New Materials of Protoceratops hellenikorhinus (Neoceratopsia: Protoceratopsidae) in Alxa Region, Inner Mongolia
-
摘要:
发现于内蒙古自治区阿拉善右旗巴音塔拉上白垩统乌兰苏海组（坎潘阶）中的3件原角龙类化石新标本，不同程度地保存了头部骨骼。其头骨较大、前颌骨齿不存在、上颌骨侧面的横向嵴近于水平且发育程度相对较弱、齿骨腹缘近于平直，显示出似希腊鼻原角龙Protoceratops hellenikorhinus的特征，应归入这一属种。阿拉善右旗巴音塔拉目前仅识别出1个属种的原角龙科化石——似希腊鼻原角龙，这一地区也成为该属种在乌拉特后旗巴音满都呼之后的第2个产出地点。似希腊鼻原角龙在巴音塔拉和巴音满都呼的恐龙动物群中均是数量占优势的分子，显示两地恐龙动物群的可对比性，同时进一步表明在晚白垩世坎潘期，内蒙古西部存在一个面积广阔、古地理环境相似的区域，该区域内不同地点的恐龙类群可以相互交流。
Abstract:Three new specimens of protoceratopsid skulls have been discovered recently from the Late Cretaceous Wulansuhai Formation (Campanian) at Bayan Tal locality in Alxa Right Banner, western Inner Mongolia Autonomous Region, northern China. The skull is relatively large, with premaxillary teeth absent. The craniocaudally arranged ridge on the lateral surface of maxilla is generally straight, and comparatively reduced. The ventral edge of dentary is nearly straight. These specimens show the representative characters only present in Protoceratops hellenikorhinus, thus should be assigned to this taxon. Only one genus and species of Protoceratopsidae has been confirmed, i.e. Protoceratops hellenikorhinus, at Bayan Tal locality. This locality becomes the second site yielding P. hellenikorhinus, following Bayan Mandahu locality in Urad Rear Banner, western Inner Mongolia. This protoceratopsid species was the dominant element among the dinosaur faunas at both Bayan Tal and Bayan Mandahu localities, which provides more paleontological evidences for the Late Cretaceous dinosaur faunal similarity between the two sites. P. hellenikorhinus has been only known at Bayan Tal and Bayan Mandahu localities during the Campanian, Late Cretaceous. This fact indicates that there may have existed a vast region in similar paleoenvironment across the western Inner Mongolia at that time, and that the dinosaurs could exchange easily within the region.
-
-
表 1 似希腊鼻原角龙Protoceratops hellenikorhinus新标本头骨部分特征测量及其与正型标本的比较 （mm）
Table 1. Some measurements and comparisons on skulls of the new specimens and holotype specimen of Protoceratops hellenikorhinus (mm)
测量特征 新标本
IMMNH-PV00522新标本
IMMNH-PV00523新标本
IMMNH-PV00524正型标本
IMM 95BM1/1头骨全长 640* – 690* 720 眶前区长 222（r）* – 262（l） 288 眶后区长 180（r） – 126（l） 170 头骨在鼻骨处高 290（r） – – 325 眶孔长 89（r） – 89（l） 103 眶孔高 62（r） – – 90 外鼻孔长 87（r） – 87（l）* 72 外鼻孔宽 35（r） – 50（l） 27 眶前窝长 – – 67（l） 71 眶前窝高 – – 87（l） 126 下颌全长 – 315（r） 364（l）* 414 下颌冠状突前部长 254（r） 182（r） 238（l）* 255 注：（l）. 左侧；（r）. 右侧；*. 估算值；–. 未知值；正型标本（IMM 95BM1/1）测量数据引自Lambert等（2001）。
下载: 导出CSV
表 2 原角龙属安氏种Protoceratops andrewsi与似希腊鼻种P. hellenikorhinus头骨特征区别
Table 2. Main differences of the skull characters between Protoceratops andrewsi and P. hellenikorhinus
特 征 安氏原角龙
Protoceratops andrewsi似希腊鼻原角龙
Protoceratops hellenikorhinus完全成年个体的头骨大小 较小，全长约500 mm 较大，全长超过700 mm 前颌骨齿 2枚，锥状 不存在 成年个体的齿骨腹缘 显著向下拱曲 平直 上颌骨侧面前后向延伸的嵴 明显上凸、显著 相对平直、减弱 鳞骨腹突 不与方轭骨接触 伸长且与方轭骨相接触 前齿骨前缘与腹缘间的夹角 成年个体的不明显，圆滑过渡 明显，约125° 隅骨后缘三角形面 略指向侧方 指向后方
下载: 导出CSV
-
[1] 白晓寅, 贺永红, 韩小锋, 等. 银额盆地哈日凹陷灰质泥岩气藏识别技术[J]. 西北地质, 2020, 53（2）: 270−279.
BAI Xiaoyin, HE Yonghong, HAN Xiaofeng, et al. Identification Technology of Grey Mudstone Gas Reservoir in Hari Sag of Yin'e Basin[J]. Northwestern Geology,2020,53(2):270−279.
[2] 陈启林, 卫平生, 杨占龙. 银根—额济纳盆地构造演化与油气勘探方向[J]. 石油实验地质, 2006, 28（4）: 311−315. doi: 10.3969/j.issn.1001-6112.2006.04.001
CHEM Qilin, WEI Pingsheng, YANG Zhanlong. Tectonic evolution and petroleum prospection in the Yin’gen-Ejina Basin[J]. Petroleum Geology & Experiment,2006,28(4):311−315. doi: 10.3969/j.issn.1001-6112.2006.04.001
[3] 陈晓云. 内蒙古鄂尔多斯地区早白垩世原角龙类化石的发现及其意义[J]. 地球学报, 2017, 38（2）: 154−158. doi: 10.3975/cagsb.2017.02.08
CHEN Xiaoyun. The discovery and significance of the protoceratopsid dinosaur from the Lower Cretaceous of Ordos region, Inner Mongolia[J]. Acta Geoscientica Sinica,2017,38(2):154−158. doi: 10.3975/cagsb.2017.02.08
[4] 陈晓云, 谭锴, 卢立伍, 等. 似希腊鼻原角龙(角龙亚目: 原角龙科)在内蒙古阿拉善地区的发现[J]. 地质学报, 2022, 96（11）: 3722−3732. doi: 10.3969/j.issn.0001-5717.2022.11.004
CHEN Xiaoyun, TAN Kai, LU Liwu, et al. Occurrence of Protoceratops hellenikorhinus (Ceratopsia: Protoceratopsidae) in Alxa region, western Inner Mongolia, China[J]. Acta Geologica Sinica,2022,96(11):3722−3732. doi: 10.3969/j.issn.0001-5717.2022.11.004
[5] 董枝明, 尤海鲁, 彭光照. 中国古脊椎动物志, 第二卷两栖类爬行类鸟类, 第五册鸟臀类恐龙[M]. 北京: 科学出版社, 2015.
DONG Zhiming, YOU Hailu, PENG Guangzhao. Palaeovertebrata Sinica, Volume II Amphibians, Reptilians, and Avians, Fascicle 5 Ornithischian Dinosaurs[M]. Beijing: Science Press, 2015.
[6] 内蒙古自治区地质矿产局. 内蒙古自治区区域地质志[M]. 北京: 地质出版社, 1991.
Bureau of Geology and Mineral Resources of Nei Mongol Autonomous Region. Regional Geology of Nei Mongol (Inner Mongolia) Autonomous Region[M]. Beijing: Geological Publishing House, 1991.
[7] 胡承志, 程政武. 巨型山东龙再研究的新进展[J]. 中国地质科学院院报, 1986, 14: 163−170.
HU Chengzhi, CHENG Zhengwu. Supplementary notes on research and its development of Shantungosaurus giganteus[J]. Bulletin of the Chinese Academy of Geological Sciences,1986,14:163−170.
[8] 胡承志, 程政武, 庞其清, 等. 巨型山东龙[M]. 北京: 地质出版社, 2001.
HU Chengzhi, CHENG Zhengwu, PANG Qiqing, et al. Shantungosaurus giganteus[M]. Beijing: Geological Publishing House, 2001.
[9] 姜亭, 周俊林, 牛亚卓, 等. 西北公益性油气地质调查进展和展望[J]. 西北地质, 2022, 55（3）: 64−80.
JIANG Ting, ZHOU Junlin, NIU Yazhuo, et al. Progress and Prospect of Public Petroleum Geological Survey in Northwest China[J]. Northwestern Geology,2022,55(3):64−80.
[10] 彭君, 李继东, 张洪安, 等. 银根—额济纳旗盆地西缘的中—新生代伸展构造[J]. 地质科学, 2018, 53（4）: 1479−1487. doi: 10.12017/dzkx.2018.088
PENG Jun, LI Jidong, ZHANG Hong'an, et al. Meso-Cenozoic extensional structures on the western margin of the Yingen-Ejinaqi Basin[J]. Chinese Journal of Geology,2018,53(4):1479−1487. doi: 10.12017/dzkx.2018.088
[11] 谭锴, 陈晓云, 卢立伍, 等. 记内蒙古阿拉善右旗晚白垩世的绘龙属(甲龙科)化石[J]. 地质学报, 2022, 96（11）: 3733−3740. doi: 10.3969/j.issn.0001-5717.2022.11.005
TAN Kai, CHEN Xiaoyun, LU Liwu, et al. On the ankylosaurid Pinacosaurus from the Late Cretaceous of Alxa Right Banner, Inner Mongolia[J]. Acta Geologica Sinica,2022,96(11):3733−3740. doi: 10.3969/j.issn.0001-5717.2022.11.005
[12] 魏建设, 王宝文, 乔世海, 等. 内蒙古西部额济纳旗希热哈达地区二叠系页岩油(气)地质条件初探[J]. 西北地质, 2018, 51（3）: 200−213.
WEI Jianshe, WANG Baowen, QIAO Shihai, et al. A Preliminary Study on the Geological Conditions of the Permian Shale Oil(Gas) in Xirehada Area, Western Inner Mongolia[J]. Northwestern Geology,2018,51(3):200−213.
[13] 魏建设, 姜亭, 王宝文, 等. 银额盆地居延海坳陷吉格达凹陷石炭系—二叠系烃源岩生物标志化合物特征及其意义[J]. 西北地质, 2020, 53（3）: 273−283.
WEI Jianshe, JIANG Ting, WANG Baowen, et al. The Biomarker Characteristics and Its Significance of the Carboniferous-Permian Source Rocks in Jigeda Sag of Juyanhai Depression in Yin'er Basin[J]. Northwestern Geology,2020,53(3):273−283.
[14] 卫平生, 姚清洲, 吴时国. 银根—额济纳旗盆地白垩纪地层、古生物群和古环境研究[J]. 西安石油大学学报(自然科学版), 2005, 20（2）: 17−21.
WEI Pingsheng, YAO Qingzhou, WU Shiguo. Study on Cretaceous stratum, palaeobiota and palaeoclimate of Yin’gen-Ejinaqi Basin[J]. Journal of Xi’an Shiyou University (Natural Science Edition),2005,20(2):17−21.
[15] 杨钟健. 首次在山西发现的恐龙化石[J]. 古脊椎动物学报, 1958, 2（4）: 231−236.
YANG Zhongjian. The first record of dinosaurian remains from Shansi[J]. Vertebrata PalAsiatica,1958,2(4):231−236.
[16] Bohlin B. Fossil reptiles from Mongolia and Kansu[J]. Sino-Swedish Expedition Publication,1953,37:1−113.
[17] Brown B, Schlaikjer E M. The structure and relationships of Protoceratops[J]. Annals of the New York Academy of Sciences,1940,40(3):133−266. doi: 10.1111/j.1749-6632.1940.tb57047.x
[18] Burns M E, Currie P J, Sissons R L, et al. Juvenile specimens of Pinacosaurus grangeri Gilmore, 1933 (Ornithischia: Ankylosauria) from the Late Cretaceous of China, with comments on the specific taxonomy of Pinacosaurus[J]. Cretaceous Research,2011,32:174−186. doi: 10.1016/j.cretres.2010.11.007
[19] Czepiński Ł. Ontogeny and variation of a protoceratopsid dinosaur Bagaceratops rozhdestvenskyi from the Late Cretaceous of the Gobi Desert[J]. Historical Biology,2020,32(10):1393−1420.
[20] Dodson P. Quantitative aspects of relative growth and sexual dimorphism in Protoceratops[J]. Journal of Paleontology,1976,50(5):929−940.
[21] Dong Z M, Currie P J. Protoceratopsian embryos from Inner Mongolia, People’s Republic of China[J]. Canadian Journal of Earth Sciences,1993,30(10-11):2248−2254.
[22] Granger W, Gregory W K. Protocetatops andrewsi, a pre-ceratopsian dinosaur from Mongolia[J]. American Museum Novitates,1923,72:1−6.
[23] Jerzykiewicz T, Currie P J, Eberth D A, et al. Djadokhta Formation correlative strata in Chinese Inner Mongolia: an overview of the stratigraphy, sedimentary geology, and paleontology and comparisons with the type locality in the pre-Altai Gobi[J]. Canadian Journal of Earth Sciences,1993,30(10-11):2180−2195.
[24] Ji S A, Zhang L F, Lu L W, et al. The first discovery of the Late Cretaceous protoceratopsid fauna from Alxa, Inner Mongolia, China[J]. Acta Geologica Sinica (English Edition),2017,91(3):1908−1909.
[25] Kurzanov S M. A new Late Cretaceous protoceratopsid genus from Mongolia[J]. Paleontological Journal,1990(4):85−91.
[26] Lambert O, Godefroit P, Li H, et al. A new species of Protoceratops (Dinosauria, Neoceratopsia) from the Late Cretaceous of Inner Mongolia (P. R. China)[J]. Bulletin de l’Institut Royal des Sciences Naturelles de Belgique, Sciences de la Terra,2001,71(Sup.):5−28.
[27] Maiorino L, Farke A A, Kotsakis T, et al. Males resemble females: re-evaluating sexual dimorphism in Protoceratops andrewsi (Neoceratopsia, Protoceratopsidae)[J]. PLoS ONE,2015,10(5):e0126464. doi: 10.1371/journal.pone.0126464
[28] Maryańska T, Osmólska H. Protoceratopsidae (Dinosauria) of Asia[J]. Palaeontologica Polonica,1975,33:133−181.
[29] Naoto H, Mahito W, Khishigiav T. New specimens of Protoceratops (Dinosauria: Neoceratopsia) from the Upper Cretaceous in Udyn Sayr, southern Gobi Area, Mongolia[J]. Paleontological Research,2012,16(3):179−198. doi: 10.2517/1342-8144-16.3.179
[30] You H L, Dodson P. Basal Ceratopsia[A]. Weishample D B, Dodson P, Olsmolska H. The Dinosauria, Second Edition[C]. Berkeley: California University Press, 2004: 478-493.
[31] You H L, Dong Z M. A new protoceratopsid (Dinosauria: Neoceratopsia) from the Late Cretaceous of Inner Mongolia, China[J]. Acta Geologica Sinica (English Edition),2003,77(3):299−303. doi: 10.1111/j.1755-6724.2003.tb00745.x
-
