摘要:
邻苯二甲酸酯类化合物(Phthalates，PAEs)作为一类持续释放并存在于环境中的有机污染物，被列入优先控制污染物名单。土壤是PAEs在环境中的最后归宿之一，中国对土壤中PAEs的污染调查和防控已全面展开。分析测试是环境监测和科学研究的基础，土壤基体标准物质是保证实验数据的准确性和可靠性的重要手段，然而，目前现有的相关标准物质无法满足实际需要。本文针对中国土壤中PAEs污染特征及实际样品分析质量控制需求，采用多家实验室联合定值的方式，研制了4种适用于土壤中不同污染水平PAEs分析的标准物质。候选物样品主要采自农田土壤、地膜覆盖土壤、塑料垃圾回收站周围土壤和塑料制品加工厂周围土壤，经过均匀性、长期稳定性和短期稳定性检验，结果表明均匀性和稳定性均满足要求；在定值过程中，针对PAEs分析空白不易控制的难点，对空白的污染源进行识别和确认，制定严格的质量控制措施，保证了全流程空白值稳定在一定范围内；9家实验室采用气相色谱-质谱法(GC-MS)对候选物中4种PAEs进行协作定值，并评估其不确定度，特性量值范围在36～2870µg/kg，同时邀请权威实验室采用同位素稀释质谱法对定值结果进行验证，确保定值结果的准确性。该系列标准物质已被批准为国家一级标准物质（编号GBW07595～GBW07598），可以满足PAEs分析质量保证与质量控制的要求，为生态地质调查评价提供技术支撑。
Abstract:Phthalates (PAEs) are a class of organic pollutants that are continuously released and present in the environment and are listed as priority-controlled pollutants. Soil is one of the main final fates of PAEs in the environment, and China has fully launched investigations and controls on soil pollution of PAEs. Analysis is the foundation of environmental monitoring and scientific research, and the certified reference materials in soil are important means to ensure the accuracy and reliability of determination for soil. However, the existing relevant reference materials do not meet the actual needs of pollution monitoring in China. In this study, according to the characteristics of PAEs pollution and quality control requirements of actual samples, four certified reference materials for PAEs analysis in soils have been developed through the nine laboratories’ collaborative analysis. The candidates were mainly collected from agricultural soils, plastic film mulched soil, industrial soil, and plastic recycling station soil. After homogeneity and stability testing, the results show that both homogeneity and stability meet the requirements. During the certification process, in response to the difficulty of controlling the PAEs analysis blank, the pollution source of the blank was identified and confirmed, and strict quality control measures were formulated to ensure that the blank concentration throughout the entire process remained stable within a certain range. Nine laboratories used gas chromatography-mass spectrometry (GC-MS) to collaboratively determine the values of 4 PAEs and evaluated their uncertainty in soils. The certified values of 4 PAEs in soils ranging from 36g/kg to 2.87mg/kg. The authoritative domestic laboratory used isotope dilution mass spectrometry to verify the accuracy of the certification results. This series of reference materials have been approved as a national first-class reference material, numbered from GBW07595 to GBW07598, which meets the requirements of PAEs analysis quality assurance and quality control, and provides technical support for ecological geological survey and evaluation.
-
-
表 1 候选物GSSO-12均匀性检验结果
Table 1. Homogeneity test for candidate GSSO-12
参数 DMP DiBP DBP DEHP 目标物平均值 (µg/kg) 37.5 409 754 653 RSD (%) 10.4 7.59 7.39 10.7 $ {M}_{\mathrm{b}\mathrm{e}\mathrm{t}\mathrm{w}\mathrm{e}\mathrm{e}\mathrm{n}} $ (µg 2/kg2)15.84 1029 2924 5255 $ {M}_{\mathrm{w}\mathrm{i}\mathrm{t}\mathrm{h}\mathrm{i}\mathrm{n}} $ (µg 2/kg2)12.62 816 2263 4156 F实测值 1.292 1.261 1.291 1.265 $ {S}_{\mathrm{b}\mathrm{b}} $ (µg/kg)1.05 8.43 14.9 19.2 注：F0.05(24，50) = 1.737。
下载: 导出CSV
表 2 候选物GSSO-12长期稳定性检验(4℃)数据和短期稳定性检验(50℃)数据
Table 2. Long stability test (4℃) and short stability test (50℃) data for candidate GSSO-12
PAEs
化合物长期稳定性检验(4℃) 短期稳定性检验(50℃) 含量平均值
(µg/kg)RSD
(%)b1 $t_{0.05} \times S(b_1) $ us1
(µg/kg)含量平均值
(µg/kg)RSD
(%)b1 $t_{0.05} \times S(b_1) $ uss
(µg/kg)DMP 36.5 5.84 −0.062 0.981 3.71 36.2 4.29 0.0095 0.829 2.61 DiBP 406 5.05 −0.242 9.57 36.2 401 2.93 −0.279 6.43 20.3 DBP 769 5.56 4.86 16.7 63.2 750 3.17 −2.917 11.1 34.9 DEHP 642 5.62 0.016 16.8 63.4 654 2.56 1.244 8.56 27.0
下载: 导出CSV
表 3 候选物GSSO-12定值校准用溶液标准物质引入的不确定度
Table 3. The uncertainty introduced by certified reference materials in calibration solutions for candidate GSSO-12
PAEs
化合物定值用溶液标准物质 候选物GSSO-12校准溶液引入的不确定度 标准物质编号 标准值
(µg/mL)相对扩展不确定度(%)
(k=2)相对不确定度
(%)量值
(µg/kg)uB1
(µg/kg)DMP GBW(E)100221 237 2 1 35.9 0.36 DiBP GBW(E)100284 1000 2 1 397 3.97 DBP GBW10134 500 3 1.5 757 11.4 DEHP GBW10165 500 3 1.5 669 10.1
下载: 导出CSV
表 4 候选物GSSO-12溶液配制引入的不确定度
Table 4. The uncertainty introduced by calibration solution preparation for candidate GSSO-12
PAEs
化合物候选物GSSO-12 量值
(µg/kg)相对不确定度
(%)uB2
(µg/kg)DMP 35.9 0.287 0.11 DiBP 397 0.457 1.83 DBP 757 0.287 2.18 DEHP 669 0.287 1.93
下载: 导出CSV
表 5 候选物GSSO-12标准曲线拟合引入的不确定度
Table 5. The uncertainty introduced by calibration curve fitting for candidate GSSO-12
PAEs
化合物候选物GSSO-12 量值
(µg/kg)uB3
(µg/kg)相对不确定度
(%)DMP 35.9 1.02 2.85 DiBP 397 2.45 0.61 DBP 757 3.23 0.43 DEHP 669 4.80 0.72
下载: 导出CSV
表 6 候选物GSSO-12样品称量引入的不确定度uB4和添加内标溶液引入的不确定度uB5
Table 6. The uncertainty introduced by sampling weigh and adding internal standard solution for candidate GSSO-12
PAEs化合物 候选物GSSO-12 量值
(µg/kg)样品称量引入的不确定度 添加内标量引入的不确定度 相对不确定度
(%)uB4
(µg/kg)相对不确定度
(%)uB5
(µg/kg)DMP 35.9 0.0892 0.032 0.326 0.12 DiBP 397 0.0892 0.36 0.326 1.31 DBP 757 0.0892 0.68 0.326 2.47 DEHP 669 0.0892 0.60 0.326 2.19
下载: 导出CSV
表 7 候选物GSSO-12的不确定度
Table 7. The uncertainty of candidate GSSO-12
PAEs化合物 量值
(µg/kg)ubb
(µg/kg)usl
(µg/kg)uss
(µg/kg)uA
(µg/kg)uB1
(µg/kg)uB2
(µg/kg)uB3
(µg/kg)uB4
(µg/kg)uB5
(µg/kg)uCRM
(µg/kg)UCRM
(µg/kg)DMP 35.9 1.05 3.71 2.61 1.38 0.36 0.11 1.02 0.032 0.12 4.98 10 DiBP 397 8.43 36.2 20.3 10.7 3.97 1.83 2.45 0.36 1.31 44.0 88 DBP 757 14.9 63.2 34.9 19.5 11.4 2.18 3.23 0.68 2.47 77.2 160 DEHP 669 19.2 63.4 27.0 13.7 10.1 1.93 4.80 0.60 2.19 73.9 150
下载: 导出CSV
表 8 四个PAEs成分分析标准物质的标准值及扩展不确定度
Table 8. Certified values and expanded uncertainties for four PAE certified reference materials
特性量 标准物质的特性量值及扩展不确定度(µg/kg) GBW07595
(GSSO-12)GBW07596
(GSSO-13)GBW07597
(GSSO-14)GBW07598
(GSSO-15)DMP 36±10 74±18 — — DiBP 397±88 1.13×103±0.25×103 88±24 314±73 DBP 0.76×103±0.16×103 1.21×103±0.26×103 413±96 302±69 DEHP 0.67×103±0.15×103 2.87×103±0.53×103 412±98 2.46×103±0.48×103 注：“—”表示该化合物未定值。
下载: 导出CSV
-
[1] Jiang N, Song P, Li X, et al. Dibutyl phthalate induced oxidative stress and genotoxicity on adult Zebrafish (Danio rerio) Brain[J]. Journal of Hazardous Materials, 2022, 424: 127749. doi: 10.1016/j.jhazmat.2021.127749
[2] Lee Y M, Lee J E, Choe W, et al. Distribution of phthalate esters in air, water, sediments, and fish in the Asan Lake of Korea[J]. Environmental International, 2019, 126: 635−643. doi: 10.1016/j.envint.2019.02.059
[3] Sun S, Wang M, Yang X, et al. Pollution characteristics and health risk assessment of phthalate esters in agricultural soil of the Yellow River Delta, China[J]. Environmental Science and Pollution Research, 2023, 30: 53370−53380. doi: 10.1007/s11356-023-26104-3
[4] Wang M, Su Y, Lu J, et al. Content level and risk assessment of phthalate esters in surface water of Bosten Lake, China[J]. Environmental Science and Pollution Research, 2023, 30: 74991−75001. doi: 10.1007/s11356-023-27627-5
[5] Mi L, Xie Z, Xu W, et al. Air-sea exchange and atmospheric deposition of phthalate esters in the South China Sea[J]. Environmental Science & Technology, 2023, 57: 11195−11205.
[6] Wang X, Zhang Y, Huang B, et al. Atmospheric phthalate pollution in plastic agricultural greenhouses in Shaanxi Province, China[J]. Environmental Pollution, 2021, 269: 116096. doi: 10.1016/j.envpol.2020.116096
[7] Cao Y, Li J, Wu R, et al. Phthalate esters in seawater and sediment of the Northern South China Sea: Occurrence, distribution, and ecological risks[J]. Science of the Total Environment, 2022, 811: 151412. doi: 10.1016/j.scitotenv.2021.151412
[8] Pausekki A, Kim S K. Horizontal and vertical distribution of phthalates ester (PAEs) in seawater and sediment of East China Sea and Korean South Sea: Traces of plastic debris[J]. Marine Pollution Bulletin, 2020, 151: 110831. doi: 10.1016/j.marpolbul.2019.110831
[9] Liu B, Lv L, Ding L, et al. Comparison of phthalate esters (PAEs) in freshwater and marine food webs: Occurrence, bioaccumulation, and trophodynamics[J]. Journal of Hazardous Materials, 2024, 466: 133534. doi: 10.1016/j.jhazmat.2024.133534
[10] Alkan N, Alkan A, Castro-Jimenez J, et al. Environmental occurrence of phthalate and organophosphate esters in sediments across the Gulf of Lion (NW Mediterranean Sea)[J]. Science of the Total Environment, 2021, 760: 143412. doi: 10.1016/j.scitotenv.2020.143412
[11] Ramirez M M B, Caamal R D, von Osten J R. Occurrence and seasonal distribution of microplastics and phthalates in sediments from the urban channel of the Ria and coast of Campeche Mexico[J]. Science of the Total Environment, 2019, 672: 97−105.472. doi: 10.1016/j.scitotenv.2019.03.472
[12] Li Y, Cheng S, Fang H, et al. Composition, distribution, health risks, and drivers of phthalates in typical red paddy soils[J]. Environmental Science and Pollution Research, 2023, 30: 94814−94826. doi: 10.1007/s11356-023-28815-z
[13] Tao H, Wang Y, Liang H, et al. Pollution characteristics of phthalate acid esters in agricultural soil of Yinchuan, Northwest China, and health risk assessment[J]. Environmental Geochemistry and Health, 2020, 42: 4313−4326. doi: 10.1007/s10653-019-00502-4
[14] Cui J, Bai R, Ding W, et al. Potential agricultural contamination and environmental risk phthalate acid esters arrived from plastic film mulching[J]. Journal of Environmental Chemical Engineering, 2024, 12: 111785. doi: 10.1016/j.jece.2023.111785
[15] Gu Y Y, Wei Q, Wang L Y, et al. A comprehensive study of the effects of phthalates on marine mussels: Bioconcentration, enzymatic activities and meta-bolomics[J]. Marine Pollution Bulletin, 2021, 168: 112393. doi: 10.1016/j.marpolbul.2021.112393
[16] He M J, Lu J F, Wang J, et al. Phthalate esters in biota, air and water in an agricultural area of Western China, with emphasis on bioaccumulation and human exposure[J]. Science of the Total Environment, 2020, 698: 134264. doi: 10.1016/j.scitotenv.2019.134264
[17] Zhang Y, Yang Y, Tao Y, et al. Phthalates (PAEs) and reproductive toxicity: Hypothalamic-pituitary-gonadal (HPG) axis aspects[J]. Journal of Hazardous Materials, 2023, 459: 132182. doi: 10.1016/j.jhazmat.2023.132182
[18] Wei L Y, Li Z H, Sun J T, et al. Pollution characteristics and health risk assessment of phthalate esters in agricultural soil and vegetables in the Yangtze River Delta of China[J]. Science of the Total Environment, 2020, 726: 137978.066. doi: 10.1016/j.scitotenv.2020.137978
[19] Xing H, Yu X, Sun J, et al. Interaction between phthalate ester and rice plants: Novel transformation pathways and metabolic-network perturbations[J]. Environmental Science & Technology, 2023, 57: 8870−8882. doi: org/10.1021/acs.est.2c09737
[20] Wang Z, Ma J, Wang T, et al. Environmental health risks induced by interaction between phthalic acid esters (PAEs) and biological macromolecules: A review[J]. Chemosphere, 2023, 328: 138578. doi: 10.1016/j.chemosphere.2023.138578
[21] Yang P, Deng L J, Xie J Y, et al. Phthalate exposure with sperm quality among healthy Chinese male adults: The role of sperm cellular function[J]. Environmental Pollution, 2023, 331: 121755. doi: org/10.1016/j.envpol.2023.121755
[22] 王亚,肖霞霞,杨云,等. 溶剂萃取-气相色谱-三重四极杆串联质谱法测定水体和土壤中6种邻苯二甲酸酯[J]. 分析科学学报, 2023, 39(3): 287−293.
Wang Y, Xiao X X, Yang Y, et al. Determination of six phthalic acid esters in water and soil samples by gas chromatography-tandem mass spectrometry with solvent extraction method[J]. Journal of Analytical Science, 2023, 39(3): 287−293.
[23] Carlon C. Derivation methods of soil screening values in Europe[R]//A review and evaluation of national procedures towards harmonization. Joint Research Centre, European Commission, 2007: 306.
[24] Li X, Wang Q, Jiang N, et al. Occurrence, source, ecological risk, and mitigation of phthalates (PAEs) in agricultural soils and the environment: A review[J]. Environmental Research, 2023, 220: 115196. doi: 10.1016/j.envres.2022.115196
[25] Tao Y, Cui Y, Zhu G, et al. Fate, ecotoxicity, and remediation of phthalic acid ester in soils[J]. Environmental Pollution, 2023, 32: 100440.
[26] Niu L, Xu Y, Xu C, et al. Status of phthalate esters contamination in agricultural soils across China and associated health risks[J]. Environmental Pollution, 2014, 195: 16−23. doi: 10.1016/j.envpol.2014.08.014
[27] Li C, Chen J, Wang J, et al. Phthalate esters in soil, plastic film, and vegetable from greenhouse vegetable production bases in Beijing, China: Concentrations, sources, and risk assessment[J]. Science of the Total Environment, 2016, 568: 1037−1043. doi: 10.1016/j.scitotenv.2016.06.077
[28] Li X, Liu W, Zhang C, et al. Fate of phthalic acid esters (PAEs) in typical greenhouse soils of different cultivation ages[J]. Bulletin of Environmental Contamination and Toxicology, 2020, 104: 301−306. doi: 10.1007/s00128-019-02756-1
[29] Li X, Li N, Wang C, et al. Occurrence of phthalate acid esters (PAEs) in protected agriculture soils and implications for human health exposure[J]. Bulletin of Environmental Contamination and Toxicology, 2022, 109: 548−555. doi: 10.1007/s00128-022-03553-z
[30] Zeng F, Cui K, Xie Z, et al. Phthalate esters (PAEs): Emerging organic contaminants in agricultural soils in Periurban areas around Guangzhou, China[J]. Environmental Pollution, 2008, 156: 425−434. doi: 10.1016/j.envpol.2008.01.045
[31] Brodskiy E S, Shelepchikov A A, Agapkina G I, et al. Phthalate esters’ content in soils of Moscow[J]. Environment and Security, 2019, 74: 88−92. doi: DOI:org/10.3103/S0147687419020029.
[32] Berenstein G, Hughes E A, Zalts A, et al. Environmental fate of dibutylphthalate in agricultural plastics: Photodegradation, migration and ecotoxicological impact on soil[J]. Chemosphere, 2022: 133221.
[33] Yesildagli B, Goktas R K, Ayaz T, et al. Phthalate ester levels in agricultural soils of greenhouses, their potential sources, the role of plastic cover material, and dietary exposure calculated from modeled concentrations in tomato[J]. Journal of Hazardous Materials, 2024, 468: 133710. doi: 10.1016/j.jhazmat.2024.133710
[34] Wang D, Xi Y, Shi X Y, et al. Effect of plastic film mulching and film residues on phthalate esters concentrations in soil and plants, and its risk assessment[J]. Environmental Pollution, 2021, 286: 117546. doi: 10.1016/j.envpol.2021.117546
[35] Tan W, Zhang Y, He X, et al. Distribution patterns of phthalic acid esters in soil particle-size fractions determine biouptake in soil-cereal crop systems[J]. Scientific Reports, 2016, 6: 31987. doi: 10.1038/srep31987
[36] Gao H, Liu Q, Yan C, et al. Macro-and/or micorplastics as an emerging threat effect crop growth and soil health[J]. Resources Conservation Recycling, 2022, 186: 106549. doi: 10.1016/j.resconrec.2022.106549
[37] Zhang J, Ren S, Xu W, et al. Effects of plastic residues and microplastics on soil ecosystems: A global meta-analysis[J]. Journal of Hazardous Materials, 2022, 435: 129065. doi: 10.1016/j.jhazmat.2022.129065
[38] Cao J, Gao X, Cheng Z, et al. The harm of residual plastic film and its accumulation driving factors in Northwest China[J]. Environmental Pollution, 2023, 318: 120910. doi: 10.1016/j.envpol.2022.120910
[39] 田芹, 佟玲, 安子怡, 等. 沉积物中多环芳烃、有机氯农药和多氯联苯成分分析标准物质研制[J]. 岩矿测试, 2022, 41(3): 511−520. doi: 10.3969/j.issn.0254-5357.2022.3.ykcs202203016
Tian Q, Tong L, An Z Y, et al. Development of certified reference materials of polycyclic aromatic hydeocarbons, organochlorine pesticides and polychlorinated biphenyls in sediments[J]. Rock and Mineral Analysis, 2022, 41(3): 511−520. doi: 10.3969/j.issn.0254-5357.2022.3.ykcs202203016
[40] 田芹, 吴淑琪, 佟玲, 等. 中国典型类型土壤中有机氯农药和多氯联苯成分分析标准物质研制[J]. 岩矿测试, 2015, 34(2): 238−244. doi: 10.15898/j.cnki.11-2131/td.2015.02.015
Tian Q, Wu S Q, Tong L, et al. Preparation of certified reference materials of organochlorine pesticides and polychlorinatedbipenyl in Chinese typical soils[J]. Rock and Mineral Analysis, 2015, 34(2): 238−244. doi: 10.15898/j.cnki.11-2131/td.2015.02.015
[41] SRM (1941b) Certificate of Analysis. Organics in marine sediment[R]. Gaithersburg: National Institute of Standards and Technology (NIST), 2022.
[42] Tolosa I, Cassi R, Huertas D. A new marine sediment certified reference material (CRM) for the determination of persistent organic contaminants: IAEA-459[J]. Environmental Science and Pollution Research, 2019, 26: 7347−7355. doi: 10.1007/s11356-018-1895-4
[43] Zhao X, Jin H, Li D, et al. Simple and rapid analysis of phthalate esters in marine sediment using ultrasound-assisted extraction combined with gas purge microsyringe extraction followed by GC–MS[J]. Marine Pollution Bulletin, 2020, 160: 111667. doi: 10.1016/j.marpolbul.2020.111667
[44] Brander S M, Renick V C, Foley M M, et al. Sampling and quality assurance and quality control: A guide for scientists investigating the occurrence of microplastics across matrices[J]. Applied Spectroscopy, 2020, 74: 1099−1125. doi: 10.1177/0003702820945713
-
