Distribution law and main controlling factors of formation water in the fifth member of the Majiagou Formation in the southeastern part of Sulige Gas Field, Ordos Basin and its influence on oil and gas exploitation
-
摘要:
研究目的 鄂尔多斯盆地苏里格气田东南部奥陶系马家沟组五段储层主要为碳酸盐岩储层，在生产过程中地层出水严重，气水关系复杂，主控因素不明确，在很大程度上制约了该区的天然气生产。
研究方法 在地层水化学特征分析的基础上，利用氯钠系数、脱硫系数、钠钙系数等参数对地层水的形成环境进行分析；进而通过单井识别、连井对比及平面展布特征刻画研究了气水分布规律；最后结合构造、古地貌、储层物性等方面研究了气水分布的主控因素及其对油气开采量的影响。
研究结果 结果表明，苏里格气田东南部马五1亚段地层水矿化度较高，平均148905.46 mg/L，pH显示弱—中酸性，水型均表现为CaCl2型，地层水整体表现为低氯钠系数、钠钙系数和脱硫系数，高氯镁系数、变质系数和盐化系数特征，地层封闭性较好，有利于气藏保存。纵向上，根据成因差异及空间分布形态将地层水分为构造低部位水、孤立透镜状水和低渗带滞留水，构造低部位水常见于研究区西部构造相对较低处和东南方向构造相对较低的鼻凹处；孤立透镜状水较为不发育。平面上看，产水井主要集中在G4-8、S158等5个区域，其中东部含水面积较大，主要为气水混合区。
结论 地层水分布受构造和前石炭纪古地貌格局及储层非均质性3个因素同时控制。构造高点控制纵向上气水分异，更容易产水，岩溶古地貌控制气水横向分布非均质性，使得某些区域渗透率低，影响开发效果，储层特征控制气驱水效率，物性较好的储层富含天然气，物性差的区块滞留水多，影响产量。
Abstract:Objective The reservoirs of the fifth member of the Ordovician Majiagou Formation in the southeastern part of the Sulige Gas Field are mainly carbonate reservoirs. During the production process, the formation water produced seriously, the gas−water relationship was complex, and the main controlling factors were unclear. Restricting natural gas production in the area.
Methods Based on the analysis of the chemical characteristics of formation water, this paper uses parameters such as chlorine−sodium coefficient, desulfurization coefficient, and sodium−calcium coefficient to analyze the formation environment of formation water; then, it studies the formation environment of formation water through single well identification, continuous well comparison, and plane distribution characteristics. The distribution rules of gas and water; finally, the main controlling factors of gas and water distribution and their impact on oil and gas production were studied based on the structure, ancient landforms and reservoir physical properties.
Results The results show that the formation water in the Ma51 subsection in the southeastern part of the Sulige gas field has high salinity, with an average of 148905.46 mg/L, PH shows weak to medium acidity, the water type is CaCl2 type, and the formation water overall is low chlorine The characteristics of sodium coefficient, sodium−calcium coefficient and desulfurization coefficient, high chlorine−magnesium coefficient, metamorphism coefficient and salinization coefficient make the formation sealing better, which is beneficial to the preservation of gas reservoirs. Vertically, the formation water is divided into structural low water, isolated lenticular water and low permeability zone retained water based on the differences in origin and spatial distribution. Water in structural low parts is common in the relatively low structures in the west of the study area and in the relatively high structures in the southeast. Low nasal recess; isolated lenticular water is less developed. On the plane, water−producing wells are mainly concentrated in five areas including G4−8 and S158. The eastern part has a larger water−bearing area and is mainly a gas−water mixing area.
Conclusions The distribution of formation water is controlled by three factors: structure, pre−Carboniferous paleo−geomorphology and reservoir heterogeneity. Structural highs control the vertical gas−water differentiation, making it easier to produce water. Karst paleo−geomorphology controls the lateral distribution heterogeneity of gas and water, making the permeability of some areas low, affecting the development effect. Reservoir characteristics control the efficiency of gas−driven water. Reservoirs with better physical properties are rich in natural gas, and blocks with poor physical properties retain more water, affecting production.
-
-
表 1 苏里格气田东南部马家沟组马五1亚段地层水化学特征
Table 1. Characterization of stratigraphic water chemistry in Ma 51 subsection, southeastern part of Sulige gas field
井号 地层水离子含量/（mg·L−1） 总矿化度/(mg·L−1) 水型 pH值 K＋＋Na＋ Ca2＋ Mg2＋ Cl− SO42− HCO3− G4-9 8253.8 6887.8 895.2 27190.2 0.0 562.1 206487.4 CaCl2 5.9 S179 11052.9 16440.8 2136.9 52067.2 31.3 449.0 82178.1 CaCl2 5.3 G3-8 11105.9 17026.0 1721.2 51978.6 52.8 410.0 82294.4 CaCl2 6.1 G0-9 17978.6 25545.5 1127.9 75785.0 229.2 404.4 121070.5 CaCl2 5.4 J51-18 28755.3 20663.2 4177.7 92701.8 0.0 612.1 146910.0 CaCl2 5.3 J49-14 18469.6 22765.4 2761.6 76524.1 0.0 462.4 120983.3 CaCl2 6.1 G2-8 16594.6 31127.1 2981.0 89023.8 0.0 534.1 157606.6 CaCl2 5.6 G04-6 16270.0 31393.5 1410.5 84463.2 0.0 449.7 133986.7 CaCl2 6.2 J52-25 10618.7 22091.7 2115.7 61427.8 0.0 324.8 96578.6 CaCl2 5.4 W26-5 20240.6 27264.4 1984.4 84980.7 0.0 401.9 134872.0 CaCl2 5.6 G4-10 13745.0 28557.2 2767.3 79574.3 9.9 328.5 124982.1 CaCl2 5.9 G2-2 25877.1 26680.5 3053.3 95800.1 0.0 320.5 155410.6 CaCl2 5.9 G1-8A 14087.3 43602.0 1057.9 101739.7 0.0 324.8 160811.7 CaCl2 5.2 G4-8 27686.8 43065.2 5936.5 135922.4 176.2 199.1 212986.1 CaCl2 6.3 J41-30 16648.4 40695.2 2115.7 103659.4 0.0 274.8 163393.5 CaCl2 5.4 G2-9 20546.2 39864.6 3643.5 112642.4 0.0 293.7 176990.3 CaCl2 5.6 S155 41618.5 46218.3 5096.9 160563.0 11.0 343.2 253851.0 CaCl2 5.1
下载: 导出CSV
表 2 马五1亚段地层水化学分析数据
Table 2. Data sheet for chemical analysis of stratigraphic water in Ma 51 subsection
井名 钠氯
系数脱硫
系数变质
系数氯镁
系数盐化
系数钠钙
系数陕179 0.16 0 20.56 49.00 115.96 0.41 G3-8 0.24 0 10.51 27.71 126.79 0.81 靖49-14 0.24 0.60 25.62 67.19 165.49 0.70 G0-9 0.14 0 41.43 96.18 187.42 0.32 靖52-25 0.19 0 12.15 29.86 189.15 0.53 G4-10 0.18 0 12.64 30.92 242.21 0.52 乌26-5 0.21 0.20 11.87 30.20 211.47 0.65 G04-6 0.17 0.02 11.89 28.76 187.83 0.48 靖51-18 0.20 0.26 9.12 22.90 151.46 0.64 G2-2 0.30 0 10.58 30.38 298.90 1.20 G2-8 0.26 0.014 11.67 31.51 166.70 0.90 G1-8A 0.21 0.12 9.60 24.37 313.28 0.67 靖41-30 0.24 0 16.31 42.82 377.22 0.74 G2-9 0.19 0 24.17 59.88 383.49 0.52 G4-9 0.27 0 11.45 31.38 48.37 0.97 G4-8 0.17 0 12.01 29.03 682.79 0.48 陕155 0.31 0 7.65 22.19 467.91 1.39
下载: 导出CSV
-
[1] Bai H, Yang G P, Ma Z X, et al. 2017. The Influence of Ordovician Palaeokarst landform of gas reservoir in the eastern part of Sulige gasfield[J]. Natural Gas Exploration and Development, 40(2): 21−25(in Chinese with English abstract).
[2] Dai J X, Li J, Luo X, et al. 2005. Alkane carbon isotopic composition and gas source in giant gas fields of Ordos Basin[J]. Acta Petrolei Sinica, (1): 18−26(in Chinese with English abstract).
[3] Dou W T, Liu X S, Wang T. 2010. The origin of formation water and the regularity of gas and water distribution for the Sulige gas field, Ordos Basin[J]. Acta Petrolei Sinica, 31(5): 767−773(in Chinese with English abstract).
[4] Duan Z Y, Li X, Chen C F, et al. 2019. Gas and water distribution and its controlling factors of Xiashihezi Formation in J58 well area, Hangjinqi area[J]. Lithologic Reservoirs, 31(3): 45−54(in Chinese with English abstract).
[5] Fan M M, Li W H, Bu J. 2016. Rare earth element characteristics of sediment samples of Triassicmaximum flooding period in Longdong area of Ordos Basin and theirprovenance significance[J]. Geological Bulletin of China, 35(2/3): 390−397(in Chinese with English abstract).
[6] Feng Z Z, Bao Z D. 1999. Lithofacies paleogeography of the Ordovician Majiagou Stage in the Ordos Basin[J]. Acta Sedimentologica Sinica, (1): 1−8(in Chinese with English abstract).
[7] Guo M , Li Z D, Du S L, et al. 2009. The genesis of formation water and its relation to oil−gas accumulation in upper paleozoic of HangJinQi area[J]. Mineralogy and Petrology, 29(1): 99−105(in Chinese with English abstract).
[8] Li A R, Qiang Q , Xu L H, et al. 2022. Chemical characteristics of formation water of Chang 2 oil formation ofYanchang Formation in Zhaike area, Ordos Basin and its indication to denseoil reservoir[J]. Natural Gas Geoscience, 33(10): 1637−1647(in Chinese with English abstract).
[9] Li X Q, Hou D J, Liu C Q, et al. 2002. Hydrochemical characteristics of lower paleozoic formationwater and idendification of natural gas enrichment area incentral gas fields in erduosi[J]. Natural Gas Industry, (4): 10−14,11−12(in Chinese with English abstract).
[10] Liang J W, Li R X, Chen Y L. 2013. Geochemical behaviors and genesis of formation water in 8th Member of Xiashihezi Formation in western Sulige gas field, Ordos Basin[J]. Oil & Gas Geology, 34(5): 625−630(in Chinese with English abstract).
[11] Luo J L, Wei X S, Yao J L, et al. 2010. Provenance and depositional facies controlling on the Upper Paleozoicexcellent natural gas−reservoir in northern Ordos basin, China[J]. Geological Bulletin of China, 29(6): 811−820(in Chinese with English abstract).
[12] Qiu T T. 2023. Carbonate reservoir evaluation of Majiagou Formation in Zhao4l well area, southeastern Jiangsu, Ordos Basin[D]. Master Thesis of Xi'an Shiyou University(in Chinese with English abstract).
[13] Tian W W, Zhang J, Fan A P, et al. 2020. Origin of Formation Water and Main Controlling Factors of Gas−Water Distribution in S120 Block of Sulige Gasfield[J]. Journal of Xi'an Shiyou University(Natural Science Edition), 35(6): 1−9(in Chinese with English abstract).
[14] Wang J P, Li Y G, Wang H, et al. 2013. Study on formation water distribution law in tight sandstone gasreservoir of Su X Block in west area of Sulige, Ordos Basin, China[J]. Journal of Chengdu University of Technology (Science & Technology Edition), 40(4): 387−393(in Chinese with English abstract).
[15] Wang L J, Wang Z, Li X Y, et al. 2025. Study on chemical characteristics and driving mechanism of shallow groundwater in Shijiazhuang area[J]. Geological Bulletin of China, 44(5): 1−11(in Chinese with English abstract).
[16] Wang Q C, Zhao S P, Wei Q L, et al. 2012. Marine carbonate reservoir characteristics of the Middle Ordovician Majiagou Formation in Ordos Basin[J]. Journal of Palaeogeography, 14(2): 229−242(in Chinese with English abstract).
[17] Wang S Y, Luo Q, Song Z X, et al. 2007. Genesis and physical modelling of aquifer in deep basin gas pool of He−8 Member in Sulige region, Ordos basin[J]. Oil & Gas Geology, (3): 413−418,426(in Chinese with English abstract).
[18] Wang Y. 2017. Analysis on Characteristics and Controlling Factors of Gas−WaterDistribution Pattern in Su 11 Block of Sulige Gas Field[J]. Unconventional Oil & Gas, (3): 25−28,14(in Chinese with English abstract).
[19] Wu J M, Kang J Y, Miao X X, et al. 2024. Complex gas water distribution law of the gas reservoir of the secondmember of Xujiahe Formation in Xinchang area, western Sichuan[J]. Natural Gas Geoscience, 35(7): 1−12(in Chinese with English abstract).
[20] Yang F, Liu Y B. 2022. Study on the influence of salt structural system on the distributioncharacteristics of potassium−rich brine reservoirs in Jiangling depression[J]. Geological Bulletin of China, 41(10): 1847−1854(in Chinese with English abstract).
[21] Yang R C, Dong L, Zhang J, et al. 2022. Origin, Distribution and Controlling Factors of Stratigraphic Water in the Western Sulige Gas Field[J]. Acta Sedimentologica Sinica, 40(1): 267−280(in Chinese with English abstract).
[22] Yu Z Y. 2017. The gas and water distribution pattern andthe main controlling factors in Ma5 Memberof Tao2 well area, Sulige Gas Field [D]. Master Thesis of Northwest University(in Chinese with English abstract).
[23] Zhang H R. 2014. Distribution of Gas−Water and Water Production Rule in Sulige Gas−area[D]. Master Thesis of Xi'an Shiyou University (in Chinese with English abstract).
[24] Zhang L, Xu T H, Yang Z K, et al. 2021. Analysis on hydrochemical characteristics of formation water in Sudong Block[J]. Unconventional Oil & Gas, 8(5): 27−33(in Chinese with English abstract).
[25] Zhao W W, Wang X J, Yang Z L, et al. 2012. Relationship between hydrochemical characteristics of Majiagou formation water in Lower Paleozoic in Sulige region and natural gas accumulation[J]. Journal of Xi'an Shiyou University(Natural Science Edition), 27(1): 35−41,52,119(in Chinese with English abstract).
[26] Zhao W Z, Wang Z C, Zhu Y X, et al. 2005. Forming mechanism of low−efficiency gas reservoir in Sulige Gas Field of Ordos Basin[J]. Acta Petrolei Sinica, (5): 9−13(in Chinese with English abstract).
[27] Zhao Y Q, Ni C H, Wu X Q, et al. 2022. Geochemical characteristics and source of Permian formation water in Hangjinqi area, Ordos Basin[J]. Petroleum Geology & Experiment, 44(2): 279−287(in Chinese with English abstract).
[28] Zhou X X. 2014. Groundwater and natural gas distribution characteristics in the continental strata of the central western Sichuan Depression [D]. Master Thesis of Zhejiang University: 28−47(in Chinese with English abstract).
[29] 白慧, 杨国平, 马志欣, 等. 2017. 苏里格气田东区奥陶系岩溶古地貌对气藏产能的影响[J]. 天然气勘探与开发, 40(2): 21−25.
[30] 戴金星, 李剑, 罗霞, 等. 2005. 鄂尔多斯盆地大气田的烷烃气碳同位素组成特征及其气源对比[J]. 石油学报, (1): 18−26.
[31] 窦伟坦, 刘新社, 王涛. 2010. 鄂尔多斯盆地苏里格气田地层水成因及气水分布规律[J]. 石油学报, 31(5): 767−773.
[32] 段治有, 李贤, 陈纯芳, 等. 2019. 杭锦旗地区J58井区下石盒子组气水分布及其控制因素[J]. 岩性油气藏, 31(3): 45−54.
[33] 范萌萌, 李文厚, 卜军. 2016. 鄂尔多斯盆地陇东地区三叠纪最大湖泛期沉积物稀土元素地球化学特征及其物源意义[J]. 地质通报, 35(2/31): 390−397.
[34] 冯增昭, 鲍志东. 1999. 鄂尔多斯奥陶纪马家沟期岩相古地理[J]. 沉积学报, (01): 1−8.
[35] 过敏, 李仲东, 杜少林, 等. 2009. 杭锦旗地区上古生界地层水成因及其与油气的关系[J]. 矿物岩石, 29(1): 99−105.
[36] 李爱荣, 强倩, 徐龙虹等. 2022. 鄂尔多斯盆地寨科地区延长组长2油层组地层水化学参数特征及对致密油藏的指示作用[J]. 天然气地球科学, 33(10): 1637−1647.
[37] 李贤庆, 侯读杰, 柳常青, 等. 2002. 鄂尔多斯中部气田下古生界水化学特征及天然气藏富集区判识[J]. 天然气工业, (4): 10−14,11−12.
[38] 梁积伟, 李荣西, 陈玉良. 2013. 鄂尔多斯盆地苏里格气田西部盒8段地层水地球化学特征及成因[J]. 石油与天然气地质, 34(5): 625−630.
[39] 罗静兰, 魏新善, 姚泾利等. 2010. 物源与沉积相对鄂尔多斯盆地北部上古生界天然气优质储层的控制[J]. 地质通报, 29(6): 811−820.
[40] 邱甜甜. 2023. 鄂尔多斯盆地苏东南召41井区马家沟组碳酸盐岩储层评价[D]. 西安石油大学硕士学位论文: 30−40.
[41] 田伟伟, 张吉, 樊爱萍, 等. 2020. 苏里格气田S120区块地层水成因及气水分布主控因素[J]. 西安石油大学学报(自然科学版), 35(6): 1−9.
[42] 王继平, 李跃刚, 王宏, 等. 2013. 苏里格西区苏X区块致密砂岩气藏地层水分布规律[J]. 成都理工大学学报(自然科学版), 40(4): 387−393.
[43] 王丽娟, 王哲, 李晓媛, 等. 2025. 石家庄地区浅层地下水化学特征及形成机制研究[J]. 地质通报, 44(5): 837−847.
[44] 王起琮, 赵淑萍, 魏钦廉, 等. 2012. 鄂尔多斯盆地中奥陶统马家沟组海相碳酸盐岩储集层特征[J]. 古地理学报, 14(2): 229−242.
[45] 王世艳, 罗群, 宋子学, 等. 2007. 鄂尔多斯盆地苏里格盒8段深盆气藏含水层成因及其物理模拟[J]. 石油与天然气地质, (3): 413−418,426.
[46] 王颖. 2017. 苏里格气田苏11区块气水分布特征及控制因素分析[J]. 非常规油气, (3): 14, 25−28.
[47] 吴见萌, 康建云, 缪祥禧, 等. 2024. 川西新场地区须二气藏气水分布规律[J]. 天然气地球科学, 35(7): 1−12.
[48] 杨飞, 刘雅博. 2022. 江陵凹陷盐隆构造体系对富钾卤水储层分布特征的影响[J]. 地质通报, 41(10): 1847−1854.
[49] 杨仁超, 董亮, 张吉, 等. 2022. 苏里格气田西区地层水成因、分布规律与控制因素[J]. 沉积学报, 40(1): 267−280.
[50] 余朱宇. 2017. 苏里格气田桃2区块马五段气、水分布规律及其主控因素[D]. 西北大学硕士学位论文: 47−59.
[51] 张海荣. 2014. 苏里格气田气水分布及产水规律研究[D]. 西安石油大学硕士学位论文: 15−27.
[52] 张林, 徐铜浩, 杨智凯, 等. 2021. 苏东区块地层水水化学特征分析[J]. 非常规油气, 8(5): 27−33.
[53] 赵卫卫, 王秀娟, 杨兆林, 等. 2012. 苏里格地区下古生界马家沟组地层水化学特征与天然气聚集关系[J]. 西安石油大学学报(自然科学版), 27(1): 35−41,52,119.
[54] 赵文智, 汪泽成, 朱怡翔, 等. 2005. 鄂尔多斯盆地苏里格气田低效气藏的形成机理[J]. 石油学报, (5): 9−13. doi: 10.7623/syxb200505002
[55] 赵永强, 倪春华, 吴小奇, 等. 2022. 鄂尔多斯盆地杭锦旗地区二叠系地层水地球化学特征和来源[J]. 石油实验地质, 44(2): 279−287.
[56] 周孝鑫. 2014. 川西坳陷中段陆相层系地下水与天然气分布特征[D]. 浙江大学硕士学位论文: 28−47.
-
