铁碳微电解填料制备及其降解黄药研究

孙慧娜; 杨淑珍; 韩桂洪; 黄艳芳; 苏胜鹏

doi:10.13779/j.cnki.issn1001-0076.2020.01.002

铁碳微电解填料制备及其降解黄药研究

郑州大学化工学院，河南郑州 450001

基金项目:
国家自然科学基金（51974280）

详细信息

作者简介: 孙慧娜(1994-), 女, 河南洛阳人, 硕士研究生, 化学工程专业, E-mail:shnzzu@126.com

通讯作者: 韩桂洪(1981-), 男, 河北昌黎人, 博士, 教授, 主要从事矿物资源加工、冶金矿山生态与环保研究工作, E-mail:hanguihong@zzu.edu.cn

中图分类号: X703

收稿日期: 2019-10-25

刊出日期: 2020-02-25

Preparation of Iron-carbon Micro-electrolytic Filler and Its Application for Degradation of Xanthate

School of Chemical Engineering Zhengzhou University, Zhengzhou 450001, China

More Information

Corresponding author: HAN Guihong, hanguihong@zzu.edu.cn

Received Date: 25 October 2019

Publish Date: 25 February 2020

摘要

摘要:
微电解是一种有效、廉价、绿色的工业废水预处理技术。本研究以铁、碳、粘结剂、造孔剂为原料优化设计制备出了微电解填料，并考察了其用于降解去除异丁基黄药的效果，重点研究了反应时间、填料用量和模拟废水初始pH值对微电解降解异丁基黄药的影响，并用GC-MS测定异丁基黄药降解后产物。结果表明，填料最佳制备条件为：m（Fe）/m（C）=1 GA6FA 1、粘结剂含量为20%、造孔剂含量为3%、煅烧温度为900 ℃、煅烧时间为2.5 h。微电解降解异丁基黄药最佳条件为：模拟废水初始pH=7、反应时间为90 min、填料用量为500 g/L，在此条件下溶液中异丁基黄药、COD、和TOC最终降解率分别为89.91%、79.91%、和35.87%。微电解降解异丁基黄药的最终产物是CO₂、H₂O和SO₄^2-。微电解可以用于净化降解选矿废水残留药剂。
- 微电解 /
- 填料 /
- 异丁基黄药 /
- 降解 /
- 废水
Abstract:
Micro-electrolysis is an effective, inexpensive, green industrial wastewater pretreatment technology. In this study, micro-electrolytic fillers were prepared by using iron, carbon, binder and pore-forming agent as raw materials, and the effects of degrading and removing isobutyl xanthate were investigated. The reaction time, filler amount, and the effect of initial pH of simulated wastewater were mainly studied on the micro-electrolysis degradation of isobutyl xanthate, the product after degradation of isobutyl xanthate were determined by GC-MS. The results show that the optimum preparation conditions of the filler are: m(Fe)/m(C)=1 GA6FA 1, binder content 20%, pore former content 3%, calcination temperature 900 ℃ and calcination time 2.5 h. The optimum conditions for micro-electrolysis degradation of isobutyl xanthate are: simulated wastewater initial pH = 7, reaction time is 90 min, and the amount of filler is 500 g/L. Under these conditions, the final degradation rates of isobutyl xanthate, COD, and TOC were 89.91%, 79.91%, and 35.87%, respectively. The final products of micro-electrolytic decomposition of isobutyl xanthate are CO₂, H₂O and SO₄^2-. Micro-electrolysis can be used to purify and remove residual xanthate in beneficiation wastewater.
- micro-electrolysis /
- filler /
- isobutyl xanthate /
- degradation /
- wastewater

HTML全文

图 1 试验流程示意图

Figure 1.

下载: 全尺寸图片幻灯片

图 2 m(Fe)/m(C)对异丁基黄药降解率的影响

Figure 2.

下载: 全尺寸图片幻灯片

图 3 煅烧温度、煅烧时间对异丁基黄药降解效果的影响

Figure 3.

下载: 全尺寸图片幻灯片

图 4 煅烧温度、煅烧时间对填料抗压强度的影响

Figure 4.

下载: 全尺寸图片幻灯片

图 5 粘结剂含量对填料抗压强度及异丁基黄药降解率的影响

Figure 5.

下载: 全尺寸图片幻灯片

图 6 造孔剂含量对填料吸水率及异丁基黄药降解率的影响

Figure 6.

下载: 全尺寸图片幻灯片

图 7 填料循环次数对异丁基黄药降解的影响

Figure 7.

下载: 全尺寸图片幻灯片

图 8 不同煅烧温度下铁碳微电解填料XRD图

Figure 8.

下载: 全尺寸图片幻灯片

图 9 填料反应前后扫描电镜图(放大倍数为500倍)：(a)反应前表面，(b)反应前截面，(c)反应后表面，(d)反应后截面

Figure 9.

下载: 全尺寸图片幻灯片

图 10 反应时间对异丁基黄药、COD降解效果的影响

Figure 10.

下载: 全尺寸图片幻灯片

图 11 反应过程中动力学拟合

Figure 11.

下载: 全尺寸图片幻灯片

图 12 填料用量对异丁基黄药降解效果的影响

Figure 12.

下载: 全尺寸图片幻灯片

图 13 pH值对异丁基黄药降解效果的影响

Figure 13.

下载: 全尺寸图片幻灯片

图 14 异丁基黄药降解前后的GC-MS总离子图谱

Figure 14.

下载: 全尺寸图片幻灯片

图 15 异丁基黄药可能降解路径推测(R为异丁基)

Figure 15.

下载: 全尺寸图片幻灯片

表 1 填料的宏观物理参数

Table 1. Macroscopic physical parameters of filler

Name	Particle size (mm)	Apparent density (g/cm³)	Bulk density (g/cm³)	Voidage (%)	Water absorption (%)	Wear rate (%)	Compressive strength (N)
Micro-electrolytic filler	5~8	2.658	1.008	62.08	18.75	4.8	64.49

下载: 导出CSV

表 2 微电解降解异丁基黄药产物分析

Table 2. Analysis of micro-electrolytic degradation products of isobutyl xanthate

Serial number	Product	Molecular formula	Structural formula
1	Isobutane	C₄H₁₀
2	Isobutanol	C₄H₁₀O
3	Diisobutyl sulfide	C₈H₁₈S
4	Carbon disulfide	CS₂
5	Isovaleric acid	C₅H₁₀O₂
6	2, 4-dimethylpentane	C₇H₁₆
7	Isobutyric acid	C₄H₇O₂
8	3-methylthiobutyric acid-S (1-methylethyl) ester	C₈H₁₆OS
9	Xanthanate	C₅H₁₀S₂
10	Diisobutyl carbonate	C₉H₁₈O₃

下载: 导出CSV

参考文献(25)

[1]	张雅潇.选矿废水处理技术及其应用[J].内蒙古科技与经济, 2017(13):88-89. doi: 10.3969/j.issn.1007-6921.2017.13.043
[2]	袁珊珊.混凝沉淀法处理多金属矿选矿废水研究[D].长沙: 中南大学, 2013.http://d.wanfangdata.com.cn/Thesis/Y2426655
[3]	Guo Y J, Cui K X, Hu M Y, et al. Fe (Ⅲ) ions enhanced catalytic properties of (BiO)₂CO₃ nanowires and mechanism study for complete degradation of xanthate[J]. Chemosphere, 2017, 181:190-196. doi: 10.1016/j.chemosphere.2017.04.069
[4]	Shao L H, Wei G T, Wang Y Z, et al. Preparation and application of acidified/calcined red mud catalyst for catalytic degradation of butyl xanthate in Fenton-like process[J]. Environmental Science and Pollution Research, 2016, 23(15):15202-15207. doi: 10.1007/s11356-016-6691-4
[5]	王瑞菲.水体中黄原酸盐及二丁基二硫代磷酸盐的分析方法研究[D].沈阳: 东北大学, 2009.http://cdmd.cnki.com.cn/Article/CDMD-10145-1013115095.htm
[6]	国家环境保护总局, 国家质量监督检验检疫总局.地表水环境质量标准: GB3838-2002[S].2002-04-28.
[7]	杨飞, 汤玉和, 周晓彤.铜硫矿选矿废水对浮选的影响及处理现状[J].材料研究与应用.2016(1):5-9. doi: 10.3969/j.issn.1673-9981.2016.01.002
[8]	Cui X Q, Li N, Chen G D, et al. Sludge based micro-electrolysis filler for removing tetracycline from solution[J]. Journal of Colloid and Interface Science, 2019, 534:490-498. doi: 10.1016/j.jcis.2018.09.061
[9]	Liu R Q, Sun W, Yang K O, et al. Decomposition of sodium butyl xanthate (SBX) in aqueous solution by means of OCF:ozonator combined with flotator[J]. Minerals Engineering, 2015, 70:222-227. doi: 10.1016/j.mineng.2014.09.020
[10]	Yi-zhong J, Yue-feng Z, Wei L. Experimental study on micro-electrolysis technology for pharmaceutical wastewater treatment[J]. Journal of Zhejiang University-Science A, 2002, 3(4):401-404. doi: 10.1631/jzus.2002.0401
[11]	Lai B, Zhou Y X, Qin H K, et al. Pretreatment of wastewater from acrylonitrile-butadiene-styrene (ABS) resin manufacturing by microelectrolysis[J]. Chemical Engineering Journal, 2012, 179:1-7. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=333b927914d18abb157819a06d46a57b
[12]	王毅博, 冯民权, 刘永红, 等.铁碳微电解技术在难治理废水中的研究进展[J].化工进展, 2018(8):3188-3196. http://d.old.wanfangdata.com.cn/Periodical/hgjz201808041
[13]	Li P, Liu Z, Wang X, et al. Enhanced decolorization of methyl orange in aqueous solution using iron-carbon micro-electrolysis activation of sodium persulfate[J]. Chemosphere, 2017, 180:100-107. doi: 10.1016/j.chemosphere.2017.04.019
[14]	柴豆.铁炭微电解法处理有机废水试验研究[D].西安: 西安工业大学, 2018.http://cdmd.cnki.com.cn/Article/CDMD-10702-1018115810.htm
[15]	李昊, 占强, 徐晓军, 李天国, 等.脉冲电强化微电解对铅锌浮选废水中锌和丁基黄药的去除[J].环境工程学报, 2016(7):3664-3670. http://d.old.wanfangdata.com.cn/Periodical/hjwrzljsysb201607046
[16]	中华人民共和国国家质量监督检验检疫总局, 中国国家标准化管理委员会.轻集料及其试验方法第2部分: 轻集料试验方法: GB-T 17431.1-2010[S].2010-09-02.
[17]	陈万堂.多元微电解处理垃圾渗滤液浓缩液的研究[D].上海: 华东师范大学, 2016.http://cdmd.cnki.com.cn/Article/CDMD-10269-1016141861.htm
[18]	唐琼瑶, 黄磊, 刘浩, 等.铜渣制备微电解填料及其处理甲基橙废水的研究[J].金属矿山.2018(1):183-186. http://d.old.wanfangdata.com.cn/Periodical/jsks201801037
[19]	Kang M M, Chen Q G, Li J J, et al. Preparation and study of a new type of Fe-C microelectrolysis filler in oil-bearing ballast water treatment[J]. Environmental Science and Pollution Research, 2019, 26(11):10673-10684. doi: 10.1007/s11356-019-04480-z
[20]	曹蓓蓓.铁炭微电解法处理硝基苯废水的试验研究[D].上海: 华东理工大学, 2014.http://cdmd.cnki.com.cn/Article/CDMD-10251-1014256043.htm
[21]	盛超.锰炭微电解填料的制备及在有机工业废水处理中的应用[D].武汉: 武汉理工大学, 2017.
[22]	刘立恒.Fe-C/Fe-Cu内电解处理二硝基重氮酚废水研究[D].重庆: 重庆大学, 2007.http://d.wanfangdata.com.cn/Thesis/D455869
[23]	Vlyssides A G, Papaioannou D, Loizidoy M, et al. Testing an electrochemical method for treatment of textile dye wastewater[J]. Waste Management, 2000, 20(7):569-574. doi: 10.1016/S0956-053X(00)00028-3
[24]	Shen Y, Nagaraj D R, Farinato R, et al. Study of xanthate decomposition in aqueous solutions[J]. Minerals Engineering, 2016, 93:10-15. doi: 10.1016/j.mineng.2016.04.004
[25]	聂蕊, 李天国, 徐晓军, 等.浮选废水中烷基黄药的电催化内电解降解特征及机制[J].中国有色金属学报, 2018(3):594-603. http://d.old.wanfangdata.com.cn/Periodical/zgysjsxb201803019
