Development Scale and Reservoir Characteristics of Sand Bodies in the Qian 5 Member of the Shiqianfeng Formation of the Shenmu Gas Field in the Ordos Basin
-
摘要:
石千峰组作为鄂尔多斯盆地二叠系区域顶部天然气储集层，具有砂岩厚度大、分布广的特点。在露头、钻测井资料与岩心沉积相分析基础上，利用露头测量法、经验公式法以及密井网解剖法，对千5段开展砂体发育规模评价研究，结合显微薄片、扫描电镜、压汞、核磁等分析手段进行千5段储层特征研究及分类评价，为后续高精度开发提供线索。研究认为，神木地区千5段为辫状河三角洲平原沉积，以辫状分流河道与洪泛平原亚相为主，局部发育洪泛越岸砂沉积；沉积期辫状河道平均水深为5～6 m，千5上亚段聚合河道宽度为800～
1200 m，千5下亚段聚合河道宽度主体为1200 ～1600 m。形成厚层岩屑砂岩、长石岩屑砂岩和岩屑长石砂岩储层，具有高岩屑含量、高原生粒间孔含量的特点，表现为4类砂岩储层：Ⅰ类微米级裂缝孔隙型；Ⅱ类微米-纳米级联通孔隙型；Ⅲ类纳米–微米级连通–孤立孔隙型；Ⅳ类纳米级孤立孔隙型。千5段砂岩浊沸石胶结作用局部富集，对寻找高孔隙度、高渗透率储层创造了潜在的物质条件。Abstract:The Shiqianfeng Formation, as the top natural gas reservoir in the Permian of the Ordos Basin, has the characteristics of large sandstone thickness and wide distribution. Based on the analysis of outcrop, drilling and logging data, and core sedimentary facies, the outcrop measurement method, empirical formula method, and dense well network dissection method were used to evaluate the development scale of sand bodies in the Qian5 member. Combining microscopic thin sections, scanning electron microscopy, mercury intrusion, nuclear magnetic resonance, and other analytical methods, the study and classification evaluation of reservoir characteristics in the Qian5 member are conducted, providing clues for subsequent high-precision development. Research suggests that the Qian5 section of the Shenmu area is a braided river delta plain deposit, mainly composed of braided distributary channels and flood plain subfacies, with locally developed flood crossing sand deposits. During the sedimentation period, the average depth of braided river channels is 5-6 m, with a width of 800-
1200 m in the upper section of Qian5 and a width of1200 -1600 m in the lower section of Qian5. Thick layers of lithic sandstone, feldspathic lithic sandstone, and lithic feldspathic sandstone reservoirs were formed, characterized by high rock debris content and high intergranular pore content. It is manifested as four types of sandstone reservoirs: type I, micron level fracture pore type; Class II micron-nano interconnected pore type; Class III nano-micron level connected to isolated pore type; Class IV nanoscale isolated pore type. The local enrichment of laumontite in the sandstone of Qian5 member has created potential material conditions for searching for reservoirs with high porosity and permeability.-
Key words:
- Ordos basin /
- Shiqianfeng Formation /
- sedimentary facies /
- researvoir /
- Shenmu oilfield
-
-
表 1 砂体宽度与聚合河道带计算数据表
Table 1. Calculation data for the width of single sand body and aggregate channel sand body
单砂体厚度（m） 单砂体宽度（m） 聚合河道带宽度（m） 厚度频率（次） 0～2 0～100 0～240 1 969 2～4 100～350 240～700 2900 4～6 350～750 700～ 1300 1776 6～8 750～ 1250 1300 ～2 0001037 8～10 1250 ～1 9002 000～ 2800 525 ＞10 ＞1 900 ＞ 2800 277
下载: 导出CSV
-
[1] 兰朝利, 张永忠, 张君峰, 等. 神木气田太原组储层特征及其控制因素[J]. 西安石油大学学报(自然科学版), 2010, 25（1）: 7−11.
LAN Chaoli, ZHANG Yongzhong, ZHANG Junfeng, et al. Reservoir characteristics of Upper Carboniferous Taiyuan Formation in Shenmu Gas field and their controlling factors[J]. Journal of Xi’an Shiyou University (Natural Science Edition),2010,25(1):7−11.
[2] 李振华, 邱隆伟, 师政, 等. 准噶尔盆地中拐地区佳二段沸石类矿物成岩作用及其对油气成藏的意义[J]. 中国石油大学学报: 自然科学版, 2014, 38（1）: 1−7.
LI Zhenhua, QIU Longwei, SHI Zheng, et al. Diagenesis of zeolite minerals and its significance for hydrocarbon accumulation in the second member of Jiamuhe formation of Zhongguai area, Junggar Basin[J]. Journal of China University of Petroleum,2014,38(1):1−7.
[3] 李君文, 陈洪德, 田景春. 鄂尔多斯盆地石千峰组高分辨率层序地层学特征[J]. 大庆石油地质与开发, 2007, 26（1）: 45−49+91. doi: 10.3969/j.issn.1000-3754.2007.01.011
LI Junwen, CHEN Hongde, TIAN Jingcun. High resolution sequence stratigraphy characteristics of Shiqianfeng Formation in Ordos Basin[J]. Petroleum Geology & Oilfield Development in Daqin,2007,26(1):45−49+91. doi: 10.3969/j.issn.1000-3754.2007.01.011
[4] 李振宏, 王欣. 鄂尔多斯盆地东部石千峰组天然气成藏机理初探[J]. 天然气地球科学, 2005, 16（3）: 314−318.
LI Zhenhong, WANG Xin. The elementary analysis of reservoir mechanism in the Shiqianfeng Formation of the eastern Ordos Basin[J]. Natural Gas Geoscience,2005,16(3):314−318.
[5] 牛艳伟, 吴鹏. 神木地区解家堡区块山西组储层“四性”关系及有效储层下限[J]. 成都理工大学学报(自然科学版), 2023, 50（5）: 513−524+550.
NIU Yanwei, WU Peng. Four property relation and lower limit of effective reservoir of Shanxi Formation in Jiejiapu Block, Shenmu area, OrdosBasin[J]. Journal of Chengdu University of Technology (Science & Technology Edition),2023,50(5):513−524+550.
[6] 欧阳明华, 史建南, 赵地, 等. 鄂尔多斯盆地苏里格气田苏5区块盒8段-山1段波形约束建模反演及模拟[J]. 成都理工大学学报(自然科学版), 2023, 50（5）: 560−568+587.
OUYANG Minghua, SHI Jiannan, ZHAO Di, et al. Waveform constrained modeling inversion and simulation of He-8 and Shan-1 Members in Su-5 Block, Sulige Gas Field, Ordos Basin, China[J]. Journal of Chengdu University of Technology (Science & Technology Edition),2023,50(5):560−568+587.
[7] 唐玮玮, 吴晓明, 王为林, 等. 鄂尔多斯盆地环县北地区延长组长72亚段重力流特征及油气地质意义[J]. 成都理工大学学报(自然科学版), 2022, 49（5）: 561−569+585.
TANG, Weiwei, WU Xiaoming, WANG Weilin, et al. Gravity flow characteristics and geological significance of oil and gas of the Chang 72 sub-member of the Yanchang Formation in the northern Huanxian area, Ordos Basin, China[J]. Journal of Chengdu University of Technology (Science & Technology Edition),2022,49(5):561−569+585.
[8] 王震亮, 张立宽, 孙明亮, 等. 鄂尔多斯盆地神木—榆林地区上石盒子组石千峰组天然气成藏机理[J]. 石油学报, 2004, 25（3）: 37−43. doi: 10.3321/j.issn:0253-2697.2004.03.007
WANG Zhenliang, ZHANG Likuan, SUN Mingliang, et al. Natural gas accumulation mechanism in Upper Shihezi and Shiqianfeng Formations of Shenmu-Yulin district in northeastern Ordos Basin[J]. Acta Petrolei Sinica,2004,25(3):37−43. doi: 10.3321/j.issn:0253-2697.2004.03.007
[9] 吴和源, 唐勇, 常秋生. 准噶尔盆地中拐凸起佳木河组沸石类胶结砂砾岩储集层成因机理[J]. 新疆石油地质, 2017, 38（3）: 281−288.
WU Heyuan, TANG Yong, CHANG Qiusheng. Genesis of Sandy Conglomerate Reservoirs Cemented by Zeolites in Jiamuhe Formation of Zhongguai Swell, Junggar Basin[J]. Xinjiang Petroleum Geology,2017,38(3):281−288.
[10] 吴和源, 唐勇, 孙玮, 等. 准噶尔盆地中拐凸起二叠系佳木河组砂砾岩沸石胶结特征及其成岩机制分析[J]. 岩石矿物学杂志, 2018, 37（1）: 75−86. doi: 10.3969/j.issn.1000-6524.2018.01.007
WU Heyuan, TANG Yong, SUN Wei, et al. An analysis of the zeolite cement in sand-conglomerate and the diagenetic mechanism of Jiamuhe Formation, Zhongguai area, Junggar Basin[J]. Acta Petrologica Et Mineralogica,2018,37(1):75−86. doi: 10.3969/j.issn.1000-6524.2018.01.007
[11] 吴颖, 孙磊, 冯敏, 等. 天环坳陷南北部盒8段地层水地化特征差异性分析[J]. 西北地质, 2024, 57（2）: 244−253.
WU Ying,SUN Lei,FENG Min,et al. Analysis on Geochemical Characteristics and Difference of Formation Water in He 8th Member in Northern and Southern Tianhuan Depression[J]. Northwestern Geology,2024,57(2):244−253.
[12] 肖玲, 胡榕, 韩永林, 等. 鄂尔多斯盆地新安边地区长7页岩油储层孔隙结构特征[J]. 成都理工大学学报(自然科学版), 2022, 49（3）: 284−293.
XIAO Lin, HU Rong, HANG Yonglin, et al. Characteristics of pore throat structure of Chang 7 shale oil sandstone reservoir in the western Xin'anbian area, Ordos Basin, China[J]. Journal of Chengdu University of Technology (Science & Technology Edition),2022,49(3):284−293.
[13] 闫小雄, 胡喜峰, 黄建松, 等. 鄂尔多斯盆地东部石千峰组浅层气藏成藏机理探讨[J]. 天然气地球科学, 2005, 16（6）: 736−740.
YAN Xiaoxiong, HU Xifeng, HANG Jiansong, et al. Discussion on forming mechanism of the Shiqianfeng Formation flower gas pool in eastern Ordos Basin[J]. Natural Gas Geoscience,2005,16(6):736−740.
[14] 杨华, 姬红, 李振宏, 等. 鄂尔多斯盆地东部上古生界石千峰组低压气藏特征[J]. 地球科学(中国地质大学学报), 2004, 29（4）: 413−419.
YANG Hua, JI Hong, LI Zhenhong, et al. Characteristics of Underpressured Gas Pool in Upper Paleozoic Shiqianfeng Formation of Eastern Ordos Basin[J]. Earth Science-Journal of China University of Geosciences,2004,29(4):413−419.
[15] 杨华, 刘新社, 闫小雄, 等. 鄂尔多斯盆地神木气田的发现与天然气成藏地质特征[J]. 天然气工业, 2015, 35（6）: 1−13.
YANG Hua, LIU Xinshe, YAN Xiaoxiong, et al. The Shenmu Gas Field in the Ordos Basin: Its discovery and reservoir- forming geological characteristics[J]. Natural Gas Industry,2015,35(6):1−13.
[16] 杨华, 刘新社, 黄道军, 等. 长庆油田天然气勘探开发进展与“十三五”发展方向[J]. 天然气工业, 2016, 36（5）: 1−14. doi: 10.3787/j.issn.1000-0976.2016.05.001
YANG Hua, LIU Xinshe, HUANG Daojun, et al. Natural gas exploration and development in the PetroChina Changqing and its prospect in the 13th Five-Year Plan[J]. Natural Gas Industry,2016,36(5):1−14. doi: 10.3787/j.issn.1000-0976.2016.05.001
[17] 张清, 孙六一, 黄道军, 等. 鄂尔多斯盆地东部石千峰组浅层气成藏机制[J]. 天然气工业, 2005, 25（4）: 12−13. doi: 10.3321/j.issn:1000-0976.2005.04.004
ZHANG Qing, SUN Liuyi, HUANG Daojun, et al. Reservoir origin mechanism of Shiqianfeng Formation on shallow gas in east Ordos Basin[J]. Natural Gas Industry,2005,25(4):12−13. doi: 10.3321/j.issn:1000-0976.2005.04.004
[18] 张翔, 田景春, 陈洪德, 等. 鄂尔多斯盆地上二叠统石千峰组岩相古地理及时空演化[J]. 成都理工大学学报(自然科学版), 2009, 36（2）: 165−171.
ZHANG Xiang, TIAN Jingchun, CHEN Hongde, et al. The lithofacies-paleogeographic and spatiotemporal evolution of Upper Permian Shiqianfeng Formation in Ordos Basin‚China[J]. Journal of Chendu University of Technology (Science& Technology Edition),2009,36(2):165−171.
[19] 张翔, 田景春, 陈洪德, 等. 鄂尔多斯盆地西部上二叠统石千峰组沉积环境地球化学表征[J]. 地球科学与环境学报, 2008, 32（4）: 418−425.
ZHANG Xiang,TIAN Jingcun,CHEN Hongde,et al. The sedimentary character and sedimentation-sequence model of the Shiqianfeng Formation in Northwestern Ordos Basin[J]. Journal of Stratigraphy,2008,32(4):418−425.
[20] 张兴良, 田景春, 王峰, 等. 致密砂岩储层成岩作用特征与孔隙演化定量评价——以鄂尔多斯盆地高桥地区二叠系下石盒子组盒8段为例[J]. 石油与天然气地质, 2014, 35（2）: 212−217.
ZHANG Xinliang, TIAN Jingchun, WANG Feng, et al. Diagenetic characteristics and quantitative porosity estimation of tight sandstone reservoirs: a case from the 8th Member of Permian Xiashihezi Formation in the Gaoqiao region, Ordos Basin[J]. Oil & Gas Geology,2014,35(2):212−217.
[21] 张瑶瑶, 杨水胜, 刘宇琪, 等. 鄂尔多斯盆地靖边油田沙洼沟地区延安组延9油藏富集规律[J]. 西北地质, 2023, 56（2）: 213−224.
ZHANG Yaoyao, YANG Shuisheng, LIU Yuqi, et al. Enrichment Enrichment Regularity of Y–9 Reservoir of Yan’an Formation in Shawagou Area of Jingbian Oilfield, Ordos Basin[J]. Northwestern Geology,2023,56(2):213−224.
[22] 朱世发, 朱筱敏, 王绪龙, 等. 准噶尔盆地西北缘二叠系沸石矿物成岩作用及对油气的意义[J]. 中国科学: 地球科学, 2011, 41（11）: 1602−1612.
ZHU Shifa, ZHU Xiaomin, WANG Xulong, et al. Zeolite diagenesis and its control on petroleum reservoir quality of Permian in northwestern margin of Junggar Basin, China[J]. Science China: Earth Sciences ,2011,41(11):1602−1612.
[23] 赵龙梅, 吴和源, 黄力, 等. 鄂尔多斯盆地东缘大宁–吉县区块及邻区山西组山2段物源分析[J]. 西北地质, 2023, 56（5）: 322−331.
ZHAO Longmei, WU Heyuan, HUANG Li, et al. Material Source Analysis of Daning−Jixian Exploration Area and Its Adjacent Shan–2 Member in the Eastern Margin of Ordos Basin[J]. Northwestern Geology,2023,56(5):322−331.
[24] 郑萌, 梁积伟, 冯振伟, 等. 鄂尔多斯盆地中部寒武纪岩相古地理研究[J]. 西北地质, 2023, 56（6）: 352−368.
ZHENG Meng, LIANG Jiwei, FENG Zhenwei, et al. Lithofacies Paleogeography of the Cambrian in the Central Ordos Basin[J]. Northwestern Geology,2023,56(6):352−368.
[25] Beard D C, Weyl P K. Influence of Texture on Porosity and Permeability of Unconsolidated Sand[J]. AAPG Bulletin,1973,57(2):349−369.
[26] Bridge J S, Mackey S D. A revised alluvial stratigraphy model[J]. Alluvial Sedimentation, 1993: 317−336.
[27] Chipera S J, Goff F, Goff C J, et al. Zeolitization of intracaldera sediments and rhyolitic rocks in the 1.25 Ma lake of Valles caldera, New Mexico, USA[J]. Journal of Volcanology & Geothermal Research,2008,178(2):317−330.
[28] Collinson J D. Vertical sequence and sand body shape in alluvial sequences[J]. AAPG, 1977: 577−586.
[29] Levy S S. Petrology of samples from drill holes USW H-3, H-4, and H-5, Yucca Mountain[J]. Nevada, 1984.
[30] Robinson J W, Mccabe P J. Sandstone-body and shale-body dimensions in a braided fluvial system; Salt Wash Sandstone Member (Morrison Formation), Garfield County, Utah[J]. AAPG Bulletin, 1997.
[31] Scherer M. Parameters Influencing Porosity in Sandstones: A Model for Sandstone Porosity Prediction: ERRATUM[J]. AAPG Bulletin,1987,71(5):485−491.
[32] Schumm S A. The effect of sediment type on the shape and stratification of some modern fluvial deposits[J]. American Journal of Science,1960,3(258):177−184.
[33] Shanley K W. Fluvial reservoir description for a giant, low-permeability gas field: Jonah field, Green River Basin[J]. Wyoming, U. S. A. 2004.
[34] Wu H, Guo M, Zhao J, et al. Densification mechanisms of tight sandstones in closed to semi-closed systems: typical example from the Upper Paleozoic in the Linxing area, Ordos Basin[J]. Arabian Journal of Geosciences,2021,14(12):1−18.
-
