Stability Evaluation Method and Protection Countermeasure of Compacted Fill Slope Based on Improvement of Ultimate Shear Strength
-
摘要:
压实度是影响填方边坡稳定性的重要因素，为了分析不同压实度下填方边坡的稳定性，设计了不同压实度下填方边坡工况，分析并建立了压实土体本构关系模型，基于有限元强度折减理论，分析了变形破坏趋势，确定极限抗剪强度。采用Bishop方法计算土条两侧的作用力，在不考虑土体侧向变形的情况下，计算得出边坡稳定性系数和填土外加应力作用下导致的沉降变形值，根据计算结果提出了填方边坡稳定性防护对策。结果表明：所提出的分析方法能够准确分析出填方边坡变形情况，有效降低了稳定性分析误差，并且将其应用于实际填方边坡稳定性分析中，具有实际应用意义。
Abstract:Compaction degree is an important factor affecting the stability of the fill slope. In order to analyze the stability of the fill slope under different compaction degree, the working conditions of the fill slope under different compaction degree were designed, and the constitutive relationship model of the compacted soil was analyzed and established. Based on the finite element strength reduction theory, the deformation and failure trend were analyzed and the ultimate shear strength was determined. Using the Bishop method to calculate the forces on both sides of the soil strip, without considering the lateral deformation of the soil, the stability coefficient of the slope and the settlement deformation value caused by the external stress of the fill soil were calculated. Based on the calculation results, stability protection measures for the fill slope were proposed. The results show that the proposed analysis method can accurately analyze the deformation of fill slopes, effectively reduce stability analysis errors, and apply it to the stability analysis of actual fill slopes, which has practical application significance.
-
Key words:
- compaction /
- fill slope /
- stability /
- protection countermeasures /
- shear strength /
- settlement deformation
-
-
表 1 土层折减系数取值表
Table 1. Values of soil layer reduction coefficient
土层液化指数 液化土层深度（m） 折减系数 ≤0.6 ≤10 0 10～20 1/3 0.6～0.8 ≤10 1/3 10～20 2/3 0.8～1.0 ≤10 2/3 10～20 1.0
下载: 导出CSV
表 2 兰州市某建设场地填方边坡参数
Table 2. Filling slope parameters of a construction site in Lanzhou
序号 指标 参数 1 饱和渗透系数（m/h） 0.108 2 饱和含水率（%） 5.21 3 残余含水率（%） 0.084 4 土体粘结强度标准值（kPa） 45 5 暴雨入渗后内聚力（kPa） 26 6 暴雨入渗后内摩擦角（°） 25.3 7 暴雨入渗后容重（KN/m3） 17.6 8 天然容重（KN/m3） 13.5 9 土体底面倾角（°） 45 10 地下水反流线平均倾角（°） 32 11 填土高度（m） 0~120 12 条块滑动面的长度（m） 315
下载: 导出CSV
-
[1] 陈东. 某高速公路下填方边坡稳定性分析及支护方案研究[J]. 公路工程, 2020, 45（1）: 114−116.
CHEN Dong. Study on Stability Analysis and Support Scheme of Lower Slope of a Highway[J]. Highway Engineering,2020,45(1):114−116.
[2] 代雪, 张家明. 某场地边坡稳定分析方法的比较研究[J]. 中国安全生产科学技术, 2021, 17（11）: 119−124.
DAI Xue, ZHANG Jiaming. Comparative study on slope stability analysis methods at a site[J]. China Safety Science and Technology,2021,17(11):119−124.
[3] 高彦斌, 罗文康, 骆佳樑, 等. 两种固结状态下软土的三轴不排水剪切模量非线性及对比[J]. 岩土工程学报, 2021, 43（S2）: 64−67.
GAO Yanbin, LUO Wenkang, LUO Jialiang, et al. Nonlinearity and comparison of triaxial undrained shear modulus of soft soil under two consolidation states[J]. Chinese Journal of Geotechnical Engineering,2021,43(S2):64−67.
[4] 韩文喜, 张日华, 王昊. 降雨和地震对高填方边坡稳定性的影响研究[J]. 水力发电, 2019, 45（12）: 31−36.
HAN Wenxi, ZHANG Rihua, WANG Hao. Study on the Influences of Rainfall and Earthquake on the Stability of High Fill Slope[J]. Water Power,2019,45(12):31−36.
[5] 贺林林, 钱进, 赵陈雨, 等. 巫山神女峰机场高填方边坡稳定性分析方法研究[J]. 合肥工业大学学报(自然科学版), 2023, 46（5）: 646−651+703.
HE Linlin, QIAN Jin, ZHAO Chenyu, et al. Study on stability analysis method of high fill slope of Wushan Shennufeng Airport[J]. Journal of Hefei University of Technology (Natural Science Edition),2023,46(5):646−651+703.
[6] 贾俊, 张茂省, 冯立, 等. 流态破坏型黄土滑坡滑带土临界特征[J]. 西北地质, 2019, 52（2）: 136−147.
JIA Jun, ZHANG Maosheng, FENG Li, et al. Critical characteristics of soil in sliding zone of fluid destructive loess landslide[J]. Northwestern Geology,2019,52(2):136−147.
[7] 蒋辽, 喻兴, 刘林洁, 等. 基于蒙特卡罗模拟的填方边坡可靠度分析[J]. 地下空间与工程学报, 2017, 13（S2）: 693−697.
JIANG Liao, YU Xing, LIU Linjie, et al. Reliability analysis of fill slope based on Monte Carlo simulation[J]. Chinese Journal of Underground Space and Engineering,2017,13(S2):693−697.
[8] 李海涛, 任光明, 范荣全, 等. 川北某变电站堆积体边坡稳定性及加固措施分析[J]. 成都理工大学学报(自然科学版), 2023, 50(4): 454−464.
LI Haitao, REN Guangming, FAN Rongjin, et al. Analysis on stability and reinforcement measures of accumulation body slope in a substation in north Sichuan[J]. Journal of Chengdu University of Technology (Science & Technology Edition), 2023, 50(4): 454−464.
[9] 刘畅, 张平松, 杨为民, 等. 税湾地震黄土滑坡的岩土动力特性及其稳定性评价[J]. 西北地质, 2020, 53（4）: 176−185.
LIU Chang, ZHANG Pingsong, YANG Weimin, et al. Geotechnical dynamic characteristics and stability evaluation of loess landslide in Shiwan earthquake[J]. Northwestern Geology,2020,53(4):176−185.
[10] 吕江, 赵晖, 杨杓, 等. 山区水下填方路堤边坡的稳定性分析[J]. 深圳大学学报: 理工版, 2021, 38（2）: 151−156.
LV Jiang, ZHAO Hui, YANG Shao, et al. Slope stability of underwater fill embankment in mountainous area[J]. Journal of Shenzhen University (Science & Engineering),2021,38(2):151−156.
[11] 任东兴, 薛鹏, 叶飞, 等. 降雨入渗条件下黏性土基坑浅层边坡稳定性分析[J]. 成都理工大学学报(自然科学版), 2022, 49（2）: 204−212.
REN Dongxing, XUE Peng, YE fei, et al. Shallow slope stability analysis of cohesive soil foundation pit under rainfall infiltration[J]. Journal of Chengdu University of Technology (Science & Technology Edition),2022,49(2):204−212.
[12] 唐亚明. 基于可靠度的黄土斜坡稳定性分析[J]. 地质通报, 2008, 27（8）: 1217−1222.
TANG Yaming. Loess slope stability analysis based on reliability[J]. Geological Bulletin of China,2008,27(8):1217−1222.
[13] 王斌, 熊宗瑜. 黄土高填方路堤沉降观测及有限元分析[J]. 港工技术与管理, 2020（5）: 17−22.
WANG Bin, XIONG Zongyu. Settlement Observation and Finite Element Analysis of Loess High Fill Embankment[J]. Technology & Management Of Port & Harbor Engineering,2020(5):17−22.
[14] 薛强, 张茂省, 毕俊擘, 等. 开挖型黄土边坡剥落侵蚀作用及变形破坏研究[J]. 西北地质, 2019, 52（2）: 158−166.
XUE Qiang, ZHANG Maoxing, BI Junbo, et al. Exfoliation Erosion and Deformation Failure of Excavated Loess Slope[J]. Northwestern Geology,2019,52(2):158−166.
[15] 向文贤, 黎应书, 许万忠, 等. 降雨入渗条件下预应力锚索加固填方边坡稳定性分析[J]. 中国煤炭地质, 2022, 34（1）: 69−74. doi: 10.3969/j.issn.1674-1803.2022.01.12
XIANG Wenxian, LI Yingshu, XU Wanzhong, et al. Prestressed Cable Anchor Reinforced Slope Stability Analysis under Rainfall Penetration Condition[J]. Coal Geology of China,2022,34(1):69−74. doi: 10.3969/j.issn.1674-1803.2022.01.12
[16] 杨智勇, 李典庆, 曹子君, 等. 考虑土质边坡多失效模式的区域概率风险分析方法[J]. 工程力学, 2019, 36（5）: 216−225.
YANG Zhiyong, LI Dianqing, CAO Zijun, et al. Region probability method for soil slope risk assessment involving multiple failure modes[J]. Engineering Mechanics,2019,36(5):216−225.
[17] 叶帅华, 张玉巧, 房光文. 黄土高填方边坡的稳定性影响因素及其变形规律[J]. 兰州理工大学学报, 2021, 47（3）: 120−126.
YE Shuaihua, ZHANG Yuqiao, FANG Guangwen. Influencing factors and deformation law of stability of loess high fill slope[J]. Journal of Lanzhou University of Technology,2021,47(3):120−126.
[18] 叶志程, 杨溢, 左晓欢, 等. 基于Midas-GTS/NX的不同工况下某填方边坡稳定性分析及加固措施[J]. 化工矿物与加工, 2021, 50（5）: 16−19.
YE Zhicheng, YANG Yi, ZUO Xiaohuan, et al. Stability analysis of a slope with reinforcement based on Midas-GTS/NX under different working conditions[J]. Industrial Minerals & Processing,2021,50(5):16−19.
[19] 赵洪, 谢友均, 龙广成, 等. 冲击荷载作用下含黏结界面混凝土破坏特征与应力应变分析[J]. 上海交通大学学报, 2022, 59（9）: 1208−1217.
ZHAO Hong, XIE Youjun, LONG Guangcheng, et al. Mechanical Characteristics and Stress and Strain Analysis of Concrete with Bonding Interface Under Impact Load[J]. Journal of Shanghai Jiaotong University,2022,59(9):1208−1217.
[20] 赵建祥, 毕鹏飞, 惠亚强. 降雨作用下高填方边坡失稳机制研究[J]. 水利水电技术(中英文), 2021, 52（S2）: 421−429.
ZHAO Jianxiang, BI Pengfei, HUI Yaqiang. Study on instability mechanism of high fill slope under rainfall[J]. Water Resources and Hydropower Technology (Chinese and English),2021,52(S2):421−429.
[21] 张文生, 罗强, 蒋良潍, 等. 小样本岩土参数下考虑矩估计偏差的土质边坡可靠度分析[J]. 岩土力学, 2019, 40（1）: 315−324.
ZHANG Wensheng, LUO Qiang, JIANG Liangwei, et al. Reliability analysis of soil slope considering moment estimation bias using small sample geotechnical param[J]. Rock and Soil Mechanics,2019,40(1):315−324.
[22] 周中, 李繁, 鲁四平. 轻质土换填路堤地基侧向变形非线性算法研究[J]. 铁道工程学报, 2022, 39（11）: 12−18. doi: 10.3969/j.issn.1006-2106.2022.11.003
ZHOU Zhong, LI Fan, LU Siping. Research on nonlinear Algorithm of lateral deformation of lightweight soil replacement embankment[J]. Journal of Railway Engineering,2022,39(11):12−18. doi: 10.3969/j.issn.1006-2106.2022.11.003
[23] 周亚东, 李龙辉, 陈思源. 饱和土一维大变形非线性热固结模型[J]. 岩石力学与工程学报, 2023, 42（9）: 2306−2314.
ZHOU Yadong, LI Longhui, CHEN Siyuan. One-dimensional nonlinear thermal consolidation model of saturated soil with large deformation[J]. Chinese Journal of Rock Mechanics and Engineering,2023,42(9):2306−2314.
[24] Li Kaiqi, Yin Zhenyu, Zhang Ning, et al. A PINN-based modelling approach for hydromechanical behaviour of unsaturated expansive soils[J]. Computers and Geotechnics, 2024, 169: 106174.
[25] Mohammad Hashem Bathayian Seyed, Maleki Mohammad. Kinematic hardening based coupled elastoplastic–viscoplastic model for describing time-dependent behavior of soils subjected to non-monotonic loadings[J]. Computers and Geotechnics, 2023, 161: 105602.
[26] Parvaneh Seyed Milad, Foster Craig D, Chi Shengwei. A hardening/softening viscoplastic model for large deformation of soil[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 2022, 46(10): 1895–1918.
[27] Xiao Yang, Liu Shuang, Shi Jinquan, et al. Temperature-Dependent SWCC Model for Unsaturated Soil[J]. International Journal of Geomechanics, 2024, 24(5): 04024071 .
[28] Peng Yu, Yin Zhenyu, Gao Fuping. Micromechanical analysis of pipeline-soil interaction in unsaturated granular soil undergoing lateral ground movement[J]. Computers and Geotechnics, 2024, 169: 106181.
-
