Study on Compressive and Flexural Properties of Red Mud/Fly Ash Filling Material for Coal Mine
-
摘要:
以赤泥为主要原料制备煤矿井充填材料，研究了激发剂种类及其掺量、粉煤灰掺量、水泥掺量及加水量对充填材料抗压强度、抗折强度的影响。研究表明：激发剂A（主要成分为木质苯磺酸钙，用量为赤泥干基的0.5%）对充填材料的激发效果最为显著；且在一定条件下抗压、抗折强度下随粉煤灰添加量增加呈先增大后减小的变化趋势；随水泥添加量的增加逐渐增大。通过各方面试验得出最优强度为：28 d抗压强度为1.30 MPa，抗折强度为0.71 Mpa，满足相关充填指标。经过浸出毒性检验，结果表明赤泥基填充材料中重金属元素均达标。
Abstract:Red mud was used as the main raw material to prepare filling materials for coal mines. The effects of the types and amounts of activators, fly ash amounts, cement amounts, and water amounts on the compressive and flexural strength of the filling materials were studied. The research showed that activator A (mainly composed of calcium lignosulfonate and added with 0.5% of dry red mud) had the most significant excitation effect on the filling material. Under certain conditions, the compressive and flexural strength first increased and then decreased with the increase of fly ash amounts, and gradually increased with the increase of the cement amounts. The optimal strength indicators obtained through various tests were as follows, the compressive strength at 28 days was 1.30 MPa, and the flexural strength was 0.71 Mpa, meeting the relevant filling indicators. The results showed that the heavy metal elements in the red mud based filling materials met the relevant emission standards after the leaching toxicity test.
-
Key words:
- coal mine well /
- red mud /
- filling /
- leaching toxicity
-
-
表 1 赤泥的主要化学成分
Table 1. Main chemical composition of red mud
/% 成分 Al2O3 Fe2O3 SiO2 CaO Na2O TiO2 Ga2O3 其他 灼减 含量 20.73 20.74 17.19 15.85 6.39 5.29 0.0044 5.51 8.3
下载: 导出CSV
表 2 粉煤灰的化学成分
Table 2. Chemical composition of fly ash
/% 成分 SiO2 Al2O3 Fe2O3 TiO2 CaO C 含量 46.09 28.08 9.61 3.13 2.74 4.39
下载: 导出CSV
表 3 矿井水的化学成分
Table 3. Chemical composition of mine water
/(mg·L−1) COD 总磷 pH SS 氨氮 总氮 氟化物 硫化物 六价铬 石油类 249 13.4 2.78 106 23.2 50.9 2.41 0.01 0.009 0.72 铁 锰 铜 锌 铅 镉 铬 汞 砷 硒 3195 12.1 1.13 1.71 0.02630 0.31392 0.08 0.00295 0.00471 0.0004
下载: 导出CSV
表 4 赤泥基填充材料毒性浸出结果
Table 4. Toxicity leaching results of red mud based filling materials
/（mg·L−1） 铅 锌 铜 镉 铅 锌 铜 镉 总锰 总铁 ND ND ND ND ND ND ND ND ND ND
下载: 导出CSV
-
[1] 耿超, 郭士会, 刘志国, 等. 赤泥资源化综合利用现状及展望[J]. 中国有色冶金, 2022, 51(5): 37−45.
GENG C, GUO S H, LIU Z G, et al. Status and prospect of comprehensive utilization of red mud resources[J]. Nonferrous Metallurgy of China, 2022, 51(5): 37−45.
[2] 李义伟, 付向辉, 李立, 等. 赤泥综合回收利用研究进展及展望[J]. 稀土, 2020, 41(6): 97−107.
LI Y W, FU X H, LI L, et al. Research progress and prospect of comprehensive recovery and utilization of red mud[J]. Rare Earth, 2020, 41(6): 97−107.
[3] MICHELLE P B, LUCAS F A, LARISSA S R, et al. Evaluation and application of sintered red mud and its incorporated clay ceramics as materials for building construction[J]. Journal of Materials Research and Technology, 2020, 9(2): 2186−2195. doi: 10.1016/j.jmrt.2019.12.049
[4] WANG S X, JIN H X, DENG Y, et al. Comprehensive utilization status of red mud in China: A critical review[J]. Journal of Cleaner Production, 2021, 289(20): 125136.
[5] 于目深, 王旭江, 孙德强, 等. 赤泥资源化利用现状研究[J]. 中国矿业, 2022, 31(6): 1−9.
YU M S, WANG X J, SUN D Q, et al. Current Status of Red Mud Resource Utilization[J]. China Mining, 2022, 31(6): 1−9.
[6] 夏帆, 崔诗才, 蒲锡鹏. 赤泥综合利用现状综述[J]. 中国资源综合利用, 2021, 39(4): 85−89.
XIA F, CUI S C, PU X P. A review on comprehensive utilization of red mud[J]. Comprehensive Utilization of Resources in China, 2021, 39(4): 85−89.
[7] 王旭东, 李伟斌, 赵君, 等. 新型赤泥基充填材料的制备与性能研究[J]. 硅酸盐通报, 2021, 40(4): 1280−1285.
WANG X D, LI W B, ZHAO J, et al. Preparation and properties of new red mud based filling materials[J]. Silicate Bulletin, 2021, 40(4): 1280−1285.
[8] 韩尚云, 姚延伟, 骆虹伟. 拜耳法赤泥脱碱技术与综合利用的研究现状[J]. 科技和产业, 2021, 21(7): 204−207.
HAN S Y, YAO Y W, LUO H W. Research status of dealkalization technology and comprehensive utilization of Bayer red mud[J]. Technology and industry, 2021, 21(7): 204−207.
[9] 陈蛟龙, 刘伟, 石存兰, 等. 赤泥综合利用技术现状及发展建议[J]. 居业, 2022, 4: 26−28.
CHEN J L, LIU W, SHI C L, et al. Present situation and development suggestions of comprehensive utilization technology of red mud[J]. Juye, 2022, 4: 26−28.
[10] 李洪达, 乐红志, 刘金婵, 等. 赤泥放射性的研究现状与进展[J]. 山东理工大学学报(自然科学版), 2020, 34(3): 40−43.
LI H D, LE H Z, LIU J C, et al. Current status and progress of radioactivity in red mud[J]. Journal of Shandong University of Technology ( Natural Science Edition ), 2020, 34(3): 40−43.
[11] 朱逸慧. 凝聚行业力量 开创赤泥综合利用新局面−2021年赤泥综合利用交流推广会召开[J]. 中国有色金属, 2022(2): 52−53.
ZHU Y H. Gather industry strength to create a new situation of comprehensive utilization of red mud - 2021 comprehensive utilization of red mud exchange promotion meeting held[J]. China Nonferrous Metals, 2022(2): 52−53.
[12] GARANAYAK L. Strength effect of alkali activated red mud slag cement in ambient condition[J]. Materials Today: Proceedings, 2021(prepublish).
[13] 幸卫鹏. 赤泥综合利用评述[J]. 世界有色金属, 2019(8): 269−270.
XING W P. Review on comprehensive utilization of red mud[J]. World Nonferrous Metals, 2019(8): 269−270.
[14] 刘培坤, 姜兰越, 杨兴华, 等. 全重选法赤泥选铁富集性能试验研究[J]. 轻金属, 2017(6): 22−27.
LIU P K, JIANG L Y, YANG X H, et al. Experimental study on iron enrichment performance of red mud by full gravity separation[J]. Light metals, 2017(6): 22−27.
[15] 季文君, 刘云, 李哲. 赤泥及粉煤灰制备免烧砖的工艺探究[J]. 中北大学学报(自然科学版), 2019, 40(6): 568−572.
JI W J, LIU Y, LI Z. Study on preparation technology of baking-free brick from red mud and fly ash[J]. Journal of North University of China (Natural Science Edition), 2019, 40(6): 568−572.
[16] 张宁, 高益凡, 李召峰, 等. 高掺量赤泥基路基充填材料试验研究[J]. 中国资源综合利用, 2020, 38(11): 10−13.
ZHANG N, GAO Y F, LI Z F, et al. Experimental study on high content red mud subgrade filling material[J]. China Resources Comprehensive Utilization, 2020, 38(11): 10−13.
[17] 满慎刚, 倪文, 祝丽萍. 矿渣及赤泥制备矿山充填胶结剂对煤矿安全管理的促进[J]. 中国煤炭, 2013(11): 120−123, 129.
MAN S G, NI W, ZHU L P. Slag and red mud preparation of mine filling cementing agent to promote coal mine safety management[J]. China Coal, 2013(11): 120−123, 129.
[18] 刘庆, 王强, 吴蓬, 等. 赤泥在胶凝材料中的应用研究进展[J]. 山东科技大学学报(自然科学版), 2022, 41(3): 66−74.
LIU Q, WANG Q, WU P, et al. Research progress on application of red mud in cementitious materials[J]. Journal of Shandong University of Science and Technology (Natural Science Edition), 2022, 41(3): 66−74.
[19] 颜贵红. 酸激发水泥基材料力学及收缩性能研究[D]. 中国矿业大学, 2018
YAN G H. Study on mechanics and shrinkage properties of acid-activated cement-based materials [D]. China University of Mining and Technology, 2018.
[20] 张翔, 何廷树, 何娟. 硅酸盐水泥-粉煤灰-脱硫石膏复合材料的性能研究[J]. 硅酸盐通报, 2014, 33(4): 796−799.
ZHANG X, HE T S, HE J. Study on properties of silicate cement-fly ash-desulfurized gypsum composites[J]. Silicate Bulletin, 2014, 33(4): 796−799.
[21] 张乐, 赵苏, 梁颖. 赤泥-粉煤灰-水泥胶砂力学性能研究[J]. 低温建筑技术, 2009, 31(1): 14−16.
ZHANG L, ZHAO S, LIANG Y. Study on mechanical properties of red mud-fly ash-cement mortar[J]. Low Temperature Building Technology, 2009, 31(1): 14−16.
[22] 纪爱民. 混凝土及水泥制品中的水[J]. 混凝土与水泥制品, 2012(6): 33−36.
JI A M. Water in concrete and cement products[J]. Concrete and Cement Products, 2012(6): 33−36.
-
