Seepage characteristics of accumulation landslides under different types of heavy rainfall stability analysis
-
摘要:
暴雨是堆积层滑坡灾害发生的主要诱因之一，暴雨作用下滑坡体渗流场的时空动态特征是评价滑坡稳定性和开展气象风险预警的关键。针对当前主要以降雨强度为变化参数的模拟分析工况存在的不足，以广东省特大型地质灾害——丰顺县三坑村滑坡群Ⅲ号滑坡为例，基于现场调查和资料分析，建立精细化滑坡地质结构模型，采用统计方法分析区内降雨特征，将暴雨划分为“均匀型”和“峰值型”两种类型，通过模拟滑坡体内浸润线及孔隙水压力的变化，分析滑坡在不同类型暴雨下的渗流场动态，进而分析滑坡的应力-应变场与位移特征，开展稳定性定量评价研究。研究结果表明：均匀型暴雨会显著影响滑坡深部渗流场，造成明显局部变形；峰值型暴雨诱发滑坡模式随雨量峰值位置的变化而有所差异，前锋型降雨诱发的变形表现出牵引式特点，随着雨量峰值后移，滑坡变形表现出推移式特点。数值模拟结果和滑坡实际变形较为吻合，研究成果可为堆积层滑坡的治理及防护工程的设计提供借鉴。
Abstract:Heavy rainfall is a major causes of sedimentary landslide disasters, and understanding the spatiotemporal dynamic characteristics of the seepage field in landslides under heavy rain is crucial for evaluating landslide stability and providing meteorological risk early warnings. Current simulations and analyses often focus primarily on rainfall intensity as the change parameter, which limits their effectiveness. This study takes the No. Ⅲ landslide of Sankeng Village Landslide Group in Fengshun County, a super-large geological disaster in Guangdong Province, as a case study. Based on the field investigation and data analysis, a refined landslide geological structure model was developed and statistical methods were used to analyze the rainfall characteristics in the area, classifying the rainfall into “uniform type” and “peak type”. The dynamics of the seepage field under these two types of rainstorms was analyzed by simulating changes in the infiltration line and pore water pressure within the landslide. The stress-strain field and displacement characteristics of the landslide were then examined, and stability was quantitatively evaluated. The results show that the uniform rainstorm will significantly affect the seepage field in the deep part of the landslide, resulting in noticeable local deformation. The landslide response to peak rainfall varies with the change of position, with forward rainfall causing traction-like deformation, while backward-moving peak rainfall induces a pushing deformation. The numerical simulation results align well with the observed deformation of the landslide. This study can provide basic information for the design of the treatment and protection engineering of the accumulation layer landslide.
-
-
表 1 岩土体物理参数
Table 1. Geotechnical physical parameters
物质 重度
/（kN·m−3）弹性模量/MPa 泊松比 天然状态 饱和状态 饱和渗透系数
/（m·s−1）饱和
含水率天然 饱和 c/kPa φ/（°） c/kPa φ/（°） 粉质黏土 18.6 5.7 4.89 0.23 22.6 18.2 21.8 16.9 3×10−9 0.35 砂质黏土 18.6 6.9 6.20 0.21 26.1 21.3 20.8 20.3 5×10−8 0.31 强风化花岗岩 19.4 20.0 20.0 0.18 21.7 22.4 18.4 21.7 3×10−10 0.22 基岩 21.3 1000.0 1000.0 0.10 1000.0 40.0 1000.0 40.0 0 0.00
下载: 导出CSV
表 2 数值模拟工况
Table 2. Cases in Numerical simulation
工况 降雨强度/（mm·d−1） 降雨时长/d 降雨类型 降雨总量/mm 工况一 240.0 3.0 均匀型 720 工况二 288.0 3.0 均匀型 864 工况三 354.0 3.0 均匀型 1062 工况四 165.9 6.4 均匀型 1062 工况五 55.9 19.0 均匀型 1062 工况六 405.0，354.0，303.0 3.0 前峰型 1062 工况七 328.5，405.0，328.5 3.0 中峰型 1062 工况八 303.0，354.0，405.0 3.0 后峰型 1062
下载: 导出CSV
-
[1] 自然资源部. 全国地质灾害通报[R]. 北京:中国地质环境监测院, 2023. [Ministry of Natural Resources,People’s Republic of China. China geological hazard bulletin[R]. Beijing:China Institute of Geological Environment Monitoring, 2023. (in Chinese)]
Ministry of Natural Resources, People’s Republic of China. China geological hazard bulletin[R]. Beijing: China Institute of Geological Environment Monitoring, 2023. （in Chinese）
[2] 李媛,孟晖,董颖,等. 中国地质灾害类型及其特征——基于全国县市地质灾害调查成果分析[J]. 中国地质灾害与防治学报,2004,15(2):29-34. [LI Yuan,MENG Hui,DONG Ying,et al. Main types and characterisitics of geo-hazard in China--Based on the results of geo-hazard survey in 290 counties[J]. The Chinese Journal of Geological Hazard and Control,2004,15(2):29-34. (in Chinese with English abstract)]
LI Yuan, MENG Hui, DONG Ying, et al. Main types and characterisitics of geo-hazard in China--Based on the results of geo-hazard survey in 290 counties[J]. The Chinese Journal of Geological Hazard and Control, 2004, 15（2）: 29-34. （in Chinese with English abstract）
[3] TSAI T L. The influence of rainstorm pattern on shallow landslide[J]. Environmental Geology,2008,53(7):1563 − 1569. doi: 10.1007/s00254-007-0767-x
[4] NG C W W,WANG B,TUNG Y K. Three-dimensional numerical investigations of groundwater responses in an unsaturated slope subjected to various rainfall patterns[J]. Canadian Geotechnical Journal,2011,38(5):1049 − 1062.
[5] 张石,郑东健,武鑫. 降雨类型对粉土边坡渗流及稳定性的影响[J]. 水力发电,2022,48(9):34 − 39. [ZHANG Shi,ZHENG Dongjian,WU Xin. Influence of rainfall types on seepage and stability of silt slope[J]. Water Power,2022,48(9):34 − 39. (in Chinese with English abstract)]
ZHANG Shi, ZHENG Dongjian, WU Xin. Influence of rainfall types on seepage and stability of silt slope[J]. Water Power, 2022, 48（9）: 34 − 39. （in Chinese with English abstract）
[6] 林鸿州,于玉贞,李广信,等. 降雨特性对土质边坡失稳的影响[J]. 岩石力学与工程学报,2009,28(1):198 − 204. [LIN Hongzhou,YU Yuzhen,LI Guangxin,et al. Influence of rainfall characteristics on soil slope failure[J]. Chinese Journal of Rock Mechanics and Engineering,2009,28(1):198 − 204. (in Chinese with English abstract)]
LIN Hongzhou, YU Yuzhen, LI Guangxin, et al. Influence of rainfall characteristics on soil slope failure[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28（1）: 198 − 204. （in Chinese with English abstract）
[7] 罗渝,何思明,何尽川. 降雨类型对浅层滑坡稳定性的影响[J]. 地球科学(中国地质大学学报),2014,39(9):1357 − 1363. [LUO Yu,HE Siming,HE Jinchuan. Effect of rainfall patterns on stability of shallow landslide[J]. Editorial Committee of Earth Science-Journal of China University of Geosciences,2014,39(9):1357 − 1363. (in Chinese with English abstract)]
LUO Yu, HE Siming, HE Jinchuan. Effect of rainfall patterns on stability of shallow landslide[J]. Editorial Committee of Earth Science-Journal of China University of Geosciences, 2014, 39（9）: 1357 − 1363. （in Chinese with English abstract）
[8] 李绍红,朱建东,王少阳,等. 考虑降雨类型的基岩型浅层边坡稳定性分析方法[J]. 水文地质工程地质,2018,45(2):131 − 135. [LI Shaohong,ZHU Jiandong,WANG Shaoyang,et al. Stability analysis methods for the bedrock shallow slope considering rainfall types[J]. Hydrogeology & Engineering Geology,2018,45(2):131 − 135. (in Chinese with English abstract)]
LI Shaohong, ZHU Jiandong, WANG Shaoyang, et al. Stability analysis methods for the bedrock shallow slope considering rainfall types[J]. Hydrogeology & Engineering Geology, 2018, 45（2）: 131 − 135. （in Chinese with English abstract）
[9] 郁舒阳,张继勋,任旭华,等. 降雨类型对浅层深层滑坡渗流及稳定性的影响[J]. 水电能源科学,2018,36(3):123 − 127. [YU Shuyang,ZHANG Jixun,REN Xuhua,et al. Influence of different rainfall patterns on seepage and stability of shallow and deep landslides[J]. Water Resources and Power,2018,36(3):123 − 127. (in Chinese with English abstract)]
YU Shuyang, ZHANG Jixun, REN Xuhua, et al. Influence of different rainfall patterns on seepage and stability of shallow and deep landslides[J]. Water Resources and Power, 2018, 36（3）: 123 − 127. （in Chinese with English abstract）
[10] 胡欣宇,赵少飞,邢明源,等. 不同降雨类型对非饱和土边坡安全系数的影响[J]. 华北科技学院学报,2021,18(5):61 − 66. [HU Xinyu,ZHAO Shaofei,XING Mingyuan,et al. The safety factors of unsaturated soil slopes under different rainfall types[J]. Journal of North China Institute of Science and Technology,2021,18(5):61 − 66. (in Chinese with English abstract)]
HU Xinyu, ZHAO Shaofei, XING Mingyuan, et al. The safety factors of unsaturated soil slopes under different rainfall types[J]. Journal of North China Institute of Science and Technology, 2021, 18（5）: 61 − 66. （in Chinese with English abstract）
[11] 唐栋,祁小辉,蒋水华,等. 不同前期降雨与土–水特征曲线对边坡稳定的影响[J]. 岩土工程学报,2015,37(增刊1):148 − 155. [TANG Dong,QI Xiaohui,JIANG Shuihua,et al. Effect of different antecedent rainfalls and SWCCs on slope stability[J]. Chinese Journal of Geotechnical Engineering,2015,37(Sup1):148 − 155. (in Chinese with English abstract)]
TANG Dong, QI Xiaohui, JIANG Shuihua, et al. Effect of different antecedent rainfalls and SWCCs on slope stability[J]. Chinese Journal of Geotechnical Engineering, 2015, 37（Sup1）: 148 − 155. （in Chinese with English abstract）
[12] PAONUZZI P,DEL FABBRO M,BOLLA A. Soil moisture profiles of unsaturated colluvial slopes susceptible to rainfall-induced landslides[J]. Geosciences,2021,12(1):6. doi: 10.3390/geosciences12010006
[13] 张维. 持时小雨诱发云南镇雄赵家沟高速远程滑坡机理研究[D]. 上海:上海交通大学,2017. [ZHANG Wei. Study on mechanism of high-speed and long run-out landslide induced by prolonged low-intensity rainfall in Zhaojiagou,Zhenxiong,Yunnan[D]. Shanghai:Shanghai Jiao Tong University,2017. (in Chinese with English abstract)]
ZHANG Wei. Study on mechanism of high-speed and long run-out landslide induced by prolonged low-intensity rainfall in Zhaojiagou, Zhenxiong, Yunnan[D]. Shanghai: Shanghai Jiao Tong University, 2017. （in Chinese with English abstract）
[14] 石振明,赵思奕,苏越. 降雨作用下堆积层滑坡的模型试验研究[J]. 水文地质工程地质,2016,43(4):135 − 140. [SHI Zhenming,ZHAO Siyi,SU Yue. An experimental study of the deposit slope failure caused by rainfall[J]. Hydrogeology & Engineering Geology,2016,43(4):135 − 140. (in Chinese with English abstract)]
SHI Zhenming, ZHAO Siyi, SU Yue. An experimental study of the deposit slope failure caused by rainfall[J]. Hydrogeology & Engineering Geology, 2016, 43（4）: 135 − 140. （in Chinese with English abstract）
[15] 徐永强,祁小博,张楠. 基于降雨与库水位耦合的三舟溪滑坡渗流模拟及稳定性分析[J]. 水文地质工程地质,2016,43(5):111 − 118. [XU Yongqiang,QI Xiaobo,ZHANG Nan. Numerical simulation and stability analysis for the seepage flow in the Sanzhouxi landslide under the associative action of reservoir water level fluctuations and rainfall infiltration[J]. Hydrogeology & Engineering Geology,2016,43(5):111 − 118. (in Chinese with English abstract)]
XU Yongqiang, QI Xiaobo, ZHANG Nan. Numerical simulation and stability analysis for the seepage flow in the Sanzhouxi landslide under the associative action of reservoir water level fluctuations and rainfall infiltration[J]. Hydrogeology & Engineering Geology, 2016, 43（5）: 111 − 118. （in Chinese with English abstract）
[16] YANG Weibin,WANG Fulei,TIE Yongbo,et al. Characteristics and dynamic process modeling of the rainfall-induced landslide on August 21,2020 in Hanyuan County,China[J]. Frontiers in Earth Science,2021,9:720872. doi: 10.3389/feart.2021.720872
[17] 孟生勇,江兴元,杨义,等. 降雨诱发堆积体滑坡水土响应与稳定性时空演化试验研究[J]. 水文地质工程地质,2023,50(1):104 − 112. [MENG Shengyong,JIANG Xingyuan,YANG Yi,et al. An experimental study of spatial-temporal evolution of water-soil response and stability of a rainfall-induced accumulation landslide[J]. Hydrogeology & Engineering Geology,2023,50(1):104 − 112. (in Chinese with English abstract)]
MENG Shengyong, JIANG Xingyuan, YANG Yi, et al. An experimental study of spatial-temporal evolution of water-soil response and stability of a rainfall-induced accumulation landslide[J]. Hydrogeology & Engineering Geology, 2023, 50（1）: 104 − 112. （in Chinese with English abstract）
[18] 冯文凯,胡芮,白慧林,等. 花岗岩残积层滑坡形成机理降雨模拟研究[J]. 科学技术与工程,2022,22(18):7799 − 7809. [FENG Wenkai,HU Rui,BAI Huilin,et al. Formation mechanism of rainfall residual layer of granite landslide[J]. Science Technology and Engineering,2022,22(18):7799 − 7809. (in Chinese with English abstract)]
FENG Wenkai, HU Rui, BAI Huilin, et al. Formation mechanism of rainfall residual layer of granite landslide[J]. Science Technology and Engineering, 2022, 22（18）: 7799 − 7809. （in Chinese with English abstract）
[19] 李思德,李远耀,殷坤龙,等. 基于物理模型试验的杆塔基础滑坡防护措施效果研究[J]. 地质科技通报,2022,41(2):209 − 218. [LI Side,LI Yuanyao,YIN Kunlong,et al. Study on the effect of tower foundation landslide protection measures based on a physical model test[J]. Bulletin of Geological Science and Technology,2022,41(2):209 − 218. (in Chinese with English abstract)]
LI Side, LI Yuanyao, YIN Kunlong, et al. Study on the effect of tower foundation landslide protection measures based on a physical model test[J]. Bulletin of Geological Science and Technology, 2022, 41（2）: 209 − 218. （in Chinese with English abstract）
[20] BAI Huilin,FENG Wenkai,LI Shuangquan,et al. Flow-slide characteristics and failure mechanism of shallow landslides in granite residual soil under heavy rainfall[J]. Journal of Mountain Science,2022,19(6):1541 − 1557. doi: 10.1007/s11629-022-7315-8
[21] 郑晓晶,殷坤龙. 基于非饱和渗流的水库库岸滑坡稳定性计算[J]. 水文地质工程地质,2007,34(2):29 − 32. [ZHENG Xiaojing,YIN Kunlong. Stability calculation of reservoir bank landslide based on unsaturated seepage flow[J]. Hydrogeology & Engineering Geology,2007,34(2):29 − 32. (in Chinese with English abstract)]
ZHENG Xiaojing, YIN Kunlong. Stability calculation of reservoir bank landslide based on unsaturated seepage flow[J]. Hydrogeology & Engineering Geology, 2007, 34（2）: 29 − 32. （in Chinese with English abstract）
[22] 刘礼领,殷坤龙. 暴雨型滑坡降水入渗机理分析[J]. 岩土力学,2008,29(4):1061 − 1066. [LIU Liling,YIN Kunlong. Analysis of rainfall infiltration mechanism of rainstorm landslide[J]. Rock and Soil Mechanics,2008,29(4):1061 − 1066. (in Chinese with English abstract)]
LIU Liling, YIN Kunlong. Analysis of rainfall infiltration mechanism of rainstorm landslide[J]. Rock and Soil Mechanics, 2008, 29（4）: 1061 − 1066. （in Chinese with English abstract）
[23] 颜斌,倪万魁,刘海松. 黄土边坡降水入渗规律及其稳定性研究[J]. 水文地质工程地质,2009,36(3):77 − 81. [YAN Bin,NI Wankui,LIU Haisong. Research on rainfall infiltration law and stability of loess slope[J]. Hydrogeology & Engineering Geology,2009,36(3):77 − 81. (in Chinese with English abstract)]
YAN Bin, NI Wankui, LIU Haisong. Research on rainfall infiltration law and stability of loess slope[J]. Hydrogeology & Engineering Geology, 2009, 36（3）: 77 − 81. （in Chinese with English abstract）
[24] 吴火珍,冯美果,焦玉勇,等. 降雨条件下堆积层滑坡体滑动机制分析[J]. 岩土力学,2010,31(增刊1):324 − 329. [WU Huozhen,FENG Meiguo,JIAO Yuyong,et al. Analysis of sliding mechanism of accumulation horizon landslide under rainfall condition[J]. Rock and Soil Mechanics,2010,31(Sup1):324 − 329. (in Chinese with English abstract)]
WU Huozhen, FENG Meiguo, JIAO Yuyong, et al. Analysis of sliding mechanism of accumulation horizon landslide under rainfall condition[J]. Rock and Soil Mechanics, 2010, 31（Sup1）: 324 − 329. （in Chinese with English abstract）
[25] SORBINO G,NICOTERA M V. Unsaturated soil mechanics in rainfall-induced flow landslides[J]. Engineering Geology,2013,165(2):105 − 132.
[26] CHO S E. Stability analysis of unsaturated soil slopes considering water-air flow caused by rainfall infiltration[J]. Engineering Geology,2016,211:184 − 197. doi: 10.1016/j.enggeo.2016.07.008
[27] 汪华斌,李建梅,金怡轩,等. 降雨诱发边坡破坏数值模拟两个关键问题的解决方法[J]. 岩土力学,2019,40(2):777 − 784. [WANG Huabin,LI Jianmei,JIN Yixuan,et al. The numerical methods for two key problems in rainfall-induced slope failure[J]. Rock and Soil Mechanics,2019,40(2):777 − 784. (in Chinese with English abstract)]
WANG Huabin, LI Jianmei, JIN Yixuan, et al. The numerical methods for two key problems in rainfall-induced slope failure[J]. Rock and Soil Mechanics, 2019, 40（2）: 777 − 784. （in Chinese with English abstract）
[28] 汤明高,吴川,吴辉隆,等. 水库滑坡地下水动态响应规律及浸润线计算模型——以石榴树包滑坡为例[J]. 水文地质工程地质,2022,49(2):115 − 125. [TANG Minggao,WU Chuan,WU Huilong,et al. Dynamic response and phreatic line calculation model of groundwater in a reservoir landslide:Exemplified by the Shiliushubao landslide[J]. Hydrogeology & Engineering Geology,2022,49(2):115 − 125. (in Chinese with English abstract)]
TANG Minggao, WU Chuan, WU Huilong, et al. Dynamic response and phreatic line calculation model of groundwater in a reservoir landslide: Exemplified by the Shiliushubao landslide[J]. Hydrogeology & Engineering Geology, 2022, 49（2）: 115 − 125. （in Chinese with English abstract）
[29] 南赟,翟淑花,李岩,等. 北京地区“23•7”特大暴雨型地质灾害特征及预警成效分析[J]. 中国地质灾害与防治学报,2024,35(2):66 − 73. [NAN Yun,ZHAI Shuhua,LI Yan,et al. Analysis on the characteristics of geological disasters and effectiveness of early warning duiring heavy rainfall on “23•7” in Beijing[J]. The Chinese Journal of Geological Hazard and Control,2024,35(2):66 − 73. (in Chinese with English abstract)]
NAN Yun, ZHAI Shuhua, LI Yan, et al. Analysis on the characteristics of geological disasters and effectiveness of early warning duiring heavy rainfall on “23•7” in Beijing[J]. The Chinese Journal of Geological Hazard and Control, 2024, 35（2）: 66 − 73. （in Chinese with English abstract）
[30] 杨帆,周悦,罗岚扬,等. 广东省降雨时空分布特征分析[J]. 中国防汛抗旱,2023,33(11):46 − 51. [YANG Fan,ZHOU Yue,LUO Lanyang,et al. Analysis of spatiotemporal distribution characteristics of rainfall in Guangdong Province[J]. China Flood & Drought Management,2023,33(11):46 − 51. (in Chinese with English abstract)]
YANG Fan, ZHOU Yue, LUO Lanyang, et al. Analysis of spatiotemporal distribution characteristics of rainfall in Guangdong Province[J]. China Flood & Drought Management, 2023, 33（11）: 46 − 51. （in Chinese with English abstract）
-
