Material Evidence Analysis and Regional Classification and Identification of Soil Based on X-ray Fluorescence Spectrometry and X-ray Diffraction
-
摘要:
在法庭科学鉴定领域，土壤、岩石等地球化学相关材料是重要的物证来源。在实际案情分析中，物证材料所提供的信息往往指向未知区域，在没有明确犯罪现场位置的情况下，预测物证的来源是一项极具挑战性的工作。针对地球化学物证信息的未知性，通过建立包含矿物组成、元素含量、地理位置等理化性质和地理信息的数据集，比对案发现场样本信息，快速确定物证样本来源，为案情调查提供有力的技术支持和证据支持。本文采集辽宁沈阳市城市内表层泥土样品(0～10cm)，应用X射线荧光光谱法(XRF)和X射线粉晶衍射法(XRD)对泥土物证样本中15种元素(SiO2、Al2O3、CaO、Cu、Zn和Pb等)和矿物成分进行测试分析；借助MapGIS软件绘制元素含量分布图，探讨研究区元素分布特点及影响因素，利用主成分分析法(PCA)对三个研究区域泥土样本进行分类鉴别。结果表明：①通过城市地质填图可以获得准确直观的元素含量分布图，法庭工作者可以比对泥土样本的元素特征，追溯物证来源。②沈阳市泥土物证样本主要由石英、长石、蒙脱石和伊利石组成(88.0%～98.0%)，XRD条形热图便于法庭工作者进行大量数据比对分析。③基于主成分分析法对三个研究区域15种元素进行降维分析，在95%的置信区间内实现显著的区域鉴别(第1组F1＜0，F2＜0；第2组F1＞0，F2＞0；第三组F1＞0，F2＜0)。④三个研究区域泥土样本中绿泥石、透闪石、高岭石、方解石和白云石存在显著差异，进一步佐证PCA分析分类的准确性。XRF与XRD的联合应用能够有效地区分城市内不同区域的泥土物证样本，为泥土物证溯源调查提供指向性研究区域，并为缩小调查范围提供重要线索。
Abstract:In the field of forensic science identification, geochemical-related materials such as soils and rocks were important sources of material evidence. In actual case analysis, the information provided by material evidence often pointed to unknown areas. Predicting the source of material evidence was an extremely challenging task when the location of the crime scene was not clear. To address the uncertainty of geochemical material evidence information, a dataset including physicochemical properties and geographic information such as mineral composition, element content, and geographical location was established. By comparing the sample information from the crime scene, the source of the material evidence samples could be quickly determined, providing strong technical and evidentiary support for case investigation. Surface soil samples (0−10cm) were collected from urban areas in Shenyang City, Liaoning Province, and X-ray fluorescence spectrometry (XRF) and X-ray powder diffraction (XRD) were applied to test and analyze 15 elements (SiO2, Al2O3, CaO, K2O, Na2O, MgO, TFe2O3, Ti, Mn, Ba, P, Zr, Cu, Zn and Pb) and mineral components in the soil material evidence samples. With the help of MapGIS software, element content distribution maps were drawn to explore the characteristics and influencing factors of element distribution in the study area. Principal component analysis (PCA) was used to classify and identify soil samples from three study areas. The results indicated that: (1) through urban geological mapping, accurate and intuitive element content distribution maps can be obtained, allowing court workers to compare the elemental characteristics of soil samples and trace the source of material evidence. (2) The soil material evidence samples from Shenyang were mainly composed of quartz, feldspar, montmorillonite, and illite (88.0%−98.0%). The XRD diffraction bar thermal map facilitated court workers to conduct comparative analysis of large amounts of data. (3) Based on PCA, a dimensionality reduction analysis of 15 elements from three study areas was conducted, and significant regional discrimination of soil samples from the three study areas was achieved within a 95% confidence interval (Group 1: F1<0, F2<0; Group 2: F1>0, F2>0; Group 3: F1>0, F2<0). (4) There were significant differences in chlorite, tremolite, kaolinite, calcite, and dolomite among soil samples from the three study areas, further supporting the accuracy of PCA classification. In summary, the combined application of XRF and XRD technology could be used to effectively distinguish soil material evidence samples from different areas within the city, providing directed research areas for soil material evidence traceability investigation and important clues to narrow down the investigation scope.
-
-
表 1 主成分分析元素载荷系数
Table 1. Element loading coefficient of principal component analysis
元素 第一主成分(F1) 第二主成分(F2) 第三主成分(F3) 载荷 系数 载荷 系数 载荷 系数 SiO2 0.969 0.500 −0.025 −0.015 0.098 0.091 Al2O3 −0.219 −0.113 −0.486 −0.292 −0.523 −0.488 CaO −0.105 −0.054 0.824 0.495 0.287 0.268 K2O −0.010 −0.005 0.003 0.002 −0.437 −0.408 Na2O 0.050 0.026 0.086 0.052 −0.131 −0.123 MgO 0.014 0.007 0.114 0.068 0.168 0.157 TFe2O3 0.007 0.003 −0.252 −0.152 −0.028 −0.026 Ti 0.0003 0.0002 −0.017 −0.010 0.143 0.133 Mn −0.004 −0.002 0.0007 0.0004 0.194 0.181 Ba −0.001 −0.0006 −0.0006 −0.0004 −0.401 −0.375 P 0.001 0.0008 0.004 0.002 0.248 0.231 Zr −0.0002 −0.0001 −0.0002 −0.00009 0.014 0.013 Cu 0.000 0.000 −0.00001 0.000 0.291 0.272 Zn −0.0006 −0.0003 0.0002 0.0001 0.179 0.167 Pb −0.001 −0.0006 −0.00008 −0.00005 −0.001 −0.001
下载: 导出CSV
表 2 主成分分析累积贡献率
Table 2. Cumulative contribution rate of principal component analysis
主成分 特征值 贡献率
(%)累计贡献率
(%)F1 2.603 52.70 52.70 F2 1.758 35.59 88.29 F3 0.428 8.66 96.95 F4 0.117 2.38 99.33 F5 0.022 0.45 99.78 F6 0.008 0.16 99.94 F7 0.003 0.06 100.0 F8 0.000 0.00 100.0 F9 0.000 0.00 100.0 F10 0.000 0.00 100.0 F11 0.000 0.00 100.0
下载: 导出CSV
表 3 三组样本的矿物组分半定量分析结果
Table 3. The semi-quantitative analysis results of mineral components of three groups of samples
样本分组 样本编号 石英
(%)长石
(%)蒙脱石
(%)伊利石
(%)绿泥石
(%)透闪石
(%)高岭石
(%)方解石
(%)白云石
(%)第1组 10 35.4 52.3 6.4 2.2 2.3 − 1.5 − − 26 53.3 27.5 4.0 9.2 2.4 3.5 − − − 27 47.0 40.8 6.4 3.8 2.0 − − − − 34 51.8 28.1 6.7 6.5 3.1 2.1 − 1.6 − 第2组 11 19.1 74.8 2.8 1.3 − − 0.9 0.5 0.6 12 41.3 35.8 3.6 9.9 − 4.5 2.0 1.3 1.8 13 38.6 37.0 4.6 7.8 − 6.6 3.0 2.4 − 30 41.9 31.5 6.4 9.1 3.2 4.8 − 1.3 1.8 第3组 19 37.6 37.2 6.7 8.4 1.9 5.4 2.9 − − 21 34.8 41.5 4.5 9.6 4.0 4.7 − 1.0 − 22 47.4 34.2 3.8 2.5 − 7.7 4.4 − − 23 40.1 39.6 3.9 9.1 2.4 2.9 2.0 − − 注：“−”表示该矿物未鉴定出。
下载: 导出CSV
-
[1] Xu X, Du C, Ma F, et al. Forensic soil analysis using laser-induced breakdown spectroscopy (LIBS) and Fourier transform infrared total attenuated reflectance spectroscopy (FTIR-ATR): Principles and case studies[J]. Forensic Science International, 2020, 310(5): 110222. doi: 10.1016/j.forsciint.2020.110222
[2] Scientific American. Science and art: Curious use of the micro-scope[J]. Scientific American, 1856, 11(30): 240−240.
[3] Norazwani B A, Loong C L, Ab A L. Evaluation of row-wise manipulations for the forensic differentiation of Malaysian soils based on ultra-performance liquid chromatographic profiles[J]. Journal of Analytical Chemistry, 2022, 77(3): 347−360. doi: 10.1134/S1061934822030029
[4] Omel’yanyuk G G, Kopelchuk N V. Expert forensic environmental and soil investigation in the administration of justice[J]. Moscow University Soil Science Bulletin, 2023, 78(6): 140−148. doi: 10.3103/S0147687423020084
[5] Foster N R, Martin B, Hoogewerff J, et al. The utility of dust for forensic intelligence: Exploring collection methods and detection limits for environmental DNA, elemental and mineralogical analyses of dust samples[J]. Forensic Science International, 2023, 344(3): 111599. doi: 10.1016/j.forsciint.2023.111599
[6] Kikkawa H S, Naganuma K, Kumisaka K, et al. Semi-automated scanning electron microscopy energy dispersive X-ray spectrometry forensic analysis of soil samples[J]. Forensic Science International, 2019, 305: 109947. doi: 10.1016/j.forsciint.2019.109947
[7] Lorna A D. Soil science in the criminal justice system[J]. Encyclopedia of Soils in the Environment (Second Edition), 2023, 3: 521−531. doi: 10.1016/B978-0-12-822974-3.00208-1
[8] Testoni S A, Prandel L V, Melo V F, et al. Conjunctive use of synchrotron X-ray diffraction and Rietveld refinement in Fe-oxide clays for forensic applications[J]. Journal of Forensic Sciences, 2022, 67(5): 2020−2031. doi: 10.1111/1556-4029.15098
[9] Murray K, Fitzpatrick R, Doyle R. Development of soil forensic methods and databases from targeted locations in Tasmania to assist Police[C]. 2012.
[10] Bong W S, Nakai I, Furuya S, et al. Development of heavy mineral and heavy element database of soil sediments in Japan using synchrotron radiation X-ray powder diffraction and high-energy (116keV) X-ray fluorescence analysis[J]. Forensic Science International, 2012, 220(1−3): 33−49. doi: 10.1016/j.forsciint.2012.01.024
[11] 郭洪玲, 王萍, 朱军, 等. 泥土物证XRF元素定量检验数据比对评价方法比较[J]. 刑事技术, 2020, 45(6): 568−574. doi: 10.16467/j.1008-3650.2020.06.004
Guo H L, Wang P, Zhu J, et al. Comparison of two statistical methods for evaluating XRF-based elemental quantitative data of soils[J]. Forensic Science and Technology, 2020, 45(6): 568−574. doi: 10.16467/j.1008-3650.2020.06.004
[12] 郭洪玲, 王萍, 朱军, 等. 法庭地质学与泥土物证检验[J]. 刑事技术, 2019, 44(1): 53−59. doi: 10.16467/j.1008-3650.2019.01.012
Guo H L, Wang P, Zhu J, et al. Forensic geology and soil examination[J]. Forensic Science and Technology, 2019, 44(1): 53−59. doi: 10.16467/j.1008-3650.2019.01.012
[13] 王黎. 法庭科学泥土物证检验及数据统计方法研究[D]. 北京: 中国人民公安大学, 2020: 16−34.
Wang L. The examination of soil evidences and research on data statistical methods in forensic science[D]. Beijing: People’s Public Security University of China, 2020: 16−34.
[14] 闵红, 刘倩, 张金阳, 等. X射线荧光光谱-X射线粉晶衍射-偏光显微镜分析12种产地铜精矿矿物学特征[J]. 岩矿测试, 2021, 40(1): 74−84. doi: 10.15898/j.cnki.11-2131/td.202004020038
Min H, Liu Q, Zhang J Y, et al. Study on the mineralogical characteristics of 12 copper concentrates by X-ray fluorescence spectrometry, X-ray powder diffraction and polarization microscope[J]. Rock and Mineral Analysis, 2021, 40(1): 74−84. doi: 10.15898/j.cnki.11-2131/td.202004020038
[15] 吕铷麟, 贾镇, 何洪源, 等. 基于ICP-MS和机器学习的土壤物证溯源研究[J]. 化学研究与应用, 2021, 33(9): 1776−1784. doi: 10.3969/j.issn.1004-1656.2021.09.020
Lyu R L, Jia Z, He H Y, et al. Research on soil material evidence traceability based on ICP-MS and machine learning[J]. Chemical Research and Application, 2021, 33(9): 1776−1784. doi: 10.3969/j.issn.1004-1656.2021.09.020
[16] 侯赛文. 基于离子色谱对典型土壤物证分析及溯源研究[D]. 北京: 中国人民公安大学, 2023: 10−11.
Hou S W. Analysis and traceability of typical soil evidence based on ion chromatography[D]. Beijing: People’s Public Security University of China, 2023: 10−11.
[17] 李廷栋, 刘勇, 丁孝忠, 等. 中国区域地质研究的十大进展[J]. 地质学报, 2022, 96(5): 1544−1581. doi: 10.19762/j.cnki.dizhixuebao.2022145
Li T D, Liu Y, Ding X Z, et al. Ten advances in regional geological research of China in recent years[J]. Acta Geologica Sinica, 2022, 96(5): 1544−1581. doi: 10.19762/j.cnki.dizhixuebao.2022145
[18] Li Q H, Li C F, Liu L J, et al. Geochemical characteristics of heavy metals of bedrock, soil, and tea in a metamorphic rock area of Guizhou Province, China[J]. Environmental Science and Pollution Research, 2023, 30(3): 7402−7414. doi: 10.1007/s11356-022-22751-0
[19] 谢学锦, 任天祥, 奚小环, 等. 中国区域化探全国扫面计划卅年[J]. 地球学报, 2009, 30(6): 700−716. doi: 10.3321/j.issn:1006-3021.2009.06.003
Xie X J, Ren T X, Xi X H, et al. The implementation of the regional geochemistry-national reconnaissance program (RGNR) in China in the past thirty years[J]. Acta Geoscientica Sinica, 2009, 30(6): 700−716. doi: 10.3321/j.issn:1006-3021.2009.06.003
[20] 杨泽, 刘国栋, 戴慧敏, 等. 黑龙江兴凯湖平原土壤硒地球化学特征及富硒土地开发潜力[J]. 地质通报, 2021, 40(10): 1773−1782. doi: 10.12097/j.issn.1671-2552.2021.10.019
Yang Z, Liu G D, Dai H M, et al. Selenium geochemistry of soil and development potential of Se-rich soil in Xingkai Lake Plain[J]. Geological Bulletin of China, 2021, 40(10): 1773−1782. doi: 10.12097/j.issn.1671-2552.2021.10.019
[21] 张妍, 赵新雷, 冯雪珍, 等. 河南荥阳市耕地土壤重金属分布特征及来源解析[J]. 岩矿测试, 2024, 43(2): 330−343. doi: 10.15898/j.ykcs.202306300084
Zhang Y, Zhao X L, Feng X Z, et al. Distribution characteristics, ecological risks, and source identification of heavy metals in cultivated land in Xingyang City[J]. Rock and Mineral Analysis, 2024, 43(2): 330−343. doi: 10.15898/j.ykcs.202306300084
[22] Wang L L, Xu J Z, Wang Y, Cheng P, et al. Hg distribution and risk assessment in soil-Bozhou peony system[J]. Environmental Earth Sciences, 2024, 83(6): 1.1−1.9. doi: 10.1007/s12665-024-11492-7
[23] 王磊, 卓小雄, 吴天生, 等. 基于1∶25万和1∶5万土地质量地球化学调查评价的土壤元素累积趋势预测——以广西南宁市西乡塘区为例[J]. 物探与化探, 2023, 47(1): 1−13. doi: 10.11720/wtyht.2023.2613
Wang L, Zhuo X X, Wu T S, et al. Prediction of the soil element accumulation trends based on 1∶250000 and 1∶50000 geochemical surveys and assessments of land quality: A case study of Xixiangtang District, Nanning City, Guangxi Zhuang Autonomous Region[J]. Geophysical and Geochemical Exploration, 2023, 47(1): 1−13. doi: 10.11720/wtyht.2023.2613
[24] 李炆颖. 沈阳经济区土地利用要素性冲突作用机理及其缓解路径研究[D]. 沈阳: 沈阳师范大学, 2022: 12−14.
Li W Y. The action mechanisms and mitigation pathways of land use elemental conflicts in Shenyang Economic Zone[D]. Shenyang: Shenyang Normal University, 2022: 12−14.
[25] 郑泓. 基于生态安全格局构建的国土空间生态修复策略研究[D]. 沈阳: 沈阳大学, 2022: 9−11.
Zheng H. Research on territorial space ecological restoration strategies based on the construction of ecolo-gical security pattern—A case study of Shenyang modern metropolitan[D]. Shenyang: Shenyang University, 2022: 9−11.
[26] 李佳宁. 沈阳市主城区土地利用分类的变化对生态环境质量的影响研究[D]. 沈阳: 沈阳农业大学, 2023: 12−14.
Li J N. Study on the impact of land use classification change on eco-environmental quality in the main urban area of Shenyang[D]. Shenyang: Shenyang Agricultural University, 2023: 12−14.
[27] Liu X, Zhang P J, Liu H, et al. Quantitative phase analysis method of palygorskite based on XRD orientational sample analysis and Rietveld full spectrum fitting[J]. Applied Clay Science, 2024, 248: 107222.1 −107222.10. doi: 10.1016/j.clay.2023.107222
[28] 刘粤惠, 刘平安. X射线衍射分析原理与应用[M]. 北京: 化学工业出版社, 2003: 217−220.
Liu E H, Liu P A. Principle and application of X-ray diffraction analysis[M]. Beijing: Press of Chemical Engineering, 2003: 217−220.
[29] 周君龙, 陈宜浩, 李全忠, 等. X射线衍射Rietveld全谱拟合法定量检测滑石混合矿物中滑石含量[J]. 冶金分析, 2023, 43(4): 18−23. doi: 10.13228/j.boyuan.issn1000-7571.011954
Zhou J L, Chen Y H, Li Q Z, et al. Quantitative determination of talc in mixed ore by X-ray diffraction Rietveld full spectrum fitting method[J]. Metallurgical Analysis, 2023, 43(4): 18−23. doi: 10.13228/j.boyuan.issn1000-7571.011954
[30] 伍月, 迟广成, 刘欣. X射线粉晶衍射法在变粒岩鉴定与分类中的应用[J]. 岩矿测试, 2020, 39(4): 546−554. doi: 10.15898/j.cnki.11-2131/td.201908050117
Wu Y, Chi G C, Liu X. Application of X-ray powder diffraction method in identification and classification of leptite[J]. Rock and Mineral Analysis, 2020, 39(4): 546−554. doi: 10.15898/j.cnki.11-2131/td.201908050117
[31] 中国科学院贵阳地球化学研究所. 矿物X射线粉晶鉴定手册[M]. 北京: 科学出版社, 1978: 117−122.
[32] 石旭飞, 代雅建, 崔健, 等. 沈阳城市地质环境问题研究[J]. 地质与资源, 2017, 26(4): 390−396. doi: 10.3969/j.issn.1671-1947.2017.04.010
Shi X F, Dai Y J, Cui J, et al. Study on the geological environment of Shenyang City[J]. Geology and Resources, 2017, 26(4): 390−396. doi: 10.3969/j.issn.1671-1947.2017.04.010
[33] Neal F, Pascal B, Huang W M, et al. Principal component analysis (PCA) unravels spectral components present in XPS spectra of complex oxide films on iron foil[J]. Applied Surface Science Advances, 2023, 17(8): 100447. doi: 10.1016/j.apsadv.2023.100447
[34] 贾宗潮, 王子鉴, 李雪莹, 等. 主成分分析和连续投影融合的海洋沉积物粒度分类研究[J]. 光谱学与光谱分析, 2023, 43(10): 3075−3080. doi: 10.3964/j.issn.1000-0593(2023)10-3075-06
Jia Z C, Wang Z J, Li X Y, et al. Marine sediment particle size classification based on the fusion of principal component analysis and continuous projection algorithm[J]. Spectroscopy and Spectral Analysis, 2023, 43(10): 3075−3080. doi: 10.3964/j.issn.1000-0593(2023)10-3075-06
[35] 刘凯, 戴慧敏, 刘国栋, 等. 基于主成分聚类法的典型黑土区土壤地球化学分类[J]. 物探与化探, 2022, 46(5): 1132−1140. doi: 10.11720/wtyht.2022.0043
Liu K, Dai H M, Liu G D, et al. Geochemical classification of the soil in a typical black soil area using the principal component analysis combined with K-means clustering algorithm[J]. Geophysical and Geochemical Exploration, 2022, 46(5): 1132−1140. doi: 10.11720/wtyht.2022.0043
[36] 王萍, 刘玲利, 郭洪玲, 等. 泥土物证的理化综合检验分析[J]. 刑事技术, 2016, 41(6): 454−458. doi: 10.16467/j.1008-3650.2016.06.006
Wang P, Liu L L, Guo H L, et al. Comprehensive analysis of soil evidence with multiple physicochemical methods[J]. Forensic Science and Technology, 2016, 41(6): 454−458. doi: 10.16467/j.1008-3650.2016.06.006
-
