The earth pressure of retaining wall with cohesive fill based on principal stress rotation
-
摘要:
填土水平墙背竖直光滑的挡墙，墙后土体处于以自重应力和水平应力为主应力的应力状态。实际工程中，挡墙背面与土体存在一定的摩擦及黏结力作用致使挡墙附近土体中的主应力发生偏转，此时，经典朗肯土压力理论不再适用。本文对挡墙附近土中的主应力状态进行旋转处理，通过分析墙后填土中应力状态摩尔圆，得到了考虑墙土摩擦和黏结力作用的黏性填土挡墙主被动土压力计算公式，分析了填土内摩擦角与墙土摩擦角对土压力的影响，使用算例将本文方法所得结果与现有黏性土土压力计算方法所得结果进行了对比分析。结果表明，朗肯土压力公式是本文所得计算公式的特例；随着墙土摩擦角和内摩擦角的增加，被动土压力逐渐加快增大；主动土压力随着内摩擦角的增加而减小；当内摩擦角较小时，主动土压力随着墙土摩擦角的增大不断减小，当内摩擦角较大时，主动土压力随着墙土摩擦角的增大先减小后增大；土内摩擦角的影响大于墙土摩擦的影响；相对于现有方法计算结果，本文方法所得主动土压力较大，被动土压力较小，墙土摩擦越大，2种方法所得结果的差值越大，土黏聚力还会加大这一差值。本文方法考虑了墙背土体主应力方向偏转的客观事实，所得计算结果将更符合实际情况。
Abstract:The soil behind a wall is in a stress state with self-weight stress and horizontal stress as the main stress for the Rankine retaining wall with horizontal fill. However, there is a certain wall-soil friction and bonding force in practice. The friction and bonding force may cause the principal stress deflection in the fill near the retaining wall, and the classical Rankine earth pressure theory is not applicable for this case. In the current study, the principal stress deflection of the fill near the retaining wall is processed both by the rotation and by the analysis of the stress from the Mohr circle in the fill behind the wall. The active and passive earth pressures of the retaining wall filled with the cohesive soil is derived, considering the wall-soil friction and bonding force. The influences of the fill friction angle and the wall-soil friction angle on the earth pressures are analyzed. The examples are further used to compare the results from this study with those with the improved Coulomb method. The results show that the Rankine earth pressure is a special case of the formula presented in this study. With the increase of the wall-soil friction angle and internal friction angle, the passive earth pressures gradually increase. The active earth pressures decrease with the increase of the internal friction angle, and the decreasing rate gradually decreases. When the internal friction angle is small, the active earth pressures decrease continuously with the increase of the wall-soil friction angle, and the decreasing speed gradually decreases. When the internal friction angle is large, the active earth pressures first decrease and then increase with the increase of the wall-soil friction angle. The effect of the fill friction angle is more obvious than that of the wall-soil friction angle. Compared with the results from other methods, the active earth pressures obtained with this method are larger, but the passive earth pressure is smaller, and their differences increase with the increase in the wall-soil friction, especially when the cohesion is considered. Because the deflection of the principal stress in the soil on the back of the wall is more consistent with the actual situations, the results from this study will be more suitable to compute the earth pressure in practice.
-
-
表 1 主动土压力算例
Table 1. Example for the active earth pressure
δ/（°） c/kPa Ea/（kN·m−1） θa/（°） ωa/（°） 柯才桐法 卢廷浩法 朗肯理论解 本文解 0 0 392.21 392.21 392.21 392.21 0 0 0 10 273.08 273.08 273.08 273.08 0 0 5 10 250.02 250.02 252.87 3.69 8.64 5 15 197.58 197.58 201.64 3.69 11.09 10 15 178.11 178.11 193.87 7.64 22.35 10 20 131.16 131.16 151.77 7.64 28.33
下载: 导出CSV
表 2 被动土压力算例
Table 2. Example for the passive earth pressure
δ/（°） c/kPa Ep/（kN·m−1） θp/（°） ωp/（°） 胡晓军法 朗肯理论解 本文方法 0 0 1213.97 1213.97 1213.97 0 0 0 10 1442.48 1442.48 1442.48 0 0 5 5 1520.39 1502.71 9.88 5.37 5 10 1664.24 1644.58 9.88 5.67 5 15 1808.09 1786.50 9.88 5.92 5 20 1951.94 1928.44 9.88 6.14 10 5 1746.65 1665.38 20.26 10.66 10 10 1924.69 1833.87 20.26 11.19 10 15 2102.73 2002.48 20.26 11.64 10 20 2280.76 2171.20 20.26 12.01
下载: 导出CSV
-
[1] 顾慰慈. 挡土墙土压力计算手册[M]. 北京: 中国建材工业出版社, 2005.
GU Weici. Handbook of Earth Pressure Calculation for Retaining Wall[M]. Beijing: China Building Materials Industry Press, 2005. (in Chinese)
[2] 王世柱. 粘性土的等值内摩擦角及主动土压力的计算[J]. 地基基础工程,1997,7(3):19 − 23. [WANG Shizhu. On the equivalent internal angle of soil and active earth pressure[J]. Foundation Engineering,1997,7(3):19 − 23. (in Chinese with English abstract)
[3] 吴能森. 粘性土挡墙主动土压力计算研究[J]. 森林工程,2002,18(2):33 − 35. [WU Nengsen. Calculating method of active earth pressure of cohesive soil[J]. Forest Engineering,2002,18(2):33 − 35. (in Chinese with English abstract) doi: 10.3969/j.issn.1001-005X.2002.02.017
[4] 朱桐浩, 刘清瑞. 粘性土主动土压力计算[J]. 四川建筑科学研究,1979,5(5):46 − 54. [ZHU Tonghao, LIU Qingrui. Calculation of active earth pressure on cohesive soil[J]. Building Science Research of Sichuan,1979,5(5):46 − 54. (in Chinese)
[5] 赵恒惠. 挡土墙后粘性填土的土压力计算[J]. 岩土工程学报,1983,5(1):134 − 146. [ZHAO Henghui. The computation of earth pressure of cohesive backfill on retaining wall[J]. Chinese Journal of Geotechnical Engineering,1983,5(1):134 − 146. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-4548.1983.01.012
[6] 顾慰慈. 粘性土主动土压力的计算[J]. 水利学报,1991,22(1):55 − 64. [GU Weici. Calculation of active earth pressure in cohesive soil[J]. Journal of Hydraulic Engineering,1991,22(1):55 − 64. (in Chinese) doi: 10.3321/j.issn:0559-9350.1991.01.011
[7] 罗绍军. 挡土墙土压力计算公式及其运算程序[J]. 水文地质工程地质,1992,19(1):42 − 43. [LUO Shaojun. Soil pressure calculation formula and computing program of retaining wall[J]. Hydrogeology & Engineering Geology,1992,19(1):42 − 43. (in Chinese)
[8] 卢廷浩. 考虑粘聚力及墙背粘着力的主动土压力公式[J]. 岩土力学,2002,23(4):470 − 473. [LU Tinghao. A formula of active earth pressure including cohesion and adhesion[J]. Rock and Soil Mechanics,2002,23(4):470 − 473. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-7598.2002.04.016
[9] 李巨文, 王翀, 梁永朵, 等. 挡土墙后粘性填土的主动土压力计算[J]. 岩土工程学报,2006,28(5):650 − 652. [LI Juwen, WANG Chong, LIANG Yongduo, et al. Computation of earth pressure of cohesive backfill on retaining wall[J]. Chinese Journal of Geotechnical Engineering,2006,28(5):650 − 652. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-4548.2006.05.019
[10] 胡晓军. 粘性土主动土压力库仑精确解的改进[J]. 岩土工程学报,2006,28(8):1049 − 1052. [HU Xiaojun. Improvement on Coulumb accurate solution of active earth pressure to cohesive soil[J]. Chinese Journal of Geotechnical Engineering,2006,28(8):1049 − 1052. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-4548.2006.08.023
[11] 胡晓军, 谭晓慧. 黏性土被动土压力计算的库仑数值解[J]. 河海大学学报(自然科学版),2009,37(3):304 − 307. [HU Xiaojun, TAN Xiaohui. Coulomb numerical solution of passive earth pressure on cohesive soil[J]. Journal of Hohai University (Natural Sciences),2009,37(3):304 − 307. (in Chinese with English abstract)
[12] 彭明祥. 挡土墙主动土压力的库仑统一解[J]. 岩土力学,2009,30(2):379 − 386. [PENG Mingxiang. Coulumb's unified solution of active earth pressure on retaining wall[J]. Rock and Soil Mechanics,2009,30(2):379 − 386. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-7598.2009.02.016
[13] 彭明祥. 挡土墙主动土压力塑性临界深度的解析解[J]. 岩土力学,2010,31(10):3179 − 3183. [PENG Mingxiang. Analytical solution of plastic critical depth for active earth pressure on retaining wall[J]. Rock and Soil Mechanics,2010,31(10):3179 − 3183. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-7598.2010.10.024
[14] 杨敏, 刘斌, 周建武. 挡土墙主动和被动土压力的统一解[J]. 同济大学学报(自然科学版),2011,39(2):187 − 193. [YANG Min, LIU Bin, ZHOU Jianwu. Unified solution of active and passive earth pressure on retaining wall[J]. Journal of Tongji University (Natural Science),2011,39(2):187 − 193. (in Chinese with English abstract) doi: 10.3969/j.issn.0253-374x.2011.02.006
[15] 曹雄, 陈奕柏, 柯才桐. 刚性挡土墙后粘性土土压力研究[J]. 海南大学学报(自然科学版),2013,31(2):155 − 161. [CAO Xiong, CHEN Yibai, KE Caitong. Earth pressure of cohesive soil acting on rigid retaining wall[J]. Natural Science Journal of Hainan University,2013,31(2):155 − 161. (in Chinese with English abstract)
[16] 柯才桐, 陈奕柏, 高洪波, 等. 条形荷载不同分布模式下挡墙主动土压力研究[J]. 岩土工程学报,2013,35(10):1922 − 1927. [KE Caitong, CHEN Yibo, GAO Hongbo, et al. Active earth pressure on retaining wall under different distribution patterns of strip surcharge[J]. Chinese Journal of Geotechnical Engineering,2013,35(10):1922 − 1927. (in Chinese with English abstract)
[17] 柯才桐, 陈奕柏, 朱嘉. 挡土墙土压力线性分布解[J]. 岩石力学与工程学报,2014,33(增刊1):3312 − 3317. [KE Caitong, CHEN Yibo, ZHU Jia. A linear distribution solution of earth pressure on retaining wall[J]. Chinese Journal of Rock Mechanics and Engineering,2014,33(Sup1):3312 − 3317. (in Chinese with English abstract)
[18] 陈建功, 胡日成, 许明. 考虑合力作用点位置的主动土压力计算[J]. 工程力学,2016,33(11):132 − 139. [CHEN Jiangong, HU Richeng, XU Ming. Active earth pressure calculation considering force point location[J]. Engineering Mechanics,2016,33(11):132 − 139. (in Chinese with English abstract) doi: 10.6052/j.issn.1000-4750.2015.03.0246
[19] 陈建功, 周廷强, 胡日成. 柔性支护结构主动土压力的变分计算方法研究[J]. 岩土力学,2016,37(12):3365 − 3370. [CHEN Jiangong, ZHOU Tingqiang, HU Richeng. A variational method for calculating the active earth pressure on a flexible retaining wall[J]. Rock and Soil Mechanics,2016,37(12):3365 − 3370. (in Chinese with English abstract)
[20] LANCELLOTTA R. Analytical solution of passive earth pressure[J]. Géotechnique,2002,52(8):617 − 619.
[21] LANCELLOTTA R. Lower-bound approach for seismic passive earth resistance[J]. Géotechnique,2007,57(3):319 − 321.
-
