Analysis of oil and gas accumulation periods in the Permian system in the central Ordos Basin: A case study of Shanxi-Shihezi Formation in Wuqi area
-
摘要:
研究目的 伊陕斜坡是鄂尔多斯盆地重要的含油气区，油气成藏时期划分对于揭示油气的赋存规律和指导勘探开发具有重要意义。
研究方法 通过对鄂尔多斯盆地吴起地区山西组−石盒子组的流体包裹体均一温度测定，结合岩石学特征和热演化史研究，确定油气充注时序。
研究结果 镜下观察结果表明，研究区山西组−石盒子组储层早期流体包裹体主要分布在石英颗粒微裂隙中及石英加大边，晚期流体包裹体主要分布在方解石胶结物。通过测试得出包裹体均一温度分布连续，早期均一温度峰值主要分布在110~120℃，晚期均一温度峰值主要分布在140~150℃。
结论 结合成岩作用与热演化史分析，可得出存在2个主要油气充注期：第一期油气充注为晚三叠世—早侏罗世（212~195 Ma），储层在早成岩B期，该时期煤系地层热演化达到成熟阶段，此时以溶蚀和交代作用为主；第二期油气充注在晚侏罗世—早白垩世（155~130 Ma），储层在中成岩A期，成岩作用以钙质胶结物溶蚀作用为主，增加了次生孔隙，达到最高热演化阶段，为主油气充注期。
Abstract:Objective The Yishan slope is an area of significant oil and gas−bearing potential within the Ordos Basin, the delineation of the oil and gas formation periods is of paramount importance in the revelation of the laws governing oil and gas storage, and in the provision of guidelines for exploration and development.
Methods The timing of oil and gas charging can be determined by measuring the homogeneous temperature of fluid inclusions in the Shanxi−Shihezi Formation in the Wuqi area of the Ordos Basin. This is combined with petrological characteristics and thermal evolution history research methods.
Results The microscopic observation results show that there are mainly two stages of fluid inclusions in the Shanxi−Shihezi Formation in the study area. The early inclusions are mainly distributed in the microcracks quartz particles and the enlarged edges of quartz, and the late inclusions are mainly distributed in the late cement. Through the implementation homogenization temperature test, the peak temperature distribution of early inclusions is 110~120℃, while the peak temperature distribution of late inclusions is 140~150℃.
Conclusions Combined with the analysis of the thermal evolution history and diagenesis, it can be concluded that there are two periods of oil and gas filling: the first period of oil and gas charging time is the Late Triassic—Early Jurassic (212~195 Ma), the reservoir is in the early diagenetic stage B. During this period, the thermal evolution of the coal−bearing stratum reaches the mature stage with dissolution and replacement being the predominant processes. The second period of oil and gas charging time, spanning the Late Jurassic to Early Cretaceous (155~130 Ma), coincides with the middle diagenetic stage A. In this stage, the diagenetic process is primarily dominated by the dissolution of calcareous cement, leading to an increase in secondary pores and the attainment of the highest thermal evolution, which marks the primary charging time.
-
Key words:
- accumulation period /
- homogenization temperature /
- fluid inclusions /
- Permian /
- the Ordos Basin
-
-
表 1 吴起地区山西组−石盒子组储层包裹体样品统计
Table 1. Stastistics of inclusion samples in the Shanxi−Shihezi Formation reservoir in Wuqi area
井号 层位 深度/m 岩性 赋存矿物产状 延1232 山西组 4028.6 灰白色中细砂岩 石英颗粒裂隙、石英加大边 延1207 山西组 3820.1 灰褐色中细砂岩 石英颗粒裂隙 延1141 山西组 3710.8 灰白色中细砂岩 石英颗粒裂隙 延1141 石盒子组 3670.2 灰白色细砂岩 石英颗粒裂隙、石英加大边 延1360 石盒子组 4180.3 浅灰色中细砂岩 石英颗粒裂隙、方解石胶结物 延1008 山西组 3931.0 深灰色细砂岩 石英颗粒裂隙、石英加大边 延1355 山西组 3983.6 灰褐色细砂岩 石英颗粒裂隙、石英加大边、方解石胶结物 延1161 石盒子组 3875.7 浅灰色中细砂岩 石英颗粒裂隙、石英加大边 延1352 山西组 3944.3 灰色砂岩 石英颗粒裂隙、石英加大边 延1350 山西组 4003.6 浅灰色中细砂岩 石英颗粒裂隙 延1366 山西组 3865.0 灰黑色细砂岩 石英颗粒裂隙、石英加大边
下载: 导出CSV
表 2 吴起地区山西组-石盒子组包裹体均一温度测试数据
Table 2. Homogeneous temperature test data of Shanxi–Shihezi Formation inclusions in Wuqi area
井号 深度/m 层位 类型 测温类型 期次 均一相态 均一温度 平均冰点/℃ 平均盐度/%NaCl 平均温度/℃ 测点数目/个 Y1232 4028.6 山西组 次生 含烃盐水包裹体 第1期 液相 105.2 9 −8.6 12.4 Y1232 4028.6 山西组 次生 含烃盐水包裹体 第2期 液相 137.1 6 −12.3 16.2 Y1207 3820.1 山西组 次生 含烃盐水包裹体 第1期 液相 114.8 7 −6.4 9.7 Y1207 3820.1 山西组 次生 含烃盐水包裹体 第2期 液相 146.2 9 −13.5 17.3 Y1141 3710.8 山西组 次生 含烃盐水包裹体 第1期 液相 112.5 14 −3.8 6.2 Y1141 3710.8 山西组 次生 含烃盐水包裹体 第2期 液相 135.6 3 −9.4 13.3 Y1141 3670.1 石盒子组 次生 含烃盐水包裹体 第1期 液相 108 12 Y1141 3670.1 石盒子组 次生 含烃盐水包裹体 第2期 液相 136 5 Y1360 4180.3 石盒子组 次生 含烃盐水包裹体 第1期 液相 116.0 5 −8.3 12.0 Y1360 4180.3 石盒子组 次生 含烃盐水包裹体 第2期 液相 138.3 3 −10.5 14.4 Y1008 3913.0 山西组 次生 含烃盐水包裹体 第1期 液相 110 11 Y1008 3913.0 山西组 次生 含烃盐水包裹体 第2期 液相 130 3 Y1355 3983.6 山西组 次生 含烃盐水包裹体 第1期 液相 100 15 Y1355 3983.6 山西组 次生 含烃盐水包裹体 第2期 液相 155 3 Y1161 3875.7 石盒子组 次生 含烃盐水包裹体 第1期 液相 97 5 −6.7 10.1 Y1161 3875.7 石盒子组 次生 含烃盐水包裹体 第2期 液相 140 3 −8.6 12.4 Y1352 3944.3 山西组 次生 含烃盐水包裹体 第1期 液相 106 4 −6.8 10.2 Y1352 3944.3 山西组 次生 含烃盐水包裹体 第2期 液相 138 3 −8.7 12.5 Y1350 4003.6 山西组 次生 含烃盐水包裹体 第1期 液相 105 5 Y1350 4003.6 山西组 次生 含烃盐水包裹体 第2期 液相 135 2 −12.7 16.6
下载: 导出CSV
-
[1] Cao Q, Gao J M, Fan L Y, et al. 2015. Characteristic and significance of fluid inclusions in Upper Paleozoic of Southwest Ordos Basin[J]. Natural Gas Geoscience, 26(12): 2245−2253 (in Chinese with English abstract) .
[2] Cao Q, Wei X S, Chen Z X, et al. 2022. Hydrocarbon charge history of the Upper Paleozoic, Ordos Basin as revealed by fluid inclusions[J]. Frontiers in Physics, 10: 836977−836980. doi: 10.3389/fphy.2022.836977
[3] Cao Y C. 2020. Study on sedimentary facies and sand body distribution rules of He 8 Member of the Upper Paleozoic Hedong Formation in Longdong area of Ordos Basin [D]. Master Dissertation of Chengdu University of Technology: 15−60 (in Chinese with English abstract).
[4] Chen H H. 2007. Advances in geochronology of hydrocarbon accumulation[J]. Oil & Gas Geology, 28(2): 143−150 (in Chinese with English abstract).
[5] Chen R Y, Luo X R, Chen Z K, et al. 2006. Restoration of burial history of four periods in Ordos Basin[J]. Acta Petrolei Sinica, 27(2): 43−47 (in Chinese with English abstract).
[6] Cui G X. 2021. Research on reservoir characteristics of Shan 1 Member in southwest of Ordos Basin[D]. Master Dissertation of Xi'an Shiyou University: 11−54 (in Chinese with English abstract).
[7] Duan Y F, Zhao W W, Yang T X, et al. 2024. Source−reservoir characteristics and accumulation rules of shale gas of Permian Shanxi Formation in Yan'an area, Ordos Basin[J]. Lithologic Reservoirs, 36(3): 72−83 (in Chinese with English abstract) .
[8] Fu J H, Guo S B, Liu X S, et al. 2013. Shale gas accumulation condition and exploration potential of the Upper Paleozoic Shanxi Formation in Ordos Basin[J]. Journal of Jilin University(Earth Science Edition), 43(2): 382−389 (in Chinese with English abstract).
[9] Gao S L, Ren Z L. 2006. Restoration of eroded thickness and its influence on thermal evolution of Upper Paleozoic source rocks in Ordos basin[J]. Oil & Gas Geology, 27(2): 180−186 (in Chinese with English abstract).
[10] Hall D L, Sterner S M, Bodnar R J. 1988. Freezing point depression of NaCl−KCl−H2O solutions[J]. Economic Geology, 83(1): 197−202. doi: 10.2113/gsecongeo.83.1.197
[11] He D F. 2022. Multi−cycle superimposed sedimentary basins in China: Formation, evolution, geologic framework and hydrocarbon occurrence[J]. Earth Science Frontiers, 29(6): 24−59 (in Chinese with English abstract).
[12] He D F, Bao H P, Kai B Z, et al. 2022. Has the Ordos Block, a cratonic block been reactivated?[J]. Oil & Gas Geology, 43(6): 1271−1291 (in Chinese with English abstract).
[13] Jia C Z, Zheng M, Zhang Y F. 2012. Unconventional hydrocarbon resources in China and the prospect of exploration and development[J]. Petroleum Exploration and Development, 39(2): 129−136 (in Chinese with English abstract).
[14] Li H. 2015. Research of source rocks in Upper Paleozoic, central Ordos Basin[D]. Doctoral Dissertation of Northwest University: 19−96 (in Chinese with English abstract).
[15] Li Y X, Wu Y W, Wang Q L, et al. 2023. Main controlling factors of continental shale gas enrichment: A case study of Shanxi Formation in Yan’an exploration area, Ordos Basin[J]. Geological Bulletin of China, 42(9): 1423−1431.
[16] Li M, Hou Y D, Luo J L, et al. 2016. Burial, diagenesis, hydrocarbon charging evolution process and quantitative analysis of porosity evolution: A case study from He 8 tight sand gas reservoir of the Upper Paleozoic in eastern Ordos Basin[J]. Oil & Gas Geology, 37(6): 882−892 (in Chinese with English abstract).
[17] Li S, Liu L, Wu J, et al. 2021. Diagenetic evolution of tight sandstone of Shanxi−Lower Shihezi Formations in the southern Ordos Basin[J]. Natural Gas Geoscience, 32(1): 47−56 (in Chinese with English abstract).
[18] Li Y L, Ni Z Y, Li X G, et al. 2024. Difference of fault−controlled gas reservoir in Hangjinqi area, Ordos Basin[J]. Journal of Jilin University (Earth Science Edition), 54(3): 773−783 (in Chinese with English abstract).
[19] Liang Y, Ren Z L, Wang Y L, et al. 2011a. Characteristics of fluid inclusions and reservoiring phases in the Yanchang Formation of Zichang area, the Ordos Basin[J]. Oil & Gas Geology, 32(2): 182−191 (in Chinese with English abstract).
[20] Liang Y, Ren Z L, Shi Z, et al. 2011b. Classification of hydrocarbon accumulation phases of the Yanchang Formation in the Fuxian−Zhengning area, Ordos Basin[J]. Acta Petrolei Sinica, 32(5): 741−748 (in Chinese with English abstract).
[21] Liang Z Z, Xu H T, Gao C L, et al. 2023. Characteristics of fluid inclusion and its indication to hydrocarbon charge and adjustment of the Triassic Yanchang Formation in southwestern margin of Ordos Basin[J]. China Petroleum Exploration, 28(2): 81−91 (in Chinese with English abstract).
[22] Liao M G, Xiao X W, Yao J L, et al. 2017. Features of fluid inclusion and their implications for hydrocarbon charging periods in the Eighth Member of the Shihezi formation, Longdong Area, Ordos Basin[J]. Geological Journal of China Universities, 23(2): 315−323 (in Chinese with English abstract).
[23] Liu G Q, Su Z T, Hao Z L, et al. 2024. Microfacies and depositional model of a carbonate−evaporite symbiotic system of the Majiagou Formation in Ordos Basin[J]. Journal of Palaeogeography (Chinese Edition), 26(2): 279−295 (in Chinese with English abstract).
[24] Liu J L, Liu K Y, Gui L L. 2019. Fluid inclusion characteristics and hydrocarbon charge history in the Upper Paleozoic, central Ordos Basin[J]. Journal of China University of Petroleum (Edition of Natural Science), 43(2): 13−24 (in Chinese with English abstract).
[25] Liu K, Wang R, Shi W, et al. 2020. Tectonic controls on Permian tight gas accumulation: Constrains from fluid inclusion and paleo−structure reconstruction in the Hangjinqi area, northern Ordos Basin, China[J]. Journal of Natural Gas Science Engineering, 83: 103616−103620. doi: 10.1016/j.jngse.2020.103616
[26] Liu R C, Ren Z L, Ma K, et al. 2019. Classification of hydrocarbon accumulation phases of Yanchang Formation in southern Ordos Basin[J]. Geoscience, 33(6): 1263−1274 (in Chinese with English abstract).
[27] Luo L R, Li J F, Yang W W, et al. 2022. Characteristics and hydrocarbon generation potential of Chang 9 source rocks on Yishaan Slope, Ordos Basin[J]. Xinjiang Petroleum Geology, 43(3): 278−284 (in Chinese with English abstract).
[28] Mclimans R K. 1987. The application of fluid inclusions to migration of oil and diagenesis in petroleum reservoirs[J]. Applied Geochemistry, 2(5/6): 585−603.
[29] Qi K, Ren Z L, Cao Z P, et al. 2017. The classification of hydrocarbon charging phases of the Nantun Formation in the Modamudi Sag, Hailar Basin[J]. Journal of Petrochemical Universities, 30(1): 60−66 (in Chinese with English abstract).
[30] Qian Q. 2014. The study of the subsidence, uplift, erosion hydrocarbon−generating, and hydrocarbon−bearing of the source rocks in the Upper Paleozoic of Ordos Basin[D]. Master Dissertation of Northwest University: 16−95 (in Chinese with English abstract).
[31] Ren Z L, Liu L, Cui J P, et al. 2008. Application of tectonic−thermal evolution history to hydrocarbon accumulation timing in sedimentary basins[J]. Oil & Gas Geology, 29(4): 502−506 (in Chinese with English abstract).
[32] Ren Z L, Qi K, Li J B, et al. 2021. Thermodynamic evolution and hydrocarbon accumulation in the Ordos Basin[J]. Oil & Gas Geology, 42(5): 1030−1042 (in Chinese with English abstract).
[33] Song J Q, Xiao H. 2024. Characteristics of fluid inclusions and accumulation process in the second member of Dengying Formation of the Sinian in central Sichuan paleo−uplift[J]. Fault−Block Oil & Gas Field, 31(5): 762−770 (in Chinese with English abstract).
[34] Sun J B, Hao S Y, Zhao Q P, et al. 2022. Reservoir characteristics and key technologies for shale gas exploration and development of the first member of the Permian Shanxi Formation in Yan'an area[J]. China Petroleum Exploration, 27(3): 110−120 (in Chinese with English abstract).
[35] Sun J B, Liu G, Shi P, et al. 2023. Reservoir characteristics and analysis of shale gas resource potential in Shanxi Formation in Yan’an area[J]. Unconventional Oil & Gas, 10(1): 44−51 (in Chinese with English abstract).
[36] Tao H, Wang J M. 2022. Characteristics of Late Triassic inclusions and hydrocarbon source charging stages in Fuxian area, northern Shaanxi[J]. Journal of Xi'an University of Science and Technology, 42(3): 537−545 (in Chinese with English abstract).
[37] Weng W F, Wang J Q, Zhang R R, et al. 2011. Denudation thickness estimation of sedimentary formation in Ordos Basin by acoustic logging information[J]. Xinjiang Petroleum Geology, 32(2): 143−146 (in Chinese with English abstract).
[38] Wu H, Liu R E, Ji Y L, et al. 2017. Fractal characteristics of pore−throat of tight gas reservoirs and its relation with percolation: A case from He 8 Member of the Permian Xiashihezi Formation in Ordos Basin[J]. Acta Sedimentologica Sinica, 35(1): 151−162 (in Chinese with English abstract).
[39] Xi J L, Liu X. 2023. Study on the structural characteristics of Chang 7 Formation in Wucangbao block of Yanchang Oilfield[J]. Petrochemical Industry Technology, 30(12): 169−171 (in Chinese with English abstract).
[40] Yuan Y L, Li W, Shen P, et al. 2019. Hydrocarbon accumulation law and development prospects of Chang 10 oil layer in Wucangbao oil area[J]. Liaoning Chemical Industry, 48(7): 703−705 (in Chinese with English abstract).
[41] Zhai Y H, He D F, Kai B Z. 2023. Tectono−depositional environment and prototype basin evolution in the Ordos Basin during the Early Permian[J]. Earth Science Frontiers, 30(2): 139−153 (in Chinese with English abstract).
[42] Zhang F Q, Chen Z Q, Zhao Z Y, et al. 2023. Hydrocarbon accumulation periods in the Upper Paleozoic strata of the western Ordos Basin, China, based on fluid inclusions and basin modeling[J]. ACS Omega, 8(23): 20536−20549. doi: 10.1021/acsomega.3c00877
[43] Zhang N, Zhang D J, Zhang S C, et al. 2005. Determination of trace iron in cobalt sulfate by AAS after separation and preconcentration by coprecipitation with Cerium Phosphate[J]. Rock and Mineral Analysis, 24(1): 40−42, 46 (in Chinese with English abstract).
[44] Zhang N, Tian Z J, Ling Y Y, et al. 2007. Raman characteristics of hydrocarbons and hydrocarbon inclusions[J]. Scientia Sinica(Terrae), 37(7): 900−907 (in Chinese with English abstract).
[45] Zhang N, Mao G J, Wang H T, et al. 2010. Raman spectroscopic characteristics of macromolecular hydrocarbons and its significance in the study of hydrocarbon inclusions[J]. Geochimica, 39(4): 345−353 (in Chinese with English abstract).
[46] Zhao B S, Li R X, Qin X L, et al. 2019. Characteristics of shale reservoirs in the Upper Paleozoic Shanxi Formation, central Ordos Basin[J]. Acta Sedimentologica Sinica, 37(6): 1140−1151 (in Chinese with English abstract).
[47] Zhong D K, Zhou L J, Sun H T, et al. 2012. Influences of petrologic features on diagenesis and pore development: An example from the Triassic Yanchang Formation in Longdong area, Ordos Basin[J]. Oil & Gas Geology, 33(6): 890−899 (in Chinese with English abstract).
[48] Zhu R J, Li R X, Liu X S, et al. 2021. Characteristics of the diagenetic evolution of tight sandstone gas reservoir and its property in the Upper Paleozoic erathem in southwestern Ordos Basin[J]. Journal of Lanzhou University(Natural Sciences), 57(5): 637−649, 658 (in Chinese with English abstract).
[49] 曹青, 高俊梅, 范立勇, 等. 2015. 鄂尔多斯盆地西南部上古生界流体包裹体特征及其意义[J]. 天然气地球科学, 26(12): 2245−2253. doi: 10.11764/j.issn.1672-1926.2015.12.2245
[50] 曹杨春. 2020. 鄂尔多斯盆地陇东地区上古生界盒8段沉积相及砂体展布规律研究[D]. 成都理工大学硕士学位论文: 15−60.
[51] 崔改霞. 2021. 鄂尔多斯盆地西南部山1段储层特征研究[D]. 西安石油大学硕士学位论文: 11−54.
[52] 陈红汉. 2007. 油气成藏年代学研究进展[J]. 石油与天然气地质, 28(2): 143−150. doi: 10.3321/j.issn:0253-9985.2007.02.003
[53] 陈瑞银, 罗晓容, 陈占坤, 等. 2006. 鄂尔多斯盆地埋藏演化史恢复[J]. 石油学报, 27(2): 43−47. doi: 10.3321/j.issn:0253-2697.2006.02.009
[54] 段逸飞, 赵卫卫, 杨天祥, 等. 2024. 鄂尔多斯盆地延安地区二叠系山西组页岩气源储特征及聚集规律[J]. 岩性油气藏, 36(3): 72−83. doi: 10.12108/yxyqc.20240307
[55] 付金华, 郭少斌, 刘新社, 等. 2013. 鄂尔多斯盆地上古生界山西组页岩气成藏条件及勘探潜力[J]. 吉林大学学报(地球科学版), 43(2): 382−389.
[56] 高胜利, 任战利. 2006. 鄂尔多斯盆地剥蚀厚度恢复及其对上古生界烃源岩热演化程度的影响[J]. 石油与天然气地质, 27(2): 180−186. doi: 10.3321/j.issn:0253-9985.2006.02.007
[57] 何登发. 2022. 中国多旋回叠合沉积盆地的形成演化、地质结构与油气分布规律[J]. 地学前缘, 29(6): 24−59.
[58] 何登发, 包洪平, 开百泽, 等. 2022. 鄂尔多斯克拉通地块活化了吗?[J]. 石油与天然气地质, 43(6): 1271−1291. doi: 10.11743/ogg20220601
[59] 贾承造, 郑民, 张永峰. 2012. 中国非常规油气资源与勘探开发前景[J]. 石油勘探与开发, 39(2): 129−136.
[60] 李浩. 2015. 鄂尔多斯盆地中部上古生界烃源岩研究[D]. 西北大学博士学位论文: 19−96.
[61] 李艳霞, 吴雨威, 王巧玲, 等. 2023. 陆相页岩气富集主控因素——以鄂尔多斯盆地延安探区山西组为例[J]. 地质通报, 42(9): 1423−1431.
[62] 李杪, 侯云东, 罗静兰, 等. 2016. 致密砂岩储层埋藏—成岩—油气充注演化过程与孔隙演化定量分析——以鄂尔多斯盆地东部上古生界盒8段天然气储层为例[J]. 石油与天然气地质, 37(6): 882−892. doi: 10.11743/ogg20160610
[63] 李松, 刘玲, 吴疆, 等. 2021. 鄂尔多斯盆地南部山西组−下石盒子组致密砂岩成岩演化[J]. 天然气地球科学, 32(1): 47−56. doi: 10.11764/j.issn.1672-1926.2020.09.008
[64] 李勇霖, 倪智勇, 李晓光, 等. 2024. 鄂尔多斯盆地杭锦旗地区断控气藏差异[J]. 吉林大学学报(地球科学版), 54(3): 773−783.
[65] 梁宇, 任战利, 王彦龙, 等. 2011a. 鄂尔多斯盆地子长地区延长组流体包裹体特征与油气成藏期次[J]. 石油与天然气地质, 32(2): 182−191.
[66] 梁宇, 任战利, 史政, 等. 2011b. 鄂尔多斯盆地富县—正宁地区延长组油气成藏期次[J]. 石油学报, 32(5): 741−748.
[67] 梁正中, 许红涛, 高超利, 等. 2023. 鄂尔多斯盆地西南缘三叠系延长组流体包裹体特征及对油气充注调整的指示[J]. 中国石油勘探, 28(2): 81−91. doi: 10.3969/j.issn.1672-7703.2023.02.008
[68] 廖明光, 肖雪薇, 姚泾利, 等. 2017. 陇东地区盒8段流体包裹体特征及成藏期次研究[J]. 高校地质学报, 23(2): 315−323.
[69] 刘国庆, 苏中堂, 郝志磊, 等. 2024. 鄂尔多斯盆地马家沟组碳酸盐岩−膏盐岩共生体系沉积微相与沉积模式[J]. 古地理学报, 26(2): 279−295. doi: 10.7605/gdlxb.2024.02.021
[70] 刘建良, 刘可禹, 桂丽黎. 2019. 鄂尔多斯盆地中部上古生界流体包裹体特征及油气充注史[J]. 中国石油大学学报(自然科学版), 43(2): 13−24.
[71] 刘润川, 任战利, 马侃, 等. 2019. 鄂尔多斯盆地南部延长组油气成藏期次研究[J]. 现代地质, 33(6): 1263−1274.
[72] 罗丽荣, 李剑锋, 杨伟伟, 等. 2022. 鄂尔多斯盆地伊陕斜坡长9烃源岩特征与生烃潜力[J]. 新疆石油地质, 43(3): 278−284.
[73] 祁凯, 任战利, 曹展鹏, 等. 2017. 海拉尔盆地莫达木吉凹陷南屯组油气充注期次研究[J]. 石油化工高等学校学报, 30(1): 60−66. doi: 10.3969/j.issn.1006-396X.2017.01.013
[74] 钱强. 2014. 鄂尔多斯盆地上古生界烃源岩沉积、沉降、抬升剥蚀及生烃性、含烃性研究[D]. 西北大学硕士学位论文: 16−95.
[75] 任战利, 刘丽, 崔军平, 等. 2008. 盆地构造热演化史在油气成藏期次研究中的应用[J]. 石油与天然气地质, 29(4): 502−506. doi: 10.3321/j.issn:0253-9985.2008.04.013
[76] 任战利, 祁凯, 李进步, 等. 2021. 鄂尔多斯盆地热动力演化史及其对油气成藏与富集的控制作用[J]. 石油与天然气地质, 42(5): 1030−1042. doi: 10.11743/ogg20210502
[77] 宋嘉琦, 肖晖. 2024. 川中古隆起震旦系灯二段流体包裹体特征与成藏过程[J]. 断块油气田, 31(5): 762−770.
[78] 孙建博, 郝世彦, 赵谦平, 等. 2022. 延安地区二叠系山西组1段页岩气储层特征及勘探开发关键技术[J]. 中国石油勘探, 27(3): 110−120. doi: 10.3969/j.issn.1672-7703.2022.03.010
[79] 孙建博, 刘刚, 史鹏, 等. 2023. 延安地区山西组页岩气储层特征及资源潜力分析[J]. 非常规油气, 10(1): 44−51.
[80] 陶华, 王建民. 2022. 陕北富县地区晚三叠世包裹体特征及烃类充注期次[J]. 西安科技大学学报, 42(3): 537−545.
[81] 翁望飞, 王建强, 张蓉蓉, 等. 2011. 利用声波测井技术计算地层剥蚀厚度——以鄂尔多斯盆地为例[J]. 新疆石油地质, 32(2): 143−146.
[82] 吴浩, 刘锐娥, 纪友亮, 等. 2017. 致密气储层孔喉分形特征及其与渗流的关系——以鄂尔多斯盆地下石盒子组盒8段为例[J]. 沉积学报, 35(1): 151−162.
[83] 席建丽, 刘祥. 2023. 吴起油田吴仓堡区块长7地层构造特征研究[J]. 石化技术, 30(12): 169−171. doi: 10.3969/j.issn.1006-0235.2023.12.059
[84] 袁耀利, 李炜, 申鹏, 等. 2019. 吴仓堡油区长10油气成藏规律与勘探开发前景[J]. 辽宁化工, 48(7): 703−705. doi: 10.3969/j.issn.1004-0935.2019.07.033
[85] 张鼐, 张大江, 张水昌, 等. 氯盐溶液的拉曼光谱特征及测试探讨[J]. 岩矿测试, 2005, (1): 40−42, 46.
[86] 张鼐, 田作基, 冷莹莹, 等. 2007. 烃和烃类包裹体的拉曼特征[J]. 中国科学(D辑: 地球科学), 37(7): 900−907.
[87] 张鼐, 毛光剑, 王汇彤, 等. 2010. 大分子烃类拉曼光谱特征及在烃包裹体研究中的意义[J]. 地球化学, 39(4): 345−353.
[88] 翟咏荷, 何登发, 开百泽. 2023. 鄂尔多斯盆地及邻区早二叠世构造−沉积环境与原型盆地演化[J]. 地学前缘, 30(2): 139−153.
[89] 赵帮胜, 李荣西, 覃小丽, 等. 2019. 鄂尔多斯盆地中部上古生界山西组页岩储层特征[J]. 沉积学报, 37(6): 1140−1151.
[90] 钟大康, 周立建, 孙海涛, 等. 2012. 储层岩石学特征对成岩作用及孔隙发育的影响——以鄂尔多斯盆地陇东地区三叠系延长组为例[J]. 石油与天然气地质, 33(6): 890−899. doi: 10.11743/ogg20120610
[91] 朱瑞静, 李荣西, 刘新社, 等. 2021. 鄂尔多斯盆地西南部上古生界致密砂岩气储层成岩演化特征及物性演化[J]. 兰州大学学报(自然科学版), 57(5): 637−649, 658.
-
