Sedimentary evolution and controlling factors of Ⅴ Oil Group in the lower Minghuazhen Formation of Neogene in Kenli 6-A Oilfield, Bohai Sea, based on 3D isochronous stratigraphic slicing
-
摘要:
新近系明化镇组下段Ⅴ油组是目前渤海浅层勘探开发重点层系之一，该时期广泛发育浅水三角洲沉积，但对其沉积演化规律及控制因素缺乏系统研究，导致对砂体空间展布认识不清，制约了砂体连通性分析及开发井位部署。以渤海垦利6-A油田为研究区，基于地震、钻井、测井等界面特征的识别，首先将明化镇组下段Ⅴ油组细分为5个亚油组，相当于4个四级层序，建立了等时层序地层格架；再以此为约束基于高度等时的三维地层切片技术揭示了Ⅴ油组沉积演化规律：早期Ⅴ-5亚油组发育大型分流河道，河道宽度＞1 km，最宽达2 km；Ⅴ-4亚油组最大湖侵期发育小型分支水系，宽度约80～300 m；Ⅴ-2、Ⅴ-3亚油组发育中型河道（河道复合体），宽度100～2 600 m；晚期Ⅴ-1亚油组大型河道与小型河道共生，大型河道宽度＞1 km，小型分流河道宽度为90～280 m。Ⅴ油组沉积演化及砂体空间展布主要受古地貌和层序共同控制，有序分布：平面上不同地貌单元控制河道规模，其中，大型河道主要分布于Ⅴ-1、Ⅴ-5沉积期的洼槽区，中型河道分布于Ⅴ-2、Ⅴ-3沉积期的断阶根部，小型分支水系主要分布于较高部位；垂向上层序控制了河道演化，其中，大型河道主要发育于二级或三级层序底部，中型河道主要发育于四级层序底部和顶部，小型分支水系则发育于四级层序湖侵面附近。预测研究区Ⅴ-1期大型河道发育潜在有利砂体，这将有效指导后续开发部署和井位优化调整，并丰富对渤海新近系浅水三角洲沉积模式的认识。
Abstract:The Ⅴ Oil Group of Kenli 6-A Oilfield in the lower Minghuazhen Formation (MF) of the Neogene is one of the key strata for shallow exploration and development in the Bohai Sea. The MF features shallow water delta deposits widely developed. However, systematic research on its evolution and controlling factors lacks, leading to poor understanding of the spatial distribution and connectivity of sand bodies. Based on the interface identification of seismic, drilling and logging, the Ⅴ Oil Group could be divided into five subgroups corresponding to four fourth-order sequences, based on which a high-precision sequence stratigraphic framework was established. The sedimentary evolution of the Ⅴ Oil Group were reproduced by high-precision isochronous three-dimensional stratigraphic slicing, showing characteristics of large distributary channels in the early Ⅴ-5 subgroup, small distributary channels in the maximum invasion period in the Ⅴ-4 subgroup, the medium-scale channels (channel complexes) in the Ⅴ-2 and Ⅴ-3 subgroups, and the co-existence of large channels and small channels in the late Ⅴ-1 sub group. The sedimentary evolution and sand body distribution were mainly controlled by the paleogeomorphology and stratigraphic sequence and distributed in an orderly manner. Different paleogeomorphology units on the plane controlled the scale of the channel. The large channel distributed mainly in the depression area during the Ⅴ-1 and Ⅴ-5 periods, the medium channel distributed in the root of the fault terrace during the Ⅴ-2 and Ⅴ-3 periods, and the small distributary channel distributed in the higher part of the sequence. In the vertical direction, the sequence controlled the change of channel, in which large channels developed at the bottom of the second- or third-order sequence, the medium-scale channel developed at the bottom and top of the fourth-order sequence, and small distributary channel developed near the fourth-order transgressive surface. It is predicted that the potentially favorable sand bodies are large channel deposits in the study area, which will effectively guide the subsequent exploration deployment and well location optimization, and enrich the understanding of the sedimentary model of the Neogene shallow-water delta in the Bohai Sea.
-
Key words:
- stratigraphic slicing /
- Bohai Sea /
- Neogene /
- Ⅴ Oil Group /
- shallow water delta /
- sedimentary evolution
-
-
[1] 代黎明,李建平,周心怀,等. 渤海海域新近系浅水三角洲沉积体系分析[J]. 岩性油气藏,2007,19(4):75-81. doi: 10.3969/j.issn.1673-8926.2007.04.013
DAI L M,LI J P,ZHOU X H,et al. Depositional system of the Neogene shallow water delta in Bohai Sea area[J]. Lithologic Reservoirs,2007,19(4):75-81. doi: 10.3969/j.issn.1673-8926.2007.04.013
[2] 朱伟林,李建平,周心怀,等. 渤海新近系浅水三角洲沉积体系与大型油气田勘探[J]. 沉积学报,2008,26(4):575-582.
ZHU W L,LI J P,ZHOU X H,et al. Neogene shallow water deltaic system and large hydrocarbon accumulations in Bohai Bay,China[J]. Acta Sedimentologica Sinica,2008,26(4):575-582.
[3] 周心怀,王德英,张新涛. 渤海海域石臼坨凸起两个亿吨级隐蔽油气藏勘探实践与启示[J]. 中国石油勘探,2016,21(4):30-37. doi: 10.3969/j.issn.1672-7703.2016.04.004
ZHOU X H,WANG D Y,ZHANG X T. Two 100 million-ton class subtle reservoirs in Shijiutuo Uplift,Bohai Sea exploration practices and enlightenments[J]. China Petroleum Exploration,2016,21(4):30-37. doi: 10.3969/j.issn.1672-7703.2016.04.004
[4] 徐长贵,杨海风,王德英,等. 渤海海域莱北低凸起新近系大面积高丰度岩性油藏形成条件[J]. 石油勘探与开发,2021,48(1):12-26. doi: 10.11698/PED.2021.01.02
XU C G,YANG H F,WANG D Y,et al. Formation conditions of Neogene large-scale high-abundance lithologic reservoir in the Laibei low uplift,Bohai Sea,East China[J]. Petroleum Exploration and Development,2021,48(1):12-26 doi: 10.11698/PED.2021.01.02
[5] 薛永安. 渤海海域垦利6-1油田的发现与浅层勘探思路的重大转变[J]. 中国海上油气,2021,33(2):1-12.
XUE Y A. Discovery of KL6-1 Oilfield and great change of shallow strata exploration ideas in Bohai Sea[J]. China offshore Oil and Gas,2021,33(2):1-12.
[6] 周心怀,王德英,于海波,等. 环渤中地区浅层大规模岩性油藏的成藏主控因素与成藏模式[J]. 石油勘探与开发,2022,49(4):660-669.
ZHOU X H,WANG D Y,YU H B,et al. Major controlling factors and hydrocarbon accumulation models of large-scale lithologic reservoirs in shallow strata around the Bozhong Sag,Bohai Bay Basin,China[J]. Petroleum Exploration and Development,2022,49(4):660-669.
[7] 徐长贵,杜晓峰,庞小军,等. 渤海南部明化镇组下段源-汇体系及其对大面积岩性油气藏的控制作用[J]. 地质力学学报,2022,28(5):728-742. doi: 10.12090/j.issn.1006-6616.20222813
XU C G,DU X F,PANG X G,et al. The source-sink system and its control on large-area lithologic reservoirs of the lower Minghuazhen Formation in the southern Bohai Sea[J]. Journal of Geomechanics,2022,28(5):728-742. doi: 10.12090/j.issn.1006-6616.20222813
[8] 吴小红,吕修祥,周心怀,等. 黄河口凹陷浅水三角洲沉积特征及其油气勘探意义[J]. 石油与天然气地质,2010,31(2):165-172. doi: 10.11743/ogg20100205
WU X H,LYU X X,ZHOU X H,et al. Depositional characteristics and hydrocarbon exploration significance of shallow deltas in Yellow River Mouth Sag[J]. Oil & Gas Geology,2010,31(2):165-172. doi: 10.11743/ogg20100205
[9] 侯东梅,周军良,赵军寿,等. 渤南低凸起西端浅水三角洲沉积特征:以B地区新近系明化镇组下段为例[J]. 断块油气田,2021,28(2):205-211.
HOU D M,ZHOU J L,ZHAO J S,et al. Sedimentary characteristics of shallow water deltas of western part of Bonan low uplift:a case study of Neogene Lower Minghuazhen Formation in B area[J]. Fault Block Oil & Field,2021,28(2):205-211.
[10] 王利良,牛成民,杨海风,等. 渤海湾盆地莱北低凸起明化镇组下段河道类型演化及其油气地质 意义[J]. 石油学报,2022,43(3):364-375.
WANG L L,NIU C M,YANG H F,et al. Evolution of channel patterns and its geological significance for oil and gas exploration in the Lower Member of Minghuazhen Formation in Laibei low uplift,Bohai Bay Basin[J]. Acta Petrolei Sinica,2022,43(3):364-375.
[11] 李国发,王亚静,熊金良,等. 薄互层地震切片解释中的几个问题:以一个三维地质模型为例[J]. 石油地球物理勘探,2014,49(2):388-393.
LI G F,WANG Y J,XIONG J L,et al. Phenomena in inter-bed reservoir interpretation on seismic slices:an example of 3D geological model[J]. Oil Geophysical Prospecting,2014,49(2):388-393.
[12] 刘华清,卫平生,李相博,等. 对地震沉积学理论创新的认识[J]. 岩性油气藏,2012,24(1):7-19. doi: 10.3969/j.issn.1673-8926.2012.01.002
LIU H Q,WEI P S,LI X B,et al. Discussion on theoretical innovation of seismic sedimentology[J]. Lithologic Reservoirs,2012,24(1):7-19. doi: 10.3969/j.issn.1673-8926.2012.01.002
[13] 付鑫,杜晓峰,官大勇,等. 地震沉积学在河流—浅水三角洲沉积相研究中的应用:以渤海海域蓬莱A构造区馆陶组为例[J]. 地质科技通报,2021,40(3):96-108.
FU X,DU X F,GUAN D Y,et al. Application of seismic sedimentology in reservoir prediction in fluvial to shallow water delta facies:a case study in Guantao Formation from the Penglai A structure area in Bohai Bay[J]. Bulletin of Geological Science and Technology,2021,40(3):96-108.
[14] 孙颖,卢异,佘晓宇,等. 地层(体)切片技术及其应用[J]. 天然气地球科学,2011,22(5):884-888. doi: 10.11764/j.issn.1672-1926.2011.05.884
SUN Y,LU Y,SHE X Y,et al. Stratal(body) slice technology and its application[J]. Natural Gas Geoscience,2011,22(5):884-888. doi: 10.11764/j.issn.1672-1926.2011.05.884
[15] 龚承林,朱一杰,邵大力,等. 海底扇规模优质储集体的分布模式与成因分析:以上新世—更新世孟加拉扇为例[J]. 沉积学报,2023,41(1):1-17.
GONG C L,ZHU Y J,SHAO D L,et al. Distribution patterns and genetic analyses of potentially productive good deep-water reservoirs:a case study from the Pliocene-Pleistocene Bengal Fan[J]. Acta Sedimentologica Sinica,2023,41(1):1-17.
[16] 李敏,朱红涛,杨香华,等. 地震多属性在少井区和无井区沉积体系分析中的应用[J]. 海洋地质与第四纪地质,2012,32(1):151-157.
LI M,ZHU H T,YANG X H,et al. Sedimentary system analysis using seismic multi-attributes technique in areas[J]. Marine Geology & Quaternary Geology,2012,32(1):151-157.
[17] 朱筱敏,董艳蕾,曾洪流,等. 沉积地质学发展新航程:地震沉积学[J]. 古地理学报,2019,21(2):189-201. doi: 10.7605/gdlxb.2019.02.011
ZHU X M,DONG Y L,ZENG H L,et al. New development trend of sedimentary geology:seismic sedimentology[J]. Journal of Palaeogeography(Chinese Edition),2019,21(2):189-201. doi: 10.7605/gdlxb.2019.02.011
[18] 厚刚福,瞿建华,朱峰,等. 古地貌对沉积体系和沉积微相的控制作用分析:以准噶尔盆地腹部白垩系清水河组为例[J]. 中国矿业大学学报,2018,47(5):1038-1045.
HOU G F,QU J H,ZHU F,et al. Analysis on the control of paleogeomorphology on sedimentary system and sedimentary microfacies:taking the Cretaceous Qingshuihe Formation in the hinterland of Junggar Basin as an example[J]. Journal of China University of Mining and Technology,2018,47(5):1038-1045.
[19] 杨哲翰,刘江艳,吕奇奇,等. 古地貌恢复及其对重力流沉积砂体的控制作用:以鄂尔多斯盆地三叠系延长组长73亚段为例[J]. 地质科技通报,2023,42(2):146-158.
YANG Z H,LIU J Y,LYU Q Q,et al. Paleogeomorphological restoration and its control on gravity flows and bodies:a case study of the Chang 73 submember of the Triassic Yanchang Formation in the Ordos Basin[J]. Bulletin of Geological Science and Technology,2023,42(2):146-158.
[20] 张振杰,宋洪亮,王欣然,等. 层序地层格架约束下的浅水三角洲沉积特征及其潜力研究[J]. 复杂油气藏,2018,11(3):35-40.
ZhANG Z J,SONG H L,WANG X R,et al. Sedimentary characteristics and potential of shallow water delta under the constraint of sequence stratigraphic framework[J]. Complex Hydrocarbon Reservoirs,2018,11(3):35-40.
-
