Field Rapid Determination of Platinum and Palladium in Geochemical Samples by Spectrophotometry with Sulfhydryl Cotton Enrichment
-
摘要:
对于地球化学样品中铂钯的测定, 传统和现代分析方法均是建立在试金或树脂及活性炭富集后用分光光度法或电感耦合等离子体质谱法测定, 而在野外满足不了这些条件。本文基于样品的性质及分光光度法的适应性强等特点, 开发了一种适合于野外简单条件下快速测定地质样品中铂和钯的分析方法。样品用盐酸-氯酸钾-氯化钠-氟化氢铵常温常压密闭分解, 巯基棉分别富集铂和钯, 灰化处理后采用三氯甲烷-石油醚(1:3) 为萃取剂, DDO为显色剂萃取比色测定铂、钯的含量。巯基棉对钯的吸附率可达98%;加入氯化亚锡-水合肼(还原剂)使铂的吸附率提高到99%。方法检出限为Pt 0.05 μg/g, Pd 0.02 μg/g, 标准物质的测定值与推荐值基本一致, 野外地质样品的测定值与实验室分析结果吻合。
Abstract:For the determination of Pt and Pd in geochemical samples, traditional and modern analytical methods are based on assaying or activated carbon and resin preconcentration and determination by Spectrophotometry and Inductively Coupled Plasma-Mass Spectrometry. However, these requirements cannot be met in the field. Based on the character of samples and the applicability of Spectrophotometry, this study develops a method in rapid determination of Pt and Pd in geochemical samples in the field. Samples are decomposed in the sealed Teflon container by the mixing of hydrochloric acid, potassium chlorate, sodium chloride, and ammonium hydrogen fluoride under normal temperature and pressure. Platinum and palladium are preconcentrated by sulfhydryl cotton. Pt and Pd are determined using chloroform petroleum and ether (1:3) as the extractant, and DDO as the chromogenic agent. The adsorption capacity of sulfhydryl cotton for Pt can reach 98%, and the adsorption capacity of stannous chloride-drazine hydrate (reducing agent) for Pd can reach 99%. The detection limits of the method are 0.05 μg/g and 0.02 μg/g for Pt and Pd, respectively. The analytical values of standard materials, GBW07291, GBW07293, and GBW07341 are consistent with the respectively recommended values. The direct determination values of geological samples in the field are consistent with the results of laboratory analyses.
-
Key words:
- geo-chemical samples /
- platinum /
- palladium /
- field analysis /
- sulfhydryl cotton preconcentraction /
- Spectrophotometry
-
-
表 1 不同样品分解体系中铂和钯的回收率
Table 1. The recovery of Pt and Pd in different sample decomposition systems
样品分解体系 GBW07291 GBW07293 铂回收率
(%)钯回收率
(%)铂回收率
(%)钯回收率
(%)王水(A) 82 85 81 83 盐酸-过氧化氢(B) 90 92 92 91 盐酸-氯酸钾-氯化钠
-氟化氢铵(C)100 96 98 101 盐酸-高锰酸钾-氯化钠
-氟化氢铵(D)97 96 105 95
下载: 导出CSV
表 2 巯基棉吸附铂时还原剂的选择及其用量对铂吸附效果的影响
Table 2. Effect of reducing agent on the adsorption of platinum with sulfhydryl cotton
氯化亚锡 碘化钾 水合肼 氯化亚锡-水合肼 加入量
(mL)铂回收率
(%)加入量
(g)铂回收率
(%)加入量
(mL)铂回收率
(%)氯化亚锡
加入量
(mL)水合肼
加入量
(mL)铂回收率
(%)0 20.0 0 20.0 0.2 62.9 0 0 65.2 0.1 66.4 0.2 68.8 0.5 77.1 0.5 1 80.5 0.2 74.0 0.5 73.2 1 93.5 1 2 94.5 0.5 86.0 1 82.8 2 90.5 2 4 99.4 1 91.2 2 78.0 3 87.0 4 8 95.6 2 86.8 5 87.2 4 97.0 6 12 93.2 5 89.4
下载: 导出CSV
表 3 方法准确度和精密度
Table 3. Accuracy and precision tests of the method
元素 GBW07291 GBW07293 GBW07341 测定
平均值
(ng/g)标准值
(ng/g)RSD
(%)测定
平均值
(ng/g)标准值
(ng/g)RSD
(%)测定
平均值
(ng/g)标准值
(ng/g)RSD
(%)铂 0.061 0.058 12.7 0.44 0.44 12.5 2.0 1.9 11.3 钯 0.060 0.060 10.4 0.61 0.57 11.3 0.53 0.57 13.1
下载: 导出CSV
-
