Study on cement slurry system in ultra-high temperature well
-
摘要: 针对目前高温水泥浆抗高温外掺料以石英砂为主，水泥石200 ℃下高温强度衰退导致环空密封失效问题，研发了具有水化活性的富硅铝材料，其加量占水泥30%~70%时200 ℃×20.7 MPa×30 d 下水泥石高温强度不衰退；将富硅铝材料作为水泥石高温强度稳定材料，优选配套外加剂，构建了富硅铝基超高温固井水泥浆体系，100~200 ℃下API 失水量< 50 mL，稠化时间150~500 min 可调，水泥浆综合性能良好；水泥石200 ℃×20.7 MPa 养护10、60、120、180 d 抗压强度均> 26 MPa，未见高温强度衰退。超声波强度曲线显示600 h 内水泥石强度持续增长直至稳定发展，水泥石高温力学性能优异。SEM 和XRD 分析表明富硅铝材料参与水泥水化反应，消除体系中氢氧化钙，生成高温性能优良的铝氧四面体和硅氧四面体相互键接的空间三维网状结构，以及托勃莫来石、钙硅铝石等水化产物维持水泥石的高温强度稳定，水泥石结构致密。该水泥浆体系在干热岩固井中应用1 个井次，固井质量优质，截至目前1000 d 水泥环密封良好。Abstract: Aiming at the strength of set cement with sand degradation leads to the annular seal failure at 200℃, rich silica-aluminum material with hydration activity was developed, and when the adding amount for 30% to 70% of cement ,the compressive strength of cement are stable at 200℃×20.7MPa×30d. Based on the rich silica-aluminum material as a high temperature stabilizer, selecting matching additives, the rich silica-aluminum ultra-high temperature cement slurry was developed, the API water loss is less than 50mL at 100~200℃, the thickening time can be adjustable between 150~500min, the comprehensive performance is good. Compressive strength of set cement cured for 10d, 60d, 120d, 180d under 200℃×20.7MPa are all greater than 26MPa, and high temperature strength decline was not observed. The ultrasonic strength curve shows that the strength of set cement grows steady within 600h. The SEM and XRD shows that, the rich silica-aluminum material participate in the cement hydration reaction, and eliminate the calcium hydroxide, and generate aluminum-oxide tetrahedron and silica-oxide tetrahedron inter-bonding three-dimensional network structure with good high temperature performance, and together with tobermolite calcium silicate bauxite to maintain the stability of the high temperature strength of cement stone. The cement slurry system has been applied in hot dry rock cementing for 1 well, and the cementing quality is good. As so far, the cement ring has been well sealed for 1000 days.
-
-
[1] 汪海阁,黄洪春,纪国栋,等.中国石油深井、超深井和水平井钻完井技术进展与挑战[J].中国石油勘探,2023,28(3):1-11.
WANG Haige, HUANG Hongchun, JI Guodong, et al. Progress and challenges of drilling and completion technologies for deep,ultra-deep and horizontal wells of CNPC[J]. China Petroleum Exploration, 2023,28(3):1-11.
[2] 王志刚,王稳石,张立烨,等.万米科学超深井钻完井现状与展望[J].科技导报,2022,40(13):27-35.
WANG Zhigang, WANG Wenshi, ZHANG Liye, et al. Present situation and prospect of drilling and completion of 10000 meter scientific ultra deep wells[J]. Science & Technology Review, 2022,40(13):27-35.
[3] 蒋国盛,郑少军,代天,等.纳米二氧化硅在固井水泥浆中的应用研究进展[J].钻探工程,2021,48(1):68-74.
JIANG Guosheng, ZHENG Shaojun, DAI Tian, et al. Research status of nano-silica application in well cementing slurry[J]. Drilling Engineering, 2021,48(1):68-74.
[4] 郤一臻,赵福金,荆京,等.山西干热岩GR1 井高温固井技术研究与实践[J].钻探工程,2022,49(6):42-47.
XI Yizhen, ZHAO Fujin, JING Jing, et al. Research and practice of cementing slurry technology for Well GR1 in Shanxi high temperature hot dry rock[J]. Drilling Engineering, 2022,49(6):42-47.
[5] 刘玲榕.抗高温水泥浆体系研究及应用[J].探矿工程(岩土钻掘工程),2018,45(9):29-33.
LIU Lingrong. Research and application of thermostable cement slurry system[J]. Exploration Engineering (Rock & Soil Drilling and Tunneling), 2018,45(9):29-33.
[6] 肖夏.高温固井水泥石力学变形及材料改性效果研究[D].成都:西南石油大学,2018.XIAO Xia. Study on mechanical deformation and material modification of high temperature cementing cement[D]:Chengdu:Southwest Petroleum University, 2018.
[7] 张国光,王春雨,代丹,等.高温高压下石英砂粒径对油井水泥石性能的影响[J].钻井液与完井液,2022,39(4):466-471.
ZHANG Guoguang, WANG Chunyu, DAI Dan, et al. The effects of particle size of silica flour on the performance of oil well cement at high temperature and high pressure[J]. Drilling Fluid& Completion Fluid, 2022,39(4):466-471.
[8] 桑来玉.硅粉对水泥石强度发展影响规律[J].钻井液与完井液,2004,21(6):41-43,49.
SANG Laiyu. Law of silica powder influence on cement stone strength development[J]. Drilling Fluid & Completion Fluid,2004,21(6):41-43,49.
[9] 张颖,陈大钧,罗杨,等.硅砂对稠油热采井水泥石强度影响的室内试验[J].石油钻采工艺,2010,32(5):44-47,52.
ZHANG Ying, CHEN Dajun, LUO Yang, et al. Laboratory study on grain size of silica in strength recession of heavy oil thermal recovery cement[J]. Oil Drilling & Production Technology,2010,32(5):44-47,52.
[10] 汪海萍,谭玉叶,吴姗,等.尾砂级配对充填体强度的影响及优化[J].有色金属(矿山部分),2014,66(4):26-30.
WANG Haiping, TAN Yuye, WU Shan, et al. Effects and optimization of tailings gradation on the backfill strength[J]. Nonferrous Metals (Mining Section), 2014,66(4):26-30.
[11] 庞学玉,秦建鲲,王治国,等.深层超高温水泥浆体配方及其强度衰退机理[J].天然气工业,2023,43(7):90-100.
PANG Xueyu, QIN Jiankun, WANG Zhiguo, et al. Formula of cementing slurry system for ultra-high temperature conditions of deep wells and its strength retrogression mechanism[J]. Natural Gas Industry, 2023,43(7):90-100.
[12] 李宁,庞学玉,艾正青,等.200℃加砂硅酸盐水泥配方优化设计及强度衰退机理[J].硅酸盐学报,2020,48(11):1824-1833.
LI Ning, PANG Xueyu, AI Zhengqing, et al. Composition optimization and strength decline mechanism of oil well cement slurry at 200℃[J]. Journal of the Chinese Ceramic Society,2020,48(11):1824-1833.
[13] 姚晓,葛荘,汪晓静,等.加砂油井水泥石高温力学性能衰退机制研究进展[J].石油钻探技术,2018,46(1):17-23.
YAO Xiao, GE Zhuang, WANG Xiaojing, et al. Research progress of degradation of mechanical properties of sand-containing cement in high temperature regimes[J]. Petroleum Drilling Techniques, 2018,46(1):17-23.
[14] 王成文,周伟,陈新,等.纳米SiO2溶胶对高温加砂油井水泥石强度作用规律及机制[J].中国石油大学学报(自然科学版),2021,45(6):79-86.
WANG Chengwen, ZHOU Wei, CHEN Xin, et al. Effect of nano-SiO2 Sol on strength of cement with addition of silica sands under high temperature[J]. Journal of China University of Petroleum (Edition of Natural Science), 2021,45(6):79-86.
[15] Jupe A C, Wilkinson A P, Luke K, et al. Class H cement hydration at 180°C and high pressure in the presence of added silica[J]. Cement and Concrete Research, 2007,38(5):660-666.
[16] Caritey J P. Brady J. Performance of thermal cements with different weighting materials[C]// Paper presented at the SPE/IADC Drilling Conference. Amsterdam, The Netherlands,2013:SPE-163544-MS.
[17] Salehpour A G, Pershikovae, Chougnet-Sirapian A, et al.Novel steam-resilient cement system for long-term steam injection well integrity:case study of a steam flooded field in Indonesia[C]//Paper presented at the SPE Unconventional Resources Conference and Exhibition-Asia Pacific. Brisbane, Australia, 2013:SPE-166994-MS.
[18] 张尚枫,宋茂林,张朝阳,等.磷酸盐改性铝酸盐水泥的研究与应用进展[J].建筑材料学报,2024,27(9):824-831,845.
ZHANG Shangfeng, SONG Maolin, ZHANG Chaoyang, et al. Progress of research and applications in phosphate modified calcium aluminate cement[J]. Journal of Building Materials,2024,27(9):824-831,845.
[19] 万向臣,张健,陈小荣.页岩油地层固井用改性铝酸盐水泥的水化行为及性能[J].油田化学,2023,40(4):614-620,626.
WAN Xiangchen, ZHANG Jian, CHEN Xiaorong. Hydration behavior and properties of modified aluminate cement for well cementing in shale oil formation[J]. Oilfield Chemistry, 2023,40(4):614-620,626.
[20] 周崇峰,费中明,李德伟,等.一种新型超高温固井水泥石抗强度衰退材料[J].钻井液与完井液,2022,39(1):71-75.
ZHOU Chongfeng, FEI Zhongming, LI Dewei, et al. Research on a new material to prevent the strength decline of set cement under ultra-high temperature[J]. Drilling Fluid & Completion Fluid, 2022,39(1):71-75.
[21] 赵峰,曾雪玲,龙丹,等.超高温固井水泥添加剂研选及工程性能评价[J].钻采工艺,2023,46(4):131-136.
ZHAO Feng, ZENG Xueling, LONG Dan, et al. Development and engineering performance evaluation of additives for ultra-high temperature cement slurry[J]. Drilling & Production Technology, 2023,46(4):131-136.
[22] 刘业金,周长顺.钢渣粉-偏高岭土再生混凝土力学性能及微观结构的研究[J].工业建筑,2022,52(2):133-138,157.
LIU Yejin, ZHOU Changshun. Study on mechanical properties and microstructure of recycled aggregate concrete containing steel slag powder and metakaolin[J]. Industrial Construction, 2022,52(2):133-138,157.
[23] 张永涛,邓成辉,王家栋,等.高炉矿渣改性铝酸盐水泥的性能研究[J].重庆科技学院学报(自然科学版),2022,24(3):45-51.
ZHANG Yongtao, DENG Chenghui, WANG Jiadong, et al.Research on properties of aluminate cement modified by blast furnace slag[J]. Journal of Chongqing University of Science and Technology (Natural Sciences Edition), 2022,24(3):45-51.
[24] 诸华军,吴其胜,张长森,等.富硅铝质活性填料提高油井水泥石性能的研究[J].建筑材料学报,2013,16(4):576-581.
ZHU Huajun, WU Qisheng, ZHANG Changsen, et al. Improved performance of oil well cement stone by active filler of silicon-rich alumina[J]. Journal of Building Materials, 2013,16(4):576-581.
[25] 丁士东,陆沛青,郭印同,等.复杂环境下水泥环全生命周期密封完整性研究进展与展望[J].石油钻探技术,2023,51(4):104-113.
DING Shidong, LU Peiqing, GUO Yintong, et al. Progress and prospect on the study of full life cycle sealing integrity of cement sheath in complex environments[J]. Petroleum Drilling Techniques, 2023,51(4):104-113.
[26] 高德利,刘奎,王宴滨,等.页岩气井井筒完整性失效力学机理与设计控制技术若干研究进展[J].石油学报,2022,43(12):1798-1812.
GAO Deli, LIU Kui, WANG Yanbin, et al. Some research advances in the failure mechanism and design& control technologies of shale gas well integrity[J]. Acta Petrolei Sinica, 2022,43(12):1798-1812.
-
