Influence on the Chemistry Quenching of Low Level Tritium in Natural Water by the Solid Polymer Electrolysis Enrichment Method
-
摘要: 固体聚合膜电解浓集法是浓缩氚含量较低（<1 Bq/m3）的天然水样的常用方法，但因水样自身含有杂质离子或电解装置聚合膜带入杂质进入浓集液，使浓集液偏酸性，在测量过程中易产生化学淬灭效应，导致氚的测量值偏低。本文研究了水样自身存在的杂质离子和聚合膜上残留的杂质离子、样品溶液的pH值及其电导率所产生的化学淬灭效应的影响，实验表明，为减少化学淬灭效应，提高测量低含量氚的准确性，需保证水样溶液呈中性，电导率≤1 μS/cm，同时避免杂质沉积在聚合膜上。如果水样溶液的pH值偏酸性、电导率大于1 μS/cm，可采用酸碱混合型离子交换树脂去除水样中自身的杂质；对于聚合膜引入的杂质，可在电解后的水样中加入微量氨水将其pH值调节至中性。Abstract: The Solid Polymer Electrolysis (SPE) enrichment method is a practical way to measure low level tritium (<1 Bq/m3) in natural water samples. However, the concentrated liquid samples are acidified by impurity ions from water samples or the process of water sample pretreatment with a SPE electrolysis device, which results in perturbation when liquid scintillation is added progressively to the concentrated liquid. Consequently, the radioactive activity of tritium will be lower than the reference value because of the chemistry quenching effect occurring in the measurement process. The influence of chemistry quenching caused by impurity ions, pH value and electrical conductivity of the low level tritium samples in the tritium measurement results are discussed in this paper. The results show that, to avoid the chemistry quenching caused by impurity ions deposited in SPE electrolysis device and improve the accuracy of measurement counting, it is necessary to keep the pH value neutral and the electrical conductivity ≤1 μS/cm. Using the ion and acid-base hybrid exchange resin column separates impurity ions for high electrical conductivity (>1 μS/cm) or acidification pH samples. For water samples the impurity ions taken by the polymer film, can be used to adjust the pH value with tiny amounts of ammonia to avoid chemistry quenching and thus reduce the low counting of the tritium natural water samples.
-
-
表 1 低氚样品蒸馏后的电导率和pH值
Table 1. The electrical conductivity and pH value of low-tritium samples treated with distillation
样品编号 电导率(μS/cm) 溶液pH值 加闪烁液后的颜色 样品1 1.3 7 清澈透明 样品2 2.5 7 清澈透明 样品3 16.5 4 乳白色 样品4 4.3 7 清澈透明 样品5 7.3 5 乳白色 样品6 2.6 7 清澈透明
下载: 导出CSV
表 2 不同电解装置电解后氚测定结果
Table 2. The analytical results of tritium treated with electrolytic device
样品 编号 装置 编号 计数率 (cpm) 电解后氚浓度 的测量值(TU) 氚浓度的 参考值(TU) 相对误差 (%) 加入闪烁液后 溶液颜色 T1 A 14.157 237.33 236.80 0.2 清亮 T2 B 15.804 235.82 236.80 -0.4 清亮 T3 C 9.516 149.69 236.80 -36.8 乳白 T4 D 11.426 183.30 236.80 -22.6 乳白
下载: 导出CSV
表 3 电解装置浓缩后溶液中杂质离子的含量
Table 3. The concentrated of impurity ions in the sample solution enriched with electrolytic device
样品编号 杂质离子的浓度(mg/L) 水样的pH值 Cr2+ Sr2+ Ca2+ Mg2+ T1 - 0.0057 1.511 0.0757 6.67 T2 - 0.0077 2.263 0.0127 6.72 T3 0.2258 0.0106 3.067 0.2852 4.34 T4 0.2606 0.0109 3.291 0.2252 3.87 注：表中仅列出4个样品中含量差异明显的元素。“-”表示测定结果小于仪器检出限。
下载: 导出CSV
-
[1] 徐小三,余宁乐,杨小勇,等.液闪谱仪在低水平测氚中测量条件选择[J].核电子学与探测技术,2012,32(5):544-546. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE201205012.htm
Xu X S,Yu N L,Yang X Y,et al.Selection of Experimental Conditions in Measuring Tritium at Low Level by the Liquid Scintillation[J]. Nuclear Electronics and Detection Technology,2012,32(5):544-546. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE201205012.htm
[2] 卞正柱,张钰,张金卫.液闪计数器进展简述[J].核电子学与探测技术,2006,26(4):536-538.
Bian Z Z,Zhang Y,Zhang J W.A Brief Progress of Liquid Flash Counter[J].Nuclear Electronics and Detection Technology,2006,26(4):536-538.
[3] 唐泉,丘寿康,左富琪,等.液闪法测氚的一些优化条件和质量检验研究[J].核电子学与探测技术,2007,27(2):418-420. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE200702071.htm
Tang Q,Qiu S K,Zuo F Q,et al.Study on Some Optimal Conditions and Quality Test of Measuring Tritium by the Liquid Scintillation Method[J].Nuclear Electronics and Detection Technology,2007,27(2):418-420. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE200702071.htm
[4] 王伟华,朱国英,陈炳如.我国部分地区环境水氚的分布规律初探[J].中国辐射卫生,2000,9(1):347-352. http://www.cnki.com.cn/Article/CJFDTOTAL-REDI200001029.htm
Wang W H,Zhu G Y,Chen B R.Preliminary Study about of Environment Tritium Water Distribution Parts of Our Country[J].Chinese Journal of Radiological Health,2000,9(1):347-352. http://www.cnki.com.cn/Article/CJFDTOTAL-REDI200001029.htm
[5] 袁政安.氚在不同水体中的浓度分布[J].上海预防医学杂志,2000,120(7):329-330. http://www.cnki.com.cn/Article/CJFDTOTAL-SHYI200007015.htm
Yuan Z A.Tritium Concentration Distribution in Different Waters[J].Shanghai Journal of Preventive Medicine,2000,120(7):329-330. http://www.cnki.com.cn/Article/CJFDTOTAL-SHYI200007015.htm
[6] 张向阳,刘福亮,张琳,等.电解法浓缩环境氚水样的性能研究[J].核电子学与探测技术,2012(11):1301-1304. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE201211016.htm
Zhang X Y,Liu F L,Zhang L,et al.The Study of Electrolysis Enrichment Performance Tritium Water Samples in Environment[J].Nuclear Electronics and Detection Technology,2012(11):1301-1304. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE201211016.htm
[7] 王华,殷建军,杨会,等.聚合膜电解浓集法测量低水平氚环境水样的氚比活度[J].岩矿测试,2011,30(6):745-750. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20110616&flag=1
Wang H,Ying J J,Yang H,et al.Application of the Solid Polymer Electrolysis Enrichment Method for Low Level Tritium in Environmental Water and the Calculation of Tritium Specific Activity[J].Rock and Mineral Analysis,2011,30(6):745-750. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20110616&flag=1
[8] 温雪莲,杨海兰,吴斌,等.SPE固体电解质氚水浓集装置及其应用[J].核电子学与探测技术,2003,23(6):583-586. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE200306026.htm
Wen X L,Yang H L,Wu B,et al.The Development and Application of Solid Polymer Electrolysis Enrichment Device of Tritium in Water[J].Nuclear Electronics and Detection Technology,2003,23(6):583-586. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE200306026.htm
[9] Gröning M,Taylor C B,Winckler G,et al.Sixth IAEA Intercomparison of Low-level Tritium Measurements in Water (TRIC2000)[R].Vienna:International Atomic Energy Agency,2001.
[10] 孟建波,桑革,薛炎,等.多种电极的SPE水电解性能研究[J].电化学,2007(2):156-159. http://www.cnki.com.cn/Article/CJFDTOTAL-DHXX200702012.htm
Meng J B,Sang G,Xue Y,et al.The Research of Several Electrodes for SPE Water Electrolysis[J].Journal of Electrochemistry,2007(2):156-159. http://www.cnki.com.cn/Article/CJFDTOTAL-DHXX200702012.htm
[11] 谢波,胡睿,刘云怒.固体聚合物电解池分离氚的理论分析[J].科技通报,2009,25(5):541-545. http://www.cnki.com.cn/Article/CJFDTOTAL-KJTB200905001.htm
Xie B,Hu R,Liu Y N.Theoretical Analysis of Tritium Separation by Solid Polymer Electrolyte[J].Bulletin of Science Technology,2009,25(5):541-545. http://www.cnki.com.cn/Article/CJFDTOTAL-KJTB200905001.htm
[12] 孟建波,桑革,薛炎,等.SPE水电解进行H/D同位素分离[J].应用化学,2007(12):1424-1427. http://www.cnki.com.cn/Article/CJFDTOTAL-YYHX200712019.htm
Meng J B,Sang G,Xue Y,et al.H/D Isotope Separation in SPE Water Electrolysis[J].Chinese Journal of Applied Chemistry,2007(12):1424-1427. http://www.cnki.com.cn/Article/CJFDTOTAL-YYHX200712019.htm
[13] 张向阳,刘福亮,张琳,等.液闪法测量水中氚放射性活度的化学淬灭效应[J].岩矿测试,2010,29(4):469-471. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20100430&flag=1
Zhang X Y,Liu F L,Zhang L,et al.Quenching Effect of Tritium Radioactivity in Water Sample Analysis by Liquid Scintillation Counting Method[J].Rock and Mineral Analysis,2010,29(4):469-471. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20100430&flag=1
[14] 张向阳.电解浓缩-液闪仪计数法分析天然水中氚含量的影响因素[J].岩矿测试,2005,24(2):109-111. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20050231&flag=1
Zhang X Y.Factors Affecting the Analysis of Tritium in Natural Water by Electrolytic Enrichment and Liquid Scintillation Counting Method[J].Rock and Mineral Analysis,2005,24(2):109-111. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20050231&flag=1
[15] 杨礼平,周明富,周卫建,等.液闪法14C年代测量中的化学淬灭校正[J].核电子学与探测技术,2005,25(4):241-245. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE504.008.htm
Yang L P,Zhou M F,Zhou W J,et al.Quench Calibration for 14C Age Determination in Liquid Scintillation Method[J].Nuclear Electronics and Detection Technology,2005,25(4):241-245. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE504.008.htm
[16] 张祖华.液体闪烁测量中常被忽略而引入很大误差的问题[J].核电子学与探测技术,2002,22(2):187-189. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE200202027.htm
Zhang Z H.A Problem of Introducing Errors in the Measurement of Liquid Scintillation[J].Nuclear Electronics and Detection Technology,2002,22(2):187-189. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE200202027.htm
[17] 董志武,周元全.杂质离子对固体聚合物电解质水电解槽性能的影响[J].化工学报,2005,56(5):900-903. http://www.cnki.com.cn/Article/CJFDTOTAL-HGSZ200505010.htm
Dong Z W,Zhou Y Q.Influence of Impure Ions on Performance of Solid Polymer Electrolyte Water Electrolyser[J].Journal of Chemical Industry and Engineering,2005,56(5):900-903. http://www.cnki.com.cn/Article/CJFDTOTAL-HGSZ200505010.htm
[18] 陈羚,程璇,张颖,等.质子交换膜NafionR的导电性与物理老化[J].高分子材料科学与工程,2005,21(5):181-184.
Chen L,Cheng X,Zhang Y,et al.The Conductivity and Physical Aging of NafionR[J].Polymer Materials Science and Engineering,2005,21(5):181-184.
-
