高梯度磁选理论与技术进展

赵嘉艺; 王星星; 祁磊; 赵志强; 王飞旺; 文金磊; 戴惠新

doi:10.13779/j.cnki.issn1001-0076.2024.03.013

高梯度磁选理论与技术进展

1.
昆明理工大学国土资源工程学院，云南昆明 650093

2.
矿物加工科学与技术国家重点实验室，北京 102628

3.
普洱市检验检测院，云南普洱 665099

4.
鹤庆北衙矿业有限公司，云南大理 671000

5.
豫光（成都）科技有限公司，四川成都 610100

基金项目: 国家自然科学基金项目(52364033);矿物加工科学与技术国家重点实验室开放基金项目(BGRIMM−KISKL−2023−12)

详细信息

作者简介: 赵嘉艺（2001—），男，硕士，主要从事磁电选矿理论与数值模拟、磁选设备研发，E-mail：zhaojiayi_mail@163.com; 王飞旺，男，1990年9月生，工学博士（博士后），内聘副教授，硕士生导师，云南省“兴滇英才支持计划”青年人才，担任《矿产保护与利用》《化工矿物与加工》等期刊青年编委。主要研究方向：（1）磁电选矿理论、工艺与数值模拟；（2）新型磁选设备研究与开发；（3）复杂难处理矿产资源综合利用。作为研究骨干参与国家自然科学基项目及企业委托项目20 余项，主持中国博士后科学基金、云南省博士后定向培养资助、云南省基础研究计划青年项目、国家重点实验室开放基金等项目；申请专利 20余件，获授权专利 10 件；发表论文 30 余篇，其中以第一作者发表 SCI 论文 7 篇（JCR 1 区 5 篇）；获2021年第一届全国博士后创新创业大赛创业赛全国优胜奖（排名第一，中国人力资源社会保障部颁发），获2022年云南省优秀博士学位论文奖（云南省教育厅颁发），获2024年中国发明协会发明创新奖二等奖（排名第一，中国发明协会颁发）

通讯作者: 王飞旺（1990—），男，讲师，主要从事磁电选矿理论与数值模拟、磁选设备研发，E-mail：wangfw0310@qq.com。

中图分类号: TD924

收稿日期: 2024-05-20

刊出日期: 2024-06-15

Progress in the Theory and Technology of Highgradient Magnetic Separation

1.
School of Land and Resource Engineering, Kunming University of Science and Technology, Kunming 650093, Yunnan, China

2.
State Key Laboratory of Mineral Processing, Beijing 102628, China

3.
Inspection and Testing Institute of Pu'er, Pu'er 665099, Yunnan, China

4.
Heqing Beiya Mining Co., Ltd, Dali 671000, Yunnan, China

5.
Yuguang (Chengdu) Technology Co., Ltd, Chengdu 610100, Sichuan, China

More Information

Corresponding author: WANG Feiwang, wangfw0310@qq.com

Received Date: 20 May 2024

Publish Date: 15 June 2024

摘要

摘要:
在高梯度磁选分离过程中存在机械夹带、磁性夹带、竞争捕获等现象，最终导致选择性差、分选腔堵塞、分选效率低等一系列问题。目前科研工作者针对高梯度磁选的理论研究主要集中于对颗粒受力分析并力的大小计算、颗粒轨迹模型和颗粒堆积模型的构建、聚磁介质的研发与优化。以颗粒受力为基础，通过颗粒的堆积模型和轨迹模型分析造成选择性差以及效率低的原因，综述聚磁介质的研发与优化，旨在为高梯度磁选技术在工业应用中的优化与理论研究提供参考，并对高梯度磁选技术理论研究的未来趋势进行展望。
- 磁选 /
- 高梯度 /
- 磁场分布 /
- 夹带
Abstract:
Mechanical entrainment, magnetic entrainment and competitive capture occur in the separation process of high gradient magnetic separation, ultimately leading to a number of problems such as poor selectivity, clogging of the sorting chamber and low sorting efficiency. At present, the theoretical study of high gradient magnetic separation mainly focuses on particle force analysis and calculation, the construction of particle trajectory model and particle stacking model, and the research and development and optimisation of polymagnetic media. Based on the particle force, this paper analyses the causes of poor selectivity as well as low efficiency through the particle stacking model and trajectory model, and reviews the development and optimization of matrix, aiming to provide a reference for the optimization and theoretical research of high-gradient magnetic separation technology in industrial applications, as well as looking forward to the future trend of theoretical research of high-gradient magnetic separation technology.
- magnetic separation /
- high gradients /
- field distribution /
- particle entrainment

HTML全文

图 1 机械夹带示意图(a—穿透；b—滞留；c—拦截)^[8]

Figure 1.

下载: 全尺寸图片幻灯片

图 2 吸引夹带示意图(a—连生体吸引；b—黏附吸引)^[7]

Figure 2.

下载: 全尺寸图片幻灯片

图 3 颗粒在聚磁介质上堆积示意图（a—低磁场中；b—高磁场中）^[10]

Figure 3.

下载: 全尺寸图片幻灯片

图 4 直径为a的聚磁介质周围的磁场分布^[8]

Figure 4.

下载: 全尺寸图片幻灯片

图 5 聚磁介质的横截面^[23]

Figure 5.

下载: 全尺寸图片幻灯片

图 6 围绕聚磁介质的颗粒运动轨迹（a—纵向配置;b—横向配置）^[24]

Figure 6.

下载: 全尺寸图片幻灯片

图 7 不同直径聚磁介质周围的磁场分布^[38]

Figure 7.

下载: 全尺寸图片幻灯片

图 8 聚磁介质矩形排列方式(左)和聚磁介质菱形排列方式(右)^[45]

Figure 8.

下载: 全尺寸图片幻灯片

参考文献(56)

[1]	DAI P, TAO M, LI X. Effect of lime (CaOH⁺) on chalcopyrite−arsenopyrite separation in high gradient magnetic separation: Experiment and molecular simulation[J]. Separation and Purification Technology, 2024, 333: 2−7.
[2]	HU Z, HAN L, LU D, et al. Pulsation curves strengthen the high gradient magnetic separation process Ⅱ: Consideration of separation performance[J]. Minerals Engineering, 2024, 205: 108480−108490. doi: 10.1016/j.mineng.2023.108480
[3]	LI W, SUN J, ZHANG X, et al. Influence of the screw−thread rod matrix on the magnetic capture behavior of bastnaesite[J]. Powder Technology, 2024, 440: 119738−119752. doi: 10.1016/j.powtec.2024.119738
[4]	LIN H , LI X , LEI Z, et al. Developing high gradient magnetic separators for greener production: Principles, design, and optimization[J]. Journal of Magnetism and Magnetic Materials, 2023: 587.
[5]	ZHENG X, WANG Y, LU D. A realistic description of influence of the magnetic field strength on high gradient magnetic separation[J]. Minerals Engineering, 2015, 79: 94−101. doi: 10.1016/j.mineng.2015.06.004
[6]	WATSON JHP, LI Z. A study on mechanical entrapment in HGMS and vibration HGMS[J]. Minerals Engineering, 1991, 4(7/8/9/10/11): 815−823.
[7]	HU Z, LIU J, GAN T, et al. High−intensity magnetic separation for recovery of LiFePO₄ and graphite from spent lithium−ion batteries[J]. Separation and Purification Technology, 2022, 297: 121486−121499. doi: 10.1016/j.seppur.2022.121486
[8]	XUE Z, WANG Y, ZHENG X, et al. Mechanical entrainment study by separately collecting particle deposit on matrix in high gradient magnetic separation[J]. Minerals Engineering, 2022, 178: 107435−10746. doi: 10.1016/j.mineng.2022.107435
[9]	XIONG D, LIU S, CHEN J. New technology of pulsating high gradient magnetic separation[J]. International Journal of Mineral Processing, 1998, 54(2): 111−127. doi: 10.1016/S0301-7516(98)00009-X
[10]	SVOBODA J. The effect of magnetic field strenght on the efficiency of magnetic separation[J]. Minerals Engineering, 1994, 7(5): 747−757.
[11]	ZHENG X, WANG Y, LU D. Investigation of the particle capture of elliptic cross−sectional matrix for high gradient magnetic separation[J]. Powder Technology, 2016, 297: 303−310. doi: 10.1016/j.powtec.2016.04.032
[12]	ZHENG X, XUE Z, WANG Y, et al. Modeling of particle capture in high gradient magnetic separation: A review[J]. Powder Technology, 2019, 352: 159−169. doi: 10.1016/j.powtec.2019.04.048
[13]	HU Z, LU D, ZHENG X, et al. Development of a high−gradient magnetic separator for enhancing selective separation: A review[J]. Powder Technology, 2023, 421: 118435−118445. doi: 10.1016/j.powtec.2023.118435
[14]	CHEN L. Effect of magnetic field orientation on high gradient magnetic separation performance[J]. Minerals Engineering, 2011, 24(1): 88−90. doi: 10.1016/j.mineng.2010.09.019
[15]	HU Z. Model of particle accumulation on matrices in transverse field pulsating high gradient magnetic separator[J]. Minerals Engineering, 2020, 146: 106105−106116. doi: 10.1016/j.mineng.2019.106105
[16]	DAHE X. Dynamic analysis of weakly magnetic mineral particles in high gradient magnetic field of rod medium[J]. Metal Mine, 1998, 8: 9−12.
[17]	YING T Y, YIACOUMI S, TSOURIS C. High−gradient magnetically seeded filtration[J]. Chemical Engineering Science, 2000, 55(6): 1101−1113. doi: 10.1016/S0009-2509(99)00383-8
[18]	JOSHI J B, NANDAKUMAR K, PATWARDHAN A W, et al. Computational fluid dynamics[M]//Advances of Computational Fluid Dynamics in Nuclear Reactor Design and Safety Assessment. Elsevier, 2019, 21−138.
[19]	NESSET J, FINCH J. The static (buildup) model of particle accumulation on single wires in high gradient magnetic separation: Experimental confirmation[J]. IEEE Trans Magn, 1981, 17(4): 1506−1509. doi: 10.1109/TMAG.1981.1061242
[20]	WATSON J H P, LI Z. Theoretical and single−wire studies of vortex magnetic separation[J]. Minerals Engineering, 1992, 5(10/11/12): 1147−1165. doi: 10.1016/0892-6875(92)90156-4
[21]	XUE Z, WANG Y, ZHENG X, et al. Role of gravitational force on mechanical entrainment of nonmagnetic particles in high gradient magnetic separation[J]. Minerals Engineering, 2022, 186: 107726−107735. doi: 10.1016/j.mineng.2022.107726
[22]	许金越, 王伊琳, 宋少先. 干式振动高梯度磁选机的分选机理与试验研究[J]. 金属矿山, 2023(2): 189−195. XU J Y, WANG Y L, SONG S X. Sorting mechanism and experimental study of dry vibrating high gradient magnetic separator[J]. Metal Mine, 2023(2): 189−195.
[23]	WATSON J H P. Magnetic filtration[J]. Journal of Applied Physics, 1973, 44(9): 4209−4213. doi: 10.1063/1.1662920
[24]	WATSON J H P. Theory of capture of particles in magnetic high−intensity filters[J]. IEEE Transactions on Magnetics, 1975, 11(5): 1597−1599. doi: 10.1109/TMAG.1975.1058807
[25]	LUBORSKY F, DRUMMOND B. High gradient magnetic separation: Theory versus experiment[J]. IEEE Trans. Magn, 1975, 6: 1696−1700.
[26]	BADESCU, V, ROTARIU, et al. Magnetic capture modelling for a transversal high filter[J]. International Journal of Applied Electromagnetics and Mechanics, 1996, 7: 57−67.
[27]	EBNER NA, GOMES CSG, HOBLEY TJ, et al. Filter capacity predictions for the capture of magnetic microparticles by high−gradient magnetic separation[J]. IEEE Trans Magn, 2007, 43(5): 1941−1949. doi: 10.1109/TMAG.2007.892080
[28]	GE W, ENCINAS A, ARAUJO E, et al. Magnetic matrices used in high gradient magnetic separation (HGMS): A review[J]. Results in Physics, 2017, 7: 4278−4286. doi: 10.1016/j.rinp.2017.10.055
[29]	LESLIE B W. Magnetic separator: CAD715885[P]. CA715885A[2024−06−16].
[30]	SVOBODA J, FUJITA T. Recent developments in magnetic methods of material separation[J]. Minerals Engineering, 2003, 16(9): 785−792. doi: 10.1016/S0892-6875(03)00212-7
[31]	SVOBODA J. Magnetic techniques for the treatment of materials[M]. Springer Netherlands, 2004.
[32]	KOLM H H. Process for magnetic separation: US3676337D[P]. 2024−03−24.
[33]	李文博, 韩跃新, 汤玉和, 等. 高梯度磁选机聚磁介质的研究概况及发展趋势[J]. 金属矿山, 2012, 41(9): 129−133. doi: 10.3969/j.issn.1001-1250.2012.09.035 LI W B, HAN Y X, TANG Y H, et al. Research overview and development trend of matrix for high gradient magnetic separator[J]. Metal Mine, 2012, 41(9): 129−133. doi: 10.3969/j.issn.1001-1250.2012.09.035
[34]	白江虎, 李具仓, 张志刚, 等. 聚磁介质用不锈导磁材料开发[J]. 中国冶金, 2017, 27(12): 4. BAI J H, LI J C, ZHANG Z G, et al. Development of Stainless Conductive Materials for matrix[J]. China Metallurgy, 2017, 27(12): 4.
[35]	GRAHAM MD. A precaution on using 316L stainless wire in HGMS matrices[J]. Magnetic Separation News, 1986, 2(2): 91−94. doi: 10.1155/1986/75394
[36]	WU W, WU C, HONG PKA, LIN C. Capture of metallic copper by high gradient magnetic separation system[J]. Environmental Technology, 2011, 32(13): 1427−1433. doi: 10.1080/09593330.2010.538439
[37]	黄燕, 李思媛. 一种铁钴合金/氮共掺杂碳气凝胶电极材料的制备方法: CN02010498865.0[P].[2024−06−16] HUANG Y, LI S Y. Preparation of an iron−cobalt alloy/nitrogen co−doped carbon aerogel electrode material: CN02010498865.0[P]. [2024−06−16].
[38]	ZHENG X, WANG Y, LU D, et al. Theoretical and experimental study on elliptic matrices in the transversal high gradient magnetic separation[J]. Minerals Engineering, 2017, 111: 68−78. doi: 10.1016/j.mineng.2017.06.007
[39]	BADESCU V, MURARIU V, ROTARIU O, et al. A new modeling of the initial buildup evolution on a wire in an axial HGMF filter[J]. Journal of Magnetism and Magnetic Materials, 1996, 163(1/2): 225−231. doi: 10.1016/S0304-8853(96)00319-8
[40]	ZHENG X, WANG Y, LU D. Study on capture radius and efficiency of fine weakly magnetic minerals in high gradient magnetic field[J]. Minerals Engineering, 2015, 74: 79−85. doi: 10.1016/j.mineng.2015.02.001
[41]	李文博, 汤玉和, 韩跃新, 等. 聚磁介质对高梯度磁选效果的影响[J]. 金属矿山, 2013, 42(12): 105−107. LI W B, TANG Y H, HAN Y X, et al. Influence of matrix on the effectiveness of high gradient magnetic separation[J]. Metal Mine, 2013, 42(12): 105−107.
[42]	于洪军, 王忠生, 李东, 等. 聚磁介质充填率对齐大山选矿厂赤铁矿高梯度强磁选的影响[J]. 金属矿山, 2017(12): 4. doi: 10.3969/j.issn.1001-1250.2017.12.024 YU H J, WANG Z S, LI D, et al. Influence of matrix filling rate on high gradient strong magnetic separation of hematite in Qidashan processing plant[J]. Metal Mine, 2017(12): 4. doi: 10.3969/j.issn.1001-1250.2017.12.024
[43]	CHEN L, LIU W, ZENG J, et al. Quantitative investigation on magnetic capture of single wires in pulsating HGMS[J]. Powder Technology, 2017, 313: 54−59. doi: 10.1016/j.powtec.2017.03.011
[44]	REN L, ZENG S, ZHANG Y. Magnetic field characteristics analysis of a single assembled magnetic medium using ANSYS software[J]. International Journal of Mining Science and Technology, 2015, 25(3): 479−487. doi: 10.1016/j.ijmst.2015.03.024
[45]	ZHENG X, GUO N, CUI R, et al. Magnetic Field simulation and experimental tests of special cross−section shape matrices for high gradient magnetic separation[J]. IEEE Transactions on Magnetics, Published online 2017, 53(3): 1−10.
[46]	XUE Z, WANG Y, ZHENG X, et al. Particle capture of special cross−section matrices in axial high gradient magnetic separation: A 3D simulation[J]. Separation and Purification Technology, 2020, 237: 116375−116386. doi: 10.1016/j.seppur.2019.116375
[47]	LI W, ZHOU L, HAN Y, et al. Numerical simulation and experimental verification for magnetic field analysis of thread magnetic matrix in high gradient magnetic separation[J]. Powder Technology, 2019, 355: 300−308. doi: 10.1016/j.powtec.2019.07.024
[48]	LI W, SUN J, ZHANG X, et al. Influence of the screw−thread rod matrix on the magnetic capture behavior of bastnaesite[J]. Powder Technology, 2024, 440: 1197738−1197749.
[49]	黄建雄. 高梯度磁选过程的棒介质排列组合研究[D]. 昆明: 昆明理工大学, 2013. HUANG J X. Study of matrix arrangement combinations for high gradient magnetic separation processes [D]. Kunming: Kunming University of Science and Technology, 2013.
[50]	CHEN L, DING L, ZHANG H, et al. Slice matrix analysis for combinatorial optimization of rod matrix in PHGMS[J]. Minerals Engineering, 2014, 58: 104−107. doi: 10.1016/j.mineng.2014.01.024
[51]	CHEN L Z, XU G D, WEN S M, et al. Effect of rod arrangement in matrix on high gradient magnetic separation performance[J]. Advanced Materials Research, 2013, 634/635/636/637/638: 3351−3354. doi: 10.4028/www.scientific.net/AMR.634-638.3351
[52]	丁利. 高梯度磁选过程的组合式棒介质研究[D]. 昆明: 昆明理工大学, 2014 DING L. Study of combined matrix for high gradient magnetic separation processes[D]. Kunming: Kunming University of Science and Technology, 2014
[53]	舒有顺, 曾海鹏, 黄红军. 六偏磷酸钠对钾长石和赤铁矿的分散作用机理[J]. 矿冶工程, 2023, 43(2): 61−65. doi: 10.3969/j.issn.0253-6099.2023.02.014 SHU Y, ZENG H, HUANG H. Dispersion mechanism of sodium hexametaphosphate on potassium feldspar and hematite[J]. Mimimg And Metallurgical Engeering, 2023, 43(2): 61−65. doi: 10.3969/j.issn.0253-6099.2023.02.014
[54]	许耀群, 李曙光, 王娟, 等. 超声波及分散剂对纳米SiO₂/CaCO₃/Al₂O₃颗粒分散特性的影响[J]. 材料导报, 2018, 32(S1): 300−304. XU Y Q, LI S G, WANG J, et al, Effect of dispersion characteristics of Nano−SiO₂/CaCO₃/Al₂O₃ by ultrasonicand dispersants[J]. Materials Reports, 2018, 32(S1): 300−304.
[55]	HUANG Z, LIN M, QIU R, et al. A novel technology of recovering magnetic micro particles from spent lithium−ion batteries by ultrasonic dispersion and waterflow−magnetic separation[J]. Resources Conservation and Recycling, 2021, 164(3): 105172−105181.
[56]	魏婷婷. 砂质高岭土选矿提纯试验研究[D]. 武汉: 武汉理工大学, 2009. WEI T T. Experimental study on the preparation and purification of sandy kaolinite [D]. Wuhan: Wuhan University of Technology, 2009.
