Numerical Simulation Study on Technology Optimization of Large Section High Fully Mechanized Caving Mining in Vertical Coal Seam
-
摘要:
乌东煤矿西采区近直立煤层采用水平分段综放开采。为提高生产效率，可通过适当提升水平分段高度代替延长较短的工作面，因此需对大段高条件下近直立煤层水平分段综放开采顶煤运移规律进行研究并优化放煤工艺参数以提高顶煤回收率。结合现场实测数据建立了各层位顶煤块度级配下的放煤模型，通过颗粒流离散元数值分析得出了大段高条件下初始放煤及周期放煤过程中顶煤运移规律，并对不同放煤参数及放煤顺序的顶煤回收量及煤损情况进行分析，提出了适用于乌东煤矿B3−6工作面的合理放煤工艺。结果表明：大段高条件下，周期放煤过程中煤矸分界线的底口处有向右侧偏转回勾的趋势，放出口提前见矸导致后续多步的放煤量较小，煤矸分界线严重滞后于放煤口，遗煤区域较大，可适当采用过量放煤缓解分界线回勾程度；采用6 m采高时，在周期放煤前期时放出体发育、顶煤流动性更好，产生的遗煤区相对较小；采用2.4 m放煤步距条件下每步放煤量更多且有助于缓解见矸过快问题；采用分段大间隔放煤方式分可以有效减小煤矸分界线的影响，遗煤范围最少，顶煤回收率达到93.23%。
Abstract:Wudong Coal Mine West Mining Area near vertical coal seam adopts horizontal section top−coal caving. In order to improve the production efficiency, the working face with short extension can be replaced by appropriately increasing the height of horizontal section. Therefore, it is necessary to study the top coal migration law of horizontal section top−coal caving in near vertical coal seam under the condition of large section height and optimize the coal caving technique to improve the top coal recovery rate. Combined with the field measured data, the model of coal drawing method under the condition of top coal size distribution of each layer is established. The top coal migration law in the process of initial coal drawing and periodic coal drawing under the condition of large section height are obtained by the Particle Flow Code numerical calculation. The top coal recovery and coal loss of each coal drawing parameter and order are analyzed, and the reasonable coal drawing technique suitable for B3−6 working face of Wudong Coal Mine is put forward. The results show that under the condition of large section height, the bottom of the coal−gangue boundary has a tendency to deflect to the right side during the periodic coal drawing process. The advance of the drawing opening position leads to a small amount of coal drawing in the subsequent multi−steps, and the coal−gangue boundary is seriously lagging behind the drawing opening position. The area of remnant coal is large. Therefore, excessive coal drawing can be appropriately used to alleviate the degree of demarcation of the boundary. When the mining height is 6 m, the development of coal drawing body and the fluidity of top coal are better in the early stage of periodic coal drawing, and the area of remnant coal is small. When the coal drawing interval is 2.4 m, the discharge amount of coal for each step is more and it is helpful to alleviate the problem of too fast seeing gangue. The coal drawing of “subsection drawing with large interval” can effectively reduce the influence of coal−gangue boundary line. The area of remnant coal is the smallest and the recovery of top coal reaches 93.23%.
-
-
表 1 4#架放煤块度
Table 1. No. 4 hydraulic support coal drawing block degree
顶煤块度
范围/cm平均块度
/cm质量
/kg质量分数
/%累积质量
分数/%<10 5.0 7.69 13.83 13.83 10~15 12.5 5.41 9.73 23.56 15~20 17.5 4.17 7.50 31.06 20~25 22.5 1.47 2.64 33.70 25~30 27.5 4.84 8.71 42.41 30~35 32.5 14.62 26.30 68.71 35~40 37.5 17.40 31.29 100.00 总计 / 55.60 100.00 /
下载: 导出CSV
表 2 12#架放煤块度
Table 2. No. 12 hydraulic support coal drawing block degree
顶煤块度
范围/cm平均块度
/cm质量
/kg质量分数
/%累积质量
分数/%<10 5.0 8.92 12.63 12.63 10~15 12.5 2.97 4.21 16.84 15~20 17.5 3.17 4.49 21.33 20~30 25 2.89 4.09 25.42 30~40 32.5 9.90 14.02 39.44 40~50 37.5 21.00 29.75 69.19 50~55 52.5 21.80 30.81 100.00 总计 / 70.60 100.00 /
下载: 导出CSV
表 3 24#架放煤块度
Table 3. No. 24 hydraulic support coal drawing block degree
顶煤块度
范围/cm平均块度
/cm质量
/kg质量分数
/%累积质量
分数/%<10 5.0 10.25 14.60 14.60 10~15 12.5 2.07 2.95 17.55 15~20 17.5 4.11 5.85 23.40 20~25 22.5 2.13 3.04 26.44 25~30 27.5 3.47 4.94 31.38 30~35 32.5 18.28 26.07 57.45 35~40 37.5 29.90 42.55 100.00 总计 / 70.21 100.00 /
下载: 导出CSV
表 4 顶煤块度均值、标准差及变异系数
Table 4. Mean, standard deviation and coefficient of variation of top coal lumpiness
支架编号 块度均值/cm 标准差/cm 变异系数 4# 27.587 12.746 0.46 12# 39.238 17.320 0.44 24# 28.496 11.897 0.42 整体 31.774 13.988 0.44
下载: 导出CSV
表 5 工作面整体顶煤块度占比
Table 5. Percentage of overall top coal lumps in the working face
顶煤块度范围/cm 质量/kg 质量分数/% 累积质量分数/% <10 26.86 13.68 13.68 10~15 10.45 5.32 19.00 15~20 11.45 5.83 24.83 20~25 3.60 1.83 26.66 25~30 11.15 5.68 32.34 30~35 23.67 12.05 44.39 35~40 49.03 24.96 69.35 40~50 17.40 8.86 78.21 50~55 42.80 21.79 100.00 总计 196.41 100.00 /
下载: 导出CSV
表 6 模拟煤矸颗粒参数表
Table 6. Parameters of simulated gangue particles
岩层 法向刚度
kn/(N·m−1)切向刚度
ks/(N·m−1)密度
ρ/(kg·m−3)块度
/cm摩擦
系数下位煤层 2×108 2×108 1440 0~30 0.4 中位煤层 2×108 2×108 1440 40~55 0.4 上位煤层 2×108 2×108 1440 30~40 0.4 垮落矸石 4×108 4×108 2500 40~60 0.4
下载: 导出CSV
表 7 模拟顶煤颗粒块度级配表
Table 7. Simulated top coal particle lumpiness grading table
顶煤块度范围/cm 各层位顶煤颗粒体积占比/% 下位顶煤 中位顶煤 上位顶煤 <10 42.29 / / 10~15 16.45 / / 15~20 18.03 / / 20~25 5.67 / / 25~30 17.56 / / 30~35 / / 32.56 35~40 / / 67.44 40~50 / 28.91 / 50~55 / 71.09 / 总计 100.00 100.00 100.00
下载: 导出CSV
表 8 各采高损煤率
Table 8. Coal loss ratio of mining height
采高/m 放煤总量/m2 遗煤量/m2 损煤率/% 4 793.60 107.12 13.50 5 768.00 101.76 13.24 6 742.40 88.71 11.95
下载: 导出CSV
表 9 各放出步距损煤率
Table 9. Coal loss rates by different coal drawing interval
步距/m 放煤总量/m2 遗煤量/m2 损煤率/% 1.6 742.40 88.71 11.95 2.4 779.52 93.31 11.97 3.2 742.40 98.98 13.44
下载: 导出CSV
表 10 倾向模型颗粒参数
Table 10. Table of particle parameters for tendency models
岩层 法向刚度
kn/(N·m−1)切向刚度
ks/(N·m−1)密度
ρ/(kg·m−3)块度/cm 摩擦
系数顶煤 2×108 2×108 1440 见区间级配 0.4 顶板 4×108 4×108 2500 40~60 0.4 底板 4×108 4×108 2500 40~60 0.4 垮落矸石 4×108 4×108 2500 40~60 0.4
下载: 导出CSV
表 11 各放煤方式的顶煤回收率
Table 11. Top coal recovery rates for different coal drawing methods
放煤方式 放出量/m2 回收率/% 顺序放煤 1027.82 85.54 端头逆序 1061.23 88.32 分段大间隔 1120.23 93.23
下载: 导出CSV
-
[1] 袁祥清. 浅谈我国急倾斜煤层开采方法应用现状[J]. 内蒙古煤炭经济, 2020, 38(21): 175−176.
YUAN X Q. Brief discussion on the application status of coal mining methods for steeply dipping coal seams in China[J]. Inner Mongolia Coal Economy, 2020, 38(21): 175−176.
[2] 杜长勇. 我国急倾斜煤层开采方法应用现状[J]. 中小企业管理与科技(上旬刊), 2015, 34(5): 100−101.
DU C Y. The application status of steeply dipping coal seam mining methods in China[J]. Management & Technology of SME, 2015, 34(5): 100−101.
[3] DENG Y H, WANG S Q. Feasibility analysis of gob−side entry retaining on a working face in a steep coal seam[J]. International Journal of Mining Science and Technology, 2014, 24(4): 499−503. doi: 10.1016/j.ijmst.2014.05.013
[4] 伍永平, 刘孔智, 贠东风, 等. 大倾角煤层安全高效开采技术研究进展[J]. 煤炭学报, 2014, 39(8): 1611−1618.
WU Y P, LIU Z K, YUN D F, et al. Research progress on the safe and efficient mining technology of steeply dipping seam[J]. Journal of China Coal Society, 2014, 39(8): 1611−1618.
[5] 董燕, 李圣军, 杨锡军. 急倾斜中厚煤层水平分段液压支架放顶煤开采技术研究[J]. 能源与环保, 2017, 39(5): 60−64+69.
DONG Y, LI S J, YANG X J. Research on horizontal section hydraulic support top−coal caving of inclined medium−thickness seam[J]. China Energy and Environmental Protection, 2017, 39(5): 60−64+69.
[6] 张锋刚, 杨文连. 急倾斜水平分段放顶煤开采应力分布规律及冲击地压防治[J]. 煤矿安全, 2023, 54(7): 101−108.
ZHANG F G, YANG W L. Stress distribution law of steeply inclined horizontal sectional caving coal mining and prevention and control of rock burst[J]. Safety in Coal Mines, 2023, 54(7): 101−108.
[7] 华乐. 天河煤矿急倾斜厚煤层采煤方法优化研究[D]. 淮南: 安徽理工大学, 2015.
HUA L. Tianhe coal mine steeply inclined thick seam coal mining method optimization research[D]. Huainan: Anhui University of Science and Technology, 2015.
[8] 王家臣, 陈祎, 张锦旺. 基于BBR的特厚煤层综放开采放煤方式优化研究[J]. 煤炭工程, 2016, 48(2): 1−4.
WANG J C, CHEN Y, ZHANG J W. Optimization study on drawing technique of longwall top−coal caving in extra−thick coal seam based on BBR system[J]. Coal Engineering, 2016, 48(2): 1−4.
[9] 张锦旺, 程东亮, 王家臣, 等. 水平分段综放开采顶煤放出体理论计算模型[J]. 煤炭学报, 2023, 48(2): 576−592.
ZHANG J W, CHENG D L, WANG J C, et al. Theoretical calculation model of top coal drawing body in horizontal sublevel top coal caving mining[J]. Journal of China Coal Society, 2023, 48(2): 576−592.
[10] 伍永平, 来兴平, 王小林, 等. 水平分段放顶煤采面预爆回收三角煤研究[J]. 矿山压力与顶板管理, 2000(4): 26−28.
WU Y P, LAI X P, WANG X L, et al. Study on pre−explosion recovery of triangular coal in horizontal sublevel caving mining face[J]. Journal of Mining & Safety Engineering, 2000(4): 26−28.
[11] 关书方, 杨健男, 姜志刚, 等. 大倾角综放工作面顶煤损失分布特征及放煤步距优化[J]. 煤炭工程, 2024, 56(9): 72−77.
GUAN S F, YANG J N, JIANG Z G, et al. Top coal loss distribution and optimization of coal caving interval in fully mechanized face with large dip angle[J]. Coal Engineering, 2024, 56(9): 72−77.
[12] 许力峰, 张勇, 李立, 等. 特厚煤层综放开采顶煤放出率影响因素分析[J]. 煤矿开采, 2012, 17(6): 25−28+45.
XU L F, ZHANG Y, LI L, et al. Influence factors of top−coal caving ratio in full−mechanized caving mining extremely−thick coal−seam[J]. Journal of Mining And Strata Control Engineering, 2012, 17(6): 25−28+45.
[13] 王家臣, 杨胜利, 李良晖, 等. 智能放煤理论与技术研究进展[J]. 工矿自动化, 2024, 50(9): 1−12.
WANG J C, YANG S L, LI L H, et al. Research progress on intelligent coal caving theory and technology[J]. Journal of Mine Automation, 2024, 50(9): 1−12.
[14] 王盛泽, 高国英. 新疆及其邻近地区现代构造应力场的区域特征[J]. 地震学报, 1992(S1): 612−620+736.
WANG S Z, GAO G Y. Regional characteristics of modern tectonic stress fields in Xinjiang and its adjacent areas[J]. Acta Seismologica Sinica, 1992(S1): 612−620+736.
[15] 魏炜杰. 考虑顶煤块度分布的综放开采顶煤放出规律研究[D]. 北京: 中国矿业大学(北京), 2021.
WEI W J. Drawing mechanism of top coal considering the size distribution in longwall top coal caving mining[D]. Beijing: China University of Mining & Technology, Beijing, 2021.
[16] 刘迪, 徐全军, 温尊礼, 等. 岩体的节理裂隙对爆破块度分布的影响分析[J]. 西部探矿工程, 2016, 28(3): 188−191.
LIU D, XU Q J, WEN Z L, et al. Analysis on the effect of joints and fractures of rock mass on blasting fragmentation distribution[J]. West−China Exploration Engineering, 2016, 28(3): 188−191.
[17] 刘一帆, 王梅, 王晨龙, 等. 地应力下节理岩体爆破损伤演化数值研究[J]. 工程爆破, 2023, 29(4): 61−68.
LIU Y F, WANG M, WANG C L, et al. Numerical study on blasting damage evolution of jointed rock mass under in−situ stress[J]. Engineering Blasting, 2023, 29(4): 61−68.
[18] 王家臣, 富强. 低位综放开采顶煤放出的散体介质流理论与应用[J]. 煤炭学报, 2002(4): 337−341.
WANG J C, FU Q. The loose medium flow field theory and its application on the longwall top−coal caving[J]. Journal of China Coal Society, 2002(4): 337−341.
[19] WEI W, WANG J, ZHANG J, et al. Drawing mechanisms of granular top coal considering the structure of hydraulic support in longwall top coal caving[J]. Bulletin of Engineering Geology and the Environment, 2023, 82(4): 138. doi: 10.1007/s10064-023-03173-9
[20] 于斌. 大采高综放割煤高度合理确定及放煤工艺研究[J]. 煤炭科学技术, 2011, 39(12): 29−32.
YU B. Study on rational mining height of fully mechanized top coal caving mining and top coal caving technology[J]. Coal Science and Technology, 2011, 39(12): 29−32.
-
