基于核磁共振标定的高压压汞孔喉分布定量评价方法

孙小龙; 张宪国; 林承焰; 赵仲祥; 马存飞; 林建力

doi:10.15898/j.cnki.11-2131/td.201706110097

基于核磁共振标定的高压压汞孔喉分布定量评价方法

1.
中国石油大学(华东)地球科学与技术学院, 山东青岛 266580

2.
山东省油藏地质重点实验室, 山东青岛 266580

基金项目:
“十三五”国家科技重大专项（2016ZX05027-004）；国家自然科学基金面上项目（41672129）；山东省沉积成矿作用与沉积矿产重点实验室开放基金（DMSM201411）

详细信息

作者简介: 孙小龙, 硕士研究生, 主要从事储层地质学研究。E-mail:upc_sxl@126.com

通讯作者: 张宪国, 博士, 硕士生导师, 主要从事油藏描述和储层地质学研究。E-mail:zhangxianguo@upc.edu.cn

中图分类号: P574.19;TE135.4

收稿日期: 2017-06-11

修回日期: 2017-07-20

录用日期: 2017-08-14

Quantitative Evaluation Method of HPMI Pore-throat Distribution Based on NMR Calibration

1.
School of Geosciences, China University of Petroleum, Qingdao 266580, China

2.
Shandong Province Key Laboratory of Reservoir Geology, Qingdao 266580, China

More Information

Corresponding author: Xian-guo ZHANG, zhangxianguo@upc.edu.cn

Received Date: 11 June 2017

Revised Date: 20 July 2017

Accepted Date: 14 August 2017

摘要

摘要: 孔喉分布是控制低渗-致密砂岩储层物性的关键因素，其评价依托于各种储层微观特征测试方法，需要综合多方法各自优势进行孔喉分布定量表征。本文提出基于核磁共振标定的高压压汞孔喉分布定量评价的方法，即通过核磁共振离心前后横向弛豫时间T₂谱图对比，依据流体赋存状态重新划分三孔隙度组分百分比法的T₂值界限T₂₁和T₂₂，对应将孔喉划分为束缚流体孔喉、过渡流体孔喉和可动流体孔喉，再结合T₂值与孔喉半径的关系将T₂值界限转化为孔喉半径界限r₁和r₂，最终依据高压压汞统计的不同流体赋存状态的孔喉含量S₁、S₂和S₃进行孔喉分布定量评价。该方法综合了核磁共振有效表征孔喉流体赋存状态和高压压汞有效表征孔喉大小的优势。将此方法应用于西湖凹陷花港组低渗-致密砂岩储层孔喉分布评价，建立了T₂值与孔喉半径平均转化系数C为0.0079，求取r₁和r₂为60 nm和160 nm，依据各类孔喉含量及其相互关系将孔喉分布划分为四类，从而为储层评价提供新的参数和思路。
- 核磁共振 /
- 三孔隙度组分百分比法 /
- T₂截止值 /
- 高压压汞 /
- 孔喉分布
Abstract: Pore throat distribution is an important factor controlling the physical properties of low-permeability and tight sandstone reservoirs. The evaluation of pore throat distribution is based on the analytical methods of micro features of reservoirs, and it is necessary to synthesize multiple methods to quantify the pore throat distribution. Quantitative evaluation method of High Pressure Mercury Injection (HPMI) pore throat distribution was developed based on Nuclear Magnetic Resonance (NMR) calibration. Fluid states can be identified by the comparison of transverse relaxation time T₂ spectrum before and after centrifugation, which enables the redefining of T₂ boundaries (T₂₁ and T₂₂) of three pore components of NMR. Furthermore, pore throat is divided into irreducible fluid pore throat, transition fluid pore throat and movable fluid pore throat accordingly. T₂ boundaries are then converted to pore throat radius boundaries r₁ and r₂ by the correlativity between T₂ value and pore throat radius. Finally, pore throat distribution is evaluated quantitatively by statistics of the content of various types of pore throat (S₁, S₂ and S₃). This method combines the advantages of HPMI describing fluid states and NMR characterizing pore throat size. The method was applied to evaluate the pore throat distribution of low-permeability and tight sandstone reservoirs in the Huagang Formation of Xihu Depression. The average conversion coefficient C between T₂ value and pore throat radius is 0.0079, and pore throat radius boundaries r₁ and r₂ are 60 nm and 160 nm, respectively. Pore throat is classified into four types according to the content of various types of pore throat, which provides new parameters and thought for further reservoirs evaluation.
- Nuclear Magnetic Resonance /
- percentages of three pore components /
- T₂ cutoff value /
- high pressure mercury injection /
- pore-throat distribution

HTML全文

图 1 改进的核磁共振三孔隙度组分百分比法示意图

Figure 1.

下载: 全尺寸图片幻灯片

图 2 核磁共振与高压压汞孔隙分量和累积量分布曲线

Figure 2.

下载: 全尺寸图片幻灯片

图 3 高压压汞三孔隙度组分百分比法示意图

Figure 3.

下载: 全尺寸图片幻灯片

图 4 依据S₁、S₂和S₃大小和相互关系的孔喉分布分类方案

Figure 4.

下载: 全尺寸图片幻灯片

图 5 各类孔喉分布类型岩石学特征和孔隙结构特征

Figure 5.

下载: 全尺寸图片幻灯片

参考文献(20)

[1]	毕明威, 陈世悦, 周兆华, 等.鄂尔多斯盆地苏里格气田苏6区块盒8段致密砂岩储层微观孔隙结构特征及其意义[J].天然气地球科学, 2015, 26(10):1851-1861. doi: 10.11764/j.issn.1672-1926.2015.10.1851 Bi M W, Chen S Y, Zhou Z H, et al.Characteristics and significance of microscopic pore structure in tight sandstone reservoir of the 8th Member of Lower Shihezi Formation in the Su6 area of Sulige Gasfield[J].Natural Gas Geoscience, 2015, 26(10):1851-1861. doi: 10.11764/j.issn.1672-1926.2015.10.1851
[2]	罗静兰, 刘新社, 付晓燕, 等.岩石学组成及其成岩演化过程对致密砂岩储集质量与产能的影响:以鄂尔多斯盆地上古生界盒8天然气储层为例[J].地球科学——中国地质大学学报, 2014, 39(5):537-545. http://www.doc88.com/p-2445313976797.html Luo J L, Liu X S, Fu X Y, et al.Impact of petrologic components and their diagenetic evolution on tight sandstone reservoir quality and gas yield:A case study from He 8 Gas-bearing reservoir of upper paleozoic in Northern Ordos Basin[J].Earth Science-Journal of China University of Geosciences, 2014, 39(5):537-545. http://www.doc88.com/p-2445313976797.html
[3]	赖锦, 王贵文, 柴毓, 等.致密砂岩储层孔隙结构成因机理分析及定量评价——以鄂尔多斯盆地姬塬地区长8油层组为例[J].地质学报, 2014, 88(11):2119-2130. http://d.wanfangdata.com.cn/Periodical/dizhixb201411009 Lai J, Wang G W, Chai Y, et al.Mechanism analysis and quantitative assessment of pore structure for tight sandstone reservoirs:An example from Chang 8 oil layer in the Jiyuan area of Ordos Basin[J].Acta Geologica Sinica, 2014, 88(11):2119-2130. http://d.wanfangdata.com.cn/Periodical/dizhixb201411009
[4]	何文祥, 杨乐, 马超亚, 等.特低渗透储层微观孔隙结构参数对渗流行为的影响——以鄂尔多斯盆地长6储层为例[J].天然气地球科学, 2011, 22(3):477-482. http://d.wanfangdata.com.cn/Periodical/trqdqkx201103014 He W X, Yang L, Ma C Y, et al.Effect of micro-pore structure parameter on seepage characteristics in ultra-low permeability reservoir:A case from Chang 6 reservoir of Ordos Basin[J]. Natural Gas Geoscience, 2011, 22(3):477-482. http://d.wanfangdata.com.cn/Periodical/trqdqkx201103014
[5]	刘曦翔, 丁晓琪, 王嘉, 等.砂岩成分对储层孔隙结构及天然气富集程度的影响——以苏里格气田西区二叠系石盒子组8段为例[J].天然气工业, 2016, 36(7):27-32. http://d.wanfangdata.com.cn/Periodical/trqgy201607004 Liu X X, Ding X Q, Wang J, et al.Influence of sandstone composition on pore structures and gas enrichment degree:A case study on the 8th member of Permian Shihezi Fm in the Western Sulige gas field, Ordos Basin[J].Natural Gas Industry, 2016, 36(7):27-32. http://d.wanfangdata.com.cn/Periodical/trqgy201607004
[6]	Sakhaee-Pour A, Bryant S L.Effect of pore structure on the producibility of tight-gas sandstones[J].AAPG Bulletin, 2014, 98(4):663-694. doi: 10.1306/08011312078
[7]	蔡芃睿, 王春连, 刘成林, 等.运用扫描电镜和压汞法研究江汉盆地古新统-白垩系砂岩储层孔喉结构及定量参数特征[J].岩矿测试, 2017, 36(2):146-155. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2017.02.008 Cai P R, Wang C L, Liu C L, et al.Study on pore structure and quantitative parameters of the Paleocene-Cretaceous sandstone reservoir in Jiangling Depression by SEM and mercury injection method[J].Rock and Mineral Analysis, 2017, 36(2):146-155. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2017.02.008
[8]	庞河清, 曾焱, 刘成川, 等.基于氮气吸附-核磁共振-氩离子抛光场发射扫描电镜研究川西须五段泥质岩储层孔隙结构[J].岩矿测试, 2017, 36(1):66-74. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2017.01.010 Pang H Q, Zeng Y, Liu C C, et al.Investigation of pore structure of a argillaceous rocks reservoir in the 5th Member of Xujiahe Formation in Western Sichuan, using NAM, NMR and AIP-FESEM[J].Rock and Mineral Analysis, 2017, 36(1):66-74. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2017.01.010
[9]	Desbois G, Urai J L, Hemes S, et al.Multi-scale analysis of porosity in diagenetically altered reservoir sandstone from the Permian Rotliegend (Germany)[J].Journal of Petroleum Science & Engineering, 2016, 24(2):128-148. https://www.sciencedirect.com/science/article/pii/S0920410516300195
[10]	张冲, 张超谟, 张占松, 等.致密气储层岩心束缚水`饱和度实验对比[J].天然气地球科学, 2016, 27(2):352-358. doi: 10.11764/j.issn.16721926.2016.02.0352 Zhang C, Zhang C M, Zhang Z S, et al.Comparative experimental study of the core irreducible water saturation of tight gas reservoir[J].Natural Gas Geoscience, 2016, 27(2):352-358. doi: 10.11764/j.issn.16721926.2016.02.0352
[11]	白松涛, 程道解, 万金彬, 等.砂岩岩石核磁共振T₂谱定量表征[J].石油学报, 2016, 37(3):382-391. doi: 10.7623/syxb201603010 Bai S T, Cheng D J, Wan J B, et al.Quantitative characterization of sandstone NMR T₂ spectrum[J].Acta Petrolei Sinica, 2016, 37(3):382-391. doi: 10.7623/syxb201603010
[12]	窦文超, 刘洛夫, 吴康军, 等.基于压汞实验研究低渗储层孔隙结构及其对渗透率的影响——以鄂尔多斯盆地西南部三叠系延长组长7储层为例[J].地质论评, 2016, 62(2):502-511. http://www.doc88.com/p-2304567875854.html Dou W C, Liu L F, Wu K J, et al.Pore structure characteristics and its effect on permeability by mercury injection measurement:An example from Triassic Chang-7 reservoir, Southwest Ordos Basin[J].Geological Review, 2016, 62(2):502-511. http://www.doc88.com/p-2304567875854.html
[13]	刘卫, 肖忠祥, 杨思玉, 等.利用核磁共振(NMR)测井资料评价储层孔隙结构方法的对比研究[J].石油地球物理勘探, 2009, 44(6):773-778. http://www.wenkuxiazai.com/doc/c3ca52c6ff00bed5b9f31de8.html Liu W, Xiao Z X, Yang S Y, et al.Comparative studies on methods of evaluation of reservoir pore structure by using NMR (nuclear magnetic resonance) well logging data[J].Oil Geophysical Prospecting, 2009, 44(6):773-778. http://www.wenkuxiazai.com/doc/c3ca52c6ff00bed5b9f31de8.html
[14]	王振华, 陈刚, 李书恒, 等.核磁共振岩心实验分析在低孔渗储层评价中的应用[J].石油实验地质, 2014, 36(6):773-779. doi: 10.11781/sysydz201406773 Wang Z H, Chen G, Li S H, et al.Application of NMR core experimental analysis in evaluation of low-porosity and low-permeability sandstone reservoirs[J].Petroleum Geology & Experiment, 2014, 36(6):773-779. doi: 10.11781/sysydz201406773
[15]	邹才能, 朱如凯, 吴松涛, 等.常规与非常规油气聚集类型、特征、机理及展望——以中国致密油和致密气为例[J].石油学报, 2012, 33(2):173-187. doi: 10.7623/syxb201202001 Zou C N, Zhu R K, Wu S T, et al.Types, characteristics, genesis and prospects of conventional and unconventional hydrocarbon accumulations:Taking tight oil and tight gas in China as an instance[J].Acta Petrolei Sinica, 2012, 33(2):173-187. doi: 10.7623/syxb201202001
[16]	肖亮, 肖忠祥.核磁共振测井T_2cutoff确定方法及适用性分析[J].地球物理学进展, 2008, 23(1):167-171. http://www.cqvip.com/QK/98047X/200801/26825177.html Xiao L, Xiao Z X.Analysis of methods for determining NMR T_2cutoff and its applicability[J].Progress in Geophysics, 2008, 23(1):167-171. http://www.cqvip.com/QK/98047X/200801/26825177.html
[17]	何雨丹, 毛志强, 肖立志, 等.核磁共振T₂分布评价岩石孔径分布的改进方法[J].地球物理学报, 2005, 48(2):373-378. https://es.scribd.com/document/265808204/I He Y D, Mao Z Q, Xiao L Z, et al.An improved method of using NMR T₂ distribution to evaluate pore size distribution[J].Chinese Journal of Geophysics, 2005, 48(2):373-378. https://es.scribd.com/document/265808204/I
[18]	李爱芬, 任晓霞, 王桂娟, 等.核磁共振研究致密砂岩孔隙结构的方法及应用[J].中国石油大学学报(自然科学版), 2015, 39(6):92-98. http://d.wanfangdata.com.cn/Periodical/sydxxb201506012 Li A F, Ren X X, Wang G J, et al.Characterization of pore structure of low permeability reservoirs using a nuclear magnetic resonance method[J].Journal of China University of Petroleum (Natural Science), 2015, 39(6):92-98. http://d.wanfangdata.com.cn/Periodical/sydxxb201506012
[19]	李军, 金武军, 王亮, 等.利用核磁共振技术确定有机孔与无机孔孔径分布——以四川盆地涪陵地区志留系龙马溪组页岩气储层为例[J].石油与天然气地质, 2016, 37(1):129-134. doi: 10.11743/ogg20160118 Li J, Jin W J, Wang L, et al.Quantitative evaluation of organic and inorganic pore size distribution by NMR:A case from the Silurian Longmaxi Formation gas shale in Fuling area, Sichuan Basin[J].Oil & Gas Geology, 2016, 37(1):129-134. doi: 10.11743/ogg20160118
[20]	周尚文, 刘洪林, 闫刚, 等.中国南方海相页岩储层可动流体及T₂截止值核磁共振研究[J].石油与天然气地质, 2016, 37(4):612-616. doi: 10.11743/ogg20160420 Zhou S W, Liu H L, Yan G, et al.NMR research of movable fluid and T₂ cutoff of marine shale in South China[J].Oil & Gas Geology, 2016, 37(4):612-616. doi: 10.11743/ogg20160420
