Characteristics and source analysis of heavy metals pollution in sediments of coastal zones in Jiangsu Province
-
摘要:
基于2020年江苏近岸海域表层沉积物中7种重金属（Pb、Cr、As、Cu、Zn、Cd和Hg）含量，分析其污染特征并追溯其来源。结果表明，江苏海域表层沉积物的平均粒径由北向南逐渐加粗，除Cr外，其他重金属平均含量均高于江苏海涂土壤环境背景值。2020年，江苏近岸海域整体处于轻度污染水平和轻微潜在生态风险水平。其中，Cd处于重度污染水平和强潜在生态风险水平，其他重金属元素处于轻度污染水平和轻微潜在生态风险水平。江苏海域中海州湾和长江口的重金属含量与污染程度均较高。在江苏近岸海域，2020年Cd和Zn的污染程度比2013年严重。重金属元素与平均粒径呈正相关，与黏土之间的正相关性最高。来源分析结果表明，重金属来源可分为交通航运与工业排放（Pb和Zn）、农业生产活动和生活污水（As和Cd）、成土母质和大气干湿沉降（Cr和Hg）、养殖生产活动（Cu）4类。与APCS-MLR模型相比，PMF模型对江苏海域重金属的自然源的解释相对较差。APCS-MLR模型结果指示，这4类来源对重金属贡献率分别为27.30%、35.55%、31.22%和5.93%。研究结果对保护江苏近岸海域生态环境和合理发展海洋经济具有重要意义。
Abstract:Based on the concentration of 7 heavy metals (Pb, Cr, As, Cu, Zn, Cd and Hg) in surface sediments of coastal zones in Jiangsu Province in 2020, we investigated the pollution characteristics and source apportionment. Results show that the average particle size in surface sediments of coastal zones in Jiangsu Province gradually thickened from north to south. The average concentrations of other heavy metals (exclusive of Cr) exceeded the background values of environmental elements in beach soils of Jiangsu Province. The coastal zones in Jiangsu Province in 2020 experienced light pollution and exhibited a slight level of potential ecological risk. Cd was at a level of severe pollution and strong potential ecological risk, while other heavy metals were at a level of mild pollution and slight potential ecological risk. High concentrations of heavy metals in sediments were observed in Haizhou Bay and the Yangtze River estuary. Compared with 2013, the pollution levels of Cd and Zn in coastal zones of Jiangsu Province were more severe in 2020. Heavy metal elements were positively correlated with the average particle size, with the strongest positive correlation with clay. Source apportionment study indicated that heavy metals were originated from four primary sources categories: 1. transportation, shipping, and industrial emissions (Pb and Zn); 2. agricultural production activities and domestic sewage (As and Cd); 3. soil parent material, atmospheric dry and wet deposition (Cr and Hg); and 4. aquaculture production activities (Cu). Compared with the APCS-MLR model, the PMF model demonstrated a relatively weaker explanatory power for the natural sources of heavy metals in the surface sediments of coastal zones of Jiangsu Province. The results of APCS-MLR model indicated that the contribution of the four identified source categories were 27.30%, 35.55%, 31.22%, and 5.93%, respectively. The results shall have important implications for the protection of the coastal ecological environment and the sustainable development in the marine economy of Jiangsu Province.
-
-
表 1 重金属评价指标的等级划分
Table 1. Classification of evaluation indexes of heavy metals
CF PLI 污染程度 NI 污染程度
单因子潜在生态风险程度 RI 综合潜在生态风险程度 ≤1 ≤1 清洁 ≤0.7 清洁 ≤40 轻微 ≤150 轻微 1～2 1～2 轻度 0.7～1 警戒 40～80 中等 150～300 中等 2～3 2～3 中度 1～2 轻度 80～160 强 300～600 强 ≥3 ≥3 重度 2～3 中度 160～320 很强 ≥600 很强 \ \ \ ≥3 重度 ≥320 极强 \ \ 注：“\”为无数据。
下载: 导出CSV
表 2 江苏海域与中国典型海域表层沉积物中重金属均值含量对比
Table 2. Comparison in average concentration of heavy metal in surface sediment of coastal zones in Jiangsu Province and typical sea in China
mg/kg
下载: 导出CSV
表 3 江苏近岸海域表层沉积物中重金属因子分析结果
Table 3. Factor analysis results of heavy metals in surface sediments of coastal zones in Jiangsu Province
因子 特征值 方差贡献率/% 累积方差贡献率/% 1 2.20 31.48 31.48 2 1.58 22.61 54.09 3 0.99 14.15 68.24 4 0.82 11.64 79.88 5 0.60 8.60 88.48 6 0.45 6.49 94.97 7 0.35 5.03 100
下载: 导出CSV
-
[1] 王颖,季小梅. 中国海陆过渡带:海岸海洋环境特征与变化研究[J]. 地理科学,2011,31(2):129-135.
WANG Y,JI X M. Environmental characteristics and changes of coastal ocean as land-ocean transitional zone of China[J]. Scientia Geographica Sinica,2011,31(2):129-135.
[2] 俞慎和,历红波. 沉积物再悬浮重金属释放机制研究进展[J]. 生态环境学报,2010,19(7):1724-1731.
YU S H,LI H B. Perspectives on the release of heavy metals via sediment resuspension[J]. Ecology and Environmental Sciences,2010,19(7):1724-1731.
[3] XU G,PEI S F,LIU J,et al. Surface sediment properties and heavy metal pollution assessment in the near-shore area,north Shandong Peninsula[J]. Marine Pollution Bulletin,2015,95(1):395-401. doi: 10.1016/j.marpolbul.2015.03.040
[4] SINGH U K ,KUMAR B. Pathways of heavy metals contamination and associated human health risk in Ajay River Basin,India[J]. Chemosphere,2017,174:183-199.
[5] SANTOS I R,SILVA-F E V,SCHAEFER C E G R,et al. Heavy metal contamination in coastal sediments and soils near the Brazilian Antarctic Station,King George Island[J]. Marine Pollution Bulletin,2005,50(2):185-194. doi: 10.1016/j.marpolbul.2004.10.009
[6] 丁言者. 江苏近岸海域水质变化特征研究[D]. 南京:南京师范大学,2015.
DING Y Z. Research on the variation characteristics of water quality in Jiangsu Coastal waters[D]. Nanjing:Nanjing Normal University,2015.
[7] 江苏省统计局. 江苏省统计年鉴[M]. 南京:江苏省统计局,2023.
Jiangsu Provincial Bureau of Statistics. Jiangsu Statistical Yearbook[M]. Nanjing:Jiangsu Provincial Bureau of Statistics,2023.
[8] 涂春超. 江苏中部近岸海域表层沉积物重金属分布特征与污染评价[D]. 南京:南京师范大学,2018.
TU C C. Distribution characteristics and pollution assessment of heavy metals in surface sediments from the coastal waters in central Jiangsu Province[D]. Nanjing:Nanjing Normal University,2018.
[9] 郑江鹏,矫新明,方南娟,等. 江苏近岸海域沉积物重金属来源及风险评价[J]. 中国环境科学,2017,37(4):1514-1522.
ZHENG J P,JIAO X M,FANG N J,et al. Sources and risk assessment of heavy metals in sediments in Jiangsu coastal areas[J]. China Environmental Science,2017,37(4):1514-1522.
[10] 江苏省人民代表大会常务委员会. 江苏省生态环境保护条例[EB/OL].[2024-03-06]. https://www.jiangsu.gov.cn/art/2024/6/4/art_64752_11262865.html.
Standing Committee of the Jiangsu Provincial People's Congress. Regulations on ecological and environmental protection of Jiangsu Province [EB/OL].[2024-03-06]. https://www.jiangsu.gov.cn/art/2024/6/4/art_64752_11262865.html.
[11] 李纯毅,崔正国,白莹,等. 循环水养殖系统重金属的分布特征及鱼体风险评估[J]. 环境化学,2023,42(3):733-742. doi: 10.7524/j.issn.0254-6108.2022062104
LI C Y,CUI Z G,BAI Y,et al. Distribution characteristics of heavy metals in recirculating aquaculture system and risk assessment of fish[J]. Environmental Chemistry,2023,42(3):733-742. doi: 10.7524/j.issn.0254-6108.2022062104
[12] 中华人民共和国国家质量监督检验检疫总局,中国国家标准化管理委员会. GB 17378.3—2007,海洋监测规范[S]. 北京:中国标准出版社,2007.
General Administration of Quality Supervision,Inspection and Quarantine of the People's Republic of China,Standardization Administration of China. GB 17378.3—2007,Specification for Marine Monitoring[S]. Beijing:China Standards Press,2007.
[13] 中华人民共和国国家质量监督检验检疫总局,中国国家标准化管理委员会. GB 12763.8—2007,海洋调查规范[S] . 北京:中国标准出版社,2007.
General Administration of Quality Supervision,Inspection and Quarantine of the People's Republic of China,Standardization Administration of China. GB 12763.8—2007,Specifications for Oceanographic Survey [S]. Beijing:China Standards Press,2007.
[14] 连云港统计局. 连云港统计年鉴 [M]. 连云港:连云港统计局,2014-2021.
Lianyungang Provincial Bureau of Statistics. Lianyungang Statistical Yearbook[M].Lianyungang:Lianyungang Provincial Bureau of Statistics,2014-2021.
[15] TOMLINSON D L,WILSON J G,HARRIS C R,et al. Problems in the assessment of heavy-metal levels in estuaries and the formation of a pollution index[J]. Helgolä ander Meeresuntersuchungen,1980,33(1/2/3/4):566-575.
[16] 陆书玉. 环境影响评价[M]. 北京:高等教育出版社,2001.
LU S Y. Environmental Impact Assessment[M]. Beijing:Higher Education Press,2001.
[17] HAKANSON L. An ecological risk index for aquatic pollution control:a sediment-ological approach[J]. Water Research,1980,14(8):975-1001 doi: 10.1016/0043-1354(80)90143-8
[18] 陈邦本,胡蓉卿,陈铭达. 江苏海涂土壤环境元素的自然背景值[J]. 南京农业大学学报,1985,3:54-60. doi: 10.7685/j.issn.1000-2030.1985.01.009
CHEN B B,HU R J,CHEN M D,et al. The natural background-values of environmental elements in the beach soils of Jiangsu Province[J]. Journal of Nanjing Agricultural University,1985,3:54-60. doi: 10.7685/j.issn.1000-2030.1985.01.009
[19] 吕利云,董树刚,刘阳,等. 南黄海近岸海域表层沉积物重金属分布特征及污染评价[J]. 海洋湖沼通报,2013(4):101-110.
LYU L Y,DONG S G,LIU Y,et al. Distributions and pollution assessment of heavy metals in surface sediments in offshore area of South Yellow Sea[J]. Transactions of Oceanology and Limnology,2013(4):101-110.
[20] GHOLIZADEH M H,MELESSE A M,REDDI L. Water quality assessment and apportionment of pollution sources using APCS-MLR and PMF receptor modeling techniques in three major rivers of South Florida[J]. Science of the Total Environment,2016,566/567:1552-1567.
[21] CAI Y Q,MAO L J,DENG X Q,et al. Trace elements in surface sediments from Xinyanggang River of Jiangsu Province,China:spatial distribution,risk assessment and source appointment[J]. Marine Pollution Bulletin,2023,187:114550. doi: 10.1016/j.marpolbul.2022.114550
[22] PAATERO P ,TAPPER U. Positive matrix factorization:a non-negative factor model with optimal utilization of error estimates of data values[J]. Environmetrics,1994,5:111-126.
[23] PAATERO P. Least squares formulation of robust non-negative factor analysis[J]. Chemometrics and Intelligent Laboratory Systems. 1997,37(1):23-35.
[24] FOLK R L. A review of grain-size parameters[J]. Sedimentology. 2010,6:73-93.
[25] 梅西,李学杰,密蓓蓓,等. 中国海域表层沉积物分布规律及沉积分异模式[J]. 中国地质,2020,47(5):1447-1462.
MEI X,LI X J,MI B B,et al. Distribution regularity and sedimentary differentiation patterns of China seas surface sediments[J]. Geology in China,2020,47(5):1447-1462.
[26] 徐亚岩,柏育材,纪炜炜,等. 中国近海沉积物中重金属的变化特征和生态风险评估[J]. 海洋渔业,2019,41(6):712-724.
XU Y Y,BAI Y C,JI W W,et al. Variation characteristics and evaluation of potential ecological risk of heavy metals in sediments of the coastal waters of China[J]. Marine Fisheries,2019,41(6):712-724.
[27] 许艳,王秋璐,曾容,等. 渤海湾表层沉积物重金属污染状况及年际变化分析[J]. 中国环境科学,2022,42(9):4255-4263.
XU Y,WANG Q L,ZENG R,et al. Pollution status and annual variations of heavy metals in the surface sediments of Bohai Bay[J]. China Environmental Science,2022,42(9):4255-4263.
[28] 陶慧敏,张娟,张潇文,等. 2021年山东近岸海域沉积物重金属分布特征及生态风险评价[J]. 环境影响评价,2023,45(5):22-28.
TAO H M,ZHANG J,ZHANG X W,et al. Distribution characteristics and ecological risk assessment of heavy metals in sediments of Shandong coastal area in 2021[J]. Environmental Impact Assessment,2023,45(5):22-28.
[29] 王喻鸣,王玉琨,陈晓宏. 南海北部海域表层沉积物重金属含量分布及来源[J]. 中山大学学报(自然科学版),2022,61(1):139-150.
WANG Y M,WANG Y K,CHEN X H. Spatial patter and provenance of heavy metal elements in the surface sediments in the northern South China Sea shelf[J]. Acta Scientiarum Naturalium Universitatis Sunyatseni,2022,61(1):139-150.
[30] 杜吉净,毛龙江,谭志海,等. 海州湾岩芯沉积物重金属污染评价和来源分析[J]. 海洋环境科学,2016,35(6):814-821.
DU J J,MAO L J,TAN Z H,et al. Pollution evaluation and source identification of heavy metals in sediments from core in Haizhou Bay[J]. Marine Environmental Science,2016,35(6):814-821.
[31] 张建坤. 长江口及苏北沿岸重金属分布特征和生态风险评价[D]. 上海:上海海洋大学,2020.
ZHANG J K. Distribution characteristics and ecological risk assessment of heavy metals in the Yangtze River Estuary and the northern Jiangsu Coast[D]. Shanghai:Shanghai Ocean University,2020.
[32] WU Y L,WANG X H,YA M L,et al. Seasonal variation and spatial transport of polycyclic aromatic hydrocarbons in water of the subtropical Jiulong River watershed and estuary,Southeast China[J]. Chemosphere,2019,234:215-223. doi: 10.1016/j.chemosphere.2019.06.067
[33] 孟昆,徐敏,徐文健,等. 海州湾北部沉积物重金属来源解析及污染评价[J]. 南京师大学报(自然科学版),2018,41(2):99-106.
MENG K,XU M,XU W J,et al. Sources apportionment and pollution assessment of heavy metals in the sediments of the northern Haizhou Bay in China[J]. Journal of Nanjing Normal University (Natural Science Edition),2018,41(2):99-106.
[34] LIU L L,DONG C M,KONG M,et al. Insights into the long-term pollution trends and sources contributions in Lake Taihu,China using multi-statistic analyses models[J]. Chemosphere,2020,242:125272. doi: 10.1016/j.chemosphere.2019.125272
[35] 雷雁翔,张斌,吴治国,等. 长岛北部海域表层沉积物重金属分布特征与风险评价及来源分析[J]. 海洋地质前沿,2023,39(3):40-50.
LEI Y X,ZHANG B,WU ZG,et al. Spatial distribution of heavy metals in the surface sediments of Changdao Island and their sources and pollution assessment[J]. Marine Geology Frontiers,2023,39(3):40-50.
[36] 吕建树. 江苏典型海岸带土壤及沉积物重金属环境地球化学研究[D]. 南京:南京大学,2015.
LYU J S. The environmental geochemistry of heavy metals in soils and sediments in typical regions of Jiangsu coastal zone,Eastern China[D]. Nanjing:Nanjing University,2015.
[37] NASRIN Y A,BEHANM K. Geochemical characteristics,partitioning,quantitative source apportionment,and ecological and health risk of heavy metals in sediments and water:a case study in Shadegan Wetland,Iran. Marine Pollution Bulletin[J]. 2019,149:110495.
[38] YANG L X,CHENG S H,WANG X F,et al. Source identification and health impact of PM2.5 in a heavily polluted urban atmosphere in China[J]. Atmospheric Environment,2013,75:265-269 doi: 10.1016/j.atmosenv.2013.04.058
[39] 盐城统计局. 盐城统计年鉴 [M]. 盐城:盐城统计局,2014-2021.
Yancheng Provincial Bureau of Statistics. Yancheng Statistical Yearbook[M]. Yancheng:Yancheng Provincial Bureau of Statistics,2014-2021.
[40] 南通统计局. 南通统计年鉴 [M]. 南通:南通统计局,2014-2021.
Nantong Provincial Bureau of Statistics. Nantong Statistical Yearbook[M]. Nantong:Nantong Provincial Bureau of Statistics,2014-2021.
[41] SONG X J,HE X R,CHEN B L,et al. Variations and ecological risk assessments of heavy metals in surface sediments from Guan River Estuary[J]. Frontiers in Marine Science,2013,37(5):25-32.
[42] 鲁如坤,时正元,熊礼明. 我国磷矿磷肥中镉的含量及其对生态环境影响的评价[J]. 土壤学报,1992,29(2):150-157.
LU R K,SHI Z Y,XIONG L M. Cadmium contents of rock phosphates and phosphate fertilizers of China and their effects on the ecological environment[J]. Acta Pedologica Sinica,1992,29(2):150-157.
[43] 罗万次,苏搏,刘熊,等. 广西北仑河口红树林保护区表层海水溶解态重金属时空分布及其影响因素[J]. 海洋通报,2014,33(6):668-675.
LUO W C,SU B,LIU X,et al. Spatial and temporal distributions and influence factors of the dissolved heavy metals in surface water in the mangrove reserve at the Beilun River Estuary in Guangxi[J]. Marine Science Bulletin,2014,33(6):668-675.
[44] ANGINO E E,MAGNUSON L M,WAUGH L M,et al. Arsenic in detergents:possible danger and pollution hazard [J]. Science. 1970,168:389-390.
[45] GUO G H,LI K,ZHANG D G,et al. Quantitative source apportionment and associated driving factor identification for soil potential toxicity elements via combining receptor models,SOM,and geo-detector method[J]. Science of the Total Environment,2022,830:154721. doi: 10.1016/j.scitotenv.2022.154721
[46] 中国水产科学研究院(农业农村部渔业生态环境监测中心). 中国渔业生态环境状况公报[R]. 北京:农业部,环境保护部,2000-2015.
Chinese Academy of Fishery Sciences Fishery Eco-Environment Monitoring Center,MARA. Report on the State of the Fishery Eco-Environment in China[R]. Beijing:Ministry of Agriculture,Ministry of Environmental Protection,2000-2015.
-
