Research on dual liquid plugging method based on thixotropic slurry
-
摘要: 针对钻井过程中裂缝型、溶洞型等严重漏失问题，提出双液法堵漏。具体是将两种或多种不同性质的流体同时注入井筒，利用混合后流体产生的触变性达到封堵漏层的一种新型堵漏技术。为了研究混合流体的堵漏性能，从而获得最佳堵漏配方，室内采用有机凝胶溶液配置水泥浆，并与坂土浆按不同比例混合，采用滞后环法测得混合浆体的触变性能以评价其堵漏性能。结果表明：有机凝胶加量为0.08%（与水泥质量比）时，有机凝胶溶液制备的水泥浆与0.25%浓度的坂土浆以10∶1.8 的比例混合后，浆体具有最好的堵漏性能，且固化后的抗压强度能满足现场施工要求。现场应用表明利用有机凝胶溶液制备的水泥浆与坂土浆组合堵漏效果良好。Abstract: Aiming at serious leakage problems such as crack type and karst cave type, a dual liquid method is proposed for plugging. Specifically, it is a new type of plugging technology that injects two or more fluids with different properties into the wellbore at the same time, and uses the thixotropy generated by the mixed fluid to seal the lost circulation layer. In order to study the plugging performance of mixed fluid and obtain the best plugging formula,organic gel solution is used to prepare cement slurry indoors, and mixed with Bantu slurry in different proportions. The thixotropy of mixed slurry is measured by hysteresis loop method to evaluate its plugging performance. The results show that when the dosage of organic gel is 0.08% bwoc, the cement slurry prepared by organic gel solution and 0.25% Bantu slurry are mixed at a ratio of 10∶1.8, the slurry has the best plugging performance, and the compressive strength after curing can meet the requirements of on-site construction. Field application shows that the combination of cement slurry prepared with organic gel solution and bentonite slurry has good plugging effect.
-
Key words:
- double-fluid method /
- plugging /
- organic gel solution /
- hysteresis loop /
- thixotropy
-
-
[1] 闫晶,张坤,郭栋.等.弹性体型胶粘材料在大庆油田裂缝性漏失中的应用研究[J].钻探工程,2024,51(2):133-139.
YAN Jing, ZHANG Kun, GUO Dong. Application of elastic adhesive material in drilling fluid plugging of fractured formation in Daqing Oilfield[J]. Drilling Engineering, 2024,51(2):133-139.
[2] 郑有成,李向碧,邓传光,等.川东北地区恶性井漏处理技术探索[J].天然气工业,2003,23(6):84-85.
ZHENG Youcheng, LI Xiangbi, DENG Chuanguang, et al.Techniques of treating seriously lost circulations in Northeast Sichuan[J]. Natural Gas Industry, 2003,23(6):84-85.
[3] 王涛,刘锋报,罗威,等.塔里木油田防漏堵漏技术进展与发展建议[J].石油钻探技术,2021,49(1):28-33.
WANG Tao, LIU Fengbao, LUO Wei, et al. The technical advance and development suggestions for leakage prevention and plugging technologies in the Tarim Oilfield[J]. Petroleum Drilling Techniques, 2021,49(1):28-33.
[4] 李奎.泸州深层页岩气呼吸性地层井漏堵漏方法及对策分析--以Y101H3-4 井为例[J].钻探工程,2022,49(5):106-110.
LI Kui. Plugging of breathing formation in deep shale gas wells in Luzhou:Taking Well Y101H3-4 for example[J]. Drilling Engineering, 2022,49(5):106-110.
[5] 刘金华.顺北油气田二叠系火成岩漏失分析及堵漏技术[J].钻探工程,2023,50(2):64-70.
LIU Jinhua. Leakage analysis and plugging technology for Permian igneous rock in Shunbei Oil and Gas Field[J]. Drilling Engineering, 2023,50(2):64-70.
[6] 李锦峰.恶性漏失地层堵漏技术研究[J].探矿工程(岩土钻掘工程),2019,46(5):19-27.
LI Jinfeng. The status and development direction of plugging technology for severe circulation loss formation[J]. Exploration Engineering (Rock & Soil Drilling and Tunneling), 2019,46(5):19-27.
[7] 曹晓春,李倍任,秦义,等.聚合物凝胶堵漏剂的研究及应用[J].当代化工,2015,44(11):2572-2574,2577.
CAO Xiaochun, LI Beiren, QIN Yi, et al. Research and application of polymer gel plugging agent[J]. Contemporary Chemical Industry, 2015,44(11):2572-2574,2577.
[8] 何鑫,王胜,何烨,等.富水砂卵石层堵漏凝胶的研制及其机理[J].钻探工程,2023,50(1):142-149.
HE Xin, WANG Sheng, HE Ye, et al. Development and mechanism of plugging gel for water-rich sand and gravel formations[J]. Drilling Engineering, 2023,50(1):142-149.
[9] 李辉,刘华康,何仲,等.塔河油田碳酸盐岩储层恶性漏失空间堵漏凝胶技术[J].钻井液与完井液,2019,36(1):25-28.
LI Hui, LIU Huakang, HE Zhong, et al. Use gel to control severe mud losses in carbonate reservoir formations in Tahe oilfield[J]. Drilling Fluid & Completion Fluid, 2019,36(1):25-28.
[10] 彭博一,于培志.破碎带地层钻探化学凝胶护壁堵漏技术的研究与应用[J].钻探工程,2022,49(1):64-71.
PENG Boyi, YU Peizhi. Research and application of chemical gel wall protection and plugging technology in fractured zone formation drilling[J]. Drilling Engineering, 2022,49(1):64-71.
[11] 卓云,曾庆旭,刘德平,等.碳酸盐岩裂缝溶洞层胶质水泥堵漏技术--以川东地区蒲005-2 井为例[J].天然气工业,2010,30(5):84-86.
ZHUO Yun, ZENG Qingxu, LIU Deping, et al. Gel cementing technology for the wells drilled in the acture-karst carbonate reservoirs:A case study of the Well Pu005-2 in eastern Sichuan Basin[J]. Natural Gas Industry, 2010,30(5):84-86.
[12] 于保国.快速凝胶堵漏技术在山西腰站矿区ZK6004 孔中的应用[J].地质装备,2016,17(4):33-35.
YU Baoguo. Application of rapid gel plugging technology in ZK6004 hole in Shanxi Yaozhan mining area[J]. Equipment for Geotechnical Engineering, 2016,17(4):33-35.
[13] 卢海川,张伟,熊超,等.触变水泥浆体系研究综述[J].精细石油化工进展,2016,17(3):21-26.
LU Haichuan, ZHANG Wei, XIONG Chao, et al. Review of research on thixotropic cement slurry systems[J]. Advances in Fine Petrochemicals, 2016,17(3):21-26.
[14] 毕宏利.坂土低密度水泥浆及应用[J].化工管理,2013(4):12.BI Hongli. Sakata low-density cement slurry and its application[J]. Chemical Enterprise Management, 2013(4):12.
[15] 侯万国,苏延磊,孙德军,等.Mg-Fe-MMH-钠质蒙脱土分散体系的触变性研究[J].化学学报,2000,58(6):722-726.
HOU Wanguo, SU Yanlei, SUN Dejun, et al. Study on the thixotropy of Magnesium Ferric Hydroxide-Montmorillonite suspension[J]. Acta Chimica Sinica, 2000,58(6):722-726.
-
