OIL AND GAS EXPLORATION PROSPECT OF HONGMIAOZI FAULT DEPRESSION IN THE SOUTHEASTERN PERIPHERY OF SONGLIAO BASIN: A Case Study of Lower Cretaceous Yingzuilazi Formation in LXD1 well
-
摘要:
红庙子断陷位于桓仁盆地北部, 是一东断西超的箕状断陷, 露头及少量钻探揭示其内发育较好的烃源岩条件. 本研究利用该断陷西部辽新地1井的钻探资料, 详细分析了前人研究薄弱的鹰嘴砬子组油气地质条件与成藏前景. 测试分析表明, 红庙子断陷鹰嘴砬子组油气显示较好, 烃源岩以半湖相灰黑色泥岩为主, 有机质丰度较高, 且有机质主体进入成熟生烃阶段, 属中等-好烃源岩. 储层虽以特低孔、低渗型为主, 但其上覆林子头组和下伏果松组均发育安山质火山岩建造储层, 为油气藏形成提供了多套储集空间. 同时, 电法勘探综合解释剖面显示, 烃源岩发育的鹰嘴砬子组不仅夹持在林子头组和果松组2套火山岩建造储层之间, 并直接与果松组火山建造储层对顶相接, 形成了有利的生储盖组合. 推测红庙子断陷具有较好的油气勘探前景.
Abstract:Hongmiaozi fault depression, located in northern Huanren Basin, is a half-graben depression faulted in the east and overlapped in the west. The outcrops and limited drilling work reveal a favorable condition for the formation of source rocks. Based on the drilling data from LXD1 well in the western fault depression, the study analyzes the oil-gas geological conditions and accumulation prospect of Yingzuilazi Formation. Test analysis shows that there is good oil-gas indication in Yingzuilazi Formation, with the source rocks dominated by semi-lacustrine grayish black mudstone, high abundance of organic matter, and the main body of organic matter in mature hydrocarbon generation stage, belonging to medium-good source rocks. Although the reservoirs are mainly of ultra-low porosity and low permeability type, the andesitic volcanic rock formation reservoirs are developed in both the overlying Linzitou Formation and underlying Guosong Formation, which provide multiple reservoir spaces for the formation of oil-gas reservoirs. Besides, the electrical exploration comprehensive interpretation section shows that the Yingzuilazi Formation with developed source rocks is sandwiched between the two volcanic formation reservoirs of Linzitou Formation and Guosong Formation, and directly contacted with the volcanic reservoir roof of Guosong Formation, forming a favorable source-reservoir-cap combination. It is inferred that Hongmiaozi fault depression has a good prospect of oil and gas exploration.
-
Key words:
- Lower Cretaceous /
- Yingzuilazi Formation /
- source rock /
- oil-gas resources /
- exploration prospect /
- Songliao Basin
-
-
表 1 辽新地1井天然气成分统计及碳同位素
Table 1. Composition of natural gas and carbon isotopes of LXD1 well
样品编号 O2/% N2/% CO2/% CH4/% 碳同位素（13CH4）/‰ 1 0 6.5 0.32 93.18 -59.9 2 10.33 6.79 1.06 81.82 -60.3 3 7.17 9.61 0.79 82.42 -60.6 4 7.6 5.29 0.3 86.81 -60.4 5 10.27 5.07 0.37 84.3 -60.5 6 8.07 4.38 0.29 87.26 -60.5
下载: 导出CSV
表 2 辽新地1井鹰嘴砬子组暗色泥岩有机质丰度与峰温参数热解分析结果
Table 2. Organic matter abundance and peak temperature parameter pyrolysis analysis results of dark mudstone in Yingzuilazi Formation of LXD1 well
深度/m 可溶烃（S1）/10-3 热解烃（S2）/10-3 生烃潜量（S1+S2）/10-3 热解峰温（Tmax）/℃ 162.9 0.51 1.42 1.93 454 163.7 0.36 0.59 0.95 453 165.5 0.40 2.12 2.52 461 168.1 0.03 3.27 3.30 459 169.2 0.28 3.44 3.72 458 169.8 0.19 1.58 1.77 460 171.4 0.47 4.56 5.03 463 173.6 0.32 3.43 3.75 465 174.8 0.21 2.75 2.93 461 175.4 0.07 0.55 0.62 461 213.6 0.85 2.44 3.29 455 252.0 0.81 3.39 4.20 461 252.6 0.63 2.72 3.35 455 253.4 0.71 1.76 2.47 462 256.2 0.60 2.24 2.84 466 257.2 0.42 1.11 1.53 463 260.3 0.27 0.49 0.76 460 261.2 0.23 0.66 0.89 459 262.2 0.14 0.25 0.39 458 263.2 0.21 0.78 0.99 457 264.6 0.92 2.32 3.24 461 265.6 0.14 0.44 0.58 464 266.5 1.06 1.89 2.95 464 267.5 1.06 1.40 2.46 466 341.4 0.01 0.20 0.21 467 342.7 0.14 0.52 0.66 468 343.6 0.04 0.42 0.46 464 345.6 0.12 0.87 0.99 466 346.8 0.19 0.71 0.90 463 348.0 0.06 0.31 0.37 464 355.6 0.30 0.74 1.04 470 458.3 0.25 0.65 0.90 466 459.5 0.23 0.71 0.94 469
下载: 导出CSV
表 3 辽新地1井鹰嘴砬子组暗色泥岩有机质类型参数热解分析结果
Table 3. Pyrolysis analysis results of organic matter type parameters of dark mudstone in Yingzuilazi Formation of LXD1 well
深度/m 岩性 样品量/mg 有机碳（TOC）/% 可溶烃（S1）/10-3 热解烃（S2）/10-3 有机CO2（S3）/10-3 生烃潜量（S1+S2）/10-3 氢指数（HI）/10-3 类型指数（TYC） 热解率（D）/% 168.1 灰黑色泥岩 83.5 0.71 0.35 1.33 1.04 1.68 187.00 1.28 19.60 259.2 灰黑色泥岩 78.1 1.24 0.72 1.58 1.17 2.30 128.00 1.35 15.42 264.0 灰黑色泥岩 95.2 1.45 0.91 2.01 0.92 2.92 138.00 2.18 16.69 313.3 灰黑色泥岩 73.9 1.38 0.36 1.42 0.95 1.78 103.00 1.49 10.68 483.5 灰黑色粉砂质泥岩 69.9 1.44 0.70 1.11 0.95 1.81 77.00 1.17 10.47
下载: 导出CSV
-
[1] 王丹丹, 张文浩, 李世臻, 等. 辽宁省红庙子盆地烃源岩特征与生烃潜力研究——来自红地1井的证据[J]. 石油实验地质, 2018, 40(4): 526-531.
Wang D D, Zhang W H, Li S Z, et al. Features and hydrocarbon potential of source rocks in the Hongdi 1 well, Hongmiaozi Basin, Liaoning Province[J]. Petroleum Geology & Experiment, 2018, 40(4): 526-531.
[2] 吉林省地质矿产局. 吉林省区域地质志[M]. 北京: 地质出版社, 1988: 208-209.
Jilin Bureau of Geology and Mineral Resources. Regional geology of Jilin Province[M]. Beijing: Geological Publishing House, 1988: 208-209. (in Chinese)
[3] 肖阳. 辽宁省红庙子盆地中生界油气勘探前景分析[D]. 长春: 吉林大学, 2020.
Xiao Y. Prospect analysis of hydrocarbon exploration of Mesozoic in Hongmiaozi Basin, Liaoning Province[D]. Changchun: Jilin University, 2020.
[4] 许敏, 薛林福, 王东坡, 等. 通化中生代盆地火山-沉积序列及盆地演化[J]. 吉林地质, 1997, 16(3): 31-35.
Xu M, Xue L F, Wang D P, et al. Mesozoic basin volcano sedimentary succession and basin evolutions in the Tonghua area[J]. Jilin Geology, 1997, 16(3): 31-35.
[5] 王丹丹. 松辽盆地外围通化地区油气地质研究[D]. 北京: 中国地质大学, 2018: 79-81.
Wang D D. Study on oil and gas geological conditions in Tonghua area, peripheral region of Songliao Basin[D]. Beijing: China University of Geosciences, 2018: 79-81.
[6] 孟元林, 申婉琪, 周新桂, 等. 东部盆地群下白垩统烃源岩特征与页岩气勘探潜力[J]. 石油与天然气地质, 2016, 37(6): 893-902.
Meng Y L, Shen W Q, Zhou X G, et al. Characteristics of the Lower Cretaceous source rocks and shale gas exploration potential of eastern basin group, NE China[J]. Oil & Gas Geology, 2016, 37(6): 893-902.
[7] 韩欣澎, 郝国丽, 刘超, 等. 通化盆地石油地质特征及油气资源潜力[J]. 世界地质, 2013, 32(2): 337-343.
Han X P, Hao G L, Liu C, et al. Petroleum geologic features and petroleum resources potential in Tonghua Basin[J]. Global Geology, 2013, 32(2): 337-343.
[8] 王丹丹, 周新桂, 李世臻, 等. 通化盆地下白垩统烃源岩石油地质特征及生烃潜力研究[J]. 地质学报, 2017, 91(9): 2119-2130.
Wang D D, Zhou X G, Li S Z, et al. Petroleum geologic features and generation potential of the Lower Cretaceous hydrocarbon source rocks in the Tonghua Basin[J]. Acta Geologica Sinica, 2017, 91(9): 2119-2130.
[9] 董清水, 高屹, 王立贤, 等. 松辽盆地外围东南部中生代残留盆地相互关系及油气勘探前景[J]. 地质与资源, 2021, 30(3): 273-283. http://www.dzyzy.cn/article/doi/10.13686/j.cnki.dzyzy.2021.03.009
Dong Q S, Gao Y, Wang L X, et al. Interrelation between Mesozoic residual basins in the southeastern periphery of Songliao Basin and oil-gas exploration prospect[J]. Geology and Resources, 2021, 30(3): 273-283. http://www.dzyzy.cn/article/doi/10.13686/j.cnki.dzyzy.2021.03.009
[10] 陈树旺, 李永飞. 松辽盆地外围油气地质调查进展[J]. 地质与资源, 2020, 29(4): 401. http://www.dzyzy.cn/article/id/10223
Chen S W, Li Y F. Progress of the geological survey for oil-gas in surroundings of Songliao Basin[J]. Geology and Resources, 2020, 29(4): 401. http://www.dzyzy.cn/article/id/10223
[11] 陈延哲. 通化盆地中生界露头沉积相及储层特征研究[J]. 吉林地质, 2015, 34(2): 24-32.
Chen Y Z. Sedimentary facies and reservoir features of the Mesozoic in Tonghua Basin[J]. Jilin Geology, 2015, 34(2): 24-32.
[12] 徐盛侠, 董清水, 楼仁兴, 等. 吉林柳河盆地沉积特征与油气勘探前景[J]. 世界地质, 2019, 38(1): 215-224.
Xu S X, Dong Q S, Lou R X, et al. Sedimentary characteristics and oil-gas exploration prospect of Liuhe Basin, Jilin[J]. Global Geology, 2019, 38(1): 215-224.
[13] 王继远, 董清水, 林冬萍, 等. 松辽盆地南部双辽断陷生储盖特征与成藏主控因素分析[J]. 世界地质, 2017, 36(1): 166-173.
Wang J Y, Dong Q S, Lin D P, et al. Analysis of source-reservoir-cap association and major factors controlling hydrocarbon accumulation in Shuangliao fault depression, southern Songliao Basin[J]. Global Geology, 2017, 36(1): 166-173.
[14] 张航, 刘玉梅, 宋立斌, 等. 吉林通化盆地三棵榆树断陷中新生代构造演化特征[J]. 世界地质, 2017, 36(4): 1092-1099.
Zhang H, Liu Y M, Song L B, et al. Characteristics of Mesozoic-Cenozoic tectonic evolution of Sankeyushu fault depression in Tonghua Basin, Jilin[J]. Global Geology, 2017, 36(4): 1092-1099.
[15] 何奕言, 程日辉, 宋立斌. 通化盆地亨通山组沉积特征及储层发育规律[J]. 世界地质, 2018, 37(3): 861-872.
He Y Y, Cheng R H, Song L B. Sedimentary characteristics and reservoir development of Hengtongshan Formation in Tonghua Basin[J]. Global Geology, 2018, 37(3): 861-872.
[16] 王丹丹, 赵松, 张文浩, 等. 松辽盆地外围通化地区高精度重磁电特征及其构造格架[J]. 中国地质, 2020, 47(4): 1056-1068.
Wang D D, Zhao S, Zhang W H, et al. Lithofacies identification and deep structure of Tonghua area in the periphery of Songliao Basin based on high-precision gravity-magnetic electrical survey[J]. Geology in China, 2020, 47(4): 1056-1068.
[17] 王丹丹, 张交东, 周新桂, 等. 东北通化盆地群下白垩统页岩油气成藏地质条件[J]. 东北石油大学学报, 2019, 43(6): 83-93.
Wang D D, Zhang J D, Zhou X G, et al. Geological conditions of hydrocarbon accumulation in Lower Cretaceous shale oil and gas in Tonghua Basin Group, Northeast China[J]. Journal of Northeast Petroleum University, 2019, 43(6): 83-93.
[18] 中国石油天然气总公司. SY/T 6285—1997油气储层评价方法[S]. 北京: 中国石油天然气总公司, 1997: 7-8.
China National Petroleum Corporation. SY/T 6285—1997 Evaluating methods of oil and gas reservoirs[S]. Beijing: China National Petroleum Corporation, 1997: 7-8.
[19] 申婉琪. 松辽盆地东部盆地群下白垩统泥页岩源盖层特征[D]. 大庆: 东北石油大学, 2017.
Shen W Q. Characteristics of the Lower Cretaceous shales and cap rock of eastern basin group to Songliao Basin[D]. Daqing: Northeast Petroleum University, 2017.
[20] 刘国东. 通化盆地三棵榆树断陷下白垩统鹰嘴砬子组储层特征[J]. 世界地质, 2020, 39(3): 610-616.
Liu G D. Reservoir characteristics of lower cretaceous Yingzuilazi Formation in Sankeyushu fault depression of Tonghua Basin[J]. Global Geology, 2020, 39(3): 610-616.
-
