Analysis of Sulfur Isotope Composition of Gypsum Samples by Elemental Analyzer-Isotope Mass Spectrometry
-
摘要: 硫酸盐硫同位素的常规分析方法是将硫酸盐转化为硫酸钡后搭配双路进样SO2法，该法易于操作、数据稳定，但样品用量大、费时费力，需要繁杂的前处理，无法满足微量分析发展方向的需求。本文以石膏为例，以元素分析仪-气体同位素质谱法（EA-IRMS）直接测定硫酸钙样品硫同位素比值，对同一样品分别采用：①硫酸钙与V2O5混合后包裹于锡杯中密封，直接进行元素分析仪-气体同位素质谱分析；②硫酸钙充分溶于去离子水中，向溶有硫酸钙样品的液体中加入沉淀试剂BaCl2，将生成的硫酸钡沉淀滤出后，用去离子水清洗2~3遍，烘干后与V2O5混合包裹于锡杯中密封再进行质谱测定。实验选取了13件δ34S值变化范围介于-20‰~+30‰之间的天然石膏样品，将获得的硫同位素比值进行对比，二者δ34SV-CDT绝对差值在0.00‰~0.24‰，表明同一样品的硫同位素比值结果在误差范围内基本一致。与常规分析方法相比，本文建立的直接在线分析时无需任何化学前处理，只需直接加入适量的V2O5，V2O5和氧气中的外部氧在瞬间燃烧的过程中替代了硫酸钙本身的氧，生成的SO2气体的氧是均一的，其硫同位素比值能代表样品的硫同位素组成，无需进行氧同位素的校正。经过验证表明，硫酸钙样品的直接在线分析是完全可行的。
-
关键词:
- 硫酸钙 /
- 硫同位素 /
- 元素分析仪-气体同位素质谱 /
- 样品前处理
Abstract:BACKGROUNDThe conventional method for the measurement of sulfur isotopes in sulfate includes mainly barite conversion coupled with dual-inlet SO2 methods. These methods are facile and reliable. However, the large amounts of samples, the length of time needed, the laborious experimental work, and complicated preprocessing are impractical for the development direction of micro-analysis. OBJECTIVESTo develop a method for determination of sulfur isotope compositions in gypsum directly through continuous flow elemental analyzer-isotope mass spectrometry (EA-IRMS). METHODSTwo different preparation methods were used. (1) Direct measurement of sulfur isotopes was carried out by mixing calcium sulfate powder with V2O5 in a tin cup using EA-IRMS. (2) Calcium sulfate was fully dissolved in deionized water. The precipitation reagent BaCl2 was added to the liquid in which the calcium sulfate sample was dissolved. After the precipitated barium sulfate was filtered out, it was washed 2 to 3 times with deionized water. Samples were dried and mixed with V2O5 in a sealed tin cup and then determined by mass spectrometry. RESULTSThe δ34S values of 13 gypsum samples ranged from -20‰ to -30‰, and the results from replicate measurements were compared for these two methods, yielding the absolute difference in δ values were 0.0-0.2 permil, indicating that the sulfur isotope ratios of the same sample were basically identical. CONCLUSIONSCompared with the conventional analysis method, the application of 'no pretreatment' to analyze the sulfur isotopes of gypsum was conducted successfully. Adding V2O5 to samples directly, during the process of instantaneous combustion, the oxygen in calcium sulfate are substituted by the external oxygen in V2O5 and oxygen gas, and the obtained oxygen of SO2 gas is uniform. Therefore, sulfur isotope ratios of SO2 can completely represent those of the calcium sulfate, making it unnecessary for oxygen isotope correction. The direct online analysis of sulfur isotopes in calcium sulfate samples using EA-IRMS is verified to be feasible. -
-
表 1 原始样品与经处理样品的δ34SV-CDT(‰)实测值对比
Table 1. Comparison of the measured δ34SV-CDT(‰) values of original samples and treated samples
样品编号 δ34SV-CDT(‰) 处理前后
的差值原始样品(CaSO4) 经处理样品(BaSO4) 样品1 -20.41 -20.65 0.24 样品2 -13.44 -13.56 0.12 样品3 0.82 0.77 0.05 样品4 1.91 2.02 0.11 样品5 -10.05 -9.95 0.10 样品6 -23.91 -24.10 0.19 样品7 15.39 15.18 0.21 样品8 30.77 30.60 0.17 样品9 24.75 24.65 0.09 样品10 32.31 32.31 0.00 样品11 19.92 20.01 0.09 样品12 8.13 8.16 0.03 样品13 -3.53 -3.62 0.09
下载: 导出CSV
-
[1] Ohmoto H, Kakegawa T, Donald R L, et al.3.4-billion-year-old biogenic pyrites from Barberton, South Africa:Sulfur isotope evidence[J].Science, 1993, 262:555-557. doi: 10.1126/science.11539502
[2] Ohmoto H, Goldhaber M B.Sulfur and Carbon Isotopes[M]//Barnes H L.Geochemistry of Hydrothermal Ore Deposits (3rd Edition).New York: John Wiley and Sons, 1997: 517-611.
[3] Ono S.Multiple-sulphur isotope biosignatures[J].Space Science Reviews, 2008, 135(1-4):203-220. doi: 10.1007/s11214-007-9267-2
[4] Partridge M A, Golding S D, Baublys K, et al.Pyrite paragenesis and multiple sulfur isotope distribution in Late Archean and Early Paleoproterozoic hamersley basin sediments[J].Earth and Planetary Science Letters, 2008, 272(1-2):0-49. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=95c4aec554daddf38e4372b5399893a7
[5] Bowins R J, Crocket J H.Sulfur and carbon isotopes in Archean banded iron formations:Implications for sulfur sources[J].Chemical Geology, 1994, 111:307-323. doi: 10.1016/0009-2541(94)90097-3
[6] Kakegawa T, Ohmoto H.Sulfur isotope evidence for the origin of 3.4 to 3.1Ga pyrite at the Princeton gold mine, Barberton Greenstone Belt, South Africa[J].Precambrian Research, 1999, 96:209-224. doi: 10.1016/S0301-9268(99)00006-6
[7] 刘成林, 王弭力, 焦鹏程.新疆罗布泊盐湖氢氧锶硫同位素地球化学及钾矿成矿物质来源[J].矿床地质, 1999, 18(3):268-275. doi: 10.3969/j.issn.0258-7106.1999.03.009
Liu C L, Wang M L, Jiao P C.Hydrogen, oxygen, strontium and sulfur isotopic geochemistry and potash-forming material sources of LOP salt lake, Xinjiang[J].Mineral Deposits, 1999, 18(3):268-275. doi: 10.3969/j.issn.0258-7106.1999.03.009
[8] 张华, 刘成林, 王立成, 等.老挝他曲盆地钾盐矿床蒸发岩硫同位素特征及成钾指示意义[J].地质论评, 2014, 60(4):851-857. http://d.old.wanfangdata.com.cn/Periodical/dzlp201404014
Zhang H, Liu C L, Wang L C, et al.Characteristics of evaporites sulfur isotope from Potash Deposit in Thakhek Basin, Laos, and its implication for potash formation[J].Geological Review, 2014, 60(4):851-857. http://d.old.wanfangdata.com.cn/Periodical/dzlp201404014
[9] 任顺利, 李延河, 曾普胜, 等.膏盐层在云南会泽和毛坪铅锌矿成矿中的作用:硫同位素证据[J].地质学报, 2018, 92(5):1041-1055. doi: 10.3969/j.issn.0001-5717.2018.05.010
Ren S L, Li Y H, Zeng P S, et al.Effect of sulfate evaporate salt layer in mineralization of the Huize and Maoping lead-zinc deposits in Yunnan:Evidence from sulfur isotope[J].Acta Geologica Sinica, 2018, 92(5):1041-1055. doi: 10.3969/j.issn.0001-5717.2018.05.010
[10] Strauss H.Geological evolution from isotope proxy signals-sulfur[J].Chemical Geology, 1999, 161(1):89-101. http://d.old.wanfangdata.com.cn/NSTLQK/NSTL_QKJJ0210439375/
[11] Ahmad K, Davies C.A model of basin evolution in the Qa'Al-Azraq, Jordan using sulfur isotope analysis to distinguish sources of sulfur and gypsum[J].Carbonates & Evaporites, DOI:10.1107/s13146-017-0138-2.
[12] 李庆宽, 樊启顺, 山发寿, 等.海陆相蒸发岩硫同位素值变化和地球化学应用[J].盐湖研究, 2018, 26(1):73-80. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yhyj201801011
Li Q K, Fan Q S, Shan F S, et al.The variation of sulfur isotope in marine-continental evaporites and its geochemical applications[J].Journal of Salt Lake Research, 2018, 26(1):73-80. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yhyj201801011
[13] Kazuya T, Yoichi N, Yuko M, et al.High-sensitivity sulfur isotopic measurements for Antarctic ice core analyses[J].Rapid Communications in Mass Spectrometry, 2018, 32:1991-1998. doi: 10.1002/rcm.8275
[14] 李延河, 段超, 韩丹, 等.膏盐层氧化障在长江中下游玢岩铁矿成矿中的作用[J].岩石学报, 2014, 30(5):1355-1368. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201405012
Li Y H, Duan C, Han D, et al.Effect of sulfate evaporate salt layer for formation of porphyrite iorn ores in the Middle-Lower Yangtze River area[J].Acta Petrologica Sinica, 2014, 30(5):1355-1368. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201405012
[15] Thode H G, Macnamara J, Collins C B.Narural variations in the isotopic content of sulphur and their signification[J].Canadian Journal of Research, 1949, Canadab-27:361-373. https://www.ncbi.nlm.nih.gov/pubmed/18130453
[16] 卞霄鹏, 刘晨晖, 朱志勇, 等.硫酸盐硫同位素的MC-ICP-MS测定方法研究[J].矿物岩石地球化学通报, 2016, 35(3):465-472. doi: 10.3969/j.issn.1007-2802.2016.03.009
Bian X P, Liu C H, Zhu Z Y, et al.Sulfur isotope measurement of sulfates by using high-resolution MC-ICP-MS[J].Bulletin of Mineralogy, Petrology and Geochemistry, 2016, 35(3):465-472. doi: 10.3969/j.issn.1007-2802.2016.03.009
[17] Giesemann A, Jaeger H J, Norman A L, et al.Online sulfur-isotope determination using an elemental analyzer coupled to a mass spectrometer[J].Analytical Chemistry, 1994, 66(18):2816-2819. doi: 10.1021/ac00090a005
[18] Baublys1 K A, Goldingl S D, Youngl E, et al.Simultaneous determination of δ33SV-CDT and δ34SV-CDT using masses 48, 49 and 50 on a continuous flow isotope ratio mass spectrometer[J]. Rapid Communications in Mass Spectrometry, 2004, 18:2765-2769. doi: 10.1002/rcm.1681
[19] Fourel F, Martineau F, Seris M, et al.Simultaneous N, C, S stable isotope analyses using a new purge and trap elemental analyzer and an isotope ratio mass spectrometer[J].Rapid Communications in Mass Spectrometry, 2014, 28(23):2587-2594. doi: 10.1002/rcm.7048
[20] Grassineau N V, Mattey D P, Lowry D.Sulfur isotope analysis of sulfide and sulfate minerals by continuous flow-isotope ratio mass spectrometry[J].Analysis Chemistry, 2001, 73:220-225. doi: 10.1021/ac000550f
[21] Grassineau N V.High-precision EA-IRMS analysis of S and C isotopes in geological materials[J].Applied Geochemistry, 2006, 21:756-765. doi: 10.1016/j.apgeochem.2006.02.015
[22] Studley S A, Ripley E M, Elswick E R, et al.Analysis of sulfides in whole rock matrices by elemental analyzer-continuous flow isotope ratios mass spectrometry[J].Chemical Geology, 2002, 192:141-148. doi: 10.1016/S0009-2541(02)00162-6
[23] 金贵善, 刘汉彬, 张建锋, 等.硫化物中硫同位素组成的EA-IRMS分析方法[J].铀矿地质, 2014, 30(3):187-192. doi: 10.3969/j.issn.1000-0658.2014.03.010
Jin G S, Liu H B, Zhang J F, et al.EA-IRMS system measurement of stable sulfur isotope in sulphide[J].Uranium Geology, 2014, 30(3):187-192. doi: 10.3969/j.issn.1000-0658.2014.03.010
[24] 韩娟, 刘汉彬, 金贵善, 等.硫同位素组成的样品提取和制备[J].地质学报, 2015, 89(增刊):82-84. http://d.old.wanfangdata.com.cn/Conference/8771780
Han J, Liu H B, Jin G S, et al.Sample extraction and preparation of sulfur isotope composition[J].Acta Geological Sinica, 2015, 89(Supplement):82-84. http://d.old.wanfangdata.com.cn/Conference/8771780
[25] Fourel F, Martineau F, Seris M, et al.Simultaneous N, C, S stable isotope analyses using a new purge and trap elemental analyzer and an isotope ratio mass spectrometer[J].Rapid Communications in Mass Spectrometry, 2014, 28(23):2587-2594. doi: 10.1002/rcm.7048
[26] Fry B, Silva S R, Kendall C, et al.Oxygen isotope corrections for online δ34S analysis[J].Rapid Communications in Mass Spectrometry, 2002, 16:854-858. doi: 10.1002/rcm.651
[27] 韩娟, 刘汉彬, 金贵善, 等.样品质量对EA-IRMS法测量硫同位素组成的影响[J].铀矿地质, 2018, 34(3):166-173. doi: 10.3969/j.issn.1000-0658.2018.03.006
Han J, Liu H B, Jin G S, et al.Sample mass influence on the measurement of sulfur isotopic composition by EA-IRMS method[J].Uranium Geology, 2018, 34(3):166-173. doi: 10.3969/j.issn.1000-0658.2018.03.006
[28] 白瑞梅, 李金城.热解硫酸钡制备硫同位素分析试样二氧化硫[J].岩矿测试, 1998, 17(1):40-43. doi: 10.3969/j.issn.0254-5357.1998.01.006 http://www.ykcs.ac.cn/article/id/ykcs_19980109
Bai R M, Li J C.Thermal decomposition of barium sulfate for preparation of sulfur dioxide used in sulfur isotope analysis[J].Rock and Mineral Analysis, 1998, 17(1):40-43. doi: 10.3969/j.issn.0254-5357.1998.01.006 http://www.ykcs.ac.cn/article/id/ykcs_19980109
-
