Maturity recovery of oil and gas from marine-continental source rock and its application of Xihu Sag, East China Sea
-
摘要:
海陆过渡相煤系烃源岩岩性多样，油气成熟度恢复难度大，影响油气源判别。以东海西湖凹陷为例，通过烃源岩镜质体反射率、饱和烃和芳香烃色谱-质谱及热模拟天然气碳同位素分析等手段，建立了油和天然气成熟度恢复方法，计算了油、气成熟度，明确了油气来源。结果显示，油成熟度主要分布于0.8%～1.0%，为成熟油；天然气成熟度主要分布于1.0%～2.0%，属于成熟—高熟气；同层段油及天然气成熟度存在差异，且垂向变化规律不同，揭示了油和天然气来源和成藏过程存在差别。综合分析认为，本区油主要来自斜坡次洼，环次洼带是油有利勘探区；天然气主要来自凹陷主洼，自主洼向斜坡带均为天然气有利区带，勘探潜力大。
Abstract:The lithology of marine-continental transitional coal source rocks is complex and changeable, and the maturity recovery of oil and gas is difficult. Taking an oil and gas field of Xihu Sag as an example, the recovery method of oil and gas maturity is established by means of vitrinite reflectance of source rock, chromatographic mass spectrometry of saturated hydrocarbon and aromatic hydrocarbon and carbon isotope analysis of thermally simulated natural gas. The maturity of oil and gas is calculated and the source of oil and gas is clarified. The results show that oil maturity is mainly distributed between 0.8% and 1.0%, which is mature oil. The maturity of natural gas is mainly distributed between 1.0% and 2.0%, belonging to mature-high mature gas. The maturity of oil and natural gas in the same interval is different, which reveals the difference in the source and accumulation process of oil and natural gas. Based on the thermal evolution history of source rocks, it is considered that the oil in this area mainly comes from the slope sub-depression, and the ring sub-depression zone is the favorable exploration area. Natural gas mainly comes from the main depression of the sag, and the slope zone is a favorable zone for natural gas, with great exploration potential.
-
-
表 1 西湖凹陷不同岩性烃源岩黄金管热模拟实验甲烷碳同位素统计表
Table 1. Methane carbon isotopes in gold tube thermal simulation experiment of different lithological source rocks in Xihu Sag
样品类型 温度/℃ Ro/% 甲烷碳同位素/‰ 煤 350 0.80 −36.70 400 1.20 −40.00 450 1.82 −35.80 480 2.52 −31.80 510 3.30 −29.20 540 3.80 −28.30 570 4.15 −27.90 600 4.45 −27.00 炭质泥岩 335 0.82 −39.70 360 1.09 −39.10 400 1.65 −37.10 455 1.93 −33.10 480 2.30 −32.20 525 2.56 −30.30 575 3.24 −30.00 泥岩 350 0.80 −47.30 400 1.20 −37.70 450 1.82 −32.60 480 2.52 −29.60 510 3.30 −27.20 540 3.80 −26.30 570 4.15 −25.90 600 4.45 −24.70
下载: 导出CSV
-
[1] 张功成,王琪,苗顺德,等. 中国近海海陆过渡相烃源岩二元分布模式:以珠江口盆地白云凹陷为例[J]. 天然气地球科学,2014,25(9):1299-1308.
ZHANG G C,WANG Q,MIAO D S,et al. The duality distribution pattern of marine-continental transitional hydrocarbon source rocks:a case study from Baiyun Sag in Pearl River Mouth Basin,China offshore[J]. Natural Gas Geoscience,2014,25(9):1299-1308.
[2] 戴金星,吴伟,房忱琛,等. 2000年以来中国大气田勘探开发特征[J]. 天然气工业,2015,35(1):1-9. doi: 10.3787/j.issn.10000976.2015.01.001
DAI J X,WU W,FANG C C,et al. Exploration and development of large gas fields in China since 2000[J]. Natural Gas Industry,2015,35(1):1-9. doi: 10.3787/j.issn.10000976.2015.01.001
[3] 姜亮. 东海陆架盆地油气资源勘探现状及含油气远景[J]. 中国海上油气(地质),2003,15(1):3-7.
JIANG L. Exploration status and perspective of petroleum resources in East China Sea Shelf Basin[J]. China Offshore Oil and Gas,2003,15(1):3-7.
[4] 杨鹏程,刘峰,沈珊,等. 西湖凹陷平北地区平湖组煤系烃源岩生烃潜力研究[J]. 海洋地质与第四纪地质,2020,40(4):139-147.
YANG P C,LIU F,SHEN S,et al. A study on the hydrocarbon generation potential of the coal-bearing source rocks in the Pinghu Formation of Pingbei area,the Xihu Sag[J]. Marine Geology & Quaternary Geology,2020,40(4):139-147.
[5] 魏恒飞,陈践发,陈晓东,等. 西湖凹陷平湖组滨海型煤系烃源岩发育环境及其控制因素[J]. 中国地质,2013,40(2):487-497. doi: 10.3969/j.issn.1000-3657.2013.02.013
WEI H F,CHEN J F,CHEN X D,et al. The controlling factors and sedimentary environment for developing coastal coal-bearing source rock of Pinghu Formation in Xihu Depression[J]. Geology in China,2013,40(2):487-497. doi: 10.3969/j.issn.1000-3657.2013.02.013
[6] 沈玉林,秦勇,郭英海,等. 基于米氏聚煤旋回划分的西湖凹陷平湖组煤系烃源岩发育特征[J]. 石油学报,2016,37(6):706-714.
SHEN Y L,QIN Y,GUO Y H ,et al. Development characteristics of coal-measure source rocks divided on the basis of Milankovich coal accumulation cycle in Pinghu Formation,Xihu Sag[J]. Acta Petrolei Sinica,2016,37(6):706-714.
[7] 赵静,黄志龙,刘春锋,等. 西湖凹陷平北地区煤系烃源岩识别与分布[J]. 岩性油气藏,2021,33(5):95-106. doi: 10.12108/yxyqc.20210509
ZHAO J,HUANG Z L,LIU C F,et al. Identification and distribution characteristics of coal-bearing source rocks in Pingbei area,Xihu Sag[J]. Lithologic Reservoirs,2021,33(5):95-106. doi: 10.12108/yxyqc.20210509
[8] 谭思哲,侯凯文,覃军,等 西湖凹陷平湖组不同煤系烃源岩热解生烃差异及其在油气勘探中的应用[J]. 吉林大学学报(地球科学版),2020,50(4):968-978.
TAN S Z,HOU K W,QIN J,et al. Differences in pyrolysis hydrocarbon generation and hydrocarbon exploration of different coal-measures source rocks in Pinghu Formation,Xihu Sag [J]. Journal of Jilin University (Earth Science Edition),2020,50(4):968-978.
[9] PETER K E,MOLDOWAN J M. The Biomarker Guide:Interpreting Molecular Fossils in Petroleum and Ancient Sediments[M]. New Jersey:Prentice Hall Inc,1993.
[10] 陈建平,王绪龙,陈践发,等. 甲烷碳同位素判识天然气及其源岩成熟度新公式[J]. 中国科学:地球科学,2021,51(4):560-581.
CHEN J P,WANG X L,CHEN J F,et al. New equation to decipher the relationship between carbon isotopic composition of methane and maturity of gas source rocks[J]. Science China:Earth Sciences,2021,51(4):560-581.
[11] 李友川,孙玉梅,兰蕾. 用乙烷碳同位素判别天然气成因类型存在问题探讨[J]. 天然气地球科学,2016,27(4):654-664. doi: 10.11764/j.issn.1672-1926.2016.04.0654
LI Y C,SUN Y M,LAN L,et al. Discussion on the recognition of gas origin by using ethane carbon isotope[J]. Natural Gas Geoscience,2016,27(4):654-664. doi: 10.11764/j.issn.1672-1926.2016.04.0654
[12] 苏奥,陈红汉,王存武等. 东海盆地西湖凹陷油气成因及成熟度判别[J]. 石油勘探与开发,2013,40(5):521-527. doi: 10.11698/PED.2013.05.02
SU A,CHEN H H,WANG C W,et al. Genesis and maturity identification of oil and gas in the Xihu Sag,East China Sea Basin[J]. Petroleum Exploration and Development,2013,40(5):521-527. doi: 10.11698/PED.2013.05.02
[13] 王勇刚,田彦宽,詹兆文,等. 东海盆地西湖凹陷原油中金刚烷类化合物特征及意义[J]. 天然气地球科学,2019,30(4):582-592. doi: 10.11764/j.issn.1672-1926.2018.12.017
WANG Y G,TIAN Y K,ZHAN Z W,et al. Characteristics and implications of diamondoids in crude oils from the Xihu Depression,East Sea Basin,China[J]. Natural Gas Geoscience,2019,30(4):582-592. doi: 10.11764/j.issn.1672-1926.2018.12.017
[14] 贾健谊,须雪豪,孙伯强. 东海西湖凹陷原油与天然气的地球化学特征[J]. 海洋石油,2000,20(2):1-7.
JIA J Y,XU X H,SUN B Q,et al. Oil/gas geochemical character in the Xihu Trough of the East China Sea[J]. Offshore oil,2000,20(2):1-7.
[15] 陈琳琳,孙伯强,王乐闻,等. 西湖凹陷中央背斜带北部花港组天然气特征及气源分析[J]. 海洋石油,2017,37(1):21-29. doi: 10.3969/j.issn.1008-2336.2017.01.021
CHEN L L,SUN B Q,WANG L W,et al. Characteristics and source of natural gas from Huagang Formation in north segment of central anticline belt of Xihu Sag[J]. Offshore oil,2017,37(1):21-29. doi: 10.3969/j.issn.1008-2336.2017.01.021
[16] 张国华. 西湖凹陷高压形成机制及其对油气成藏的影响[J]. 中国海上油气,2013,25(2):1-8.
ZHANG G H. Origin mechanism of high formation pressure and its influence on hydrocarbon accumulation in Xihu Sag[J]. China Offshore Oil and Gas,2013,25(2):1-8.
[17] 高伟中,孙鹏,田超,等. 东海盆地西湖凹陷地应力场与油气运移关系探讨[J]. 油气藏评价与开发,2015,5(1):1-6. doi: 10.3969/j.issn.2095-1426.2015.01.001
GAO W Z,SUN P,TIAN C,et al. Relation between crustal stress field and hydrocarbon migration in Xihu Sag,East China Sea Basin[J]. Reservoir Evaluation and Development,2015,5(1):1-6. doi: 10.3969/j.issn.2095-1426.2015.01.001
[18] 周心怀,高顺莉,高伟中,等. 东海陆架盆地西湖凹陷平北斜坡带海陆过渡型岩性油气藏形成与分布预测[J]. 中国石油勘探,2019,24(2):153-164.
ZHOU X H,GAO S L,GAO W Z,et al. Formation and distribution of marine-continental transitional lithologic reservoirs in Pingbei Slope Belt,Xihu Sag,East China Sea Shelf Basin[J]. China Petroleum Exploration,2019,24(2):153-164.
[19] 沈伟锋,于仲坤,刁慧,等. 西湖凹陷热流演化史模拟及成藏意义[J]. 中国海上油气,2020,32(1):42-53.
SHEN W F,YU Z K,DIAO H,et al. Simulation of heat flow evolution history in Xihu Sag and its significance for hydrocarbon accumulation[J]. China Offshore Oil and Gas,2020,32(1):42-53.
[20] 蔡华,秦兰芝,刘英辉. 西湖凹陷平北斜坡带海陆过渡相源-汇系统差异性及其耦合模式[J]. 地球科学,2019,44(3):880-897.
CAI H,QIN L Z,LIU Y H,et al. Differentiation and coupling model of source-to-sink systems with transitional facies in Pingbei Slope of Xihu Sag[J]. Earth Science,2019,44(3):880-897.
[21] 于水. 西湖凹陷西斜坡平湖组烃源岩沉积成因分析[J]. 地球科学,2020,45(5):1722-1736.
YU S. Depositional genesis analysis of source rock in Pinghu Formation of western slope,Xihu Depression[J]. Earth Science,2020,45(5):1722-1736.
[22] 朱扬明,周洁,顾圣啸,等. 西湖凹陷始新统平湖组煤系烃源岩分子地球化学特征[J]. 石油学报,2012,33(1):32-39. doi: 10.7623/syxb201201004
ZHU Y M,ZHOU J,GU S X,et al. Molecular geochemistry of Eocene Pinghu Formation coal-bearing source rocks in the Xihu Depression,East China Sea Shelf Basin[J]. Acta Petrolei Sinica,2012,33(1):32-39. doi: 10.7623/syxb201201004
[23] 丁飞,刘金水,蒋一鸣,等. 东海陆架盆地西湖凹陷孔雀亭区油气来源及运移方向[J]. 海洋地质与第四纪地质,2021,41 (2):156-165.
DING F,LIU J S,JIANG Y M,et al. Source and migration direction of oil and gas in Kongqueting area,Xihu Sag,East China Sea Shelf Basin [J],Marine Geology & Quaternary Geology,2021,41 (2):156-165.
[24] 戴金星. 天然气中烷烃气碳同位素研究的意义[J]. 天然气工业,2011,31(12):1-6. doi: 10.3787/j.issn.1000-0976.2011.12.001
DAI J X. Significance of the study on carbon isotopes of alkane gases[J]. Natural Gas Industry,2011,31(12):1-6. doi: 10.3787/j.issn.1000-0976.2011.12.001
[25] PHILP R P. Fossil Fuel Biomarkers-Aplication and Spectra [M]. Amsterdam:Elsevier,1985.
[26] MACKENZIE A S,PATIENCE R L,MAAXWELL J R,et al. Molecular parameters of maturation in the Toarcian shales,Paris Basin,France-I. Changes in the configurations of acyclic isoprenoid alkanes,steranes and triterpanes[J]. Geochimica et Cosmochimica Acta,1980,44(11):1709-1721. doi: 10.1016/0016-7037(80)90222-7
[27] ALEXANDER R,KAGI R I,ROWLAND S J,et al. The effects of thermal maturity on distributions of dimethylnaphthalenes and trimethylnaphthalenes in some ancient sediments and petroleums[J]. Geochimica et Cosmochimica Acta,1985,49(2):385-395. doi: 10.1016/0016-7037(85)90031-6
[28] 李颖,朱扬明,郝芳,等. 四川盆地北部上三叠统须家河组高成熟煤系烃源岩芳烃热演化与应用[J]. 中国科学:地球科学,2015,45(7):953-962.
LI Y,ZHU Y M,HAO F,et al. Thermal evolution and applications of aromatic hydrocarbons in highly mature coal-bearing source rocks of the Upper Triassic Xujiahe Formation in the northern Sichuan Basin[J]. Science China:Earth Sciences,2015,45(7):953-962.
[29] SZCZERBA M,ROSPONDEK M J. Controls on distributions of methylphenanthrenes in sedimentary rock extracts:critical evaluation of existing geochemical data from molecular modeling[J]. Organic Geochemistry,2010,41(12):1297-1311 doi: 10.1016/j.orggeochem.2010.09.009
[30] RADKE M. Application of aromatic compounds as maturity indicators in source rocks and crude oils[J]. Marine & Petroleum Geology,1988,5(3):224-236
[31] RADKE M,VRIEND S P,RAMANAMPISOA L R. Alkyldibenzofuranes in terrestrial rocks:influence of organic facies and maturation[J]. Geochimica et Cosmochimica Acta,2000,64(2):275-286 doi: 10.1016/S0016-7037(99)00287-2
[32] 沈忠民,魏金花,朱宏权,等. 川西坳陷煤系烃源岩成熟度特征及成熟度指标对比研究[J]. 矿物岩石,2009,29(4):83-88. doi: 10.3969/j.issn.1001-6872.2009.04.012
SHEN Z M,WEI J H,ZHU H Q,et al. Comparative research on maturity and its indicators of coal measure source rock from West Sichuan Basin Depression[J]. Mineralogy and Petrology,2009,29(4):83-88. doi: 10.3969/j.issn.1001-6872.2009.04.012
[33] 刘文汇,徐永昌. 煤型气碳同位素演化二阶段分馏模式及机理[J]. 地球化学,1999,28(4):359-366. doi: 10.3321/j.issn:0379-1726.1999.04.006
LIU W H,XU Y C. A two-stage model of carbon isotopic fractionation in coal-gas[J]. Geochimica,1999,28(4):359-366. doi: 10.3321/j.issn:0379-1726.1999.04.006
[34] 刁慧,刘金水,侯读杰,等. 中国近海断-坳转换期煤系烃源岩特征-以西湖凹陷平湖组烃源岩为例[J]. 海洋地质与第四纪地质,2019,39(6):102-114.
DIAO H,LIU J S,HOU D J,et al. Coal bearing source rocks formed in the transitional stage from faulting to depression nearshore China:a case from the Pinghu Formation in the Xihu Sag[J]. Marine Geology & Quaternary Geology,2019,39(6):102-114.
[35] 刘文汇,王杰,腾格尔,等. 油气同位素地球化学研究现状与进展[J]. 地质学报,2015,89(S1):160-163.
LIU W H,WANG J,TENG G E,et al. Research status and progress of oil and gas isotope geochemistry[J]. Acta Geologica Sinica,2015,89(S1):160-163.
[36] 刁慧,邹玮,李宁,等. 东海盆地西湖凹陷武云亭构造油气来源与成藏模式[J]. 地质科技通报,2020,39(3):110-119.
DIAO H,ZOU W,LI N,et al. Hydrocarbon origin and reservoir forming model of Wuyunting Structure in Xihu Depression,East China Sea Basin[J]. Bulletin of Geological Science and Technology,2020,39(3):110-119.
[37] 张玉红,周世新,左亚彬. 碳同位素在天然气运移路径示踪中的应用研究进展[J]. 矿物岩石地球化学通报,2018,37(6):1198-1204.
ZHANG Y H,ZHOU S X,ZUO Y B. A review of the application of carbon isotopes in tracing the pathway of natural gas migration[J]. Bulletin of Mineralogy,Petrology and Geochemistry,2018,37(6):1198-1204.
-
