Application of Comprehensive Geophysical Prospecting Method in the Prediction of Mineral Resources in Qinling with High Vegetation Coverage and Deep Cut Area
-
摘要:
北秦岭地区是中国重要的金多金属资源产地，特别是近年来蟒岭岩体周缘作为北秦岭成矿带的重要矿集区之一，其成矿作用及控矿系统备受瞩目，但区内林木茂密地形切割严重，未系统开展过地球物理工作。笔者通过应用综合地球物理方法在北秦岭蟒岭岩体南缘庙沟地区开展找矿预测，探索秦岭成矿带深切割、高植被覆盖区找矿预测技术方法组合。在工作区开展地面高精度磁法、激电中梯及可控源音频大地电磁测量（CSAMT）等地球物理探测，综合物探方法联合解译了区域各地层间接触关系以及隐伏岩体侵位形成的推覆形态，对区域含矿断裂带形态展开研究，预测区域赋矿部位与成矿潜力，结合工程揭露结果总结地球物理找矿标志，圈定有利成矿区，为今后该地区勘查提供重要依据。
Abstract:The North Qinling area is an important source of gold polymetallic resources in China, especially in recent years, the periphery of the Mangling pluton is one of the important ore concentration areas of the North Qinling metallogenic belt, and its metallogenic effect and ore-controlling system have attracted much attention. However, the densely forested terrain in the area is severely cut, and no systematic geophysical work has been carried out. In this paper, through the application of comprehensive geophysical method Miaogou area on the southern margin of the n North Qinling rock pythons ridge predicting prospecting and exploration deep cut and high vegetation coverage area of the Qinling metallogenic belt in the prospecting prediction techniques combination. In the work area, geophysical surveys such as ground high-precision magnetic method, IP and controlled source audio magnetotelluric survey (CSAMT) are carried out. The comprehensive geophysical method jointly interprets the contact relationship between various layers in the region and the formation of the emplacement of the hidden rock mass. The shape of the nappe and the research on the shape of the regional ore-bearing fault zone. Conduct research on the morphology of the regional ore-bearing fault zone, predict the ore-bearing location and metallogenic potential of the region, summarize the geophysical prospecting signs based on the results of engineering disclosure, delineate favorable metallogenic areas, and provide an important basis for future exploration in this area.
-
-
表 1 矿区岩、矿石电性参数表
Table 1. Mine rock and ore electrical parameter table
岩性 块数 电阻率ρ（Ω·m） 极化率η（%） 备注 区间 平均值 区间 平均值 花岗岩岩体 20 306～ 1615 721.6 0.365～2.97 0.79 狮子坪岩体 砾岩 10 153～423 242.2 0.275～1.2 0.61 晚侏罗纪 石英片岩 16 44～314 214.3 1.06～1.48 1.27 二叠纪 蚀变石英片岩 20 60～238 127.68 0.56～32.31 4.03 破碎 接触带 8 772～996 878.8 6.34～9.5 7.78 未破碎 安山岩 5 298～457 361.3 0.83～1.08 0.96 含碳质片岩 5 23～47 31 5.13～6.15 5.49
下载: 导出CSV
表 2 矿区岩、矿石磁性参数表
Table 2. Mine rock and ore magnetic parameter table
岩性 块数 磁化率SI（10−6） 备注 区间 平均值 花岗岩岩体 37 105～654 324.4 狮子坪岩体 砾岩 15 10～28 16.3 晚侏罗纪 石英片岩 20 0～4 1.73 二叠纪 蚀变石英片岩 15 -4～4 0.13 破碎 蚀变石英片岩 10 9～16 12.8 未破碎 安山岩 5 371～504 422 含碳质片岩 10 3～12 7.1
下载: 导出CSV
-
[1] 程远, 秦曦, 赵晓晓, 等. 东秦岭钼铅锌银多金属矿集区地球物理场特征及综合信息找矿模型[J]. 地质与勘探, 2018, 54(4): 747-761 doi: 10.13712/j.cnki.dzykt.2018.04.008
CHENG Yuan, QIN Xi, ZHAO Xiaoxiao, et al. Geophysical Characteristics and Prospecting Model Based on Comprehensive Information in the Molybdenum, Lead, Zinc and Silver Polymetallic Ore Concentration Area of the East Qinling Mountains[J]. Geology and Exploration, 2018, 54(4): 747-761. doi: 10.13712/j.cnki.dzykt.2018.04.008
[2] 陈靖, 郭文波, 王宏宇, 等. 综合电磁法在凤太二里河铅锌矿深部的找矿效果分析[J]. 西北地质, 2024, 57（1）: 196−206.
CHEN Jing, GUO Wenbo, WANG Hongyu, et al. Analysis on Prospecting Effect of Integrated Electromagnetic Methods in Deep Prospecting of Fengtai Erlihe Lead−Zinc Deposit[J]. Northwestern Geology, 2024, 57（1）: 196−206.
[3] 党勘峰, 张望, 陈小刚, 等. 北秦岭蟒岭地区萤石矿地质特征与找矿潜力[J]. 矿产勘查, 2020, 11(02): 286-294
DANG Kanfeng, ZHANG Zhan, CHEN Xiaogang, et al. Geological characteristics and prospecting potential of fluorite deposits in Mangling area, North Qinling Mountains [J]. Mineral exploration, 2020, 11(02): 286-294.
[4] 高猛, 付翰泽, 陈川. 遥感技术在和田玉成矿要素识别与找矿预测中的应用——以南阿尔金塔什萨依一带为例[J]. 西北地质, 2019, 52(03): 240-252 doi: 10.19751/j.cnki.61-1149/p.2019.03.023
GAO Meng, FU Hanze, CHEN Chuan. Hetian Jade Metalogenic Factors Identification and Prospecting Prediction by Remote Sensing Technology: Example from Tashisayi Area in South Altyn [J]. Northwestern Geology, 2019, 52(03): 240-252. doi: 10.19751/j.cnki.61-1149/p.2019.03.023
[5] 郭良辉, 孟小红, 石磊, 等. 优化滤波方法及其在中国大陆布格重力异常数据处理中的应用[J]. 地球物理学报, 2012, 55(12): 4078-4088 doi: 10.6038/j.issn.0001-5733.2012.12.020
GUO Lianghui, MENG Xiaohong, SHI Lei, et al. Preferential filtering method and its application to Bouguer gravity anomaly of Chinese continent[J]. Chinese Journal of Geophysics, 2012, 55(12): 4078-4088. doi: 10.6038/j.issn.0001-5733.2012.12.020
[6] 郭培虹, 耿涛, 冯治汉, 等. 基于地球物理场的华阳川铀矿区深部构造特征及其深部找矿潜力[J]. 西北地质, 2024, 57（4）: 182−190.
GUO Peihong, GENG Tao, FENG Zhihan, et al. Deep Structural Characteristics and Prospecting Potential of Huayangchuan Uranium Deposit Based on Geophysical Field[J]. Northwestern Geology, 2024, 57（4）: 182−190.
[7] 郭岐明, 赵江林, 陈清敏, 等. 东秦岭钼多金属成矿带蟒岭矿集区南部晚侏罗世埃达克岩的厘定及成矿意义[J]. 矿床地质, 2019, 38(6): 1297-1320 doi: 10.16111/j.0258-7106.2019.06.007
GUO Qiming, ZHAO Jianglin, CHEN Qingmin, et al. Identification of adakitic rock in southern Mangling mining area of East Qinling molybdenum polymetallic metallogenic belt and its metallogenic significance [J]. Mineral Deposits, 2019, 38(6): 1297-1320. doi: 10.16111/j.0258-7106.2019.06.007
[8] 姜寒冰, 李宗会, 杨合群, 等. 秦岭地区成矿单元划分[J]. 西北地质, 2014, 47(02): 146-155 doi: 10.3969/j.issn.1009-6248.2014.02.017
JIANG Hanbing, LI Zonghui, YANG Hequn, et al. Division of Metalogenic Unit in the Qinling Area [J]. Northwestern Geology, 2014, 47(02): 146-155. doi: 10.3969/j.issn.1009-6248.2014.02.017
[9] 焦阳, 冯俊环. 西秦岭地区猪婆沟金矿成矿物质来源及矿床成因分析[J]. 西北地质, 2024, 57（1）: 219−229.
JIAO Yang, FENG Junhuan. Source of ore Forming Materials and Genesis of Zhupogou Gold Deposit in West Qinling Mountains[J]. Northwestern Geology, 2024, 57（1）: 219−229.
[10] 柯昌辉, 王晓霞, 李金宝, 等. 北秦岭马河钼矿区花岗岩类的锆石U-Pb年龄、地球化学特征及其地质意义[J]. 岩石学报, 2012, 28(1): 267-278
KE Changhui, WANG Xiaoxia, LI Jinbao, et al. Geochronology and geo- logical significance of the granites from the Mahe Mo deposit in the North Qinling[J]. Acta Petrologica Sinica, 2012, 28(1): 267-278.
[11] 柯昌辉, 王晓霞, 杨阳, 等. 北秦岭南台钼多金属矿床成岩成矿年龄及锆石Hf同位素组成[J]. 中国地质, 2012, 39(6): 1562-1576 doi: 10.3969/j.issn.1000-3657.2012.06.007
KE Changhui, WANG Xiaoxia, YANG Yang, et al. Rock-forming and ore-forming ages of the Nantai Mo polymetallic deposit in North Qinling Mountains and its zircon Hf isotope composition[J]. Geology in China, 2012, 39(6): 1562-1576. doi: 10.3969/j.issn.1000-3657.2012.06.007
[12] 李荣亮, 田建荣, 刘洋, 等. 综合物探方法在甘肃梧桐井铁铜多金属矿勘查中的应用[J]. 地质与勘探, 2017, 53(04): 755-764.
LI Rongliang, TIAN Jianrong, LIU Yang, et al. Application of in- tegrated geophysical methods to exploration in the Wutongjing iron- copper polymetallic deposit of Gansu Provice[J]. Geology and Exploration, 2017, 53(4): 0755- 0764.
[13] 林方丽, 王光杰, 杨晓勇. 综合电磁法在矿区深部成矿机制中的应用研究——以皖南乌溪多金属矿区为例[J]. 地球物理学报, 2016, 59(11): 4323-4337.
LIN Fangli, WAN Gguangjie, YANG Xiaoyong. Application of comprehensive electromagnetic study in deep mineralization mechanism-A case study of the Wuxi polymetallic ore deposit, south Anhui[J]. Chinese Journal of Geophysics, 2016, 59(11): 423-4337.
[14] 刘诚, 孙彪, 魏立勇, 等. 综合电法勘探在西秦岭寨上金矿的应用研究[J]. 地质与勘探, 2020, 56(06): 1226-1237
LIU Cheng, SUN Biao, WEI Liyong, et al. Application of the integrated electrical method to exploration in the Zhaishang gold deposit, West Qinling. Geology and Exploration, 2020, 56(6): 1226~1237.
[15] 刘诚, 李含, 孙彪, 等. 西秦岭寨上金矿综合地球物理研究[J]. 地质论评, 2022, 68(2): 658-672 doi: 10.16509/j.georeview.2022.01.091
LIU Cheng, LI Han, SUN Biao, et al. Comprehensive geophysical study of Zhaishang gold deposit, West Qinling [J]. Geological Review, 2022, 68(2): 658-672. doi: 10.16509/j.georeview.2022.01.091
[16] 刘诚, 唐卫东, 杨凯, 等. 荒漠浅覆盖区萤石矿定位预测技术研究[J]. 西北地质, 2024, 57（4）: 144−156.
LIU Cheng, TANG Weidong, YANG Kai, et al. Research on Location and Prediction Technology of Fluorite Deposits in Shallow Desert Coverage Area[J]. Northwestern Geology, 2024, 57（4）: 144−156.
[17] 刘鲜民, 徐新光, 李磊. 综合物探方法在河南夜长坪钼钨矿外围找矿中的应用及效果[J]. 矿产勘查, 2015, 6(04): 445-450 doi: 10.3969/j.issn.1674-7801.2015.04.015
LIU Xianmin, XU Xinguang, LI Lei. Application and prospecting effect of comprehensive geophysical prospecting in the adjacent region of Yechangping Mo deposit, Henan[J]. Mineral Exploration, 2015, 6(04): 445-450. doi: 10.3969/j.issn.1674-7801.2015.04.015
[18] 陆桂福, 米宏泽, 刘瑞德, 等. 综合物探在斑岩型银钼多金属矿勘查中的应用[J]. 物探与化探, 2014, 38(04): 835-839
LU Guifu, MI Hongze, LIU Ruide, et al. The application of integrated geophysical exploration technology to the prospecting for porphyry silver-molybdenum poly- metallic deposits[J]. Geophysical and Geochemical Exploration, 2014, 38(04): 835-839.
[19] 卢焱, 李健, 白雪山, 等. 地面磁法在隐伏铁矿勘查中的应用-以河北滦平Ⅱ号铁矿为例[J]. 吉林大学学报(地球科学版), 2008, 38(4): 698–702
LU Yan, LI Jian, BAI Xueshan, et al. Application of Magnetic Survey on Hidden Iron Deposit Prospecting Case Study on Luanping II Iron Deposit in Hebei Province China[J]. Journal of Jilin University (Earth Science Edition), 2008, 38(4): 698-702.
[20] 毛景文, 叶会寿, 王瑞廷, 等. 东秦岭中生代钼铅锌银多金属矿床模型及其找矿评价[J]. 地质通报, 2009, 28(1): 72-79 doi: 10.3969/j.issn.1671-2552.2009.01.009
MAO Jingwen, YE Huishou, WANG Ruiting, et al. Mineral deposit model of Mesozoic porphyry Mo and vein-type Pb-Zn-Ag ore deposits in the eastern Qinling, Central China and its implication for prospecting[J]. Geological Bulletin of China, 2009, 28(1): 72-79 doi: 10.3969/j.issn.1671-2552.2009.01.009
[21] 孟小红, 石磊, 郭良辉, 等. 青藏高原东北缘重力异常多尺度横向构造分析[J]. 地球物理学报, 2012, 55(12): 3933-3941
MENG Xiaohong, SHI Lei, GUO Lianghui, et al. Multi-scale analyses of transverse structures based on gravity anomalies in the northeastern margin of the Tibetan Plateau. Chinese Journalof Geophysics, 2012, 55(12): 3933-3941.
[22] 孟银生, 杨立强, 张瑞忠, 等. 第四系覆盖区深部热液脉型矿体综合地球物理方法定位预测——内蒙古维拉斯托矿区北侧隐伏矿体勘查例析[J]. 地球学报, 2016, 37(06): 745-755 doi: 10.3975/cagsb.2016.06.09
MENG Yinsheng, YANG Liqiang, ZHANG Ruizhong, et al. Application of Integrated Geophysical Methods to the Prospecting for Concealed Hydrothermal Vein-type Orebodies beneath Quaternary Sediments: A Case Study of the Northern Area of the Weilasituo Copper Polymetallic Deposit[J]. Acta Geoscientica Sinica, 2016, 37(6): 745-755. doi: 10.3975/cagsb.2016.06.09
[23] 庞振甲, 成欢, 冀月飞. 陕西省略阳县陶家沟地区地质地球物理特征及找矿预测[J]. 西北地质, 2022, 55(01): 93-100 doi: 10.19751/j.cnki.61-1149/p.2022.01.007
PANG Zhenjia, CHENG Huan, JI Yuefei. Geophysical Characteristics and Prospecting Prediction of Taojiagou Area in Lueyang County, Shaanxi Province[J]. Northwestern Geology, 2022, 55(1): 93-100. doi: 10.19751/j.cnki.61-1149/p.2022.01.007
[24] 任广利, 范廷宾, 余元军, 等. 多源遥感信息在喀喇昆仑火烧云一带找矿预测中的应用[J]. 地质与勘探, 2017, 53(06): 1164-1173.
REN Guangli, FAN Tingbin, YU Yuanjun, et al. Application of multisource remote sensing information to metallogenic prediction in the Huoshaoyun region of Karakorum, Xinjiang [J]. Geology and Exploration, 2017, 53(6): 1164- 1173.
[25] 孙博, 李桐林, 李鹤, 等. 可控源音频大地电磁测深法勘查深度研究[J]. 地球物理学进展, 2015, 30(2): 836–839 doi: 10.6038/pg20150247
SUN Bo, LI Tonglin, LI He, et al. Study on the sounding of CSAMT[J]. Progress in Geophysics, 2015, 30(2): 836-839. doi: 10.6038/pg20150247
[26] 邰文星, 金尚刚, 何彦南, 等. 综合物探方法在湖北大冶鸡冠咀铜金矿深部及外围找矿中的应用[J]. 地质与勘探, 2019, 55(04): 1010-1025
TAI Wenxing, JIN Shanggang, HE Yannan, et al. Application of integrated geophysical methods to prospecting in the deep subsurface and peripheral area of the Jiguanzui copper - gold deposit in Daye of Hubei Province[J]. Geology and Exploration, 2019, 55(4): 1010-1025.
[27] 徐荣华, 楼法生, 刘献满, 等. 综合物探法在九瑞宝山—夫山地区找矿中的应用[J]. 地球物理学进展, 2017, 32(06): 2571-2580
XU Ronghua, LOU Fasheng, LIU Xianman, et al. 2017. Applied of comprehensive geophysical prospecting method for exploreing mine in Jiurui area. Progress in Geophysics, 2017, 32(6): 2571-2580.
[28] 张成信, 任永健, 金松, 等. 物化探综合找矿方法在内蒙古喀喇沁旗大西沟萤石矿找矿中的应用[J]. 西北地质, 2024, 57（4）: 135−143.
ZHANG Chengxin, REN Yongjian, JIN Song, et al. Application of Comprehensive Geophysical and Geochemical Exploration Method in the Daxigou Fluorite Deposit, Kalaqin banner, Inner Mongolia[J]. Northwestern Geology, 2024, 57（4）: 135−143.
[29] 赵小星. 西藏桑木岗地区遥感线性构造和蚀变信息提取与找矿预测[J]. 现代地质, 2017, 31(4): 851-859 doi: 10.3969/j.issn.1000-8527.2017.04.019
ZHAO Xiaoxing. Extraction of Linear Structure and Alteration Information Based on Remote Sensing Images and Ore-prospecting Prognosis for Sangmugang in Tibet [J]. Geoscience, 2017, 31(4): 851-859. doi: 10.3969/j.issn.1000-8527.2017.04.019
[30] 周聪, 汤井田, 任政勇, 等. 音频大地电磁法“死频带”畸变数据的Rhoplus校正[J]. 地球物理学报, 2015, 58(12): 4648-4660 doi: 10.6038/cjg20151226
ZHOU Cong, TANG Jingtian, REN Zhengyong, et al. Application of the Rhoplus method to audio magnetoteluric dead band distortion data[J]. Chinese Journal of Geophysics, 2015, 58(12): 4648–4660. doi: 10.6038/cjg20151226
[31] 朱雪丽, 董王仓, 李维成, 陈丽荣. 陕南秦岭造山带侵入岩的控矿作用及其找矿意义[J]. 西北地质, 2021, 54(3): 163-173 doi: 10.19751/j.cnki.61-1149/p.2021.03.013
ZHU Xueli, DONG Wangcang, LI Weicheng, et al. Ore-controlling Factors and Prospecting Significance of Intrusive Rocks in South Shaanxi Qinling Orogenic Belt[J]. Northwestern Geology, 2021, 54(3): 163-173. doi: 10.19751/j.cnki.61-1149/p.2021.03.013
[32] Han Yigui, Zhang Shihong, Pirajno F, et al. U–Pb and Re–Os isotopic systematics and zircon Ce4+/Ce3+ ratios in the Shiyaogou Mo deposit in eastern Qinling, central China: insights into the oxidation state of granitoids and Mo (Au) mineralization[J]. Ore Geology Reviews, 2013, 55: 29-47. doi: 10.1016/j.oregeorev.2013.04.006
[33] Zeng Hualin, Xu Deshu, Tan Handong. A model study for estimating optimum upward-continuation height for gravity separation with application to a Bouguer gravity anomaly over a mineral deposit, Jilin province, northeast China[J]. Geophysics, 2007, 72(4): 145−150.
-
