Study on Resistance Characteristics of Embedded Counterflow Column Type Wind Caps in Suspension Roaster
-
摘要:
采用床层压降—气量法，系统地开展了内嵌逆流柱型风帽在悬浮焙烧炉运行过程中的阻力特性研究。通过冷态实验探索了风帽数量以及风帽芯帽管小孔数量对内嵌逆流柱型风帽布风装置阻力特性的影响，并根据相似理论推导出不同温度条件下内嵌逆流柱型风帽的阻力特性。结果表明：内嵌逆流柱型风帽布风装置的阻力随着风帽数量和风帽芯管小孔数量的增多而减小，颗粒临界风量随着矿石颗粒粒度的增大而增大，而矿石床层高度对临界风量的影响较小，研究结果为悬浮焙烧炉工业化生产过程中操作参数的设计及优化提供了理论和数据支撑。
Abstract:The resistance characteristics of the inline counterflow column type wind caps during the operation of suspension roaster was systematically investigated based on the bed pressure drop-air flow method. The influences of air flow and numbers of small holes in the core cap tube on the resistance characteristics of the air distribution device with embedded counter-current column type wind caps were explored by cold tests, and the resistance characteristics of the embedded counter-current column type wind caps under different temperature conditions were deduced according to similar theory. The results showed that the resistance of the air distribution device with embedded counterflow column type wind caps decreased with the increase of the number of wind caps and the number of small holes of the wind cap core tube. The critical airflow increased with the increase of ore particle size while having a small influence on the ore bed height. The research results provide theoretical and data support for the design and optimization of operating parameters in the industrial production of suspension roasting.
-
-
表 1 实验物料的物理性质
Table 1. Physical properties of the test materials
固体物料 粒度
/mm体积平均
粒径/mm真密度
/(kg·m−3)表观密度
/(kg·m−3)堆积密度
/(kg·m−3)A −0.074+0.053 0.061 3250 1530 1750 B −0.106+0.074 0.093 3310 1680 1360 C −0.15+0.106 0.141 3894 2560 1890 D −0.18+0.15 0.166 3562 1890 1627
下载: 导出CSV
表 2 不同温度下的雷诺数
Table 2. Reynolds number at different temperatures
温度/℃ 400 500 600 700 800 900 1000 雷诺数 2346.59 1867.75 1533.46 1284.79 1100.56 954.44 836.83
下载: 导出CSV
-
[1] 韩跃新, 孙永升, 李艳军, 等. 我国铁矿选矿技术最新进展[J]. 金属矿山, 2015(2): 1−11.
HAN Y X, SUN Y S, LI Y J, et al. Latest progress in iron ore beneficiation technology in China[J]. Metal Mine, 2015(2): 1−11.
[2] 刘杰, 周明顺, 翟立威, 等. 中国复杂难选铁矿的研究现状[J]. 中国矿业, 2011, 20(5): 63−66. doi: 10.3969/j.issn.1004-4051.2011.05.019
LIU J, ZHOU M S, ZHAI L W, et al. Research status of complex and refractory iron ores in China[J]. China Mining Magazine, 2011, 20(5): 63−66. doi: 10.3969/j.issn.1004-4051.2011.05.019
[3] 张宗旺, 李健, 李燕, 等. 国内难选铁矿的开发利用现状及发展[J]. 有色金属科学与金属, 2012, 3(1): 72−77.
ZHANG Z W, LI J, LI Y, et al. Current situation and development of selecting iron mines for exploitation in China[J]. Nonferrous Metals Science and Engineering, 2012, 3(1): 72−77.
[4] CHENG L, BASU P, CEN K. Solids circulation rate prediction in a pressurized loop-seal[J]. Chemical Engineering Research & Design, 1998, 76(6): 761−763.
[5] 王文仲. 循环流化床锅炉风帽及布风板的实验与数值模拟研究[D]. 北京: 中国科学院研究生院, 2009
WANG W Z. Experimental and numerical simulation study on wind cap and air distribution plate of circulating fluidized bed boiler [D]. Beijing: Graduate University of Chinese Academy of Sciences, 2009.
[6] 王擎, 孙键, 李绚天, 等. 循环流化床锅炉Loop Seal型返料装置的实验研究[J]. 化工机械, 1999(4): 3−7+26.
WANG Q, SUN J, LI X T, et al. Experimental study on the Loop Seal type return device of a circulating fluidized bed boiler[J]. Chemical Engineering Machinery, 1999(4): 3−7+26.
[7] 陈逸. CFB锅炉U型阀内气固流动特性的数值模拟与实验研究[D]. 上海: 上海交通大学, 2012
CHEN, Y. Numerical simulation and experimental study on gas-solid flow characteristics in U-shaped valve of CFB boiler [D]. Shanghai: Shanghai Jiao Tong University, 2012.
[8] 彭莉, 李洪钟, 朱庆山. U型阀结构下颗粒流态化排料的数学模型[J]. 过程工程学报, 2012, 12(3): 382−387.
PENG L, LI H Z, ZHU Q S. Mathematical model of granular flow discharge under the structure of u-shaped valve[J]. Journal of Process Engineering of China, 2012, 12(3): 382−387.
[9] 徐钊. 循环流化床锅炉U型回料阀调节特性的研究[D]. 上海: 上海交通大学, 2013
XU Z. Research on the regulation characteristics of U-shaped return valve for circulating fluidized bed boiler[D]. Shanghai: Shanghai Jiao Tong University, Shanghai, 2013.
[10] 杨雪平. CFB炉膛风帽区域与回料阀内两相流动特性的研究[D]. 上海: 上海交通大学, 2009
YANG X P. Study on two-phase flow characteristics in tuyere cap region and return valve of CFB boiler[D]. Shanghai: Shanghai Jiao Tong University, 2009.
[11] BASU P, BUTLER J. Studies on the operation of loop-seal in circulating fluidized bed boilers[J]. Applied Energy, 2009, 86(9): 1723−1731. doi: 10.1016/j.apenergy.2008.11.024
[12] HENG L, BASU P. Effect of pressure on loop seal operation for a pressurized circulating fluidized bed[J]. Powder Technology, 1999, 103(3): 203−211. doi: 10.1016/S0032-5910(99)00018-2
[13] BOTSIO E, BASU P. Experimental investigation into the hydrodynamics of flow of solids through a loop seal recycle chamber[J]. Can. J. Chem. Eng., 2005(83): 554−558.
[14] LI C J, LI H Z, ZHU Q S. A hydrodynamic model of loop-seal for a circulating fluidized bed[J]. Powder Technology, 2014, 252(1): 14−19.
[15] BASU P, CHENG L. An analysis of loop seal operations in a circulating fluidized bed[J]. Chemical Engineering Research & Design, 2000, 78(7): 991−998.
-
