UPPER PALEOZOIC SEQUENCE STRATIGRAPHIC FRAMEWORK AND SOURCE-RESERVOIR-CAP CHARACTERISTICS IN EASTERN LIAONING PROVINCE
-
摘要:
辽东地区上古生界石炭系-二叠系发育较齐全. 在区域构造沉积演化、岩石组合特征、沉积相分析等研究基础上, 运用层序地层学理论和方法, 对辽东地区上古生界进行层序地层研究. 将石炭系本溪组-二叠系蛤蟆山组划分为1个超层序、6个层序, 分别发育于陆表海、滨岸、三角洲及河流沉积背景下. 通过建立区域层序地层格架, 探讨在层序地层格架内以体系域为单位的生储盖组合发育特征, 认为上古生界区域性烃源岩和盖层主要形成于凝缩段和水进体系域上部、高位体系域下部, 有利储层主要发育在低位体系域和水进体系域, 纵向上构成2种类型5套生储盖组合, 其中山西组"自生自储型"为上古生界致密砂岩气最有利的组合类型.
Abstract:The Upper Paleozoic Carboniferous-Permian strata are well developed in eastern Liaoning Province. Based on the regional tectonic sedimentary evolution, rock association characteristics and sedimentary facies analysis, the paper studies the sequence stratigraphy of Upper Paleozoic in eastern Liaoning with the theory and method of sequence stratigraphy. The Carboniferous Benxi Formation-Permian Hamashan Formation is recognized as 1 supersequence including 6 sequences, which are developed in epicontinental sea, shoreland, delta and fluvial sedimentary setting respectively. By establishing the regional sequence stratigraphic framework, the paper discusses the development characteristics of source-reservoir-cap assemblages with system tract as unit in the sequence stratigraphic framework. It is considered that the Upper Paleozoic regional source rocks and caps were mainly formed in the condensed section and upper transgressive system tract, and the lower highstand system tract, with the favorable reservoirs mainly developed in the lowstand and transgressive system tracts, forming two types, five sets of source-reservoir-cap combinations vertically, among which the self-generation and self-reservoir type of Shanxi Formation is the most favorable assemblage of Upper Paleozoic tight sandstone gas.
-
-
表 1 辽东地区上古生界烃源岩参数表
Table 1. Parameters of Upper Paleozoic source rocks in eastern Liaoning Province
层位 岩性 TOC（平均）/% 氯仿沥青“A”（平均）/% 生烃潜量（平均）/10-3 Ro/% 有机质类型 综合评价 山西组上段 泥岩 2.95 0.011 0.7 2.31 Ⅱ—Ⅲ 好 煤 45.8 7.34 山西组下段 泥岩 3.31 0.01 0.63 2.35 Ⅱ—Ⅲ 极好—好 煤 58.2 15.28 太原组 泥岩 0.78 0.00995 0.12 2.42 Ⅱ—Ⅲ 中等
下载: 导出CSV
表 2 辽东地区上古生界储层参数表
Table 2. Parameters of Upper Paleozoic reservoirs in eastern Liaoning Province
层位 岩性 孔隙度/% 孔隙类型 渗透率/mD 综合评价 石盒子组彩家段 长石岩屑砂岩 1.6~9.0 残余粒间孔、岩屑溶孔 0.01~0.1 超低孔、超低渗 石盒子组柳塘段 长石岩屑砂岩 2.4~5.1 残余粒间孔、粒内溶孔 山西组上段 石英砂岩、长石岩屑砂岩 2.5~4.6 粒内溶孔、残余粒间孔 山西组下段 岩屑砂岩、岩屑石英砂岩 2.7~3.6 晶内溶孔 本溪组 含砾岩屑石英砂岩 2.6~3.6 残余粒间孔、粒内溶孔
下载: 导出CSV
-
[1] 辽宁省地质矿产局. 中国区域地质志·辽宁志[M]. 北京: 地质出版社, 2017: 185-221.
Liaoning Bureau of Geology and Mineral Resources. Regional geology of China: Liaoning Province[M]. Beijing: Geological Publishing House, 2017: 185-221. (in Chinese)
[2] 费平. 辽宁沉积盖层建造组合与构造古地理时空演化关系讨论[J]. 地质与资源, 2016, 25(1): 17-21. http://www.dzyzy.cn/article/doi/10.13686/j.cnki.dzyzy.2016.01.003
Fei P. Relationship between the composition of sedimentary cover formation and space-time evolution of tectonic paleogeography in Liaoning Province[J]. Geology and Resources, 2016, 25(1): 17-21. http://www.dzyzy.cn/article/doi/10.13686/j.cnki.dzyzy.2016.01.003
[3] 张诚, 代宗仰, 鲁明宇, 等. 辽河东部地区晚古生代沉积相分析[J]. 重庆科技学院学报(自然科学版), 2011, 13(6): 55-58.
Zhang C, Dai Z Y, Lu M Y, et al. Sedimentary facies analysis of Late Palaeozoic in eastern area of Liaohe[J]. Journal of Chongqing University of Science and Technology (Natural Science Edition), 2011, 13(6): 55-58.
[4] 郭胜哲, 张立东, 张长捷, 等. 辽宁太子河盆地元古宙—古生代层序地层[J]. 地质与资源, 2001, 10(1): 1-10. http://www.dzyzy.cn/article/id/9754
Guo S Z, Zhang L D, Zhang C J, et al. Proterozoic-Paleozoic sequence stratigraphic in the Taizi River Basin of Liaoning Province[J]. Geology and Resources, 2001, 10(1): 1-10. http://www.dzyzy.cn/article/id/9754
[5] 吴子杰, 潘玉啟, 包洪伟, 等. 辽东太子河地区寒武系中统层序地层划分及特征[J]. 地质与资源, 2015, 24(4): 295-300. http://www.dzyzy.cn/article/doi/10.13686/j.cnki.dzyzy.2015.04.002
Wu Z J, Pan Y Q, Bao H W, et al. Sequence stratigraphy and characteristics of Middle Cambrian in Taizihe area, eastern Liaoning Province[J]. Geology and Resources, 2015, 24(4): 295-300. http://www.dzyzy.cn/article/doi/10.13686/j.cnki.dzyzy.2015.04.002
[6] 沈玉林, 郭英海, 李壮福, 等. 鄂尔多斯盆地北部苏里格庙含油气区上古生界层序地层研究[J]. 地球学报, 2007, 28(1): 72-78.
Shen Y L, Guo Y H, Li Z F, et al. Sequence stratigraphy study of the Upper Paleozoic of the Suligemiao oil and gas-bearing area, North Ordos Basin[J]. Acta Geoscientica Sinica, 2007, 28(1): 72-78.
[7] 于兴河, 王香增, 王念喜, 等. 鄂尔多斯盆地东南部上古生界层序地层格架及含气砂体沉积演化特征[J]. 古地理学报, 2017, 19(6): 935-954.
Yu X H, Wang X Z, Wang N X, et al. Sequence stratigraphic framework and sedimentary evolution characteristics of gas-bearing sandbody in the Upper Paleozoic in southeastern Ordos Basin[J]. Journal of Palaeogeography, 2017, 19(6): 935-954.
[8] 刘畅. 鄂尔多斯盆地临兴地区上古生界层序地层格架及沉积模式[J]. 非常规油气, 2019, 6(1): 23-33.
Liu C. Sequence stratigraphy framework and sedimentary model of Upper Paleozoic in Linxing area, Ordos Basin[J]. Unconventional Oil & Gas, 2019, 6(1): 23-33.
[9] 陈洪德, 侯中健, 田景春, 等. 鄂尔多斯地区晚古生代沉积层序地层学与盆地构造演化研究[J]. 矿物岩石, 2001, 21(3): 16-22.
Chen H D, Hou Z J, Tian J C, et al. Study on sequence stratigraphy of deposits and tectono-sedimentary evolution in Ordos Basin during Late Palaeozoic[J]. Journal of Mineralogy and Petrology, 2001, 21(3): 16-22.
[10] 侯中健, 陈洪德, 田景春, 等. 鄂尔多斯地区晚古生代陆相沉积层序地层学研究[J]. 矿物岩石, 2001, 21(3): 114-123.
Hou Z J, Chen H D, Tian J C, et al. Study on sequence stratigraphy of continental deposits in Ordos Basin during Later Palaeozoic Era[J]. Journal of Mineralogy and Petrology, 2001, 21(3): 114-123.
[11] 杨欣德, 李星云, 辽宁省地质矿产勘查开发局. 辽宁省岩石地层[M]. 武汉: 中国地质大学出版社, 1997: 1-247.
Yang X D, Li X Y, Liaoning Bureau of Geology and Mineral Resources Exploration. Lithostratigraphy of Liaoning Province[M]. Wuhan: China University of Geosciences Press, 1997: 1-247.
[12] 王烜, 潘玉啟, 吴子杰, 等. 辽东本溪-桓仁地区古生界事件地层划分及特征[J]. 地质与资源, 2015, 24(4): 317-324. http://www.dzyzy.cn/article/doi/10.13686/j.cnki.dzyzy.2015.04.005
Wang X, Pan Y Q, Wu Z J, et al. Event stratigraphy of the Paleozoic Erathem in Benxi-Huanren region, eastern Liaoning Province: Division and characteristics[J]. Geology and Resources, 2015, 24(4): 317-324. http://www.dzyzy.cn/article/doi/10.13686/j.cnki.dzyzy.2015.04.005
[13] 王海鹏. 辽宁省岩石地层太原组地质年代的确定[J]. 地质与资源, 2015, 24(4): 287-294. http://www.dzyzy.cn/article/doi/10.13686/j.cnki.dzyzy.2015.04.001
Wang H P. Determination of the geological age of lithostratigraphic Taiyuan Formation in Liaoning Province[J]. Geology and Resources, 2015, 24(4): 287-294. http://www.dzyzy.cn/article/doi/10.13686/j.cnki.dzyzy.2015.04.001
[14] 彭玉鲸, 陈跃军, 刘跃文. 本溪组——岩石地层和年代地层与穿时性[J]. 世界地质, 2003, 22(2): 111-118.
Peng Y J, Chen Y J, Liu Y W. Benxi Formation: Lithohorizon and chronohorizon with diachronism[J]. Global Geology, 2003, 22(2): 111-118.
[15] 李明娟, 张洪年, 胡宗全. 济阳坳陷上古生界层序划分与等时格架建立[J]. 石油物探, 2006, 45(1): 83-87.
Li M J, Zhang H N, Hu Z Q. Division of Upper Paleozoic stratigraphic sequence and establishment of isochronal stratigraphic frame in Jiyang depression[J]. Geophysical Prospecting for Petroleum, 2006, 45(1): 83-87.
[16] 于鹏. 广覆式生烃理念在辽河东部凸起油气成藏中的应用[J]. 西安石油大学学报(自然科学版), 2014, 29(4): 24-30.
Yu P. Application of widely-covered hydrocarbon generation concept to hydrocarbon accumulation in Eastern Uplift, Liaohe Depression[J]. Journal of Xi'an Shiyou University (Natural Science Edition), 2014, 29(4): 24-30.
[17] 葛明娜, 张金川, 毛俊莉, 等. 辽河坳陷东部凸起上古生界页岩气资源潜力评价[J]. 天然气工业, 2012, 32(9): 28-32, 128.
Ge M N, Zhang J C, Mao J L, et al. Evaluation on Neopaleozoic shale gas resource potential in the Eastern Salient of the Liaohe Depression[J]. Natural Gas Industry, 2012, 32(9): 28-32, 128.
[18] 李春华, 于鹏, 毛俊莉, 等. 辽河坳陷东部凸起上古生界致密砂岩气成藏特征[J]. 特种油气藏, 2013, 20(1): 19-22.
Li C H, Yu P, Mao J L, et al. Diagenetic characteristics of tight sandstone of Upper Paleozoic of East Uplift in Liaohe Depression[J]. Special Oil and Gas Reservoirs, 2013, 20(1): 19-22, 155-156.
[19] 陈洪德, 覃建雄, 田景春, 等. 中国南方古生界层序格架中的生储盖组合类型及特征[J]. 石油与天然气地质, 2004, 25(1): 62-69.
Chen H D, Tan J X, Qin J C, et al. Types and features of source-reservoir-cap rock combinations in Paleozoic sequence in southern China[J]. Oil & Gas Geology, 2004, 25(1): 62-69.
[20] 陈洪德, 倪新锋, 田景春, 等. 华南海相下组合层序地层格架与油气勘探[J]. 石油与天然气地质, 2006, 27(3): 370-377.
Chen H D, Ni X F, Tian J C, et al. Sequence stratigraphic framework of marine lower assemblage in South China and petroleum exploration[J]. Oil & Gas Geology, 2006, 27(3): 370-377.
-
