摘要:
重金属污染是海洋环境评价的重要内容，为了解万宁潟湖红树林区域海水重金属含量分布及质量现状，于2022年10月采集了调查区红树林区域20个表层海水样品，对7种常见重金属元素（Hg、Cr、Cu、Zn、Pb、Cd、As）进行分析。采用综合污染指数法、Hakanson指数法以及风险商评价法等评估了红树林区域海水重金属分布及污染情况，并基于相关性分析及双向分层聚类分析方法分析了重金属来源。结果表明，研究区Hg、Cu、Pb、Cd元素的平均含量分别为0.044、14.975、0.695、0.628 μg/L，Cr、Zn、As元素在各站位均未达检出限；海水重金属元素分布及污染情况整体呈现出：老爷海潟湖红树林区域优于小海潟湖红树林区域、连片自然林区域优于其他区域、河口区域劣于其他区域的特征；所有重金属元素中以Cu元素超标程度及生物风险程度相对较高；重金属主要来源于渔业养殖和农业生产等陆源人为活动以及港口运输及船舶尾气等的大气沉降，部分区域受到点源状人为活动的影响。相关评价结果可为万宁潟湖周边红树林生态系统保护提供参考。
Abstract:Heavy metal pollution is a major issue of marine environmental assessment. To clarify the distribution and concentration of heavy metals (Hg, Cr, Cu, Zn, Pb, Cd and As) in seawater of mangrove areas in Wanning Lagoon, Hainan South China, 20 surface seawater samples were collected in mid-October 2022 for analysis. Comprehensive pollution evaluation method, Hakanson index, and risk quotient were used. The originations of heavy metals were traced based on correlation analysis and bidirectional stratified cluster analysis. Results show that the average contents of Hg, Cu, Pb, and Cd were 0.044, 14.975, 0.695, and 0.628 μg/L, respectively, and Cr, Zn and As were below the detection limits in all stations. In terms of heavy metal pollution status, the Laoyehai area was better than the Xiaohai area, the natural mangrove forest area was better than other areas, and the estuary area was worse than other areas. The content of Cu exceeded the benchmark and so the degree of biological risk was relatively high among all heavy metals. Heavy metals mainly come from land-based anthropogenic activities such as fishery breeding and agricultural production, as well as atmospheric subsidence of port transportation and ship emission, and some areas were affected by point-source anthropogenic activities. This study provided a reference for the protection of mangrove ecosystem around Wanning Lagoon.
-
Key words:
- Wanning Lagoon /
- mangroves /
- surface seawater /
- heavy metals /
- risk assessment
-
-
WQI≤1 1＜WQI≤2 2＜WQI≤3 WQI＞3 清洁 轻微污染 中度污染 严重污染
下载: 导出CSV
元素 Cu Zn Pb Cd As Cr Hg 毒性响应系数
5 1 5 30 10 2 40 评价标准值
（μg/L）5 20 1 1 20 50 0.05
下载: 导出CSV
潜在生态危害系数
EiEi＜40 40≤
Ei＜8080≤
Ei＜160160≤
Ei＜320Ei≥80 轻微 中等 强 很强 极强 潜在生态危害指数RI RI＜150 150≤RI＜300 300≤RI＜600 RI≥300 轻微 中等 强 很强
下载: 导出CSV
元素 Cu Zn Pb Cd As Cr Hg
/（μg/L）3.46 25.54 234.06 1.07 0.5 25.43 2.84 风险商RQ RQ≤0.1 0.1＜RQ≤1 RQ＞1 低生态风险 中等生态风险 高生态风险
下载: 导出CSV
表 5 万宁潟湖红树林区域重金属含量
Table 5. Heavy metal contents in the mangrove area of Wanning Lagoon
元素 Hg Cr Cu Zn Pb Cd As 检出限/(μg/L) 0.007 0.400 0.200 3.100 0.030 0.010 0.500 检出率/% 80 0 60 0 20 80 0 范围/(μg/L) 0.0 035～0.124 — 0.1～48.2 — 0.015～4.00 0.005～1.17 — 算术平均值/(μg/L) 0.044 — 14.975 — 0.695 0.628 — 标准偏差/(μg/L) 0.041 — 16.754 — 1.415 0.407 — 变异系数 0.914 — 1.119 — 2.036 0.649 — 海水水质标准/(μg/L) Ⅰ 0.05 50 5 20 1 1 20 Ⅱ 0.2 100 10 20 5 5 30 Ⅲ 0.5 200 50 100 10 10 50 Ⅳ 500 500 50 注：“—”表示未达检出限。
下载: 导出CSV
表 6 重金属质量浓度与海水环境因子的相关性分析
Table 6. Correlation analysis of mass concentration of heavy metals and environmental factors in seawater
pH T SAL DO COD Hg Cu Pb Cd pH 1 T 0.651** 1 SAL −0.529* −0.094 1 DO −0.299 −0.154 0.256 1 COD 0.027 0.250 0.297 −0.246 1 Hg −0.043 −0.095 −0.473* 0.128 −0.175 1 Cu 0.524* 0.338 −0.107 −0.137 0.065 −0.242 1 Pb 0.223 0.410 −0.102 −0.088 −0.150 0.052 0.443* 1 Cd 0.159 −0.306 −0.475* −0.029 −0.312 0.152 −0.092 −0.044 1 注：**表示在0.01水平下（双侧检验）相关性显著；*表示在0.05水平下（双侧检验）相关性显著。
下载: 导出CSV
-
[1] 卢振峰,唐棣,李乐,等. 海南老爷海表层沉积物重金属分布特征及污染评价[J]. 海洋环境科学,2023,42(3):410-417.
LU Z F ,TANG D,LI L,et al. Distribution characteristics and pollution evaluation of heavy metals in the surface sediment of Laoyehai Lagoon,Hainan Province[J]. Marine Environmental Science,2023,42(3):410-417.
[2] 范成新,刘敏,王圣瑞,等. 近20年来我国沉积物环境与污染控制研究进展与展望[J]. 地球科学进展,2021,36(4):346-374.
FAN C X,LIU M,WANG S R,et al. Research progress and prospect of sediment environment and pollution control in China in recent 20 years[J]. Advances in Earth Science,2021,36(4):346-374.
[3] 吴瑞. 海南岛潟湖环境现状及治理对策[J]. 热带农业工程,2020,44(3):99-101.
WU R. Current status and controlling strategies of lagoon environment in Hainan Island[J]. Tropical Agricultural Engineering,2020,44(3):99-101.
[4] 陈新平,王斌,尹子祺,等. 红树林防灾减灾功能研究进展及保护修复建议[J]. 海洋通报,2023,42(4):469-480.
CHEN X P,WANG B,YIN Z Q,et al. Research progress on mangrove forest disaster prevention and mitigation functions and suggestions for protection and restoration[J]. Marine Science Bulletin,2023,42(4):469-480.
[5] 王友绍. 红树林分子生态学 [M]. 北京:科学出版社,2019.
WANG Y S. Molecular Ecology of Mangroves[M]. Beijing:Science Press,2019.
[6] INYANG A,ZHOU Y,Y. Characteristics of water quality and their eutrophication assessment on the mangrove ecosystems along the Guangdong coast[J]. Journal of Tropical Oceanography,2022,41(6):1-11.
[7] WANG Y,GU J. Ecological responses,adaptation and mechanisms of mangrove wetland ecosystem to global climate change and anthropogenic activities[J]. International Biodeterioration & Biodegradation,2021,162:105248.
[8] 阎琨,庞国涛,邢新丽,等. 广西企沙半岛近岸表层海水重金属分布、来源及生态风险评价[J]. 海洋环境科学,2023,42(1):89-96.
YAN K,PANG G T,XING X L,et al. Distribution,source analysis and ecological risk assessment of heavy metals in surface seawater near Qisha Peninsula,Guangxi Province[J]. Marine Environmental Science,2023,42(1):89-96.
[9] 许观嫦,徐颂军,宋焱,等. 深圳红树林自然保护区海水重金属质量评价[J]. 华南师范大学学报(自然科学版),2015,47(1):101-108.
XU G C,XU S J ,SONG Y,et al. Evaluation on the seawater's heavy metals in Shenzhen mangrove nature reserve[J]. Journal of South China Normal University(Natural Science Edition),2015,47(1):101-108.
[10] 张璐瑶. 亚热带潟湖地区生态保育、多元共治的路径探索:以万宁小海为例[C]//中国城市规划学会,成都市人民政府. 面向高质量发展的空间治理: 2021中国城市规划年会论文集(16乡村规划). 北京:中国建筑工业出版社,2021:10.
ZHANG L Y. The path research on ecological conservation and multi-governance in the subtropical lagoon area[C]//Chinese Society of Urban Planning,Chengdu Municipal People's Government. Spatial Governance for High-Quality Development - Proceedings of the 2021 China Urban Planning Annual Conference (16 Rural Planning). Beijing:China Building Industry Press,2021:10.
[11] 马文超,王焱,朱卓毅. 高强度养殖活动下老爷海溶解氧的亏损及有机质成分的响应[J]. 华东师范大学学报(自然科学版),2021(2):85-99.
MA W C,WANG Y,ZHU Z Y. Oxygen depletion and the response of organic matter in Laoyehai,a lagoon with strong aquaculture activities[J]. Journal of East China Normal University (Natural Science),2021(2):85-99.
[12] 徐永辉,黄文国,梁泰尔. 万宁小海海水增养殖区海域水质状况分析与评价[J]. 广东化工,2021,48(8):204-207. doi: 10.3969/j.issn.1007-1865.2021.08.078
XU Y H,HUANG W G,LIANG T E. Analysis and evaluation of water quality in Xiaohai mariculture area of Wanning[J]. Guangdong Chemical Industry,2021,48(8):204-207. doi: 10.3969/j.issn.1007-1865.2021.08.078
[13] 朱志雄,骆丽珍,陈石泉,等. 海南小海海水富营养化和重金属特征分析与评价[J]. 海洋湖沼通报,2020,5:131-138.
ZHU Z X,LUO L Z ,CHEN S Q,et al. Analysis and evaluation of eutrophication of seawater and characteristics of heavy metal in Xiaohai,Hainan Province [J]. Transactions of Oceanology and Limnology,2020,5:131-138.
[14] 宋德卓,薛积彬,孙升升. 海南小海潟湖沉积物地球化学揭示的近千年气候环境变化[J]. 地球化学,2022,51(2):202-212.
SONG D Z,XUE J B,SUN S S,et al. Climate and environmental changes revealed by sedimentary geochemical elements of the Xiaohai Lagoon (Hainan) during the last millennium[J]. Geochimica,2022,51(2):202-212.
[15] 游爱华,薛积彬,谢露华,等. 海南东部小海潟湖沉积物地球化学特征及对古台风活动的指示[J]. 湖泊科学,2019,31(6):1758-1769. doi: 10.18307/2019.0618
YOU A H,XUE J B,XIE L H,et al. Geochemical characteristics of sediments in the Xiaohai Lagoon ( Eastern Hainan) and implications for the paleo-typhoon activities[J]. Journal of Lake Sciences,2019,31(6):1758-1769. doi: 10.18307/2019.0618
[16] 骆丽珍,朱志雄,陈石泉,等. 万宁小海潟湖表层沉积物时空分布特征与污染评价[J]. 海洋湖沼通报,2022,44(2):103-111.
LUO L Z,ZHU Z X ,CHEN S Q,et al. Spatial distribution and contamination evaluation of surface sediment in Xiaohai,Wanning[J]. Transactions of Oceanology and Limnology,2022,44(2):103-111.
[17] 林钟扬,倪建宇,时连强,等. 海南小海表层沉积环境及重金属污染综合评价[J]. 海洋学研究,2011,29(2):12-23.
LIN Z Y,NI J Y,SHI L Q,et al. Comprehensive evaluation of the environment and the heavy metals pollution in the surface sediments of Xiaohai,Hainan Province[J]. Journal of Marine Sciences,2011,29(2):12-23.
[18] 刘兴健,葛晨东. 海南岛小海潟湖沉积环境演变研究[J]. 海洋通报,2007(4):71-79.
LIU X J,GE C D. Sedimentary environment evolvement of Xiaohai Lagoon in the Hainan Island[J]. Marine Science Bulletin,2007(4):71-79.
[19] 徐阁,王德鸿,韩留玉,等. 海南万宁海域海洋生物重金属分析与评价[J]. 生态科学,2023,42(3):106-113.
XU G,WANG D H,HAN L Y,et al. Analysis and evaluation of heavy metals in marine organisms in Wanning ocean area[J]. Ecological Science,2023,42(3):106-113.
[20] 全国海洋标准化技术委员会. GB 17378.3—2007,海洋监测规范 第3部分:样品采集、贮存与运输[S]. 北京:中国标准出版社,2007.
National Technical Committee for Marine Standardization. GB 17378.3-2007,Marine monitoring specifications part 3:sample collection,storage and transportation [S]. Beijing:China Standards Press,2007.
[21] 全国海洋标准化技术委员会. GB 17378.4—2007,海洋监测规范 第4部分:海水分析[S]. 北京:中国标准出版社,2007.
National Technical Committee for Marine Standardization. GB 17378.4-2007,Marine monitoring specifications part 4:seawater analysis [S]. Beijing:China Standards Press,2007.
[22] SUN Q B,GAO F,CHEN Z L,et al. The content and pollution evaluation of heavy metals in surface seawater in Dalian Bay[J]. Earth and Environmental Science,2019,227:062021.
[23] 赵明杰,孙志佳,闫兴国,等. 广东吴川近岸海域表层海水重金属含量及生态风险分析[J]. 海洋地质前沿,2023,39(1):70-76.
ZHAO M J,SUN Z J,YAN X G,et al. Analysis of heavy metal content and ecological risk in surface seawater of Wuchuan coastal area,Guangdong Province[J]. Marine Geology Frontiers,2023,39(1):70-76.
[24] 国家海洋局,国家环境保护局. GB 3097—1997,海水水质标准[S]. 北京:中国标准出版社,1998.
State Oceanic Administration,State Environmental Protection Administration. GB 3097-1997,seawater quality standard[S]. Beijing:China Standards Press,1998.
[25] 刘宪斌,朱浩然,郭夏青,等. 河北黄骅近岸海域表层海水重金属污染特征及生态风险评价[J]. 安全与环境学报,2020,20(2):747-755.
LIU X B,ZHU H R,GUO X Q,et al. On situation of heavy metal contaminant residents in seawater along Huanghua coast area and potential ecological risk assessment,Cangzhou,Hebei Province[J]. Journal of Safety and Environment,2020,20(2):747-755.
[26] 刘慧杰,刘文君,刘继平,等. 南中国海表层海水重金属含量及其潜在生态风险分析[J]. 中国环境科学,2017,37(10):3891-3898.
LIU H J,LIU W J,LIU J P,et al. Heavy metals concentration and its potential ecological risk assessment of surface seawater in South China Sea[J]. China Environmental Science,2017,37(10):3891-3898.
[27] ZOLEZZI M ,CATTANEO C,TARAZONA J V . Probabilistic ecological risk assessment of 1,2,4-trichlorobenzene at a former industrial contaminated site[J]. Environmental Science & Technology,2005,39(9):2920-2926.
[28] LI X,CHI W Q,TIAN H,et al. Probabilistic ecological risk assessment of heavy metals in western Laizhou Bay,Shandong Province,China[J]. Plos One,2019,14:e0213011. doi: 10.1371/journal.pone.0213011
[29] 崔衍波,冯永亮,刘群群,等. 东营市三个河口区域表层海水重金属的分布与生态风险评价[J]. 中国海洋大学学报(自然科学版),2019,49(1):93-101.
CUI Y B,FENG Y L,LIU Q Q,et al. Distribution and ecological risk assessment of heavy metals in surface seawater from three estuaries in Dongying[J]. Periodical of Ocean University of China (Natural Science),2019,49(1):93-101.
[30] WANG Z,DU Y,YANG C,et al. Occurrence and ecological hazard assessment of selected antibiotics in the surface waters in and around Lake Honghu,China[J]. Science of the Total Environment,2017,609:1423-1432. doi: 10.1016/j.scitotenv.2017.08.009
[31] 中国环境监测总站,浙江省舟山海洋生态环境监测站. HJ 442—2008,近岸海域环境监测规范[S]. 北京:中国环境科学出版社,2008.
China National Environmental Monitoring Center,Zhejiang Provincial Zhoushan Marine Ecological Environment Monitoring Station. HJ 442-2008,specifications for monitoring of coastal waters [S]. Beijing:China Environmental Science Press,2008.
[32] 王霞. 黄河上游典型地区底泥重金属调查与污染评价[D]. 兰州:兰州交通大学,2014.
WANG X. Investigation and pollution assessment of heavy metals in surface sediments from typical regions in upstream of Yellow River[D]. Lanzhou:Lanzhou Jiaotong University,2014.
[33] 杜建国,赵佳懿,陈彬,等. 应用物种敏感性分布评估重金属对海洋生物的生态风险[J]. 生态毒理学报,2013,8(4):561-570.
DU J G,ZHAO J Y,CHEN B,et al. Assessing ecological risks of heavy metals to marine organisms by species sensitivity distributions[J]. Asian Journal of Ecotoxicology,2013,8(4):561-570.
[34] WANG X Y,ZHAO L L,XU H Z,et al. Spatial and seasonal characteristics of dissolved heavy metals in the surface seawater of the Yellow River Estuary,China[J]. Marine Pollution Bulletin,2018,137:465-473. doi: 10.1016/j.marpolbul.2018.10.052
[35] 公金文,陈发荣,郑立,等. 红海湾表层海水重金属含量与污染评价[J]. 海洋科学进展,2021,39(4):570-580.
GONG J W,CHEN F R,ZHENG L,et al. The concentrations and pollution assessment of heavy metal in surface seawater in Honghai Bay[J]. Advances in Marine Science,2021,39(4):570-580.
[36] 罗万次,苏搏,刘熊,等. 广西北仑河口红树林保护区表层海水溶解态重金属时空分布及其影响因素[J]. 海洋通报,2014,33(6):668-675.
LUO W C,SU B,LIU X,et al. Spatial and temporal distributions and influence factors of the dissolved heavy metals in surface water in the mangrove reserve at the Beilun River Estuary in Guangxi[J]. Marine Science Bulletin,2014,33(6):668-675.
[37] 李劳钰,王宗灵,魏修华,等. 南黄海西部冬季表层水中的溶解态重金属分布特征分析[J]. 海洋科学进展,2009,27(2):201-210.
LI L Y,WANG Z L,WEI X H,et al. Distribution of dissolved heavy metals in the surface water in the west area of the Southern Yellow Sea in winter[J]. Advances in Marine Science,2009,27(2):201-210.
[38] HAN X M,WANG J Q,CAI W Q,et al. The pollution status of heavy metals in the surface seawater and sediments of the Tianjin coastal area,North China[J]. IJERPH,2021,18(21):11243. doi: 10.3390/ijerph182111243
[39] 时春景,李红霞,张言,等. 永定河上覆水、间隙水和沉积物中重金属的分布特征[J]. 环境化学,2017,36(1):48-61.
SHI C J,LI H X,ZHANG Y,et al. Distribution characteristics of heavy metals in overlying water-pore water-sediment in the Yongding River[J]. Environmental Chemistry,2017,36(1):48-61.
[40] 孙维萍,潘建明,吕海燕,等. 2006年夏冬季长江口、杭州湾及邻近海域表层海水溶解态重金属的平面分布特征[J]. 海洋学研究,2009,27(1):37-43.
SUN W P,PAN J M,LYU H Y,et al. Distribution of dissolved trace metals in summer and winter of 2006 in Changjiang River Estuary and Hangzhouwan Bay[J]. Journal of Marine Sciences,2009,27(1):37-43.
[41] 王小静,张帅,简慧敏,等. 大辽河口溶解态重金属的变化特征及影响因素研究[J]. 中国海洋大学学报(自然科学版),2011,41(10):79-86.
WANG X J,ZHANG S,JIAN H M,et al. Variation characteristics of dissolved heavy metals in the Daliaohe Estuary[J]. Periodical of Ocean University of China (Natural Science),2011,41(10):79-86.
-
