Determination of Trace Silver in Geological Samples by Inductively Coupled Plasma-Mass Spectrometry with Acid Decomposition and Internal Standard Calibration
-
摘要:
应用电感耦合等离子体质谱法（ICP-MS）测定地质样品中的痕量银时，Zr、Nb、Mo的氧化物以及氢氧化物对银的两个质量数107Ag和109Ag造成严重的质谱重叠干扰，导致结果有明显的偏差。针对此问题，本文基于107Ag的质谱干扰相对单一，只有90Zr16OH+和91Zr16O+对107Ag产生干扰，在ICP-MS分析中选用107Ag对银进行测定。样品前处理中采用氢氟酸、高氯酸、硝酸敞开消解，在浸提液中加入过量氨水，将107Ag的主要干扰元素Zr通过生成沉淀实现分离，以Re作内标补偿基体效应和信号漂移，采用ICP-MS测定了水系沉积物、岩石、土壤国家标准物质中痕量银的含量，测试值与认定值一致，方法检出限为0.0031μg/g，相对标准偏差（RSD）为4.38%。该方法简捷，在浸取液中加入氨水之前可以先测定常见金属元素，实现了浸取溶液的循环再利用。
Abstract:BACKGROUND Inductively coupled plasma-mass spectrometry (ICP-MS) is used for the determination of trace silver in geological samples. Hydroxides and oxides of Zr, Nb, Mo cause serious overlapping interference on the two mass numbers of 107Ag and 109Ag, which can result in a significant deviation of the results.
OBJECTIVES To develop a method for precise determination of trace Ag in geological samples.
METHODS Considering that the MS interference of 107Ag is relatively simple and only 90Zr16OH+ and 91Zr16O+ have interferences on 107Ag, 107Ag was selected for the determination of silver in ICP-MS analysis. In the sample pretreatment, hydrofluoric acid, perchloric acid and nitric acid were used for open digestion, and excessive ammonia was added to the extraction solution. The main interference element Zr of 107Ag was separated by precipitation. Trace silver was determined with Re as the internal standard to complement matrix effect and signal drift.
RESULTS The content of trace silver in national standard materials of stream sediment, rock and soil was determined by ICP-MS. The test value was consistent with the certified value. The detection limit of the method was 0.0031μg/g, and the relative standard deviation (RSD) was 4.38%.
CONCLUSIONS The method has the advantages of simple and accurate measurement of trace silver. Moreover, common metal elements can be determined before adding ammonia to the leaching solution, so that the extraction solution can be recycled.
-
-
表 1 样品不同处理方式ICP-MS测定锆的强度对比
Table 1. Comparison of zirconium strength measured by ICP-MS with different sample pretreatment methods
样品处理条件 锆的强度(cps) 平行样1 平行样2 平行样3 王水溶解空白 2353.2 2387.4 2311.6 王水溶解GBW07309 83247.3 84118.3 84212.2 三酸溶解空白 2415.7 2378.4 2411.3 三酸溶解GBW07309 1018157.0 1054670.4 1034180.6 三酸溶解-氨水除锆处理GBW07309 2576.3 2502.7 2532.3
下载: 导出CSV
表 2 不同元素加标回收率对比
Table 2. Comparison of spiked recovery of different elements
分析元素 加标量
(μg/L)本法平行测定的银含量
(μg/ L)平均值
(μg/L)加标回收率
(%)Ag 5.00 4.88 4.90 4.87 4.90 4.89 97.82 4.89 4.86 4.91 4.92 Rh 5.00 2.33 2.38 2.33 2.34 2.38 46.55 2.31 2.33 2.30 2.30 Re 5.00 5.01 5.00 4.95 4.93 4.98 99.68 5.03 4.98 5.03 4.94
下载: 导出CSV
表 3 方法精密度
Table 3. Precision tests of the method
GBW07309中Ag的认定值(μg/g) 本法测定的银含量(μg/g) RSD(%) 平行测定值 平均值 0.089±0.010 0.088 0.083 0.095 0.091 0.090 4.38 0.094 0.088 0.095 0.087 0.086 0.093 0.093 0.088
下载: 导出CSV
表 4 方法准确度
Table 4. Accuracy tests of the method
标准物质编号 银含量(μg/g) 标准偏差允许范围
(μg/g)测定值 认定值 GBW07309 0.092 0.089 ±0.010 GBW07310 0.26 0.27 ±0.02 GBW07311 3.3 3.2 ±0.4 GBW07312 1.11 1.15 ±0.11 GBW07404 0.075 0.070 ±0.011 GBW07405 4.4 4.4 ±0.4 GBW07406 0.021 0.20 ±0.02 GBW07407 0.063 0.057 ±0.011
下载: 导出CSV
-
[1] 陈永红, 姜莹, 洪博, 等. 2015-2016年中国银分析测定的进展[J]. 黄金, 2018, 39(2): 71-75. https://www.cnki.com.cn/Article/CJFDTOTAL-HJZZ201802018.htm
Chen Y H, Jiang Y, Hong B, et al. Progress of silver analysis and determination in China from 2015 to 2016[J]. Gold, 2018, 39(2): 71-75. https://www.cnki.com.cn/Article/CJFDTOTAL-HJZZ201802018.htm
[2] 陈永红, 洪博, 孟宪伟, 等. 2017-2018年中国银分析测定的进展[J]. 黄金, 2020, 41(2): 81-86. https://www.cnki.com.cn/Article/CJFDTOTAL-HJZZ202002018.htm
Chen Y H, Hong B, Meng X W, et al. Progress of silver analysis and determination in China from 2017 to 2018[J]. Gold, 2020, 41(2): 81-86. https://www.cnki.com.cn/Article/CJFDTOTAL-HJZZ202002018.htm
[3] 张恒维. 电感耦合等离子体发射光谱法测定地质样品中银和铜的应用研究[D]. 北京: 中国地质大学(北京), 2018.
Zhang H W. Determination of silver and copper in geological samples by ICP-AES[D]. Beijing: China University of Geosciences (Beijing), 2018.
[4] 张帆, 王浩杰, 蔡薇, 等. 沉淀分离后电感耦合等离子体发射光谱法分析99.99%银中的杂质元素[J]. 生物化工, 2018, 4(6): 106-107, 119. doi: 10.3969/j.issn.2096-0387.2018.06.029
Zhang F, Wang H J, Cai W, et al. ICP-AES analysis after precipitation separation 99.99% impurity elements in silver[J]. Biochemistry, 2018, 4(6): 106-107, 119. doi: 10.3969/j.issn.2096-0387.2018.06.029
[5] 李超, 刘英波, 韩豫萍, 等. 发射光谱法测定地球化学物料中的微量银锡硼[J]. 云南冶金, 2018, 47(3): 84-88. doi: 10.3969/j.issn.1006-0308.2018.03.014
Li C, Liu Y B, Han Y P, et al. Determination of trace silver, tin and boron in geochemical materials by emission spectrometry[J]. Yunnan Metallurgy, 2018, 47(3): 84-88. doi: 10.3969/j.issn.1006-0308.2018.03.014
[6] 苏丹, 云作敏. 火焰原子吸收法测定岩石样品中微量银方法的改进[J]. 黄金, 2010, 31(10): 63-64. doi: 10.3969/j.issn.1001-1277.2010.10.015
Su D, Yun Z M. Improvement of the method for the determination of trace silver in rock samples by FAAS[J]. Gold, 2010, 31(10): 63-64. doi: 10.3969/j.issn.1001-1277.2010.10.015
[7] 姚旭. 萃取富集-火焰原子吸收法测定化探样品中的微量银[J]. 天津化工, 2016, 30(6): 54-55. doi: 10.3969/j.issn.1008-1267.2016.06.021
Yao X. Determination of trace silver in geochemical exploration samples by extraction enrichment flame atomic absorption spectrometry[J]. Tianjin Chemical Industry, 2016, 30(6): 54-55. doi: 10.3969/j.issn.1008-1267.2016.06.021
[8] 宛瑞静. 探讨火焰原子吸收法测定岩石、土壤中微量银[J]. 世界有色金属, 2018(20): 202-203. doi: 10.3969/j.issn.1002-5065.2018.20.115
Wan R J. Determination of trace silver in rock and soil by FAAS[J]. World Nonferrous Metals, 2018(20): 202-203. doi: 10.3969/j.issn.1002-5065.2018.20.115
[9] 陈洪流, 柳城, 高升, 等. 酸性硫脲浸取-石墨炉原子吸收光谱法测定化探样品中的微量银[J]. 黄金, 2018, 39(7): 80-82. https://www.cnki.com.cn/Article/CJFDTOTAL-HJZZ201807018.htm
Chen H L, Liu C, Gao S, et al. Determination of trace silver in geochemical exploration samples by acid thiourea leaching graphite furnace atomic absorption spectrometry[J]. Gold, 2018, 39(7): 80-82. https://www.cnki.com.cn/Article/CJFDTOTAL-HJZZ201807018.htm
[10] 林越华. 石墨炉原子吸收光谱法测定地质样品中微量银[J]. 山东工业技术, 2015(2): 311. https://www.cnki.com.cn/Article/CJFDTOTAL-SDGJ201502274.htm
Lin Y H. Determination of trace silver in geological samples by GFAAS[J]. Shandong Industrial Technology, 2015(2): 311. https://www.cnki.com.cn/Article/CJFDTOTAL-SDGJ201502274.htm
[11] 朱继芬. 离子交换树脂分离富集-分光光度法测定矿石中微量钼、银[D]. 沈阳: 辽宁大学, 2011.
Zhu J F. Determination of trace molybdenum and silver in ores by ion exchange resin separation and concentration spectrophotometry[D]. Shenyang: Liaoning University, 2011.
[12] 张鸣, 林海山. 留铅灰吹-电位滴定法测定导电银浆中的银含量[J]. 材料研究与应用, 2013, 7(1): 61-63. doi: 10.3969/j.issn.1673-9981.2013.01.014
Zhang M, Lin H S. Determination of silver content in conductive silver paste by lead retention soot blowing potentiometric titration[J]. Materials Research and Application, 2013, 7(1): 61-63. doi: 10.3969/j.issn.1673-9981.2013.01.014
[13] 郝志红, 姚建贞, 唐瑞玲, 等. 直流电弧全谱直读原子发射光谱法(DC-Arc-AES)测定地球化学样品中痕量硼、钼、银、锡、铅的方法研究[J]. 光谱学与光谱分析, 2015, 35(2): 527-533. doi: 10.3964/j.issn.1000-0593(2015)02-0527-07
Hao Z H, Yao J Z, Tang R L, et al. Determination of trace boron, molybdenum, silver, tin and lead in geochemical samples by DC arc direct reading atomic emission spectrometry[J]. Spectroscopy and Spectral Analysis, 2015, 35(2): 527-533. doi: 10.3964/j.issn.1000-0593(2015)02-0527-07
[14] 肖刘萍. 灰吹富集-氯化钠电位滴定法测定贵铅中银[J]. 冶金分析, 2018, 38(3): 56-60. https://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201803010.htm
Xiao L P. Determination of silver in precious lead by potentiometric titration after soot blowing enrichment[J]. Metallurgical Analysis, 2018, 38(3): 56-60. https://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201803010.htm
[15] 赵质元. Prodigy直流电弧法直接测定地质样品中银锡硼等痕量元素[J]. 岩矿测试, 2012, 31(5): 922-923. doi: 10.3969/j.issn.0254-5357.2012.05.028
Zhao Z Y. Direct determination of trace elements such as silver, tin and boron in geological samples by prodigy DC arc method[J]. Rock and Mineral Analysis, 2012, 31(5): 922-923. doi: 10.3969/j.issn.0254-5357.2012.05.028
[16] 盛建林. 粗铜中金银的测定——湿干联合试金法[J]. 黄金, 1994, 15(2): 59-60. https://www.cnki.com.cn/Article/CJFDTOTAL-HJZZ402.015.htm
Sheng J L. Determination of gold and silver in crude copper by wet dry combined assay[J]. Gold, 1994, 15(2): 59-60. https://www.cnki.com.cn/Article/CJFDTOTAL-HJZZ402.015.htm
[17] 孙中华, 章志仁, 毛英, 等. 电弧蒸馏光谱法测定化探样品中痕量银锡铅硼镓[J]. 岩矿测试, 2004, 23(2): 153-156. doi: 10.3969/j.issn.0254-5357.2004.02.015
Sun Z H, Zhang Z R, Mao Y, et al. Determination of trace Ag, Sn, Pb, B, Ga in geochemical exploration samples by arc distillation spectrometry[J]. Rock and Mineral Analysis, 2004, 23(2): 153-156. doi: 10.3969/j.issn.0254-5357.2004.02.015
[18] 张小叶. 磁性材料和碳材料对水中银纳米的富集分离研究[D]. 重庆: 西南大学, 2016.
Zhang X Y. Enrichment and separation of silver nanoparticles in water by magnetic and carbon materials[D]. Chongqing: Southwest University, 2016.
[19] 刘向磊, 孙文军, 文田耀, 等. 负载泡塑富集-电感耦合等离子体质谱法测定地质样品中痕量金和银[J]. 分析化学, 2015, 43(9): 1371-1376. https://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201509022.htm
Liu X L, Sun W J, Wen T Y, et al. Determination of trace gold and silver in geological samples by ICP-MS with loaded foam enrichment[J]. Analytical Chemistry, 2015, 43(9): 1371-1376. https://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201509022.htm
[20] Gros M, Lorand J P, Luguet A. Analysis of platinum group elements and gold in geological materials using NiS fire assay and Te coprecipitation; the NiS dissolution step revisited[J]. Chemical Geology, 2002, 185: 179-190. doi: 10.1016/S0009-2541(01)00405-3
[21] 高玉花, 毕建玲, 殷学博, 等. P507负载泡塑分离-ICP-MS测定地质样品中的痕量银[J]. 山东国土资源, 2015, 31(12): 70-73. doi: 10.3969/j.issn.1672-6979.2015.12.031
Gao Y H, Bi J L, Yin X B. Determination of trace silver in geological samples by P507 loaded foam separation ICP-MS[J]. Shandong Land Resources, 2015, 31(12): 70-73. doi: 10.3969/j.issn.1672-6979.2015.12.031
[22] 周丽萍, 李中玺. 王水提取-电感耦合等离子体质谱法同时测定地质样品中微量银、镉、铋[J]. 分析试验室, 2005, 24(9): 20-25. doi: 10.3969/j.issn.1000-0720.2005.09.006
Zhou L P, Li Z X. Simultaneous determination of silver, cadmium and bismuth in geological samples by aqua regia extraction-inductively coupled plasma mass spectrometry[J]. Analytical Laboratory, 2005, 24(9): 20-25. doi: 10.3969/j.issn.1000-0720.2005.09.006
[23] Xu J, Hu Z C, Liu, Y S, et al. Direct determination of Ag in geological samples by membrane desolvation-inductively coupled plasma-mass spectrometer[J]. Chinese Journal of Analytical Chemistry, 2008, 36(11): 1493-1498. doi: 10.1016/S1872-2040(09)60002-5
[24] 韩国军, 伍星, 童坚. 膜去溶-ICP-MS测定高纯CeO2中14种痕量稀土杂质分析方法研究[J]. 中国稀土学报, 2009, 27(1): 137-144. doi: 10.3321/j.issn:1000-4343.2009.01.025
Han G J, Wu X, Tong J. Determination of 14 trace rare earth impurities in high purity CeO2 by membrane desolvation ICP-MS[J]. Chinese Journal of Rare Earth, 2009, 27(1): 137-144. doi: 10.3321/j.issn:1000-4343.2009.01.025
[25] 朱志刚, 李美丽, 孙元芳, 等. ICP-MS测定银的干扰现象分析与方法建立[J]. 分析仪器, 2016(5): 70-74. https://www.cnki.com.cn/Article/CJFDTOTAL-FXYQ201605017.htm
Zhu Z G, Li M L, Sun Y F, et al. Interference analysis and method establishment for determination of silver by ICP-MS[J]. Analytical Instrument, 2016(5): 70-74. https://www.cnki.com.cn/Article/CJFDTOTAL-FXYQ201605017.htm
[26] 刘静波, 张更宇. 全自动消解电感耦合等离子体质谱仪测定环境土壤中铍钡铊银[J]. 分析试验室, 2018, 37(2): 207-211. https://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201802017.htm
Liu J B, Zhang G Y. Determination of beryllium, barium, thallium and silver in environmental soil by fully automatic digestion inductively coupled plasma mass spectrometry[J]. Analytical Laboratory, 2018, 37(2): 207-211. https://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201802017.htm
[27] 郎闻生. 微波消解-电感耦合等离子体质谱法测定环境土壤中银的研究[J]. 黑龙江环境通报, 2018, 42(4): 44-47. doi: 10.3969/j.issn.1674-263X.2018.04.013
Lang W S. Determination of silver in environmental soil by microwave digestion inductively coupled plasma mass spectrometry[J]. Heilongjiang Environmental Bulletin, 2018, 42(4): 44-47. doi: 10.3969/j.issn.1674-263X.2018.04.013
[28] 王家恒, 刘冬云. 动态反应池-电感耦合等离子体质谱法同时测定地质样品中的金和银[J]. 分析试验室, 2017, 36(7): 819-822. https://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201707018.htm
Wang J H, Liu D Y. Simultaneous determination of gold and silver in geological samples by dynamic reactor inductively coupled plasma mass spectrometry[J]. Analytical Laboratory, 2017, 36(7): 819-822. https://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201707018.htm
[29] 《岩石矿物分析》编委会. 岩石矿物分析(第四版第一分册)[M]. 北京: 地质出版社, 2011: 201-208.
The editorial committee of < Rock and Mineral Analysis > . Rock and mineral analysis (The fourth edition: Vol. Ⅰ)[M]. Beijing: Geological Publishing House, 2011: 201-208.
[30] Young R S. Chenmical analysis in extractive metallurgy[M]. London: Charles Griffin, 1971.
-
