ZONING EVALUATION OF MINE GEOLOGICAL ENVIRONMENT IN XUCHANG CITY, HENAN PROVINCE
-
摘要:
以斜坡单元作为评价单元, 通过建立区域地质环境背景、资源损毁和地质灾害3要素评价指标体系, 对各评价指标进行量化, 赋予权重, 利用GIS图层叠加分析, 对许昌市矿山地质环境进行分区评价. 分区结果与现状调查结果较为一致, 验证了此方法的实用性, 为规划与治理该地区矿山环境地质问题提供参考依据.
Abstract:Taking slope unit as evaluation unit, through establishing the evaluation index system of three factors including regional geological environment background, resource damage and geological hazard, the evaluation indexes are quantified and weighted to make the zoning evaluation of mine geological environment in Xuchang City by layer overlapping analysis of GIS technology. The zoning results are consistent with the current survey, which verifies the practicability of the method and provides reference for planning and treatment of mine geological environment in the area.
-
Key words:
- GIS /
- slope unit /
- mine geological environment /
- zoning evaluation /
- geological hazard /
- Henan Province
-
-
表 1 矿山地质环境评价指标体系
Table 1. Evaluation index system of mine geological environment
要素层 指标层 组成要素 区域地质
环境背景地形地貌 地形坡度 植被覆盖 植被覆盖程度 多年平均降水 年降水量强度 资源损毁 土地压占与破坏 采矿场+废石堆+煤矸石占压土地等 地形地貌景观破坏 破坏面积及强度 水资源破坏 破坏强度 地质灾害 地面塌陷 影响范围 地裂缝 破坏程度 崩塌及隐患 可能造成的影响与危害
下载: 导出CSV
表 2 各指标因子等级及其赋值标准和加权评定分值
Table 2. Grading of each index factors with assignment standard and weighted evaluation score
分级 Ⅰ级 Ⅱ级 Ⅲ级 Ⅳ级 因子评定分值 0.3 0.5 0.7 0.9 加权评定分值 < 0.4 0.4~0.6 0.6~0.8 >0.8
下载: 导出CSV
表 3 各评价指标等级分级
Table 3. Grading of each evaluation index
要素层 指标层 影响程度分级及量值 好（0.3） 较好（0.5） 较差（0.7） 区域地质
环境背景地形地貌坡度/（°） < 10 10~30 >30 植被覆盖/% >40 20~40 < 20 多年平均降水/mm < 400 400~600 >600 资源损毁 土地压占与破坏 较轻 较严重 严重 地形地貌破坏 较轻 较严重 严重 含水层破坏/（m3/d） 3000 300~10000 ＞10000 地质灾害 地面塌陷/km2 < 0.1 0.1~1 >1 地裂缝/m < 100 100~500 >500 崩塌及隐患/104 m3 < 1 1~10 >10
下载: 导出CSV
表 4 许昌地区矿山地质环境评价指标权重
Table 4. Weights of mine geological environment evaluation index in Xuchang area
要素层 权重 指标层 权重 地质环境条件 0.105 地形地貌 0.163 植被覆盖 0.540 多年平均降水 0.297 资源损毁 0.258 土地压占与破坏 0.412 地形地貌破坏 0.421 水资源破坏 0.167 地质灾害 0.637 地面塌陷 0.446 地裂缝 0.243 崩塌及隐患 0.088 采空区 0.223
下载: 导出CSV
-
[1] 温守钦, 李仁锋, 任群智, 等. GIS技术在地质灾害区划中的应用[J]. 中国地质, 2005, 32(3): 512-517. doi: 10.3969/j.issn.1000-3657.2005.03.023
Wen S Q, Li R F, Ren Q Z, et al. Application of GIS technology in the regionalization of geological hazards[J]. Geology in China, 2005, 32(3): 512-517. doi: 10.3969/j.issn.1000-3657.2005.03.023
[2] 吴柏清, 何政伟. GIS技术在四川省九龙县地质灾害危险性评价中的应用[J]. 中国地质灾害与防治学报, 2008, 19(2): 114-117, 123. doi: 10.3969/j.issn.1003-8035.2008.02.024
Wu B Q, He Z W. Application of GIS technology in the risk assessment of geological hazards in Jiulong County[J]. The Chinese Journal of Geological Hazard and Control, 2008, 19(2): 114-117, 123. doi: 10.3969/j.issn.1003-8035.2008.02.024
[3] 尚慧, 倪万魁, 程花. 斜坡单元划分在彭阳县地质灾害危险性区划中的应用[J]. 中国水土保持, 2011(3): 48-50. doi: 10.3969/j.issn.1000-0941.2011.03.019
Shang H, Ni W K, Cheng H. Application of slope unit division to risk zoning of geological hazards of Pengyang County[J]. Soil and Water Conservation in China, 2011(3): 48-50. doi: 10.3969/j.issn.1000-0941.2011.03.019
[4] 周启鸣, 刘学军. 数字地形分析[M]. 北京: 科学出版社, 2006: 52-70.
Zhou Q M, Liu X J. Digital terrain analysis[M]. Beijing: Science Press, 2006: 52-70. (in Chinese)
[5] 汤国安, 杨昕. ArcGIS地理信息系统空间分析实验教程[M]. 北京: 科学出版社, 2006: 429-445.
Tang G A, Yang X. ArcGIS spatial analysis experiment course[M]. Beijing: Science Press, 2006: 429-445. (in Chinese)
[6] 何芳, 徐友宁, 袁汉春. 矿山环境地质问题综合评价客观权值确定方法探讨[J]. 中国地质, 2008, 35(2): 337-343. doi: 10.3969/j.issn.1000-3657.2008.02.019
He F, Xu Y N, Yuan H C. Method for the determination of objective weight-values in the comprehensive evaluation of mine environmental geological problems[J]. Geology in China, 2008, 35(2): 337-343. doi: 10.3969/j.issn.1000-3657.2008.02.019
[7] 黄栋良, 万益宏. 湖南常德市矿山地质环境综合评价分区研究[J]. 地质学刊, 2010, 34(1): 104-109. doi: 10.3969/j.issn.1674-3636.2010.01.104
Huang D L, Wan Y H. Study on evaluation partition of mine geological environment in Changde of Hunan[J]. Journal of Geology, 2010, 34 (1): 104-109. doi: 10.3969/j.issn.1674-3636.2010.01.104
[8] 高永志, 郑卫政, 初禹. 基于RS与GIS的黑龙江省矿山地质环境评价研究[J]. 地质与资源, 2016, 25(2): 171-175. doi: 10.3969/j.issn.1671-1947.2016.02.014 http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract8624.shtml
GAO Y Z, Zheng W Z, Chu Y. Assessment of geological environment of mines in Heilongjiang province based on RS and GIS[J]. Geology and Resources, 2016, 25(2): 171-175. doi: 10.3969/j.issn.1671-1947.2016.02.014 http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract8624.shtml
[9] 廖振威, 王志星, 黄诚, 等. 基于RS和GIS的广西矿山地质环境综合评价[J]. 中国地质调查, 2016, 3(4): 43-48. https://www.cnki.com.cn/Article/CJFDTOTAL-DZDC201604007.htm
Liao Z Wei, Wang Z X, Huang C, et al. Comprehensive evaluation of mine geological environment in Guangxi based on RS and GIS[J]. Geological Survey of China, 2016, 3(4): 43-48. https://www.cnki.com.cn/Article/CJFDTOTAL-DZDC201604007.htm
[10] 孙厚云, 金兴, 王晨昇, 等. 基于RS、GIS与AHP的巴音高勒小流域矿集区地质环境综合评价[J]. 矿产勘查, 2019, 10(8): 2093-2103. doi: 10.3969/j.issn.1674-7801.2019.08.046
Sun H Y, Jin X, Wang C S, et al. Comprehensive evaluation of geological environment in mineral concentrated areas of Bayingaole watershed based on AHP, RS and GIS[J]. Mineral Exploration, 2019, 10(8): 2093-2103. doi: 10.3969/j.issn.1674-7801.2019.08.046
[11] 东启亮, 张路飞, 张志科, 等. 基于AHP的大尺度空间域矿山地质环境评价研究[J]. 矿产勘查, 2020, 11(8): 1780-1787. doi: 10.3969/j.issn.1674-7801.2020.08.031
Dong Q L, Zhang L F, Zhang Z K, et al. Research on mine geological environment evaluation based on AHP in large scale spatial region[J]. Mineral Exploration, 2020, 11(8): 1780-1787. doi: 10.3969/j.issn.1674-7801.2020.08.031
[12] 郭峰, 聂邦亮, 石长柏, 等. 宜昌市夷陵区磷矿矿山地质环境综合评估分区评价[J]. 资源环境与工程, 2012, 26(3): 240-244. doi: 10.3969/j.issn.1671-1211.2012.03.009
Guo F, Nie B L, Shi C B, et al. Zoning evaluation of comprehensive evaluation of phosphate mine geological environment in Yiling District, Yichang city[J]. Resources Environment & Engineering, 2012, 26 (3): 240-244. doi: 10.3969/j.issn.1671-1211.2012.03.009
[13] 殷坤龙, 朱良峰. 滑坡灾害空间区划及GIS应用研究[J]. 地学前缘, 2001, 8(2): 279-284. doi: 10.3321/j.issn:1005-2321.2001.02.010
Yin K L, Zhu L F. Landslide hazard zonation and application of GIS [J]. Earth Science Frontiers, 2001, 8(2): 279-284. doi: 10.3321/j.issn:1005-2321.2001.02.010
[14] 崔剑, 白朝军, 宋轩. 基于层次分析法的河南省矿山环境评价[J]. 河南科技, 2019(5): 149-153. doi: 10.3969/j.issn.1003-5168.2019.05.056
Cui J, Bai C J, Song X. Mine environment evaluation in Henan Province by analytic hierarchy process[J]. Henan Science and Technology, 2019(5): 149-153. doi: 10.3969/j.issn.1003-5168.2019.05.056
[15] 罗清威, 冯有利. 基于层次分析法的矿山地质环境问题危害程度综合评价[J]. 地质灾害与环境保护, 2015, 26(3): 85-88. doi: 10.3969/j.issn.1006-4362.2015.03.018
Luo Q W, Feng Y L. Comprehensive assessment for damage degree of geo-environmental problems at mines, based on the analytic hierarchy process[J]. Journal of Geological Hazards and Environment Preservation, 2015, 26(3): 85-88. doi: 10.3969/j.issn.1006-4362.2015.03.018
[16] 李雪宇, 文武飞. 基于层次分析法和GIS的矿山地质环境综合评价——以湘潭市雨湖、岳塘区为例[J]. 国土资源导刊, 2020, 17 (2): 49-54. doi: 10.3969/j.issn.1672-5603.2020.02.012
Li X Y, Wen W F. Comprehensive impact assessment of mine geological environment based on AHP and GIS: A case study of Yuhu and Yuetang Districts in Xiangtan[J]. Land & Resources Herald, 2020, 17(2): 49-54. doi: 10.3969/j.issn.1672-5603.2020.02.012
[17] 朱双燕, 范旭光, 王莹. 基于综合判断法的矿山地质环境分区评价[J]. 能源与环保, 2019, 41(5): 62-65. https://www.cnki.com.cn/Article/CJFDTOTAL-ZZMT201905015.htm
Zhu S Y, Fan X G, Wang Y, et al. Partition evaluation of mine geological environment based on comprehensive judgment method[J]. China Energy and Environmental Protection, 2019, 41(5): 62-65. https://www.cnki.com.cn/Article/CJFDTOTAL-ZZMT201905015.htm
[18] 宋高举, 黄继超, 吴东民. 基于斜坡单元划分法的汝阳县地质灾害易发性区划[J]. 地质灾害与环境保护, 2015, 26(1): 103-107. doi: 10.3969/j.issn.1006-4362.2015.01.020
Song G J, Huang J C, Wu D M, et al. Applying slope unit division method in Zoning Ruyang County in terms of geo-hazard proneness [J]. Journal of Geological Hazards and Environment Preservation, 2015, 26(1): 103-107. doi: 10.3969/j.issn.1006-4362.2015.01.020
[19] 张公, 刘承勇, 黄继超, 等. 基于GIS技术的修武县地质灾害易发性分析[J]. 地下水, 2018, 40(1): 124-125, 176. https://www.cnki.com.cn/Article/CJFDTOTAL-DXSU201801048.htm
Zhang G, Liu C Y, Huang J C, et al. Analysis of geological hazard susceptibility in Xiuwu County based on GIS technology[J]. Ground Water, 2018, 40(1): 124-125, 176. (in Chinese) https://www.cnki.com.cn/Article/CJFDTOTAL-DXSU201801048.htm
[20] 宋高举, 郑栋材, 黄继超, 等. 许昌市矿山地质环境问题浅析[J]. 地质灾害与环境保护, 2020, 31(2): 57-61. https://www.cnki.com.cn/Article/CJFDTOTAL-DZHB202002011.htm
Song G J, Zheng D C, Huang J C, et al. Brief analysis of mine geological environment problems in Xuchang City[J]. Journal of Geological Hazards and Environment Preservation, 2020, 31(2): 57-61. https://www.cnki.com.cn/Article/CJFDTOTAL-DZHB202002011.htm
[21] 邬光海, 王晨昇, 陈鸿汉. 内蒙古废弃钨钼矿区周围土壤重金属污染生态环境评价及成因分析[J]. 中国地质, 2020, 47(6): 1838-1852. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI202006020.htm
Wu G H, Wang C S, Chen H H. Eco-environmental assessment and genetic analysis of heavy metal pollution in the soil around the abandoned tungsten-molybdenum mine area in Inner Mongolia[J]. Geology in China, 2020, 47(6): 1838-1852. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI202006020.htm
-
