Analysis of differential accumulation between hanging and foot walls of Panyu 25 Fault in the western Baiyun Sub-sag
-
摘要:
白云凹陷是珠江口盆地重要的油气产区，现对白云凹陷的研究主要集中在白云主洼，对白云西洼的油气勘探研究仍十分薄弱。近年来，对白云西洼加大了油气勘探力度，于番禺25断裂上下盘实施钻探，结果差异明显。为进一步探索白云西洼勘探潜力，本文通过对番禺25断裂上下盘开展差异成藏分析，探讨该地区的油气成藏规律。通过井上PVT样特征、MDT压力、天然气组分、碳同位素特征及成藏期古构造分析认为，番禺25断裂分割性强，油气成藏期上升盘与下降盘为2个独立的块体，表现为差异性成藏。烃类地化分析表明，上升盘凝析气来源于白云3次洼，下降盘的油气来源于临近的番禺25次洼。本文初步厘清了白云西洼的成藏规律，以期指导该地区的勘探部署：围绕白云3次洼优势运移路径开展天然气的勘探，围绕番禺25次洼近源开展原油的勘探；同时，也为其他地区断裂上下盘差异性成藏研究提供了有益借鉴。
Abstract:Baiyun Sag is an important oil and gas producing area in the Pearl River Mouth Basin. At present, research of Baiyun Sag is mainly in the main body of the sag, while it was understudied in the western Baiyun Sub-sag. In recent years, the oil and gas exploration in the subsag has been intensified, and the drilling has been carried out in the hanging wall and foot walls of Panyu 25 Fault. To further explore the exploration potential of the subsag, the differential accumulation between the hanging wall and foot wall was analyzed and the hydrocarbon accumulation rule in this area was discussed. Based on the PVT (pressure, volume, temperature) characteristics of samples, the MDT (mini drill stem testing) pressure analysis, natural gas composition, carbon isotope characteristics, and paleotectonic analysis of accumulation period, it is concluded that Panyu 25 fault has strong segmentation, and the hanging and foot walls are two independent blocks in the key accumulation period, showing different hydrocarbon accumulation. Geochemical analysis of hydrocarbons showed that the condensate gas in the up-thrown side came from Baiyun 3 Sub-sag, while the oil and gas in the down-thrown side originated from the adjacent Panyu 25 Sub-sag. The accumulation rule of the western Baiyun Sub-sag was clarified, which is beneficial to the exploration and deployment of this area. The natural gas exploration should be carried out around the dominant migration path of Baiyun 3 Sub-sag, and the crude oil exploration should also be conducted around the proximate source of Panyu 25 Sub-sag. This study provided a useful reference for the research on the differential accumulation of the hanging and foot walls of faults in other areas.
-
-
表 1 白云西洼天然气组分及碳同位素
Table 1. Natural gas components and carbon isotopes in the western Baiyun Sub-sag
类型 深度/m 井名 C1/% C2/% C3/% 干燥系数/% 气油比 δ13C1/‰ δ13C2/‰ δ13C2/‰ PVT样品 3 070.5 PY25-A 57.91 14.14 11.82 63.94 1 846.9 −38.09 −29.66 −28.49 3 047.0 PY25-B 78.00 8.60 3.44 93.50 15 001.0 −36.60 −25.30 −25.80 3 072.5 PY25-B 80.70 7.30 2.71 94.80 14 652.0 −37.20 −25.30 −25.00 3 603.6 BY3-A 82.10 4.50 1.44 92.00 23 331.0 −31.70 −26.30 −24.56
下载: 导出CSV
-
[1] 张智辉. 珠江口盆地白云西洼油气输导体系特征研究[D]. 北京:中国石油大学(北京),2017.
ZHANG Z H. Characteristics of oil and gas transport system in western Baiyun sub-Sag,Pearl River Mouth Basin[D]. Beijing:China University of Petroleum (Beijing),2017.
[2] 庞雄奇,罗群,姜振学,等. 叠合盆地断裂上、下盘油气差异聚集效应及成因机理[J]. 地质科学,2003,38(3):297-306. doi: 10.3321/j.issn:0563-5020.2003.03.003
PANG X Q,LUO Q,JIANG Z X,et al. Accumulating diversity and its mechanism between hanging and lower walls of fault in superimposed basin[J]. Chinese Journal of Geology,2003,38(3):297-306. doi: 10.3321/j.issn:0563-5020.2003.03.003
[3] 王风华,罗群,李玉喜,李荣权. 柴达木盆地断裂上下盘油气差异聚集效应与成因[J]. 油气地质与采收率,2007,14(2):19-22.
WANG F H,LUO Q ,LI Y X,et al. Accumulation and origin of oil-gas difference between hanging wall and foot-wall blocks in Qaidam Basin[J]. Petroleum Geology and Recovery Efficiency,2007,14(2):19-22.
[4] 罗群,黄捍东,李玉喜. 柴达木盆地北缘浅层滑脱断裂下盘油气富集规律及控藏模式[J]. 中国石油大学学报(自然科学版),2009,33(3):34-38.
LUO Q,HUANG H D,LI Y X. Petroleum accumulating feature and fault controlling petroleum accumulation model on the downblock of shallow slip fault in north margin of Qaidam Basin[J]. Journal of China University of Petroleum (Edition of Natural Science),2009,33(3):34-38.
[5] 张树林,罗群,白新华. 大庆长垣以西断层倾向盘天然气聚集效应与成因分析[J]. 大庆石油地质与开发,1997,16(1):9-11.
ZHANG S L,LUO Q,BAI X H. Analysis of gas accumulation effect and genesis in upper walls of faults to the west of Daqing placanticline[J]. Petroleum Geology & Oilfield Development in Daqing,1997,16(1):9-11
[6] 姜大朋,何敏,张向涛,等. 箕状断陷控洼断裂上下盘油气成藏差异性及勘探实践:以南海北部珠江口盆地惠州凹陷X洼为例[J]. 吉林大学学报(地球科学版),2019,49(2):346-355.
JIANG D P,HE M,ZHANG X T,et al. Difference of hydrocarbon accumulation between hanging and foot wall of half graben boundary fault and exploration practice:a case study of X Sag in Huizhou Depression,Pearl River Mouth Basin,northern South China Sea[J]. Journal of Jilin University (Earth Science Edition),2019,49(2):346-355.
[7] 吴景富,杨树春,张功成,等. 南海北部深水区盆地热历史及烃源岩热演化研究[J]. 地球物理学报,2013,56(1):170-180. doi: 10.6038/cjg20130117
WU J F,YANG S C,ZHANG G C,et al. Geothermal history and thermal evolution of the source rocks in the deep-water area of the northern South China Sea[J]. Chinese Journal of Geophysics,2013,56(1):170-180. doi: 10.6038/cjg20130117
[8] 张健,宋海斌. 南海北部大陆架盆地热结构[J]. 地质力学学报,2001,7(3):238-244. doi: 10.3969/j.issn.1006-6616.2001.03.007
ZHANG J,SONG H B. The thermal structure of main sedimentary basins in the northern margin of the South China Sea[J]. Journal of Geomechanics,2001,7(3):238-244. doi: 10.3969/j.issn.1006-6616.2001.03.007
[9] 崔洁,何家雄,周永章,等. 珠江口盆地白云凹陷天然气成因及油气资源潜力分析[J]. 天然气地球科学,2009,20(1):125-130.
CUI J,HE J X,ZHOU Y Z,et al. Origin of nature gas and resource potential of oil and gas in Baiyun Sag,Pearl River Mouth Basin[J]. Natural Gas Geoscience,2009,20(1):125-130.
[10] 唐晓音,黄少鹏,杨树春,等. 南海珠江口盆地钻井BHT温度校正及现今地温场特征[J]. 地球物理学报,2016,59(8):2911-292.
TANG X Y,HUANG S P,YANG S C,et al. Correcting on logging-derived temperatures of the Pearl River Mouth Basin and characteristics of its present temperature field[J]. Chinese Journal of Geophysics,2016,59(8):2911-2921.
[11] 朱伟林. 南海北部深水区油气地质特征[J]. 石油学报,2010,31(4):521-527. doi: 10.7623/syxb201004001
ZHU W L. Petroleum geology in deep water area of northern continental margin in South China Sea[J]. Acta Petrolei Sinica,2010,31(4):521-527. doi: 10.7623/syxb201004001
[12] 胡杰,龙祖烈,黄玉平,等. 珠江口盆地白云凹陷新生代构造-热演化模拟[J]. 地球物理学报,2021,64(5):1654-1665.
HU J,LONG Z L,HUANG Y P,et al. Tectonic-thermal modelling of Baiyun Sag,Pearl River Mouth Basin,since Cenozoic[J]. Chinese Journal of Geophysics,2021,64(5):1654-1665.
[13] 朱俊章,施和生,庞雄,等. 白云凹陷天然气生成与大中型气田形成关系[J]. 天然气地球科学,2012,23(2):213-221.
ZHU J Z,SHI H S,PANG X,et al. Discussion on natural gas generation and giant-medium size gas field formation in Baiyun Sag[J]. Natural Gas Geoscience,2012,23(2):213-221.
[14] 李骥. 珠江口盆地白云西凹与番禺27洼文昌及恩平组沉积体系研究[D]. 北京:中国石油大学(北京),2018.
LI J. Study on the depositional system of Wenchang and Enping Formation in Baiyunxi Sag of Pearl River Mouth Basin and Panyu 27 Sag[D]. Beijing:China University of Petroleum (Beijing),2018.
[15] 吴伟,白晓婧,刘惟庆,等. 白云凹陷北坡珠江组下部储层生物遗迹及沉积演化特征[J]. 中国石油大学学报(自然科学版),2023,47(1):12-24.
WU W,BAI X J,LIU W Q,et al. Reservoir biorelics and sedimentary evolution characteristics of the lower Zhujiang Formation on the north slope of Baiyun Depression[J]. Journal of China University of Petroleum (Edition of Natural Science),2023,47(1):12-24.
[16] 司朝年,邬兴威,夏东领,等. 致密砂岩油“甜点”预测技术研究:以渭北油田延长组长3油层为例[J]. 地球物理学进展,2015,30(2):664-671.
SI C N,WU X W,XIA D L,et al. The research of “sweet spot”prediction technology for tight sandstone reservoir:a case study of Chang 3 reservoir of Yanchang Formation in Weibei Oilfield[J]. Progress in Geophysics,2015,30(2):664-671.
[17] 张亮,马光克,刘巍,等. 子波相位与振幅属性关系研究:以DF气田为例[J]. 地球物理学进展,2018,33(3):1297-1302.
ZHANG L,MA G K,LIU W,et al. Relationship between wavelet phase and amplitude attributes of DF Gas Field[J]. Progress in Geophysics,2018,33(3):1297-1302.
[18] 常涧峰,徐耀东,田同辉,等. 埕北古7潜山太古界油气藏流体类型识别[J]. 油气地质与采收率,2012,19(4):21-23.
CHANG J F,XU Y D,TIAN T H,et al. Reservoir fluid type identification for Archaeozoic reservoir in Chengbeigu 7 buried hills[J]. Petroleum Geology and Recovery Efficiency,2012,19(4):21-23.
[19] 马安来,漆立新. 顺北地区四号断裂带奥陶系超深层油气地球化学特征与相态差异性成因[J]. 地学前缘,2023,30(6):247-262.
MA A L,QI L X. Geochemical characteristics of oil and gas and difference in fluid phase in the ultra-deep Ordovician reservoirs from No. 4 fault of north Shuntuoguole area of Tarim Basin,NW China[J]. Earth Science Frontiers,2023,30(6):247-262.
[20] 姜文亚,柳飒. 层序地层格架中优质烃源岩分布与控制因素:以歧口凹陷古近系为例[J]. 中国石油勘探,2015,20(2):51-58.
JIANG W Y,LIU S. Distribution and controlling factors of high-quality hydrocarbon source rock in sequential stratigraphic framework:taking Paleogene system in Qikou Depression for instance[J]. China Petroleum Exploration,2015,20(2):51-58.
[21] 戴金星,邹才能,张水昌,等. 无机成因和有机成因烷烃气的鉴别[J]. 中国科学:地球科学,2008,38(11):1329-1341.
DAI J X,ZOU C N,ZHANG S C,et al. Identification of inorganic and organic alkanes[J]. Science in China:Earth Sciences,2008,38(11):1329-1341.
[22] 戴金星. 天然气中烷烃气碳同位素研究的意义[J]. 天然气工业,2011,31(12):1-6.
DAI J X. Significance of the study on carbon isotopes of alkane gases[J]. Natural Gas Industry,2011,31(12):1-6.
[23] 刘文汇,陈孟晋,关平,等. 天然气成烃、成藏三元地球化学示踪体系及实践[M]. 兰州:甘肃科学技术出版社,2009:132-134.
LIU W H,CHEN M J,GUAN P,et al. Ternary Geochemical Tracer System and Practice of Hydrocarbon Generation and Accumulation of Natural Gas[M]. Lanzhou:Gansu Science and Technology Press,2009:132-134.
[24] 胡国艺,李剑,李谨,等. 判识天然气成因的轻烃指标探讨[J]. 中国科学:地球科学,2007,37(增刊2):111-117.
HU G Y,LI J,LI J,et al. Discussion on light hydrocarbon index for identifying the origin of natural gas[J]. Science in China:Earth Sciences,2007,37(S2):111-117.
[25] 郭潇潇,熊小峰,徐新德,等. 莺歌海盆地天然气类型划分与来源分析[J]. 特种油气藏,2017,24(5):54-58.
GUO X X,XIONG X F,XU X D,et al. Type classification and origin analysis of natural gas in the Yinggehai Basin[J]. Special Oil and Gas Reservoirs,2017,24(5):54-58.
[26] 龙祖烈,陈聪,马宁,等. 珠江口盆地深水区白云凹陷油气成因来源与成藏特征[J]. 中国海上油气,2020,32(4):36-45.
LONG Z L,CHEN C,MA N,et al. Origin and hydrocarbon accumulation characteristics of Baiyun Sag in deep water area of Pearl River Mouth Basin[J]. China Offshore Oil and Gas,2020,32(4):36-45.
[27] 米立军,何敏,翟普强,等. 珠江口盆地深水区白云凹陷高热流背景油气类型与成藏时期综合分析[J]. 中国海上油气,2019,31(1):1-12.
MI L J,HE M,ZHAI P Q,et al. Integrated study on hydrocarbon types and accumulation periods of Baiyun Sag,deep water area of Pearl River Mouth Basin under the high heat flow background[J]. China Offshore Oil and Gas,2019,31(1):1-12.
-
