Development Characteristics and Genetic Evolution of Carbonate Karst Ancient River: Example from the Middle-Lower Ordovician in Block-12 of Tahe Oilfield, Tarim Basin
-
摘要:
为了明确塔里木盆地塔河油田12区中—下奥陶统顶面古河道的成因，利用地震剖面分析、地震属性提取等技术，结合钻井资料刻画了古地貌、古水系发育特征，定量描述古河道的河曲特征，并基于现代岩溶理论建立了古河道成因演化模式。结果表明：中—下奥陶统顶面古河道为“深切河曲”古岩溶地貌，深切河曲特征表现为河谷主要呈“V”字形，两侧河谷坡岸对称，谷壁陡峭，发育由于截弯取直形成的离堆山、天生桥等标志性地貌；中—下奥陶统顶面古河道发育“高弯曲率”河曲形态，深切河曲的单个河曲弯曲率Ｃ值都在2.20以上，平均值为4.27，SN向河曲带弯曲率Ｃ值为1.87，EW向河曲带的弯曲率Ｃ值为2.38；塔河油田12区中—下奥陶统顶面深切河曲经历志留系沉积期、自由河曲期、深切河曲期等3个演化阶段，其成因与华力西早期运动构造作用关系密切。
Abstract:In order to clarify the origin of the ancient river channel on the top of the Middle and Lower Ordovician in Block 12 of Tahe Oilfield, the Tarim basin, using techniques of seismic profile analysis and seismic attribute extraction, combined with drilling data, the development characteristics of the ancient landform and ancient water system are depicted, the meander characteristics of the ancient river channel are quantitatively describe, and the genetic evolution model of the ancient river channel is established.The results show that the ancient channel on the top of the Middle and Lower Ordovician is entrenched meander river, and the entrenched meander is characterized by a "V" shape of the valley, symmetrical slope banks on both sides of the valley, steep valley walls, and the development of the meander core and natural bridge formed by process of natural cutoff. The ancient channel on the top of the Middle-Lower Ordovician developed a "high curvature" meander shape. Statistical meander parameters indicate that the meander ratio C values are larger than 2.20, with an average value is 4.27, the C value of the whole North-South meander is 1.87, and the C value of the whole East-West meander is 2.38. The evolution of meandering superimposed Valley in block-12 has three stages: Silurian sedimentary period, free-meander and entrenched-meander, and its genesis is closely related to the early Hercynian movement.
-
Key words:
- Tarim basin /
- Tahe Oilfield /
- middle-lower Ordovician /
- ancient river /
- entrenched meander /
- meander core /
- meander parameter /
- meander ratio
-
-
表 1 12区古河道单河曲参数统计（标注位置见图3）
Table 1. Statistics of single meander parameters of ancient river in block-12
单个河曲名称 单个河曲参数 河道长度S（km） 曲流颈长度L（km） 弯曲率C 封闭率e 河曲轴长M（km） 1 4.50 0.60 7.50 0.88 1.44 2 2.40 1.03 2.33 0.70 0.96 3 2.14 0.79 2.70 0.73 0.85 4 2.90 0.56 5.18 0.84 1.00 5 1.76 0.68 2.59 0.72 0.69 6 2.09 0.95 2.20 0.69 0.84 7 3.02 1.30 2.32 0.70 1.15 8 7.25 0.69 10.51 0.91 2.36 9 3.05 1.32 2.31 0.70 0.90 10 4.01 1.80 2.23 0.69 1.34 11 4.85 1.74 2.79 0.74 1.73 12 4.44 0.81 5.48 0.85 1.96 13 4.35 0.60 7.25 0.88 1.75
下载: 导出CSV
表 2 12区古河道河曲带参数统计
Table 2. Statistics of meander belt parameters of ancient river in block-12
河曲带名称 河曲带参数 河道长度S（km） 河曲带轴长L（km） 弯曲率C 波幅W（km） 波长λ（km） SN向河曲带 15.00 8.02 1.87 0.60 2.67 EW向河曲带 39.95 16.81 2.38 0.86 1.97
下载: 导出CSV
-
[1] 蔡忠贤, 张恒, 漆立新, 等. 塔里木盆地中—下奥陶统岩溶水文地貌结构类型及特征[J]. 石油学报, 2020, 41（1）: 43−58.
CAI Zhongxian, ZHANG Heng, QI Lixin, et al. Types and characteristics of karst hydrogeomorphologic architecture in the Middle-Lower Ordovician, Tarim Basin[J]. Acta Petrologica Sinica,2020,41(1):43−58.
[2] 陈占坤, 张忠民, 冯兴强. 塔河油田志留系沉积相及层序地层学研究[J]. 石油地质与工程, 2009, 23（6）: 1−4+134.
CHEN Zhankun, ZHANG Zhongmin, FENG Xingqiang. Researches on sedimentary facies and sequences stratigraphy of Silurian in Tahe oilfield[J]. Petroleum Geology and Engineering,2009,23(6):1−4+134.
[3] 淡永, 邹灏, 梁彬, 等. 塔北哈拉哈塘加里东期多期岩溶古地貌恢复与洞穴储层分布预测[J]. 石油与天然气地质, 2016, 37（3）: 304−312.
DAN Yong, ZOU Hao, LIANG Bin, et al. Restoration of multistage paleogeomorphology during Caledonian period and paleokarst cavernous reservoir prediction in Halahatang area, northern Tarim basin[J]. Oil & Gas Geology,2016,37(3):304−312.
[4] 邓兴梁, 张庆玉, 梁彬, 等. 塔中Ⅱ区奥陶系鹰山组岩溶古地貌恢复方法研究[J]. 中国岩溶, 2015, 34（2）: 154−158.
DENG Xingliang, ZHANG Qingyu, LIANG Bin, et al. Reconstruction of karst palaeogeomorphology for the Ordovician Yingshan formation in the central Tarim basin[J]. Carsologica Sinica,2015,34(2):154−158.
[5] 翟晓先, 云露. 塔里木盆地塔河大型油田地质特征及勘探思路回顾[J]. 石油与天然气地质, 2008, 29（05）: 565−573.
ZHAI Xiaoxian, YUN Lu. Geology of giant Tahe oilfield and a review of exploration thinking in Tarim Basin[J]. Oil & Gas Geology,2008,29(05):565−573.
[6] 范春花, 蒲仁海, 漆立新, 等. 塔河地区志留系的对比[J]. 地质论评, 2007, 53（1）: 1−5+145.
FAN Chunhua, PU Renhai, QI Lixin, et al. The Silurian Correlation in Tahe Area, Tarim Basin, Northwestern China[J]. Geological Review,2007,53(1):1−5+145.
[7] 高玉飞, 钟建华. 塔河油田四区奥陶系储层裂缝特征及其意义[J]. 西北地质, 2013, 46（2）: 186−194.
GAO Yufei, ZHONG Jianhua. The Characters of Fractures and Its Significance of the Reservoir in Ordovician in the Forth Block of Tahe Oil Field[J]. Northwestern Geology,2013,46(2):186−194.
[8] 郭川, 田亮, 鲍典. 塔河油田12区奥陶系油藏东部区域岩溶古河道识别及其意义[J]. 石油地质与工程, 2016, 30（01）: 26−31+147.
GUO Chuan,TIAN Liang,BAO Dian. Regional karst old channel identification and its significance of eastern Ordovician reservoir of block-12 in Tahe oilfield[J]. Petroleum Geology and Engineering,2016,30(01):26−31+147.
[9] 侯啓东, 任收麦, 郭天旭, 等. 塔里木盆地西南坳陷二叠系页岩油气地质条件分析[J]. 西北地质, 2020, 53（01）: 168−177.
HOU Qidong, REN Shoumai, GUO Tianxu, et al. Analysis of Geological Conditions of Permian Shale Oil and Gas in the Southwestern Depression of the Tarim Basin, Northwest China[J]. Northwestern Geology,2020,53(01):168−177.
[10] 江华军, 李长安, 张玉芬, 等. 嘉陵江曲流型叠置河谷成因对区域地质环境的响应[J]. 地球科学(中国地质大学学报), 2014, 39（11）: 1666−1674.
JIANG Huajun, LI Chang’an, ZHANG Yufen, et al. Origin of Meander Shape-Superimposed Valleys in the Middle Jialing River: Responses to Regional Geological Environment[J]. Earth Science—Journal of China University of Geosciences,2014,39(11):1666−1674.
[11] 江华军, 李长安, 张玉芬, 等. 嘉陵江古河曲发育的古地理环境重建[J]. 中国地质, 2013, 40（2）: 460−468.
JIANG Huajun, LI Chang’an, ZHANG Yufen, et al. The reconstruction of paleogeographic environment for the development of the Jialing River’s ancient meander[J]. Geology in China,2013,40(2):460−468.
[12] 姜应兵, 李兴娟. 塔里木盆地塔河油田TH12402井区中下奥陶统古岩溶洞穴发育模式[J]. 古地理学报, 2021, 23（04）: 824−836.
JIANG Yingbing, LI Xingjuan. Development model of middle and lower Ordovician paleokarst caves in well th12402 area of Tahe oilfield, Tarim Basin[J]. Journal of Paleogeography,2021,23(04):824−836.
[13] 康志宏. 塔河碳酸盐岩油藏岩溶古地貌研究[J]. 新疆石油地质, 2006, 27（05）: 522−525.
KANG Zhihong. Study on Karst paleogeomorphology of Tahe carbonate reservoir[J]. Xinjiang Petroleum Geology,2006,27(05):522−525.
[14] 李源, 鲁新便, 蔡忠贤, 等. 塔河油田海西早期古水文地貌特征及其对洞穴发育的控制[J]. 石油学报, 2016, 37（08）: 1011−1020.
LI Yuan, LU Xinbian, CAI Zhongxian, et al. Hydrogeomorphologic characteristics and its controlling caves in Hercynian, Tahe Oilfield[J]. Acta Petrologica Sinica,2016,37(08):1011−1020.
[15] 李源, 鲁新便, 蔡忠贤, 等. 塔里木盆地塔河油田岩溶峡谷区海西早期洞穴系统发育模式[J]. 古地理学报, 2017, 19（02）: 364−372.
LI Yuan, LU xinbian, CAI Zhongxian, et al. Development model of Hercynian cave system in karst canyon area of Tahe Oilfield, Tarim Basin[J]. Journal of Paleogeography,2017,19(02):364−372.
[16] 鲁新便, 何成江, 邓光校, 等. 塔河油田奥陶系油藏喀斯特古河道发育特征描述[J]. 石油实验地质, 2014, 36（03）: 268−274.
LU Xinbian, HE Chengjiang, DENG Guangxiao, et al. Development features of karst ancient river system in Ordovician reservoirs, Tahe Oil Field[J]. Petroleum Geology & Experiment,2014,36(03):268−274.
[17] 刘学利, 郑小杰, 屈兴勃, 等. 塔河油田9区下油组块状叠置厚油层渗流屏障研究[J]. 西北地质, 2023, 56（2）: 260−271.
LIU Xueli, ZHENG Xiaojie, QU Xingbo, et al. Research on Seepage Barriers of Massive and Superimposed Thick Oil Layers in the Low Oil Formation of No. 9 Block in Tahe Oilfield[J]. Northwestern Geology,2023,56(2):260−271.
[18] 吕海涛, 张哨楠, 马庆佑. 塔里木盆地中北部断裂体系划分及形成机制探讨[J]. 石油实验地质, 2017, 39（04）: 444−452.
LV Haitao, ZHANG Shaonan, MA Qingyou. Division and formation mechanism of fault system in the middle and north of Tarim Basin[J]. Petroleum Experimental Geology,2017,39(04):444−452.
[19] 宁超众, 胡素云, 潘文庆, 等. 塔里木盆地哈拉哈塘地区奥陶系良里塔格组古地貌与岩溶洞穴特征[J]. 石油与天然气地质, 2020, 41（5）: 985−995.
NING Chaozhong, HU Suyun, PAN Wenqing, et al. Characterization of paleo-topography and karst caves in Ordovician Lianglitage formation, Halahatang oilfield, Tarim basin[J]. Oil & Gas Geology,2020,41(5):985−995.
[20] 漆立新, 云露. 塔河油田奥陶系碳酸盐岩岩溶发育特征与主控因素[J]. 石油与天然气地质, 2010, 31（1）: 1−12.
QI Lixin, YUN Lu. Development characteristics and main controlling factors of the Ordovician carbonate karst in Tahe oilfield[J]. Oil & Gas Geology,2010,31(1):1−12.
[21] 任美锷. 岩溶学概论[M]. 北京: 商务印书馆, 1983.
REN Mei’e. Karst introduction [M]. Beijing: The Commercial Press, 1983.
[22] 夏永涛, 刘永立, 刘存革, 等. 塔河油田西北部加里东中期古水系特征及其地质意义[J]. 中国岩溶, 2019, 38（3）: 438−443.
XIA Yongtao, LIU Yongli, LIU Cunge, et al. Characteristics and geological significance of Middle Caledonian palaeodrainage pat- tern in the northwest of Tahe oilfield[J]. Carsologica Sinica,2019,38(3):438−443.
[23] 杨明德. 喀斯特流域水文地貌系统[M]. 北京: 地质出版社, 1998.
YANG Mingde. Karst river basin landform system [M]. Beijing: Geological Publishing House, 1998.
[24] 张斌, 陈文, 喻顺, 等. 南天山洋古生代期间俯冲作用过程探讨[J]. 岩石学报, 2014, 30（08）: 2351−2362.
ZHANG Bin, CHEN Wen, YU Shun, et al. Discussion on subduction process during Paleozoic in South Tianshan ocean[J]. Journal of Rock,2014,30(08):2351−2362.
[25] 张斌, 艾南山, 黄正文, 等. 中国嘉陵江河曲的形态与成因[J]. 科学通报, 2007, 52（22）: 2671−2682.
ZHANG Bin, AI Nanshan, HUANG Zhengwen, et al. Morphology and genesis of Jialing River meander in China[J]. Science Bulletin,2007,52(22):2671−2682.
[26] 张翔, 田景春, 彭军. 塔里木盆地志留-泥盆纪岩相古地理及时空演化特征研究[J]. 沉积学报, 2008, 26（05）: 762−771.
ZHANG Xiang, TIAN Jingchun, PENG Jun. Study on lithofacies paleogeography and temporal and spatial evolution characteristics of Silurian Devonian in Tarim Basin[J]. Journal of Sedimentation,2008,26(05):762−771.
[27] 张长建, 吕艳萍, 张振哲. 塔里木盆地塔河油田西部斜坡区中下奥陶统古岩溶洞穴发育特征[J]. 石油实验地质, 2022, 44（06）: 1008−1017+1047.
ZHANG Changjian, LÜ Yanping, ZHANG Zhenzhe. Features of Middle-Lower Ordovician paleo-karst caves in western slope area, Tahe Oil Field, Tarim Basin[J]. Petroleum Geology & Experiment,2022,44(06):1008−1017+1047.
[28] 朱筱敏, 王贵文, 谢庆宾. 塔里木盆地志留系沉积体系及分布特征[J]. 石油大学学报(自然科学版), 2002, 26（3）: 5−11+9.
ZHU Xiaomin, WANG Guiwen, XIE Qingbin. Characteristics and distribution of depositional systems of silurian in tarim basin[J]. Journal of the University of Petroleum, China ( Edition of Natural Science),2002,26(3):5−11+9.
[29] 邹豹君. 小地貌学原理[M]. 北京: 商务印书馆, 1985.
ZOU Baojun. Principles of small geomorphology [M]. Beijing: Commercial Press, 1985.
-
