Synthesis of Amino Polyurethane Foam and Its Application in Trace Gold Enrichment in Geological Samples
-
摘要: 采用泡塑（PUF）富集，AAS或ICP-OES测定地质样品中痕量金是常用的分析方法。与活性炭相比，PUF的选择性好，但吸附容量偏低，可将泡塑负载不同的萃取剂或修饰不同的官能团提高吸附容量。本文将聚醚型泡塑经盐酸水解制备成氨基泡塑（PUF-NH2）。红外光谱和扫描电镜表征显示，PUF-NH2峰形发生了明显红移（3376.5 cm-1），其中的氨基数量显著增加，另外PUF-NH2的高分子出现明显断裂，发生水解后裸露出的氨基具有还原性，在吸附金的过程中易与金离子在PUF-NH2表面发生氧化还原反应，形成金纳米颗粒。改性后的PUF-NH2吸附容量达到96 mg/g，与PUF相比提高了8倍。将PUF-NH2应用于富集地质样品中的金，经炭化灼烧、50%王水提取后用ICP-OES测定，金的加标回收率在95.0%～105.0%之间，检出限为0.15 μg/g。 实验证明用PUF-NH2处理样品提高了富集倍数和分析灵敏度，有利于低品位矿石的分析。
-
关键词:
- 地质样品 /
- 金 /
- 回收率 /
- 氨基泡塑 /
- 电感耦合等离子体发射光谱法
Abstract: The common method for the determination of Au in geological samples is by Atomic Absorption Spectrometry (AAS) and Inductively Coupled Plasma-Optical Emission Spectrometry (ICP-OES) after enrichment by polyurethane foam (PUF). Compared with activated carbon, PUF has a good selectivity but has a low absorption capacity. PUF loaded by different extraction agents or modified with different functional groups can improve the absorption capacity. PUF was treated with hydrochloric acid to prepare PUF-NH2. Infrared Spectrum and Scanned Electron Microscope results show the peak of PUF-NH2 shows obvious red shift, and the amount of amino group increases obviously. Macromolecule of PUF-NH2 shows obvious fracture. The amino group after hydrolysis is reduced, which is easy to achieve in an oxide-reduction reaction with Au ions during the absorption of Au to form Au nanoparticles. Modified PUF-NH2 achieved absorption capacity of 96 mg/g, which is an 8-fold improvement compared to PUF. Using PUF-NH2 to enrich Au in geological samples, the samples were first ashed and then digested by 50% aqua regia. Gold was determined by ICP-OES. The recovery by standard-addition ranged from 95.0% to 105.0% and the detection limit was 0.15 μg/g. The experimental results show that the enrichment degree and analytical sensitivity are improved by using PUF-NH2, which is suitable for the determination Au in low grade ores. -
-
表 1 Langmuir、Freundlich和Dubinin吸附计算参数
Table 1. Parameters of the Langmuir,Freundlich and Dubinin isotherms for the adsorption of Au(Ⅲ)
吸附类型 等温常数 280 K 298 K 323 K Langmuir Qmax (mg/g) 98.94 95.99 78.45 K (L/mg) 0.05890 0.05532 0.03371 R2 0.9900 0.9912 0.9876 RL 0.0215~0.6334 0.0219~6424 0.0351~0.7511 Freundlich Kf(mg/g)(L/mg)1/n 7.808 7.102 4.743 n 2.021 2.001 1.954 R2 0.9794 0.9720 0.9690 Dubinin QD-R (mg/g) 3.451 3.462 3.214 β×10-2(mol2/J2) -8.703 -10.494 -7.726 E 2.390 2.175 2.538 R2 0.5200 0.5561 0.3716
下载: 导出CSV
表 2 国家标准物质和实际样品测定结果
Table 2. Analytical results of Au in certified reference materials and actual samples
标准物质编号 提取方式 金含量(μg/g) RSD(%) 实际样品编号 金含量(μg/g) 金加标回收率(%) 测量值 标准值 测量值 加标量 总量 GBW07804 灰化硫脲解脱 2.45±0.16 2.50 ± 0.20 3.6 1# 5.88 5.00 10.68 96.2 2.44±0.25 5.0 2# 1.04 1.00 1.99 95.0 GBW(E)070067 灰化硫脲解脱 0.66±0.03 0.64±0.03 4.4 3# 0.24 0.20 0.45 105.0 0.67±0.05 5.1
下载: 导出CSV
-
[1] Corti C W,Holliday R J.Commercial Aaspects of Gold Applications:From Materials Science to Chemical Science[J].Gold Bulletin,2004,37(1):20-26.
[2] Pyrzynska K.Sorbent Materials for Separation and Preconcentration of Gold in Environmental and Geological Samples-A Review[J].Analytica Chimica Acta,2012,741(5):9-14. http://cn.bing.com/academic/profile?id=2159170970&encoded=0&v=paper_preview&mkt=zh-cn
[3] Resano M,García-Ruiz E,Belarra M A,et al.Solid Sampling in the Determination of Precious Metals at Ultratrace Levels[J].TrAC Trends in Analytical Chemistry,2007,26(5):385-395. doi: 10.1016/j.trac.2007.01.015
[4] Gros M,Lorand J P,Luguet A.Analysis of Platinum Group Elements and Gold in Geological Materials Using NiS Fire Assay and Te Coprecipitation:The NiS Dissolution Step Revisited[J].Chemical Geology,2002,185(3-4):179-190. doi: 10.1016/S0009-2541(01)00405-3
[5] Kim M L,Tudino M B.Evaluation of Performance of Three Different Hybrid Mesoporous Solids Based on Silica for Preconcentration Purposes in Analytical Chemistry:From the Study of Sorption Features to the Determination of Elements of Group IB[J].Talanta,2010,82(3):923-930. doi: 10.1016/j.talanta.2010.05.057
[6] Donia A M,Atia A A,Elwakeel K Z.Gold(Ⅲ) Recovery Using Synthetic Chelating Resins with Amine,Thio and Amine/Mercaptan Functionalities[J].Separation and Purification Technology,2005,42(2):111-116. doi: 10.1016/j.seppur.2004.06.009
[7] Chang Y C,Chen D H.Recovery of Gold(Ⅲ) Ions by a Chitosancoated Magnetic Nano-adsorbent[J].Gold Bulletin,2006,39(3):98-102. doi: 10.1007/BF03215536
[8] Chakrapani G,Mahanta P L,Murty D S R,et al.Preconcentration of Traces of Gold,Silver and Palladium on Activated Carbon and Its Determination in Geological Samples by Flame AAS after Wet Ashing[J].Talanta,2001,53(6):1139-1147. doi: 10.1016/S0039-9140(00)00601-9
[9] Bashammakh A S,Bahhafi S O,Al-Shareef F M,et al.Development of an Analytical Method for Trace Gold in Aqueous Solution Using Polyurethane Foam Sorbents:Kinetic and Thermodynamic Characteristic of Gold(Ⅲ) Sorption[J].Analytical Sciences,2009,25(3):413-418. doi: 10.2116/analsci.25.413
[10] Lemos V A,Santos M S,Santos E S,et al.Application of Polyurethane Foam as a Sorbent for Trace Metal Preconcentration-A Review[J].Spectrochimica Acta Part B:Atomic Spectroscopy,2007,62(1):4-12. doi: 10.1016/j.sab.2006.12.006
[11] Farag A B,Soliman M H,Abdel-Rasoul O S,et al.Sorption Characteristics and Chromatographic Separation of Gold (Ⅰ and Ⅲ) from Silver and Base Metal Ions Using Polyurethane Foams[J].Analytica Chimica Acta,2007,601:218-229. doi: 10.1016/j.aca.2007.08.049
[12] Moawed E A,El-Shahat M F.Synthesis,Characterization of Low Density Polyhydroxy Polyurethane Foam and Its Application for Separation and Determination of Gold in Water and Ores Samples[J].Analytica Chimica Acta,2013,788(25):200-207.
[13] 邢夏,徐进力,陈海杰,等.抗坏血酸为基体改进剂石墨炉原子吸收光谱法测定金矿区植物样品中的痕量[J].岩矿测试,2015,34(3):319-324. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20150310&flag=1
Xing X,Xu J L,Chen H J,et al.Determination of Trace Gold in Plant Samples from a Gold Mining Area by Graphite Furnace Atomic Absorption Spectrometry with Ascorbic Acid as the Matrix Modifier[J].Rock and Mineral Analysis,2015,34(3):319-324. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20150310&flag=1
[14] 李跃光,陈为亮.贵金属元素分析中的分离富集技术应用进展[J].贵金属,2012,33(4):71-74. http://www.cnki.com.cn/Article/CJFDTOTAL-GJSZ201204016.htm
Li Y G,Chen W L.Comments on Technical Progress of Separation and Concentration for Precious Metals Elemental Analysis[J].Precious Metals,2012,33(4):71-74. http://www.cnki.com.cn/Article/CJFDTOTAL-GJSZ201204016.htm
[15] 辛仁轩编著.等离子体发射光谱分析[M].北京:化学工业出版社,2005:140-144.
Xin R X.Plasma Emission Spectrum Analysis[M].Beijing:Chemical Industry Press,2005:140-144.
[16] 胡皆汉编著.实用红外光谱学[M].北京:科学出版社,2011:286-292.
Hu J H.Practical Infrared Spectroscopy[M].Beijing:Science Press,2011:286-292.
[17] Moaweda E A,Abulkibashb A B,El-Shahatc M F.Synthesis and Characterization of Iodo Polyurethane Foam and Its Application in Removing of Aniline Blue and Crystal Violet from Laundry Waste Water[J].Journal of Taibah University for Science,2015,9(1):80-88. doi: 10.1016/j.jtusci.2014.07.003
[18] Moaweda E A,Ishaqb I,Abdul-Rahmanb A,et al.Synthesis,Characterization of Carbon Polyurethane Powder and Its Application for Separation and Spectrophotometric Determination of Platinum in Pharmaceutical and Ore Samples[J].Talanta,2014,121:113-121. doi: 10.1016/j.talanta.2013.12.050
[19] Langmuir I.The Adsorption of Gases on Plane Surfaces of Glass,Mica and Platinum[J].Journal of the American Chemical Society,1918,40(9):1361-1403. doi: 10.1021/ja02242a004
[20] Xue D S,Wang H Y,Liu Y H,et al.Cytosinefun-ctionalized Polyurethane Foam and Its Use as a Sorbent for the Determination of Gold in Geological Samples[J].Analytical Methods,2016,8:29-39. doi: 10.1039/C5AY01737H
[21] James B C.Equivalency of the Dubinin-Polanyi Equa-tions and the QM Based Sorption Isotherm Equation.B.Simulations of Geterogeneous Surfaces[J].Microporous and Mesoporous Materials,2000,38(2-3):377-383. doi: 10.1016/S1387-1811(00)00158-X
[22] 谈建安,黑文龙,黄兴华,等.泡塑吸附-电感耦合等离子体发射光谱法测定矿石中的金[J].岩矿测试,2009,28(2):147-150. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20090212&flag=1
Tan J A,Hei W L,Huang X H,et al.Determination of Gold in Ores by Inductively Coupled Plasma-Atomic Emission Spectrometry with Plastic Foam Absorption[J].Rock and Mineral Analysis,2009,28(2):147-150. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20090212&flag=1
-
