, Ramli M F, et al. 2021. Exploring urban tree diversity and carbon stocks in Zaria Metropolis, North Western Nigeria[J]. Applied Geography, 127(1): 102385.
[6] Ding Y, Wang G Q, Gui F, et al. 2023. Ecosystem carbon storage in Hangzhou Bay Area based on InVEST and PLUS models[J]. Environmental Science, 44(6): 3343−3352 (in Chinese with English abstract).
[7] Fang J Y, Wang Z M. 2001. Forest biomass estimation at region-al and global levels, with special reference to China’s forest biomass[J]. Ecological Research, 16(3): 587−592. doi: 10.1046/j.1440-1703.2001.00419.x
[8] Gao Y, He N P, Wang Y F. 2013. Characteristics of carbon sequestration by ecosystem and progress in its research.[J]. Journal of Natural Resources, 28(7): 1264−1274 (in Chinese with English abstract).
[9] Guo P T, Cha Z Z, Luo W, 2023. Acquiring environmental factor weights using normalized difference vegetation index for soil management zoning[J]. Transactions of the Chinese Society of Agricultural Engineering, 39(3): 60-67(in Chinese with English abstract).
[10] Guo S P. 2011. Analysis on carbon stock and potential carbon sequestration in Heilongjiang Province[J]. Forest Engineering, 27(3): 9−11,6(in Chinese with English abstract).
[11] Guo Y D, Zhang Q L, Zhang R, et al. 2022. Construction of remote sensing model for biomass estimation of artificial shrubbery in Kubuqi Desert[J]. Journal of Northeast Forestry University2, 50(9): 56−60(in Chinese with English abstract).
[12] Jiao Y, Hu H Q. 2005. Carbon storage and its dynamics of forest vegetations in Heilongjiang Province[J]. Chinese Journal of Applied Ecology, 16(12): 2248−2252(in Chinese with English abstract).
[13] Li H H, Li C B, Wu J, et al. 2022. Spatio-temporal dynamics and climate response ofgrassland net primary productivity in Shiyang River basin from 2000 to 2020[J]. Pratacultural Science, 39(10): 2048−2061(in Chinese with English abstract).
[14] Li R W, Ye C C, Wang Y, et al. 2021. Carbon storage estimation and its drivering force analysis based on InVEST model in the Tibetan Plateau[J]. Acta Agrestia Sinica, 29(z1): 43−51(in Chinese with English abstract).
[15] Li Y, Zhao Y Z, Zhuo Z Q, et al. 2023. Analysis of ecological problems and its conservation-restoration strategy of mountains, rivers, forests, farmlands, lakes and grasslands in the Xiaoxing'an Mountains-Sanjiang Plain[J]. Ecological Science. 42(1): 95−104(in Chinese with English abstract).
[16] Liu G, Zhang J, Li Jie, et al. 2021. Study on change in carbon storage and its spatial pattern in Mata Watershed from 1999 to 2016 based on InVEST model[J]. Arid Zone Research, 38(1): 267−274 (in Chinese with English abstract).
[17] Liu Y N, Xi M, Zhang L X, et al. 2019. Carbon storage distribution characteristics of wetlands in China and its influencing factors[J]. Chinese journal of applied ecology, 30(7): 2481−2489 (in Chinese with English abstract).
[18] Liu Y, Zang J, Zhuo D M, et al. 2021. Temporal and spatial variation of carbon storage in the Shule River Basin based on InVEST model[J]. Acta Ecologica Sinica, 41(10): 4052−4065 (in Chinese with English abstract).
[19] Lu Y Y, Xu X L, Li J C, et al. 2022. Research on the spatio-temporal variation of carbon storage in the Xinjiang Tianshan Mountains based on the InVEST model[J]. Arid Zone Research, 39(6): 1896−1906(in Chinese with English abstract).
[20] Man W D, Wang Z M, Liu M Y, et al. 2016. Spatio-temporal dynamics analysis of cropland in Northeast China during 1990-2013 based on remote sensing[J]. Transactions of the Chinese Society of Agricultural Engineering, 32(7): 1−10(in Chinese with English abstract).
[21] Piao S L, Fang J Y, He J S, et al. 2004. Spatial distribution of grassland biomass in China[J]. Chinese Journal of Plant Ecology, (4): 491−498(in Chinese with English abstract).
[22] Qu C, Li W, Xu J, et al. 2023. Potential impact of black land conservation and utilization on carbon storage in Heilongjiang Province[J]. Journal of Northwest Forestry University, 38(5): 194−203(in Chinese with English abstract).
[23] Wang C W, Luo J J, Tang H H. 2023. Analysis on the driving force of spatial and temporal differentiation of carbon storage in the Taihang Mountains based on InVEST model[J]. Ecology and Environmental Sciences, 32(2): 215−225 (in Chinese with English abstract).
[24] Wang J F, Xu C D. 2017. Geodetector: Principle and prospective[J]. Acta Geographica Sinica, 72(1): 116−134(in Chinese with English abstract).
[25] Wang L X, Ding H L, Liu Z. 2022. Spatiotemporal change of NPP based on CASA model and its response to climate change in Jing River Basin[J]. Research of Soil and Water Conservation, 29(1): 190−196(in Chinese with English abstract).
[26] Wang S Q, Liu J Y, Yu G R. 2003. Error analysis of estimating terrestrial soil organic carbon storage in China[J]. Chinese Journal of Applied Ecology, 14(5): 797−802(in Chinese with English abstract).
[27] Wang S Q, Zhou C H. 1999. Estimating soil carbon reservior of terrestrial ecosystem in China[J]. Geographical Research, 18(4): 349−356(in Chinese with English abstract).
[28] Wu H, Xu H. 2021. Remote sensing retrieval and calibration of forest vegetation carbon density based on time-series data[J]. Forest and Grassland Resources Research, 281(6): 43−51 (in Chinese with English abstract).
[29] Xu W Y, Jin X B, Yang X H, et al. 2018. The estimation of forest vegetation biomass in China in spatial grid[J]. Journal of Natural Resources, 33(10): 1725−1741(in Chinese with English abstract). doi: 10.31497/zrzyxb.20170802
[30] Yang X W, Zhang L J, Qin Y C, et al. 2022. Temporal and spatial variation and driving factors of carbon storage in the lower yellow river since 1995[J]. Journal of Henan University(Natural Science), 52(1): 20−33(in Chinese with English abstract).
[31] You H Z, Bi J, Wang C, et al. 2018. Altitudinal distribution rule of betula platyphylla forest's soil organic carbon density and its influencing factors in Xiaowutai Mountain in Hebei[J]. Ecology and Environmental Sciences, 27(3): 432−437(in Chinese with English abstract).
[32] Zhang C H, Wang L Y, Song Q W, et al. 2018. Biomass carbon stocks and dynamics of forests in Heilongjiang Province from 1973 to 2013[J]. China Environmental Science, 38(12): 4678−4686(in Chinese with English abstract).
[33] Zhang M M, Liu M Y, Chang Q R, et al. 2018. Spatial distribution of organic carbon in topsoil of the loess tableland in Shaanxi Province during 1985-2015[J]. Journal of Natural Resources, 33(11): 2032−2045 (in Chinese with English abstract). doi: 10.31497/zrzyxb.20171085
[34] Zhao M M, Zhao N, Liu Y, et al. 2019. An overview of forest carbon measurement methods[J]. Acta Ecologica Sinica, 39(11): 3797−3807 (in Chinese with English abstract).
[35] 程积民, 程杰, 杨晓梅, 等. 2012. 黄土高原草地植被碳密度的空间分布特征[J]. 生态学报, 32(1): 226−237.
[36] 程金, 黄文卿, 张世昌, 等. 2023. 福建省表层土壤有机碳密度空间分布及影响因素分析[J]. 农业资源与环境学报, 40(4): 805−816.
[37] 崔晓宇, 徐文韬, 关其锐. 2021. 东海有机碳存量估算[J]. 红外与激光工程, 50(6): 110−121.
[38] 丁岳, 王柳柱, 桂峰, 等. 2023. 基于InVEST模型和PLUS模型的环杭州湾生态系统碳储量[J]. 环境科学, 44(6): 3343−3352.
[39] 高扬, 何念鹏, 汪亚峰. 2013. 生态系统固碳特征及其研究进展[J]. 自然资源学报, 28(7): 1264−1274. doi: 10.11849/zrzyxb.2013.07.018
[40] 郭澎涛, 茶正早, 罗微. 2023. 基于归一化植被指数获取环境因子权重的土壤管理分区方法[J]. 农业工程学报, 39(3): 60−67. doi: 10.11975/j.issn.1002-6819.202208189
[41] 郭树平. 2011. 黑龙江省碳储量及碳汇潜力分析[J]. 森林工程, 27(3): 9−11, 6. doi: 10.3969/j.issn.1001-005X.2011.03.003
[42] 郭玉东, 张秋良, 张榕, 等. 2022. 库布齐沙漠人工灌木林生物量的遥感估测模型构建[J]. 东北林业大学学报, 50(9): 56−60.
[43] 焦燕, 胡海清. 2005. 黑龙江省森林植被碳储量及其动态变化[J]. 应用生态学报, 16(12): 2248−2252. doi: 10.3321/j.issn:1001-9332.2005.12.005
[44] 李怀海, 李纯斌, 吴静, 吉珍霞, 等. 2022. 2000—2020年石羊河流域草地净初级生产力时空动态及其对气候的响应[J]. 草业科学, 39(10): 2048−2061.
[45] 李若玮, 叶冲冲, 王毅, 等. 2021. 基于InVEST模型的青藏高原碳储量估算及其驱动力分析[J]. 草地学报, 29(z1): 43−51.
[46] 李勇, 赵云泽, 卓志清, 等. 2023. 小兴安岭—三江平原区生态问题辨析及山水林田湖草保护修复策略[J]. 生态科学, 42(1): 95−104.
[47] 刘冠, 李国庆, 李洁, 等. 2021. 基于InVEST模型的1999-2016年麻塔流域碳储量变化及空间格局研究[J]. 干旱区研究, 38(1): 267−274.
[48] 刘亚男, 郗敏, 张希丽, 等. 2019. 中国湿地碳储量分布特征及其影响因素[J]. 应用生态学报, 30(7): 2481−2489.
[49] 刘洋, 张军, 周冬梅, 等. 2021. 基于InVEST模型的疏勒河流域碳储量时空变化研究[J]. 生态学报, 41(10): 4052−4065.
[50] 卢雅焱, 徐晓亮, 李基才, 等. 2022. 基于InVEST模型的新疆天山碳储量时空演变研究[J]. 干旱区研究, 39(6): 1896−1906.
[51] 满卫东, 王宗明, 刘明月, 等. 2016. 1990-2013年东北地区耕地时空变化遥感分析[J]. 农业工程学报, 32(7): 1−10. doi: 10.11975/j.issn.1002-6819.2016.07.001
[52] 朴世龙, 方精云, 贺金生, 等. 2004. 中国草地植被生物量及其空间分布格局[J]. 植物生态学报, (4): 491−498. doi: 10.3321/j.issn:1005-264X.2004.04.007
[53] 曲琛, 李文, 徐嘉, 等. 2023. 黑龙江黑土地保护利用对碳储量的潜在影响[J]. 西北林学院学报, 38(5): 194−203. doi: 10.3969/j.issn.1001-7461.2023.05.26
[54] 王成武, 罗俊杰, 唐鸿湖. 2023. 基于InVEST模型的太行山沿线地区生态系统碳储量时空分异驱动力分析[J]. 生态环境学报, 32(2): 215−225.
[55] 王劲峰, 徐成东. 2017. 地理探测器: 原理与展望[J]. 地理学报, 72(1): 116−134. doi: 10.11821/dlxb201701010
[56] 王丽霞, 丁慧兰, 刘招, 等. 2022. 基于CASA模型探究泾河流域植被NPP时空动态及其对气候变化的响应[J]. 水土保持通报, 29(1): 190−196.
[57] 王绍强, 刘纪远, 于贵瑞. 2003. 中国陆地土壤有机碳蓄积量估算误差分析[J]. 应用生态学报, 14(5): 797−802. doi: 10.3321/j.issn:1001-9332.2003.05.034
[58] 王绍强, 周成虎. 1999. 中国陆地土壤有机碳库的估算[J]. 地理研究, 18(4): 349−356. doi: 10.3321/j.issn:1000-0585.1999.04.003
[59] 吴恒, 胥辉. 2021. 森林植被碳密度遥感反演和校准研究[J]. 林业资源管理, 281(6): 43−51.
[60] 徐伟义, 金晓斌, 杨绪红, 等. 2018. 中国森林植被生物量空间网格化估计[J]. 自然资源学报, 33(10): 1725−1741.
[61] 杨小琬, 张丽君, 秦耀辰, 等. 2022. 1995年以来黄河下游碳储量时空变化及驱动因素[J]. 河南大学学报(自然科学版), 52(1): 20−33.
[62] 尤海丹, 毕君, 王超, 等. 2018. 河北小五台山不同海拔白桦林土壤有机碳密度分布特征及影响因素[J]. 生态环境学报, 27(3): 432−437.
[63] 张春华, 王莉媛, 宋茜薇, 等. 2018. 1973—2013年黑龙江省森林碳储量及其动态变化[J]. 中国环境科学, 38(12): 4678−4686. doi: 10.3969/j.issn.1000-6923.2018.12.036
[64] 张萌萌, 刘梦云, 常庆瑞, 等. 2018. 1985—2015年陕西黄土台塬表层土壤有机碳空间分布[J]. 自然资源学报, 33(11): 2032−2045.
[65] 赵苗苗, 赵娜, 刘羽, 等. 2019. 森林碳计量方法研究进展[J]. 生态学报, 39(11): 3797−3807.
-
