FAVORABLE LITHOFACIES AND SWEET SPOT OPTIMIZATION OF THE Ek21 SHALE OIL IN CANGDONG SAG, BOHAI BAY BASIN
-
摘要:
为了优选出目标层位页岩有利岩相与预测页岩油分布甜点区, 采用主成分分析法(PCA), 对页岩油资源量(滞留烃)、物性(孔隙度、渗透率)、工程性质(脆性指数、岩石力学参数)3个主地质成分进行分析. 结果表明, 纹层状长英质页岩相与纹层状混合质页岩相滞留烃含量高、孔渗性好且脆性指数偏大; 王官屯、七里店以南、沈家铺东南地区为页岩油分布甜点区, 具有较好油气显示.
Abstract:To optimize the favorable lithofacies of shale and predict the sweet spots of shale oil distribution in the first sub-member of the second member of Kongdian Formation (Ek21), the principal component analysis (PCA) is used to analyze three main geological components of shale oil, including resources (retained hydrocarbon), physical properties (porosity and permeability) and engineering properties (brittleness index and rock mechanics parameter). The results show that the lamellar felsic shale facies and lamellar mixed shale facies have high retained hydrocarbon content, with good porosity and permeability, and high brittleness index. Areas such as Wangguantun, south of Qilidian and southeast of Shenjiapu are all sweet spots of shale oil distribution with good oil-gas show.
-
Key words:
- principal component analysis /
- retained hydrocarbon /
- porosity /
- permeability /
- shale oil sweet spot /
- Bohai Bay Basin
-
-
表 1 页岩样品三轴力学实验结果
Table 1. Triaxial mechanical test results of shale samples
样品编号 密度/（g/cm3） 围压/MPa 抗压强/MPa 泊松比 杨氏模量/GPa 工1-1 2.53 5 — — — 工1-2 2.54 15 92.49 0.252 19.53 工1-3 2.54 25 180.52 0.268 31.55 工1-4 2.53 35 220.05 0.222 30.07 工2-1 2.37 5 132.75 0.2 23.98 工2-2 2.39 15 230.11 0.24 22.48 工2-3 2.44 25 262.21 0.214 27.42 工2-4 2.47 35 288.63 0.218 29.21
下载: 导出CSV
-
[1] 王成善. 《松辽盆地及外围油气资源地质调查专辑》序[J]. 地质与资源, 2021, 30(3): 219. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract10288.shtml
Wang C S. Special issue on geological survey for oil and gas resources in Songliao Basin and its periphery areas: Preface[J]. Geology and Resources, 2021, 30(3): 219-219. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract10288.shtml
[2] 陈树旺, 许光, 杨建国, 等. 松辽盆地及外围油气资源基础地质调查——"十三五"阶段进展与未来工作展望[J]. 地质与资源, 2021, 30(3): 221-231, 248. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract10290.shtml
Chen S W, Xu G, Yang J G, et al. Foundational geological survey for oil and gas resources in Songliao Basin and its periphery areas: Progress and prospect[J]. Geology and Resources, 2021, 30(3): 221-231, 248. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract10290.shtml
[3] 柳波, 刘俊杰, 付晓飞, 等. 松辽盆地陆相页岩油地质研究方法与勘探评价进展[J]. 地质与资源, 2021, 30(3): 239-248. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract10292.shtml
Liu B, Liu J J, Fu X F, et al. Progress in geological research methods and exploration evaluation of continental shale oil in Songliao Basin[J]. Geology and Resources, 2021, 30(3): 239-248. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract10292.shtml
[4] 杨建国, 李士超, 姚玉来, 等. 松辽盆地北部陆相页岩油调查取得重大突破[J]. 地质与资源, 2020, 29(3): 300. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract10208.shtml
Yang J G, Li S C, Yao Y L, et al. Significant breakthrough in the continental shale oil survey in northern Songliao Basin[J]. Geology and Resources, 2020, 29(3): 300. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract10208.shtml
[5] 朱如凯, 邹才能, 吴松涛, 等. 中国陆相致密油形成机理与富集规律[J]. 石油与天然气地质, 2019, 40(6): 1168-1184. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201906002.htm
Zhu R K, Zou C N, Wu S T, et al. Mechanism for generation and accumulation of continental tight oil in China[J]. Oil & Gas Geology, 2019, 40(6): 1168-1184. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201906002.htm
[6] 夏彤彤. 准噶尔盆地中部侏罗系八道湾组储层特征研究[D]. 青岛: 中国石油大学(华东), 2018.
Xia T T. Reservoir characteristics of the Badaowan Formation in central Junggar Basin[D]. Qingdao: China University of Petroleum (East China), 2018.
[7] 董玉菲. 基于组合权重GRA法的村庄生活污水集中处理技术优选研究[D]. 长沙: 湖南大学, 2019.
Dong Y F. Optimization of centralized treatment technology for village domestic sewage based on combined weight GRA method[D]. Changsha: Hunan University, 2019.
[8] 董振国, 陈宏亮, 乔朝泽. 湖南保靖区块龙马溪组页岩气成藏地质因素分析[J]. 录井工程, 2019, 30(4): 131-140. doi: 10.3969/j.issn.1672-9803.2019.04.024
Dong Z G, Chen H L, Qiao C Z. Analysis of geofactor of shale gas accumulation in Longmaxi Formation in Baojing block, Hunan Province[J]. Mud Logging Engineering, 2019, 30(4): 131-140. doi: 10.3969/j.issn.1672-9803.2019.04.024
[9] 雷丹凤, 王莉, 张晓伟, 等. 影响页岩气井产量的关键因素研究[C] //2016年全国天然气学术年会论文集. 银川: 中国石油学会天然气专业委员会, 2016: 1025-1032.
Lei D F, Wang L, Zhang X W, et al. Research on the key factors affecting the production of shale gas wells[C]//Proceedings of the 2016 National Natural Gas Academic Conference. Yinchuan: Institute of Petroleum and Gas Professional Committee of China, 2016: 1025- 1032. (in Chinese)
[10] 姜生玲, 朱亮亮, 洪克岩, 等. 主成分分析法在页岩气有利区优选中的应用[J]. 地质学刊, 2017, 41(2): 251-256. doi: 10.3969/j.issn.1674-3636.2017.02.013
Jiang S L, Zhu L L, Hong K Y, et al. Application of principal component analysis in shale gas favorable areas optimization[J]. Journal of Geology, 2017, 41(2): 251-256. doi: 10.3969/j.issn.1674-3636.2017.02.013
[11] 张鹏飞, 卢双舫, 李俊乾, 等. 湖相页岩油有利甜点区优选方法及应用——以渤海湾盆地东营凹陷沙河街组为例[J]. 石油与天然气地质, 2019, 40(6): 1339-1350. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201906018.htm
Zhang P F, Lu S F, Li J Q, et al. Identification method of sweet spot zone in lacustrine shale oil reservoir and its application: A case study of the Shahejie Formation in Dongying sag, Bohai Bay basin[J]. Oil & Gas Geology, 2019, 40(6): 1339-1350. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201906018.htm
[12] 郑付刚. 主成分回归分析在确定大坝效应量分量中的应用[J]. 水力发电, 2010, 36(12): 84-87.
Zheng F G. Application of principal component regression analysis in determining the component proportion of dam effect variable[J]. Water Power, 2010, 36(12): 84-87.
[13] 夏遵义, 马海洋, 房堃. 渤海湾盆地沾化凹陷陆相页岩储层岩石力学特征及可压裂性研究[J]. 石油实验地质, 2019, 41(1): 134-141.
Xia Z Y, Ma H Y, Fang K. Rock mechanical properties and fracability of continental shale in Zhanhua sag, Bohai Bay basin[J]. Petroleum Geology & Experiment, 2019, 41(1): 134-141.
[14] 师政. 南堡凹陷及周边凸起古岩溶作用特征及发育模式研究[D]. 青岛: 中国石油大学(华东), 2016.
Shi Z. The research on palaeokarst characteristics and development model in Nanpu sag and surrounding uplift[D]. Qingdao: China University of Petroleum (East China), 2016.
[15] 周立宏, 蒲秀刚, 肖敦清, 等. 渤海湾盆地沧东凹陷孔二段页岩油形成条件及富集主控因素[J]. 天然气地球科学, 2018, 29(9): 1323-1332.
Zhou L H, Pu X G, Xiao D Q, et al. Geological conditions for shale oil formation and the main controlling factors for the enrichment of the 2nd member of Kongdian Formation in the Cangdong sag, Bohai Bay basin[J]. Natural Gas Geoscience, 2018, 29(9): 1323-1332.
[16] 李洪香, 马红. 黄骅坳陷云质岩类致密油形成条件与勘探方向[J]. 特种油气藏, 2015, 22(5): 18-22. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ201505003.htm
Li H X, Ma H. Forming conditions and exploration direction of dolomitic tight oil in Huanghua depression[J]. Special Oil & Gas Reservoirs, 2015, 22(5): 18-22. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ201505003.htm
[17] 李凤霞, 高勇, 汪津, 等. 沧东凹陷孔二段常非一体化成藏研究与实践[J]. 录井工程, 2019, 30(2): 95-99, 136-137.
Li F X, Gao Y, Wang J, et al. Research and practice on integrated hydrocarbon accumulation of conventional and unconventional oil and gas reservoirs in Member 2 of Kongdian Formation in Cangdong sag[J]. Mud Logging Engineering, 2019, 30(2): 95-99, 136-137.
[18] 蒲秀刚, 金凤鸣, 韩文中, 等. 陆相页岩油甜点地质特征与勘探关键技术——以沧东凹陷孔店组二段为例[J]. 石油学报, 2019, 40 (8): 997-1012. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201908011.htm
Pu X G, Jin F M, Han W Z, et al. Sweet spots geological characteristics and key exploration technologies of continental shale oil: A case study of Member 2 of Kongdian Formation in Cangdong sag[J]. Acta Petrolei Sinica, 2019, 40(8): 997-1012. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201908011.htm
[19] 韩文中, 赵贤正, 金凤鸣, 等. 渤海湾盆地沧东凹陷孔二段湖相页岩油甜点评价与勘探实践[J]. 石油勘探与开发, 2021, 48(4): 777-786. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK202104012.htm
Han W Z, Zhao X Z, Jin F M, et al. Sweet spots evaluation and exploration of lacustrine shale oil of the second member of Paleogene Kongdian Formation in Cangdong sag, Bohai Bay basin[J]. Petroleum Exploration and Development, 2021, 48(4): 777-786. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK202104012.htm
[20] 赵贤正, 周立宏, 蒲秀刚, 等. 湖相页岩滞留烃形成条件与富集模式——以渤海湾盆地黄骅坳陷古近系为例[J]. 石油勘探与开发, 2020, 47(5): 856-869. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK202005004.htm
Zhao X Z, Zhou L H, Pu X G, et al. Formation conditions and enrichment model of retained petroleum in lacustrine shale: A case study of the Paleogene in Huanghua depression, Bohai Bay basin, China[J]. Petroleum Exploration and Development, 2020, 47(5): 856-869. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK202005004.htm
[21] 朱日房, 张林晔, 李政, 等. 陆相断陷盆地页岩油资源潜力评价——以东营凹陷沙三段下亚段为例[J]. 油气地质与采收率, 2019, 26(1): 129-136. https://www.cnki.com.cn/Article/CJFDTOTAL-YQCS201901014.htm
Zhu R F, Zhang L Y, Li Z, et al. Evaluation of shale oil resource potential in continental rift basin: A case study of Lower Es3 Member in Dongying sag[J]. Petroleum Geology and Recovery Efficiency, 2019, 26(1): 129-136. https://www.cnki.com.cn/Article/CJFDTOTAL-YQCS201901014.htm
[22] Jarvie D M, Jarvie B M, Weldon D, et al. Components and processes impacting production success from unconventional shale resource systems[J/OL]. Search and Discovery Article #40908, 2012.
[23] 姜南. 鄂尔多斯盆地合水地区长7油层组含油富集区优选[D]. 西安: 西北大学, 2017.
Jiang N. Oil enrichment area optimization of Chang 7 reservoir in Heshui area, Ordos basin[D]. Xi'an: Northwest University, 2017.
[24] 郭同翠, 姜明军, 纪迎章, 等. 叠前地质统计学反演在页岩甜点和薄夹层预测中的应用——以西加拿大盆地W区块为例[J]. 石油地球物理勘探, 2020, 55(1): 167-175. https://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ202001020.htm
Guo T C, Jiang M J, Ji Y Z, et al. The application of prestack geostatistical inversion in the prediction of shale sweet spots and thin interbeds: A case study of Block W in Western Canada Basin[J]. Oil Geophysical Prospecting, 2020, 55(1): 167-175. https://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ202001020.htm
[25] 鄢继华, 蒲秀刚, 周立宏, 等. 基于X射线衍射数据的细粒沉积岩岩石定名方法与应用[J]. 中国石油勘探, 2015, 20(1): 48-54.
Yan J H, Pu X G, Zhou L H, et al. Naming method of fine-grained sedimentary rocks on basis of X-ray diffraction data[J]. China Petroleum Exploration, 2015, 20(1): 48-54.
[26] 李珊珊. 辽河油田致密油气勘探现状分析[J]. 内蒙古石油化工, 2015, 41(10): 61-64.
Li S S. Analysis on the current situation of tight oil and gas exploration in Liaohe oilfield[J]. Inner Mongolia Petrochemical Industry, 2015, 41(10): 61-64. (in Chinese)
[27] 张敏. 致密油藏体积压裂水平井缝网设计及效果评价[D]. 青岛: 中国石油大学(华东), 2017.
Zhang M. Design optimization and performance estimation of volume fracturing horizontal well in tight oil reservoir[D]. Qingdao: China University of Petroleum (East China), 2017.
-
