摘要:
利用尾矿制备发泡陶瓷是尾矿高值化利用途径之一，但烧结参数和尾矿成分组成对钽铌尾矿基发泡陶瓷抗压强度的影响尚不清楚。为此，以钽铌尾矿为主要原料、高岭土(28%)和钠长石(12%)为辅助材料、碳化硅（SiC）为发泡剂，采用直接发泡法制备了钽铌尾矿基发泡陶瓷，研究了烧结温度、保温时间、SiC掺量和尾矿加入量对发泡陶瓷抗压强度的影响。结果表明，随着保温时间和烧结温度的增加，发泡陶瓷的抗压强度均呈减小的趋势；同时，抗压强度随着尾矿加入量的增加而增加，随着SiC掺量的增大钽铌尾矿基发泡陶瓷的抗压强度先减小后增大。机理分析表明，孔隙结构变化是导致其抗压强度改变的主要因素。在烧结温度为1150 ℃、保温时间为40 min、尾矿加入量为65%、SiC掺量为0.5%条件下，制备的发泡陶瓷抗压强度和孔隙率分别为9.94 MPa和67.16%。本研究为钽铌尾矿制备高强度发泡陶瓷提供了理论依据。
Abstract:The preparation of foamed ceramics from tailings is one of the high value utilization ways. Unfortunately, the influences of sintering parameters and raw composition on the compressive strength of tantalum-niobium tailings-based foamed ceramics are still obscure. In this paper, tantalum-niobium tailings-based foamed ceramics were prepared by direct foaming method with tantalum-niobium tailings as the main raw material, kaolin(28%) and albite(12%) as auxiliary materials, and silicon carbide (SiC) as the foaming agent. The influence of sintering temperature, holding time, SiC content and tailings addition amount on the compressive strength of the foamed ceramics were investigated. The results showed that with increasing holding time and sintering temperature, the compressive strength of foamed ceramics decreases. Furthermore, the compressive strength of tantalum-niobium tailings-based foamed ceramics with the increase of SiC content, first decreased and then increased. Further analysis of the influencing mechanism indicated that the change of pore structure was the main factor leading to the change of compressive strength.The compressive strength and porosity of the foamed ceramic prepared under the conditions of sintering temperature of 1150 ℃, holding time of 40 min, tailings addition amount of 65%, and SiC content of 0.5% are 9.94 MPa and 67.16% respectively.This paper provides a theoretical basis for the preparation of high-strength foamed ceramics from tantalum-niobium tailings.
-
Key words:
- tantalum niobium tailings /
- foam ceramics /
- compressive strength
-
-
表 1 钽铌尾矿、高岭土和钠长石的化学成分
Table 1. Chemical composition of tantalum niobium tailings, kaolin and albite
/% 原料 SiO2 Al2O3 Fe2O3 MgO K2O Na2O CaO 其他 钽铌尾矿 71.60 16.45 0.13 0.03 2.20 6.60 0.19 2.80 高岭土 55.70 42.50 0.80 − − − − 1.0 钠长石 70.26 17.80 0.06 0.12 0.87 9.50 − 1.39
下载: 导出CSV
表 2 发泡陶瓷的原料组成和烧结条件
Table 2. Chemical composition of raw materials and sintering conditions of foam ceramics
影响因素 原料组成/% 烧结条件 钽铌
尾矿高岭土 钠长石 SiC 温度/℃ 保温
时间/minSiC掺量 60 28 12 0.1 1150 40 60 28 12 0.3 1150 40 60 28 12 0.5 1150 40 60 28 12 0.7 1150 40 60 28 12 1 1150 40 烧结温度 60 28 12 0.5 1110 40 60 28 12 0.5 1130 40 60 28 12 0.5 1150 40 60 28 12 0.5 1170 40 60 28 12 0.5 1200 40 保温时间 60 28 12 0.5 1150 20 60 28 12 0.5 1150 30 60 28 12 0.5 1150 40 60 28 12 0.5 1150 50 60 28 12 0.5 1150 60 钽铌尾矿加入量 60 28 12 0.5 1150 40 65 28 12 0.5 1150 40 70 28 12 0.5 1150 40 75 28 12 0.5 1150 40 80 28 12 0.5 1150 40
下载: 导出CSV
-
[1] WANG M, XU S. Preparation and applications of foam ceramics; proceedings of the IOP Conference Series: Earth and Environmental Science, F, 2018[C]. IOP Publishing.
[2] DONG L, TONG X, LI X, et al. Some developments and new insights of environmental problems and deep mining strategy for cleaner production in mines[J]. Journal of Cleaner Production, 2019, 210: 1562−1578. doi: 10.1016/j.jclepro.2018.10.291
[3] 李泽华, 邢军, 孙晓刚, 等. 利用高炉矿渣和铁尾矿制备开孔发泡陶瓷的研究[J]. 金属矿山, 2022(10): 238−244.
LI Z H, XING J, SUN X G, et al. Study on Preparation of open-cell foamed ceramics from blast furnace slag and iron tailings[J]. Metal Mine, 2022(10): 238−244.
[4] LI L, JIANG T, CHEN B, et al. Overall utilization of vanadium–titanium magnetite tailings to prepare lightweight foam ceramics[J]. Process Safety and Environmental Protection, 2020, 139: 305−314. doi: 10.1016/j.psep.2020.04.034
[5] 江彬轩, 李月明, 王竹梅, 等. 利用黄金尾矿废渣制备多孔墙体建材的研究[J]. 中国陶瓷, 2021, 57(12): 65−71.
JIANG B X, LI Y M, WANG Z M, et al. Preparation of porous wall materials from gold tailings[J]. China Ceramics, 2021, 57(12): 65−71.
[6] ZHU X, SUN N, HUANG Y, et al. Preparation of full tailings-based foam ceramics and auxiliary foaming effect of vanadium-titanium magnetite tailings[J]. Journal of Non-Crystalline Solids, 2021, 571: 121063. doi: 10.1016/j.jnoncrysol.2021.121063
[7] 潘德安, 逯海洋, 刘晓敏, 等. 高硅铁尾矿制备轻质闭孔泡沫陶瓷研究[J]. 中国陶瓷, 2020, 56(3): 51−58.
PAN D A, LU H Y, LIU X M, et al. Study on preparation of lightweight closed-pore foaming ceramics with high silicon iron tailings[J]. China Ceramics, 2020, 56(3): 51−58.
[8] LIU M, YANG X, GUO J, et al. Fabrication of SiC foam ceramics at a low sintering temperature by adding fly ash[J]. Ceramics International, 2022, 48(20): 30462−30467. doi: 10.1016/j.ceramint.2022.06.326
[9] HUI T, SUN H, PENG T, et al. Recycling of extracted titanium slag and gold tailings for preparation of self-glazed ceramic foams[J]. Ceramics International, 2022, 48(16): 23415−23427. doi: 10.1016/j.ceramint.2022.04.333
[10] HUI T, SUN H J, PENG T J. Preparation and characterization of cordierite-based ceramic foams with permeable property from asbestos tailings and coal fly ash[J]. Journal of Alloys and Compounds, 2021, 885: 160967. doi: 10.1016/j.jallcom.2021.160967
[11] 张国涛, 邓仕豪, 杨景琪. 以铜尾矿制备发泡陶瓷墙板的研究[J]. 山东陶瓷, 2020, 43(1): 3−7.
ZHANG G T, DENG S H, YANG J Q. Study on preparation of foamed ceramic wallboard from copper tailings[J]. Shandong Ceramics, 2020, 43(1): 3−7.
[12] 赵威, 张国春, 周春生, 等. 商洛钼尾矿制备泡沫陶瓷的研究[J]. 人工晶体学报, 2017, 46(3): 475−479.
ZHAO W, ZHANG G C, ZHOU C S, et al. Preparation of foaming ceramics with Shangluo molybdenum tailings[J]. Journal of Synthetic Crystals, 2017, 46(3): 475−479.
[13] TANG Z, LIANG J, JIANG W, et al. Preparation of high strength foam ceramics from sand shale and steel slag[J]. Ceramics International, 2020, 46(7): 9256−9262. doi: 10.1016/j.ceramint.2019.12.179
[14] CHEN Y, WANG N, OLA O, et al. Porous ceramics: Light in weight but heavy in energy and environment technologies[J]. Materials Science and Engineering: Reports, 2021, 143: 100589. doi: 10.1016/j.mser.2020.100589
[15] LI X, PAN M, TAO M, et al. Preparation of high closed porosity foamed ceramics from coal gangue waste for thermal insulation applications[J]. Ceramics International, 2022, 48(24): 37055−37063. doi: 10.1016/j.ceramint.2022.08.280
[16] 赵威, 韩硕, 陈明堃. 钼尾矿基发泡陶瓷墙材的制备及其性能研究[J]. 商洛学院学报, 2021, 35(6): 1−5+12.
ZHAO W, HUAN S, CHEN M K. A studyon preparation and performance of molybdenum tailings-based foamed ceramic wall materials[J]. Journal of Shangluo University, 2021, 35(6): 1−5+12.
[17] 胡红喜, 张忠汉, 刘超, 等. 内蒙古某钽铌尾矿回收锂云母工艺[J]. 有色金属(选矿部分), 2022(5): 79−84+136.
HU H X, ZHANG Z H, LIU C, et al. Process for recovering lepidolite from tantalum-niobium tailings in inner mongolia[J]. Nonferrous Metals(Mineral Processing Section), 2022(5): 79−84+136.
[18] 汪劲刚, 何桂春, 肖志, 等. 钽铌尾矿制备发泡陶瓷研究[J]. 有色金属科学与工程: 1-12[2023-05-27]. http://kns.cnki.net/kcms/detail/36.1311.tf.20221209.1657.004.html.
WANG J G, HE G C, XIAO Z, et al. Preparation of foamed ceramics from tantalum niobium tailings[J]. Nonferrous Metals Science and Engineering: 1-12[2023-05-27]. http://kns.cnki.net/kcms/detail/36.1311.tf.20221209.1657.004.html.
[19] 熊惠明, 鲜雯, 邓威, 等. 锂渣基发泡陶瓷的制备及其性能研究[J]. 非金属矿, 2023, 46(1): 99−102+6.
XIONG H M, XIAN W, DENG W, et al. Preparation of lithium slag based foamed ceramics and high temperature phase transformation[J]. Non-Metallic Mines, 2023, 46(1): 99−102+6.
[20] 赵绘婷, 董龙浩, 谢梅竹, 等. 以煤矸石制备发泡陶瓷的研究[J]. 中国陶瓷工业, 2022, 29(3): 26−30.
ZHAO H T, DONG L H, XIE M Z, et al. Study on preparation of foamed ceramics from coal gangue[J]. China Ceramic Industry, 2022, 29(3): 26−30.
[21] 潘红, 王瑾, 高子栋, 等. 发泡陶瓷多孔保温材料的制备及性能影响研究[J]. 广东建材, 2022, 38(3): 1−5.
PAN H, WANG J, GAO Z D, et al. A studyon preparation and properties influence of porous foamed ceramic[J]. Guangdong Building Materials, 2022, 38(3): 1−5.
[22] 朱建平, 乐红志, 白荣, 等. 利用黄金尾矿制备发泡陶瓷的研究[J]. 硅酸盐通报, 2021, 40(9): 2989−2997.
ZHU J P, YUE H Z, BAI R, et al. Research on preparation of foamed ceramics from gold tailings[J]. Bulletin of the Chinese Ceramic Society, 2021, 40(9): 2989−2997.
[23] LI L, JIANG T, ZHOU M, et al. The influence of temperature and SiC content on the recycling of iron ore tailings for the preparation of value-added foam ceramics[J]. Journal of Material Cycles and Waste Management, 2021, 23: 330−340. doi: 10.1007/s10163-020-01135-x
[24] XIA F, CUI S, PU X. Performance study of foam ceramics prepared by direct foaming method using red mud and K-feldspar washed waste[J]. Ceramics International, 2022, 48(4): 5197−5203. doi: 10.1016/j.ceramint.2021.11.059
-
