Reservoir prediction of channel sublacustrine fan in faulted lacustrine basin: take the middle sub-member of the Third Member of Shahejie Formation in Laizhouwan Sag as an example
-
摘要:
渤海湾盆地莱州湾凹陷沙三段发育大型水道型湖底扇岩性圈闭,成藏背景较好,勘探潜力较大,但湖底扇沉积特征不明确,储层分布难以精细刻画,制约了勘探的进程。因此,在地震沉积学、沉积学理论指导下,提出了以不同重力流水道类型地震相分析为基础优选敏感属性,平面剖面结合精细刻画湖底扇的展布,最终确立有利储层发育区的技术思路,以期为研究区湖底扇型岩性油气藏勘探部署提供有利的支持。分析认为,湖底扇水道具有中—弱振幅、杂乱反射特征,与湖相泥岩的平行连续、强振幅反射具有明显差异,以此为基础优选分频倾角相干和基于灰度共生矩阵的地震结构属性及神经网络波形分类技术对湖底扇边界以及内幕水道进行刻画。其中,限制水道复合体及叠置水道复合体砂岩厚度大,两类水道发育区域是研究区的有利储层发育区。限制水道复合体分布在F1断裂坡折带下,水道厚度及宽度较大;叠置水道复合体分布在F2断裂坡折带下。
Abstract:Large channel sublacustrine fan lithologic traps are in the Third Member of Shahejie Formation in Laizhouwan Sag, Bohai Bay Basin, with good reservoir forming background and great exploration potential. However, the sedimentary characteristics of sublacustrine fan are not clear, and the reservoir distribution is difficult to be delineated, which restrict the exploration process. Therefore, under the guidance of seismic sedimentology and sedimentology theory, a method of optimizing attributes based on seismic facies analysis of different gravity flow channel types was proposed, and the distribution of sublustrine fan was described in detail with plane section, and favorable reservoir development area was finally established. This study will provide favorable support for the exploration and deployment of sublacustrine fan lithologic reservoirs in the study area. It is recognized that the sublacustrine fan channel has the chaotic characteristics of medium and weak amplitude, which is obviously different from the parallel and continuous strong amplitude reflection of lacustrine mudstone. Based on this, the coherence attribute of frequency-divided dip coherency, seismic structure attribute based on gray level co-occurrence matrix and waveform classification technique of neural network were selected to characterize the boundary of sublustrine fan and the inner channel. The sandstone thickness of restricted channel complex and superimposed channel complex is large, and the two channel development areas are favorable reservoir areas in the study area. The restricted channel complex is distributed under the slope break zone of F1 fault, and the channel thickness and width are large. Superimposed channel complexes are distributed under the slope break zone of F2 fault.
-
-
表 1 重力流水道分类
Table 1. Classification of gravity flow channel
-
[1] 于兴河,姜辉,李胜利,等. 中国东部中、新生代陆相断陷盆地沉积充填模式及其控制因素:以济阳坳陷东营凹陷为例[J]. 岩性油气藏,2007,19(1):39-45. doi: 10.3969/j.issn.1673-8926.2007.01.007
[2] 郭玉新. 渤中凹陷埕岛东坡东三段沉积物重力流类型及沉积模式[J]. 油气地质与采收率,2021,28(3):14-24.
[3] 杨剑萍,黄雅睿,卢惠东,等. 东营凹陷营11 北地区沙三中亚段重力流触发机制[J]. 中国石油大学学报(自然科学版),2021,45(4):1-11.
[4] 杨有星,金振奎. 黄骅坳陷港中地区古近系沙三段湖底扇沉积相特征[J]. 现代地质,2012,26(2):355-362.
[5] 彭文绪,辛仁臣,孙和风,等. 渤海海域莱州湾凹陷的形成和演化[J]. 石油学报,2009,30(5):654-660. doi: 10.3321/j.issn:0253-2697.2009.05.004
[6] 杨海风,涂翔,赵弟江,等. 渤海湾盆地莱州湾凹陷沙河街组第三、第四段烃源岩有机相特征[J]. 成都理工大学学报(自然科学版),2021,48(1):72-81. doi: 10.3969/j.issn.1671-9727.2021.01.08
[7] 张建民,秦祎,郭诚,等. 莱州湾凹陷垦利油区沙三上亚段辫状河三角洲沉积特征表征[J]. 高校地质学报,2021,27(5):515-525. doi: 10.16108/j.issn1006-7493.2020082
[8] 秦祎,朱筱敏,王彤,等. 陆相断陷湖盆强制湖退及沉积响应:以莱州湾凹陷沙三段为例[J]. 古地理学报,2020,22(3):457-468.
[9] 辛云路,任建业,李建平,等. 构造-古地貌对沉积的控制作用:以渤海南部莱州湾凹陷沙三段为例[J]. 石油勘探与开发,2013,40(3):302-308. doi: 10.11698/PED.2013.03.06
[10] 牛成民. 渤海南部海域莱州湾凹陷构造演化与油气成藏[J]. 石油与天然气地质,2012,33(3):424-431.
[11] 苑书金. 地震相干体技术的研究综述[J]. 勘探地球物理进展,2007,30(1):7-15.
[12] 尹川,杜向东,赵汝敏,等. 小波分频倾角相干在复杂断裂解释中的应用[J]. 石油地球物理勘探,2015,50(2):346-350.
[13] 胡英,陈辉,贺振华,等. 基于地震纹理属性和模糊聚类划分地震相[J]. 石油地球物理勘探,2013,48(1):114-120. doi: 10.13810/j.cnki.issn.1000-7210.2013.01.018
[14] 朱石磊,段林娣,林畅松,等. 基于灰度共生矩阵的地震数据空间结构属性分析技术[J]. 石油地球物理勘探,2012,47(6):951-957.
[15] 逯宇佳,曹俊兴,刘哲哿,等. 波形分类技术在缝洞型储层流体识别中的应用[J]. 石油学报,2019,40(2):182-189. doi: 10.7623/syxb201902006
[16] 程彦,赵镨,林建东,等. 地震波形分类技术在地质异常体解释中的应用[J]. 煤田地质与勘探,2020,48(6):87-92.
-
