Instability mechanism of massive oblique bedding rock landslide in the Three-Gorges Reservoir: A case study of the Longjing landslide in Shizhu County of Chongqing City
-
摘要:
长江三峡库区位于我国地形第二、三级阶梯过渡地带，地质环境复杂，斜倾顺层基岩滑坡较为发育。本文以重庆石柱龙井滑坡为例，详细分析了大型斜倾顺层基岩滑坡的变形特征、成因机理和破坏模式、并采用极限平衡法计算了滑坡在四种工况条件下的稳定性。结果表明：（1）龙井滑坡位于扬子准地台石柱向斜北西翼，体积约1.42×106 m3，主滑方向162°，前缘发育两个次级滑坡；（2）受地形地貌、地层构造、地下水和降雨等因素影响，滑坡目前处于蠕滑变形阶段，变形方式主要为拉张裂缝、剪切裂缝和局部鼓胀变形；（3）滑坡同时处于暴雨和前缘次级滑坡滑动条件下，稳定性为1.03，处于欠稳定状态，滑坡易沿软弱夹层发生整体滑动破坏。
Abstract:The Three Gorges Reservoir is located in the transition zone of the second and third terrains in China. Taking the Longjing landslide in Chongqing as an example, this paper analyzes in detail the deformation characteristics, formation mechanism and failure pattern of the oblique bedding slope, and calculates the stability of the slope under four working conditions by using the limit equilibrium method. The results show that: (1) Longjing landslide is located in the northwest wing of the syncline of the stone pillar of the Yangtze platform, with a volume of 142.83×104 m3 and the main sliding direction of 162°. (2) Under the influence of topographical features, stratigraphic structure, groundwater, rainfall and other factors, the slope is currently in the stage of creep deformation. The deformation pattern are mainly tensile fractures, shear fractures and local bulging deformation. (3) The slope is under the sliding conditions of rainstorm and leading secondary landslide at the same time, and its stability factor is 1.03, so it is in an under-stable state. The slope is prone to overall sliding failure along the weak intercalated layer.
-
-
表 1 滑体物理力学参数表
Table 1. Physical and mechanical parameters of the sliding body
滑体岩性 天然重度
/(kN·m−3)饱和重度
/(kN·m−3)天然 饱和 c/kPa φ/（°） c/kPa φ/（°） 粉质粘土
夹碎石20.10 20.40 16.60 22.69 14.30 19.94 砂土 17.50 17.80 11.70 27.76 9.50 22.80 泥岩 25.20 25.30 800 34.35 500 33.17 砂岩 24.60 24.70 790 36.62 550 35.39
下载: 导出CSV
表 2 滑带物理力学参数
Table 2. Physical and mechanical parameters of rockmass at the sliding zone
滑带岩性 天然（峰值） 饱和（峰值） 饱和（残余值） c/kPa φ/（°） c/kPa φ/（°） c/kPa φ/（°） 泥化软弱夹层 15.90 10.60 13.50 8.86 11.10 6.36
下载: 导出CSV
表 3 稳定性系数计算成果表
Table 3. Calculation results of FOS
工况 滑面
型态剪出口
位置剩余
下滑力
/（kN·m−1）稳定性
系数稳定
状态工况1 折线 悦黄公路内侧 1035.30 1.20 基本稳定 工况2 1765.97 1.13 基本稳定 工况3 1328.89 1.16 基本稳定 工况4 2317.68 1.03 欠稳定
下载: 导出CSV
-
[1] 余飞, 陈善雄, 余和平. 顺层岩质边坡渐进破坏及失稳机理的数值模拟研究[J]. 岩土力学,2005,26(增刊 2):36 − 40. [YU Fei, CHEN Shanxiong, YU Heping. Numerical simulation study on progressive destruction and failure mechanism of bedding rock slopes[J]. Rock and Soil Mechanics,2005,26(Sup 2):36 − 40. (in Chinese with English abstract)
[2] 白云峰, 周德培, 王科, 等. 顺层滑坡的发育环境及分布特征[J]. 自然灾害学报,2004,13(3):39 − 43. [BAI Yunfeng, ZHOU Depei, WANG Ke, et al. Development environment and distribution characteristics of bedding plane landslides[J]. Journal of Natural Disasters,2004,13(3):39 − 43. (in Chinese with English abstract) doi: 10.3969/j.issn.1004-4574.2004.03.008
[3] 长江水利委员会. 三峡工程地质研究[M]. 武汉: 湖北科学技术出版社, 1997.
Changjiang Water Resources Commission. Engineering geology study in the Three Gorges Reservoir area[M]. Wuhan: Hubei Science & Technology Press, 1997.(in Chinese)
[4] 殷跃平. 长江三峡库区移民迁建新址重大地质灾害及防治研究[M].北京: 地质出版社, 2004: 31.
YIN Yue ping. Major geologic hazards and the prevention on relocation sites of the Three Gorges Reservoir, the Yangtze River[M]. Beijing: Geological Publishing House, 2004: 31. (in Chinese)
[5] 廖秋林, 李晓, 李守定, 等. 三峡库区千将坪滑坡的发生、地质地貌特征、成因及滑坡判据研究[J]. 岩石力学与工程学报,2005,24(17):3146 − 3153. [LIAO Qiulin, LI Xiao, LI Shouding, et al. Occurrence, geology and geomorphy characteristics and origin of qianjiangping landslide in Three Gorges reservoir area and study on ancient landslide criterion[J]. Chinese Journal of Rock Mechanics and Engineering,2005,24(17):3146 − 3153. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-6915.2005.17.023
[6] YIN Y P, SUN P, ZHANG M, et al. Mechanism on apparent dip sliding of oblique inclined bedding rockslide at Jiweishan, Chongqing, China[J]. Landslides,2011,8(1):49 − 65. doi: 10.1007/s10346-010-0237-5
[7] 许强, 黄润秋, 殷跃平, 等. 2009年6·5重庆武隆鸡尾山崩滑灾害基本特征与成因机理初步研究[J]. 工程地质学报,2009,17(4):433 − 444. [XU Qiang, HUANG Runqiu, YIN Yueping, et al. The Jiweishan landslide of June 5, 2009 in Wulong, Chongqing: characteristics and failure mechanism[J]. Journal of Engineering Geology,2009,17(4):433 − 444. (in Chinese with English abstract) doi: 10.3969/j.issn.1004-9665.2009.04.001
[8] 朱赛楠, 李滨, 冯振. 乌江流域含炭质钙质页岩三轴流变力学特性分析[J]. 中国地质灾害与防治学报,2015,26(4):144 − 151. [ZHU Sainan, LI Bin, FENG Zhen. Analysis of triaxial rheological mechanical properties of carbonaceous and calcareous shale in Wujiang river basin[J]. The Chinese Journal of Geological Hazard and Control,2015,26(4):144 − 151. (in Chinese with English abstract)
[9] 朱赛楠, 殷跃平, 李滨. 二叠系炭质页岩软弱夹层剪切蠕变特性研究[J]. 岩土力学,2019,40(4):1377 − 1386. [ZHU Sainan, YIN Yueping, LI Bin. Shear creep behavior of soft interlayer in Permian carbonaceous shale[J]. Rock and Soil Mechanics,2019,40(4):1377 − 1386. (in Chinese with English abstract)
[10] 谢定义, 巫志辉, 郭耀堂. 极限平衡理论在饱和砂土动力失稳过程分析中的应用[J]. 土木工程学报,1981,14(4):17 − 28. [XIE Dingyi, WU Zhihui, GUO Yaotang. Application of limit equilibrium theory to the analysis of dynamic failure process of saturated sand[J]. China Civil Engineering Journal,1981,14(4):17 − 28. (in Chinese with English abstract)
[11] 陈全明, 方琼, 罗冠枝, 等. 缓倾顺层岩质斜坡破坏条件和变形机制分析: 以常吉高速公路朱雀洞滑坡为例[J]. 中国地质灾害与防治学报,2020,31(2):18 − 23. [CHEN Quanming, FANG Qiong, LUO Guanzhi, et al. Failure conditions and mechanism of the gentle dip bedding slopes: A case study of the Zhuquedong landslide[J]. The Chinese Journal of Geological Hazard and Control,2020,31(2):18 − 23. (in Chinese with English abstract)
[12] 喻永祥, 何伟, 李勇, 等. 雪浪山横山寺西侧顺层岩质高边坡变形破坏机理与治理方案分析[J]. 中国地质灾害与防治学报,2020,31(2):33 − 43. [YU Yongxiang, HE Wei, LI Yong, et al. Stability evaluation and treatment measure study of high bedding rock slope on the west side of Hengshan temple in Xuelang mountain[J]. The Chinese Journal of Geological Hazard and Control,2020,31(2):33 − 43. (in Chinese with English abstract)
[13] FREDLUND D G, KRAHN J, PUFAHL D E. The relationship of limit equilibrium slope stability method[C]// In: Proc. the 10th Int. Conf. Soil Mech. Found. Eng. Stockholm, Sweden: [s. n.], 1981: 409-416.
[14] 邹广电, 蒋婉莹. 边坡稳定性分析的一个改建条分法[J]. 岩石力学与工程学报,2003,22(12):1953 − 1959. [ZOU Guangdian, JIANG Wanying. Rebuilt slice method for slope stability analysis[J]. Chinese Journal of Rock Mechanics and Engineering,2003,22(12):1953 − 1959. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-6915.2003.12.002
[15] 曾亚武, 田伟明. 边坡稳定性分析的有限元法与极限平衡法的结合[J]. 岩石力学与工程学报,2005,24(增刊2):5355 − 5359. [ZENG Yawu, TIAN Weiming. Slope stability analysis by combining fem with limit equilibrium method[J]. Chinese Journal of Rock Mechanics and Engineering,2005,24(Sup2):5355 − 5359. (in Chinese with English abstract)
[16] 殷跃平. 斜倾厚层山体滑坡视向滑动机制研究: 以重庆武隆鸡尾山滑坡为例[J]. 岩石力学与工程学报,2010,29(2):217 − 226. [YIN Yueping. Mechanism of apparent dip slide of inclined bedding rockslide:A case study of Jiweishan rockslide in Wulong, Chongqing[J]. Chinese Journal of Rock Mechanics and Engineering,2010,29(2):217 − 226. (in Chinese with English abstract)
[17] 朱赛楠. 厚层基岩滑坡软弱夹层演化过程及控滑机理研究[D]. 西安: 长安大学, 2016.
ZHU Sainan. Research on evolution process and controlling mechanism of weak layer from thick layered bedrock landslide[D]. Xi'an: Changan University, 2016. (in Chinese with English abstract)
[18] YIN Yueping, LI Bin, WANG Wenpei, et al. Mechanism of the December 2015 catastrophic landslide at the Shenzhen landfill and controlling geotechnical risks of urbanization[J]. Engineering,2016,2(2):230 − 249. doi: 10.1016/J.ENG.2016.02.005
[19] 李守定, 李晓, 吴疆, 等. 大型基岩顺层滑坡滑带形成演化过程与模式[J]. 岩石力学与工程学报,2007,26(12):2473 − 2480. [LI Shouding, LI Xiao, WU Jiang, et al. Evolution process and pattern of sliding zone in large consequent bedding rock landslide[J]. Chinese Journal of Rock Mechanics and Engineering,2007,26(12):2473 − 2480. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-6915.2007.12.012
[20] 邹宗兴, 唐辉明, 熊承仁, 等. 大型顺层岩质滑坡渐进破坏地质力学模型与稳定性分析[J]. 岩石力学与工程学报,2012,31(11):2222 − 2231. [ZOU Zongxing, TANG Huiming, XIONG Chengren, et al. Geomechanical model of progressive failure for large consequent bedding rockslide and its stability analysis[J]. Chinese Journal of Rock Mechanics and Engineering,2012,31(11):2222 − 2231. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-6915.2012.11.010
[21] 殷跃平, 胡时友, 石胜伟. 滑坡防治技术指南[M]. 北京: 地质出版社, 2018.
YIN Yueping, HU Shiyou, SHI Shengwei. Technical guidelines for landslide control[M]. Beijing: Geological Publishing House, 2018.(in Chinese)
[22] 黄盛锋, 陈志波, 郑道哲. 基于灰色关联度法和强度折减法的边坡稳定性影响因素敏感性分析[J]. 中国地质灾害与防治学报,2020,31(3):35 − 40. [HUANG Shengfeng, CHEN Zhibo, ZHENG Daozhe. Sensitivity analysis of factors influencing slope stability based on grey correlation and strength reduction method[J]. The Chinese Journal of Geological Hazard and Control,2020,31(3):35 − 40. (in Chinese with English abstract)
[23] 何阳, 徐定芳. 基于强度折减法的边坡安全预警及失稳判据研究[J]. 华南地质与矿产,2019,35(3):343 − 347. [HE Yang, XU Dingfang. Research on security warning and instability criterion of slope based on strength reduction method[J]. Geology and Mineral Resources of South China,2019,35(3):343 − 347. (in Chinese with English abstract)
[24] 武亚遵, 田方正, 林云, 等. 基于强度折减法的软弱泥岩隧道围岩稳定性分析[J]. 中国地质灾害与防治学报,2018,29(5):65 − 71. [WU Yazun, TIAN Fangzheng, LIN Yun, et al. Analysis on the tunnel surrounding rock stability of weak mudstone based on strength reduction method[J]. The Chinese Journal of Geological Hazard and Control,2018,29(5):65 − 71. (in Chinese with English abstract)
-
