Mechanochemical Activated Coal Gangue One-step Preparation of High-efficiency Coagulant
-
摘要:
以含高岭石类煤矸石为例，提出了利用高能球磨活化工艺诱导煤矸石中高岭石晶体结构破坏，并与硫酸混合一步制备粉末铝基混凝剂，代替传统的高温活化酸碱工艺的新思路。所制备的混凝剂通过XRD、TEM、CP/MAS NMR进行表征，并对浊度、正磷酸根、五价砷、及腐殖酸等多种污染物质的去除率来对该混凝剂性能进行评价。结果表明该混凝剂具有高活性并对以上四种污染物的去除率分别达到95.95%、91.2%、89.6%和93.73%。所制备的混凝剂能够成为现有铝基混凝剂的替代品，该制备工艺简单、清洁、环保、经济，拓展了含高岭石煤矸石尾矿利用新途径，并为更廉价而又高效的混凝剂的使用提供了可能。
Abstract:Taking kaolinite as an example, A novel process to prepare aluminum-sulfuric acid coagulant is examined by the high-energy ball milling activation of Coal gangue, followed by co-grinding with concentrated sulfuric acid, instead of the traditional high-temperature activated acid-alkali process. The prepared coagulant is characterized by X-ray diffraction (XRD), transmission electron microscope (TEM) and nuclear magnetic resonance (CP/MAS NMR). Besides, the performance of the coagulant was evaluated by the removal rate of pollutants such as turbidity, orthophosphate, pentavalent arsenic, and humic acid. The results show that the coagulant has high activity and the removal rates of the above four pollutants reach 95.95%, 91.2%, 89.6% and 93.73%, respectively. The prepared coagulant can be used as a substitute for the existing aluminum-based coagulant. The preparation process is simple, clean production and environmental-friendly, in addition, it expands a new route to utilize kaolinite-rich tailings of coal mining gangue etc and provides the use of high efficient coagulant cheaper possibility.
-
Key words:
- clean production /
- kaolinite /
- coal gangue /
- high-energy ball mill /
- coagulant
-
-
图 4 (a) 图中表示不同加酸量后的成品对高岭土浑浊液去除效果，投加量(以Al计)为40 mg·L-1；(b)图中表示2 g煤矸石+0.8 g H2SO4样品在不同混磨时间所展现对高岭土浑浊液去除的效果(投加量以Al计)
Figure 4.
表 1 贵州遵义含高岭石类煤矸石XRF成分分析
Table 1. XRF composition analysis of kaolinite containing kaolinite in Zunyi, Guizhou
Composition SiO2 Al2O3 TiO2 Fe2O3 CaO MgO Other Proportion (%) 55.52 21.42 4.58 0.78 1.01 0.78 15.91
下载: 导出CSV
-
[1] 胡雪婷, 塔林托亚, 赵斯琴, 等.由煤系高岭土制备硫酸铝及其絮凝性能[J].应用化工, 2017, 46(6):1074-1077. doi: 10.3969/j.issn.1671-3206.2017.06.012
[2] 郭利娜.内蒙伊利石型黏土矿制备白炭黑及聚合硫酸铝研究[D].西安: 西安科技大学, 2018.
http://cdmd.cnki.com.cn/Article/CDMD-10704-1018882684.htm [3] 张洪, 王明勇, 丘关南, 等.用工业废铝渣和废酸制备聚合硫酸铝的研究[J].轻工科技, 2017, 33(3):93-94. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QKC20172017041000085298
[4] Hassan A, Arif M, Shariq M. Use of geopolymer concrete for a cleaner and sustainable environment-a review of mechanical properties and microstructure[J]. Journal of Cleaner Production, 2019, 223:704-728. doi: 10.1016/j.jclepro.2019.03.051
[5] Su Z, Guo L, Zhang Z, et al. Influence of different fibers on properties of thermal insulation composites based on geopolymer blended with glazed hollow bead[J]. Construction and Building Materials, 2019, 203:525-540. doi: 10.1016/j.conbuildmat.2019.01.121
[6] Ayodele O B, Abdullah A Z. Exploring kaolinite as dry methane reforming catalyst support:influences of chemical activation, organic ligand functionalization and calcination temperature[J]. Applied Catalysis A:General, 2019, 576:20-31. doi: 10.1016/j.apcata.2019.02.034
[7] Zhang Z H, Zhu H J, Zhou C H, et al. Geopolymer from kaolin in china:an overview[J]. Applied Clay Science, 2016, 119:31-41. doi: 10.1016/j.clay.2015.04.023
[8] He P, Jia D, Lin T, et al. Effects of high-temperature heat treatment on the mechanical properties of unidirectional carbon fiber reinforced geopolymer composites[J]. Ceramics International, 2010, 36(4):1447-1453. doi: 10.1016/j.ceramint.2010.02.012
[9] Firdous R, Stephan D, Djobo J N Y. Natural pozzolan based geopolymers:a review on mechanical, microstructural and durability characteristics[J]. Construction and Building Materials, 2018, 190:1251-1263. doi: 10.1016/j.conbuildmat.2018.09.191
[10] Melo C R, Riella H G, Kuhnen N C, et al. Synthesis of 4a zeolites from kaolin for obtaining 5a zeolites through ionic exchange for adsorption of arsenic[J]. Materials Science and Engineering:B, 2012, 177(4):345-349. doi: 10.1016/j.mseb.2012.01.015
[11] Cagnetta G, Robertson J, Huang J, et al. Mechanochemical destruction of halogenated organic pollutants:A critical review[J]. Journal of Hazardous Materials, 2016, 313:85-102. doi: 10.1016/j.jhazmat.2016.03.076
[12] Qu J, Zhang Q, Li X, et al. Mechanochemical approaches to synthesize layered double hydroxides:a review[J]. Applied Clay Science, 2016, 119:185-192. doi: 10.1016/j.clay.2015.10.018
[13] Makó é, Senkár Z, Kristóf J, et al. Surface modification of mechanochemically activated kaolinites by selective leaching[J]. Journal of Colloid and Interface Science, 2006, 294(2):362-370. doi: 10.1016/j.jcis.2005.07.033
[14] Horváth E, Frost R L, Makó é, et al. Thermal treatment of mechanochemically activated kaolinite[J]. Thermochimica Acta, 2003, 404(1-2):227-234. doi: 10.1016/S0040-6031(03)00184-9
[15] Frost R L, Horváth E, Makó é, et al. Modification of low- and High-Defect kaolinite surfaces:implications for kaolinite mineral processing[J]. Journal of Colloid and Interface Science, 2004, 270(2):337-346. doi: 10.1016/j.jcis.2003.10.034
[16] Solihin, Zhang Q, Tongamp W, et al. Mechanochemical synthesis of kaolin-KH2PO4 and kaolin-NH4H2PO4 complexes for application as slow release fertilizer[J]. Powder Technology, 2011, 212(2):354-358. doi: 10.1016/j.powtec.2011.06.012
[17] Lei Z, Cagnetta G, Li X, et al. Enhanced adsorption of potassium nitrate with potassium cation on H3PO4 modified kaolinite and nitrate anion into Mg-Al layered double hydroxide[J]. Applied Clay Science, 2018, 154:10-16. doi: 10.1016/j.clay.2017.12.040
[18] 方燕, 陶奇, 陈爱清, 等.机械研磨高岭石的固体29Si、27Al核磁共振光谱研究[J].矿物学报, 2017, 37(6):677-683. http://www.cqvip.com/QK/95783X/201706/674269305.html
[19] Tao Q, Fang Y, Li T, et al. Silylation of saponite with 3-Aminopropyltriethoxysilane[J]. Applied Clay Science, 2016, 132-133:133-139. doi: 10.1016/j.clay.2016.05.026
[20] Temuujin J, Okada K, MacKenzie K J D, et al. Characterization of porous silica prepared from mechanically amorphized kaolinite by selective leaching[J]. Powder Technology, 2001, 121(2):259-262. http://d.old.wanfangdata.com.cn/NSTLQK/10.1016-S0032-5910(01)00363-1/
[21] 司鹏, 乔秀臣, 于建国.机械力化学效应对高岭石铝氧多面体的影响[J].武汉理工大学学报, 2011, 33(5):22-26. doi: 10.3963/j.issn.1671-4431.2011.05.006
-
