鞍千磁赤铁矿石磁选—反浮选工艺优化研究

朱一民; 葛婧; 刘杰; 韩跃新

doi:10.13779/j.cnki.issn1001-0076.2023.03.009

鞍千磁赤铁矿石磁选—反浮选工艺优化研究

1.
东北大学资源与土木工程学院，辽宁沈阳 110819

2.
难采选铁矿资源高效开发利用技术国家地方联合工程研究中心，辽宁沈阳 110819

基金项目: 辽宁省“兴辽英才计划”项目青年拔尖人才项目（XLYC2007055）

详细信息

作者简介: 朱一民（1964—），女，教授，博士，博士研究生导师，主要研究方向为浮选药剂研发与机理研究; 葛婧（1999—），女，辽宁大连人，硕士研究生。现就读于东北大学矿物加工工程专业，师从朱一民教授，主要从事绿柱石浮选药剂研究

通讯作者: 葛婧（1999—），女，硕士研究生，主要从事绿柱石浮选药剂研究

中图分类号: TD951.1

收稿日期: 2023-05-13

刊出日期: 2023-06-15

Optimization Study of Magnetic Separation − Reverse Flotation Process for Magnetic Hematite Ore in Anqian

1.
School of Resource and Civil Engineering, Northeastern University, Shenyang 110819, China

2.
National−Local Joint Engineering Resarch Center of Refractory Iron Ore Resources Efficient Utilization Technology, Shenyang 110819, China

More Information

Corresponding author: GE Jing

Received Date: 13 May 2023

Publish Date: 15 June 2023

摘要

摘要:
随着鞍千矿山入选矿石中磁性矿含量增加，为解决当前鞍千矿石联合分选工艺流程中重选精矿品位低、浮选提质困难、浮选尾矿铁损失严重等问题，以鞍千原矿为研究对象，开展原矿磨矿—两段弱磁选—强磁选—反浮选工艺优化实验研究。结果表明：原矿在最佳磨矿细度为−0.043 mm含量80%、两段弱磁选磁场磁感应强度均为0.1 T、强磁选磁场磁感应强度为0.7 T的条件下，得到高品位的弱磁选精矿，由弱磁选精选尾矿与强磁选精矿混合制备的混磁精矿，作为反浮选给矿；在反浮选最佳药剂制度为矿浆温度35±1℃、pH为11.5、淀粉用量800 g/t、CaO用量1000 g/t、粗选和精选捕收剂（TD−Ⅱ）用量分别为1000 g/t和450 g/t的条件下，经一次粗选一次精选三次扫选反浮选闭路实验，获得了浮选精矿TFe品位为67.16%、对浮选给矿回收率为93.99%的技术指标。最终采用二段弱磁选—强磁选—反浮选工艺获得了产率为36.94%、铁品位为68.80%、铁回收率为88.19%的铁精矿。通过FTIR分析表明，淀粉可以通过物理吸附的方式选择性吸附在赤铁矿表面，抑制了捕收剂在赤铁矿表面的吸附。
- 磁选 /
- 反浮选 /
- 赤铁矿 /
- 磁铁矿
Abstract:
With the increase of magnetic mineral content in the raw ore of Anqian mine, there are many problems such as low grade of gravity separation concentrate, difficulty in improving flotation concentrates quality, and serious iron loss of flotation tailings in the current joint beneficiation process. In order to solve these problems, an experimental research of process optimization was carried out based on the Anqian iron ore, including grinding, two stages of low intensity magnetic separation, high intensity magnetic separation, and reverse flotation. The results showed that under the condition of the optimal grinding fineness of −0.043 mm with a content of 80%, the magnetic induction intensity of both two stages low intensity magnetic separation of 0.1 T, and the magnetic induction intensity of high intensity magnetic separation of 0.7 T, the mixed magnetic concentrates consisted of the second stage low intensity magnetic separation tailings and high intensity magnetic separation concentrates was obtained, which was used as the feed of reverse flotation. Furthermore, the optimal reagent regime for reverse flotation was determined as slurry temperature of 35±1 ℃, pH of 11.5, starch dosage of 800 g/t, CaO dosage of 1000 g/t, and collector (TD−Ⅱ) dosages of 1000 g/t and 450 g/t for rough and cleaning, respectively. Under the condition of the above optimal reagent regime, the technical indicators for flotation concentrate of a TFe grade of 67.16% and a recovery of 93.99% calculated by flotation feed were obtained through one rough, one cleaning, and three scavenging in reverse flotation closed circuit experiments. Two stages low intensity magnetic separation—high intensity magnetic separation—reverse flotation can obtain the final iron concentrate with yield of 36.94%, iron grade of 68.80% and iron recovery of 88.19%. FTIR analysis showed that starch can selectively adsorbed on the surface of hematite through physical adsorption, which inhibited the adsorption of collectors on the surface of hematite.
- magnetic separation /
- reverse flotation /
- hematite /
- magnetite

HTML全文

图 1 原矿XRD图谱

Figure 1.

下载: 全尺寸图片幻灯片

图 2 实验原则工艺流程

Figure 2.

下载: 全尺寸图片幻灯片

图 3 反浮选流程

Figure 3.

下载: 全尺寸图片幻灯片

图 4 磨矿细度对反浮选铁精矿指标的影响

Figure 4.

下载: 全尺寸图片幻灯片

图 5 抑制剂用量对反浮选铁精矿指标的影响

Figure 5.

下载: 全尺寸图片幻灯片

图 6 粗选捕收剂用量对反浮选铁精矿指标的影响

Figure 6.

下载: 全尺寸图片幻灯片

图 7 矿浆温度对反浮选铁精矿指标的影响

Figure 7.

下载: 全尺寸图片幻灯片

图 8 反浮选闭路实验流程

Figure 8.

下载: 全尺寸图片幻灯片

图 9 淀粉与赤铁矿和石英作用前后的红外光谱图

Figure 9.

下载: 全尺寸图片幻灯片

表 1 原矿化学组成分析结果

Table 1. Analysis results of chemical composition of raw ore /%

成分	TFe	FeO	SiO₂	Al₂O₃	CaO	MgO	S	P	烧失
含量	28.99	8.10	48.27	0.20	1.80	2.57	0.015	0.066	1.51

下载: 导出CSV

表 2 原矿铁化学物相分析结果

Table 2. Analysis results of iron chemical phase of raw ore /%

物相	磁性铁中的铁	碳酸铁中的铁	赤褐铁中的铁	硫化铁中的铁	硅酸铁中的铁	总铁
含量	17.62	0.48	9.16	0.49	1.24	28.99
分布率	60.80	1.61	31.61	1.68	4.30	100.00

下载: 导出CSV

表 3 磁选回路选矿指标

Table 3. Beneficiation index of magnetic separation circuit /%

产品名称	产率	Fe品位	回收率
弱磁精矿	23.50	69.74	57.28
弱磁精选尾矿	3.05	32.82	3.50
强磁精矿	19.81	42.88	29.70
浮选给矿	22.86	41.54	33.20
强磁尾矿	53.64	5.08	9.52
原矿	100.00	28.60	100.00

下载: 导出CSV

表 4 混磁精矿反浮选闭路实验结果

Table 4. Results of reverse flotation closed circuit test of mixed magnetic concentrate /%

产品名称	作业产率	铁品位	铁回收率
浮选精矿	58.78	67.16	93.09
浮选尾矿	41.22	6.12	6.91
合计	100	42.00	100.00

下载: 导出CSV

表 5 全流程试验结果

Table 5. The whole process test results /%

产品名称	产率		Fe品位	Fe回收率
产品名称	对浮选给矿	对原矿	Fe品位	对浮选给矿	对原矿
弱磁精矿	−	23.50	69.74	−	57.28
浮选精矿	58.78	13.44	67.16	93.09	30.91
浮选尾矿	41.22	9.42	6.12	6.91	2.30
浮选给矿	100.00	22.86	42.00	100.00	33.20
强磁尾矿	−	53.64	5.08	−	9.53
原矿	−	100.0	28.71	−	100.00
最终铁精矿	−	36.94	68.80	−	88.19

下载: 导出CSV

表 6 浮选精矿和浮选尾矿化学成分分析结果

Table 6. Analysis results of chemical composition of flotation concentrate and talings /%

产品	TFe	FeO	SiO₂	Al₂O₃	CaO	MgO	S	P	烧失
浮选精矿	67.16	18.06	4.18	0.12	0.55	0.63	0.02	0.01	0.54
浮选尾矿	6.12	2.49	83.83	0.41	1.35	3.22	0.01	0.04	2.12

下载: 导出CSV
