Study on the effect of fissures in expansive soils on permeability and engineering effects of canal slopes
-
摘要:
膨胀土是一种特殊的非饱和土，也是南水北调中线渠首段土体的主要成分。与一般黏性土相比，膨胀土具有裂隙性，裂隙的存在会对其渗透性产生影响，进而影响到膨胀土渠坡的实际排水效果。为了探究膨胀土渗透性与其裂隙和含水量之间的关系，采用自制的渗流装置对相关地区的非饱和膨胀土进行渗流试验。试验结果表明，不同初始条件的土样在饱和环境中渗流时其渗透系数都会随着渗流的进行而逐渐减小。在同等初始含水率情况下，土样的裂隙率越大，渗透系数越大，渗透系数到达稳定状态所需的时间就越长；在相同初始裂隙率情况下，初始含水率低的土样，渗透性小但基质吸力大，吸水后会迅速膨胀导致渗透性越来越差。通过分析土体从不同初始条件开始渗流至饱和状态期间土体渗透系数的变化过程，可以发现在渗流开始的2 h以内，渠坡排水设施的排水效果最好，在8 h内渠坡排水设施都具有一定效果，超过8 h后排水效果有限。
Abstract:Expansive soils represent a special type of unsaturated soil and constitute a major component of the soil structure in the initial canal section of the middle route of the South-to-North Water Transfer Project(MR-SNWTP). Compared to typical cohesive soils, expansive soils exhibit fissures that can impact their permeability, subsequently influencing the drainage efficiency of expansive soil slopes. To investigate the relationship between permeability of expansive soils, fissures, and moisture content, percolation tests were carried out on unsaturated expansive soils in the relevant region using a self-made permeability apparatus. The experimental results indicate that the permeability coefficient of soil samples with different initial conditions decreases gradually during percolation in a saturated environment. At the same initial water content, the greater the fracture ratios of the soil sample, the greater the permeability coefficient and the longer it takes for the permeability coefficient to reach a steady state. Under equal initial moisture content, greater fissure rates of soil samples result in higher permeability coefficients, and the time required for the permeability coefficient to stabilize increases. Under the same initial fissure rate, soil samples with lower initial moisture content exhibit lower permeability but higher matric suction; however, rapid expansion due to water absorption leads deteriorating permeability. By analyzing the changes in soil permeability coefficients during the transition from different initial conditions to a saturated state, it is observed that the drainage effectiveness of canal slope drainage facilities is most significant within 2 hours of the start of the seepage, remains noticeable within 8 hours, and becomes limited after 8 hours.
-
Key words:
- geological engineering /
- expansive soil /
- seepage test /
- fissure ratios /
- drainage effectiveness
-
-
表 1 试样基本参数指标
Table 1. Fundamental parameters of test samples
编号 含水率/% 重度/（kN·m−3） 黏聚力/kPa 内摩擦角/（°） 1 12.4 19.1 14.0 11.0 2 10.1 22.1 20.0 14.0 3 25.4 19.7 24.0 16.0 4 29.1 19.9 61.3 22.8 5 28.2 20.3 72.5 25.0
下载: 导出CSV
表 2 不同工况试验参数表
Table 2. Experimental parameters for different working conditions
试样 初始裂隙率/% 初始含水率/% 工况1 14.0 5 工况2 11.5 10 工况3 9.0 15 工况4 6.5 20 工况5 4.0 25
下载: 导出CSV
-
[1] 宋博. 排水设施对膨胀土渠坡渗流场变化影响研究[D]. 徐州:中国矿业大学,2022. [SONG Bo. Study on the influence of drainage facilities on the seepage field change of expansive soil channel slope[D]. Xuzhou:China University of Mining and Technology,2022. (in Chinese with English abstract)]
SONG Bo. Study on the influence of drainage facilities on the seepage field change of expansive soil channel slope[D]. Xuzhou: China University of Mining and Technology, 2022. （in Chinese with English abstract）
[2] 李斌,郝继锋,鞠远江,等. 渠坡非饱和膨胀土含水率与强度关系试验研究[J]. 水文地质工程地质,2022,49(5):129 − 136. [LI Bin,HAO Jifeng,JU Yuanjiang,et al. Experimental study on the relationship between water content and strength of unsaturated expansive soil on canal slope[J]. Hydrogeology & Engineering Geology,2022,49(5):129 − 136. (in Chinese with Englishabstract)]
LI Bin, HAO Jifeng, JU Yuanjiang, et al. Experimental study on the relationship between water content and strength of unsaturated expansive soil on canal slope[J]. Hydrogeology & Engineering Geology, 2022, 49（5）: 129 − 136. （in Chinese with Englishabstract）
[3] 蒙学礼,蒙发强,李涣森,等. 裂隙岩体非线性渗流特性分析[J]. 中国地质灾害与防治学报,2020,31(4):121 − 125. [MENG Xueli,MENG Faqiang,LI Huansen,et al. Analysis of nonlinear seepage characteristics of fractured rock mass[J]. The Chinese Journal of Geological Hazard and Control,2020,31(4):121 − 125. (in Chinese with English abstract)] doi: 10.16031/j.cnki.issn.1003-8035.2020.04.16
MENG Xueli, MENG Faqiang, LI Huansen, et al. Analysis of nonlinear seepage characteristics of fractured rock mass[J]. The Chinese Journal of Geological Hazard and Control, 2020, 31（4）: 121 − 125. （in Chinese with English abstract） doi: 10.16031/j.cnki.issn.1003-8035.2020.04.16
[4] 雷怡,帅飞翔,孙红月,等. 边坡负压排水非稳定流研究 [J]. 吉林大学学报(地球科学版), 2022, 52 (1): 162-170. [LEI Yi, SHUAI Feixiang, SUN Hongyue, et al. Research on unsteady flow in slope drainage under negative pressure [J]. Journal of Jilin University (Earth Science Edition), 2022, 52 (1): 162-170.(in Chinese with English abstract).]
LEI Yi, SHUAI Feixiang, SUN Hongyue, et al. Research on unsteady flow in slope drainage under negative pressure [J]. Journal of Jilin University (Earth Science Edition), 2022, 52 (1): 162－170.（in Chinese with English abstract）.
[5] RICHARDS L A. Capillary conduction of liquids through porous mediums[J]. Physics,1931,1(5):318 − 333. doi: 10.1063/1.1745010
[6] 师文豪,杨天鸿. 渗流应力耦合作用下顺倾向层状边坡各向异性渗流特征数值模拟 [J]. 吉林大学学报(地球科学版), 2021, 51 (6): 1783-1788. [SHI Wenhao, YANG Tianhong. Numerical simulation of anisotropic seepage characteristics of layered slope in the direction of inclination under coupled action of seepage stress[J]. Journal of Jilin University (Earth Sciences), 2021, 51 (6): 1783-1788.(in Chinese with English abstract).]
SHI Wenhao, YANG Tianhong. Numerical simulation of anisotropic seepage characteristics of layered slope in the direction of inclination under coupled action of seepage stress[J]. Journal of Jilin University (Earth Sciences), 2021, 51 (6): 1783－1788.（in Chinese with English abstract）.
[7] FIPPS G,SKAGGS R W,NIEBER J L. Drains as a boundary condition in finite elements[J]. Water Resources Research,1986,22(11):1613 − 1621. doi: 10.1029/WR022i011p01613
[8] ZIENKIEWICZ O C,CHEUNG Y K. Finite Element in Solution of Field Problems[J]. Water Resources Reseach,1965,14(2):220 − 225.
[9] SZABO B A,MCCAIG I W. A mathematical model for transient free surface flow in nonhomogeneous or anisotropic porous media[J]. Journal of the American Water Resources Association,1968,4(3):5 − 18. doi: 10.1111/j.1752-1688.1968.tb05759.x
[10] NEUMAN C P,CASASAYAS F G. Galerkin solutions of stiff two-point boundary-value problems[J]. Journal of Optimization Theory and Applications,1973,11(2):203 − 212. doi: 10.1007/BF00935884
[11] FREDLUND D G. An overview of unsaturated soil behavior. Proceedings of sessions of Dallas[J]. Water Resources Reseach,1993,4(3):24 − 28.
[12] THAKUR V K S,SREEDEEP S,SINGH D N. Parameters affecting soil–water characteristic curves of fine-grained soils[J]. Journal of Geotechnical and Geoenvironmental Engineering,2005,131(4):521 − 524. doi: 10.1061/(ASCE)1090-0241(2005)131:4(521)
[13] AL-MAHBASHI A M,ELKADY T Y,AL-SHAMRANI M A. Hysteresis soil-water characteristic curves of highly expansive clay[J]. European Journal of Environmental and Civil Engineering,2018,22(9):1041 − 1059. doi: 10.1080/19648189.2016.1229232
[14] SILLERS W S,FREDLUND D G,ZAKERZAHEH N. Mathematical attributes of some soil-water characteristic curve models[J]. Geotechnical & Geological Engineering,2001,19(3):243 − 283.
[15] SILLERS W S,FREDLUND D G. Statistical assessment of soil-water characteristic curve models for geotechnical engineering[J]. Canadian Geotechnical Journal,2001,38(6):1297 − 1313. doi: 10.1139/t01-066
[16] 李萍,李同录,王红,等. 非饱和黄土土-水特征曲线与渗透系数Childs & Collis-Geroge模型预测[J]. 岩土力学,2013,34(增刊2):184 − 189. [LI Ping,LI Tonglu,WANG Hong,et al. Soil-water characteristic curve and permeability perdiction on Childs & Collis-Geroge model of unsaturated loess[J]. Rock and Soil Mechanics,2013,34(Sup 2):184 − 189. (in Chinese with English abstract)]
LI Ping, LI Tonglu, WANG Hong, et al. Soil-water characteristic curve and permeability perdiction on Childs & Collis-Geroge model of unsaturated loess[J]. Rock and Soil Mechanics, 2013, 34（Sup 2）: 184 − 189. （in Chinese with English abstract）
[17] 张琦,杨忠年,时伟,等. 冻融循环下初始含水率对非饱和膨胀土剪切特性试验[J]. 吉林大学学报(地球科学版),2021,51(5):1544 − 1550. [ZHANG Qi, YANG Zhongnian, SHI Wei, et al. Shear characteristics test of unsaturated swelling clay under freeze-thaw cycles with different initial water content[J]. Journal of Jilin University (Earth Sciences),2021,51(5):1544 − 1550. (in Chinese with English abstract)]
ZHANG Qi, YANG Zhongnian, SHI Wei, et al. Shear characteristics test of unsaturated swelling clay under freeze-thaw cycles with different initial water content［J］. Journal of Jilin University （Earth Sciences）, 2021, 51（5）: 1544 − 1550. （in Chinese with English abstract）
[18] 李志清,李涛,胡瑞林,等. 非饱和土土水特征曲线(SWCC)测试与预测[J]. 工程地质学报,2007,15(5):700 − 707. [LI Zhiqing,LI Tao,HU Ruilin,et al. Methods for testing and predicting of swcc in unsaturated soil mechanics[J]. Journal of Engineering Geology,2007,15(5):700 − 707. (in Chinese with English abstract)] doi: 10.3969/j.issn.1004-9665.2007.05.020
LI Zhiqing, LI Tao, HU Ruilin, et al. Methods for testing and predicting of swcc in unsaturated soil mechanics[J]. Journal of Engineering Geology, 2007, 15（5）: 700 − 707. （in Chinese with English abstract） doi: 10.3969/j.issn.1004-9665.2007.05.020
[19] 马洪波,师占宾,孙文. 由土—水特征曲线预测非饱和混合填料渗透系数[J]. 中国建材科技,2018,27(1):74 − 77. [MA Hongbo,SHI Zhanbin,SUN Wen. Predicting coefficient of permeability from soil-water characteristic curve for Unsaturated mixed packing[J]. China Building Materials Science & Technology,2018,27(1):74 − 77. (in Chinese with English abstract)]
MA Hongbo, SHI Zhanbin, SUN Wen. Predicting coefficient of permeability from soil-water characteristic curve for Unsaturated mixed packing[J]. China Building Materials Science & Technology, 2018, 27（1）: 74 − 77. （in Chinese with English abstract）
[20] 袁俊平,殷宗泽. 考虑裂隙非饱和膨胀土边坡入渗模型与数值模拟[J]. 岩土力学,2004,25(10):1581 − 1586. [YUAN Junping,YIN Zongze. Numerical model and simulation of expansive soils slope infiltration considered fissures[J]. Rock and Soil Mechanics,2004,25(10):1581 − 1586. (in Chinese with English abstract)] doi: 10.3969/j.issn.1000-7598.2004.10.014
YUAN Junping, YIN Zongze. Numerical model and simulation of expansive soils slope infiltration considered fissures[J]. Rock and Soil Mechanics, 2004, 25（10）: 1581 − 1586. （in Chinese with English abstract） doi: 10.3969/j.issn.1000-7598.2004.10.014
[21] 陈铁林,邓刚,陈生水,等. 裂隙对非饱和土边坡稳定性的影响[J]. 岩土工程学报,2006,28(2):210 − 215. [CHEN Tielin,DENG Gang,CHEN Shengshui,et al. Effects of fissures on stability of unsaturated soil slope[J]. Chinese Journal of Geotechnical Engineering,2006,28(2):210 − 215. (in Chinese with English abstract)]
CHEN Tielin, DENG Gang, CHEN Shengshui, et al. Effects of fissures on stability of unsaturated soil slope[J]. Chinese Journal of Geotechnical Engineering, 2006, 28（2）: 210 − 215. （in Chinese with English abstract）
[22] 吕建航,杨忠年,时伟,等. 冻融循环下加筋膨胀土边坡稳定性模型试验 [J]. 吉林大学学报(地球科学版), 2021, 51 (5): 1587-1596. [LYU Jianhang, YANG Zhongnian, SHI Wei, et al. Model test on stability of reinforced expansive soil slope under freeze-thaw cycles [J]. Journal of Jilin University (Earth Sciences), 2021, 51 (5): 1587-1596.(in Chinese with English abstract).]
LYU Jianhang, YANG Zhongnian, SHI Wei, et al. Model test on stability of reinforced expansive soil slope under freeze-thaw cycles [J]. Journal of Jilin University (Earth Sciences), 2021, 51 (5): 1587－1596.（in Chinese with English abstract）.
[23] 王玮,钱家忠,马雷,等. 基于相关指标的裂隙岩体渗透系数估算模型研究[J]. 水文地质工程地质,2021,48(3):82 − 89. [WANG Wei,QIAN Jiazhong,MA Lei,et al. A model for estimating hydraulic conductivity of fractured rock mass based on correlation indexes[J]. Hydrogeology & Engineering Geology,2021,48(3):82 − 89. (in Chinese with English abstract)] doi: 10.16030/j.cnki.issn.1000-3665.202006045
WANG Wei, QIAN Jiazhong, MA Lei, et al. A model for estimating hydraulic conductivity of fractured rock mass based on correlation indexes[J]. Hydrogeology & Engineering Geology, 2021, 48（3）: 82 − 89. （in Chinese with English abstract） doi: 10.16030/j.cnki.issn.1000-3665.202006045
[24] 袁俊平. 非饱和膨胀土的裂隙概化模型与边坡稳定研究[D]. 南京:河海大学,2003. [YUAN Junping. Study on generalized fracture model and slope stability of unsaturated expansive soil[D]. Nanjing:Hohai University,2003. (in Chinese with English abstract)]
YUAN Junping. Study on generalized fracture model and slope stability of unsaturated expansive soil[D]. Nanjing: Hohai University, 2003. （in Chinese with English abstract）
[25] 施斌,唐朝生,王宝军,等. 粘性土在不同温度下龟裂的发展及其机理讨论[J]. 高校地质学报,2009,15(2):192 − 198. [SHI Bin,TANG Chaosheng,WANG Baojun,et al. Development and mechanism of desiccation cracking of clayey soil under different temperatures[J]. Geological Journal of China Universities,2009,15(2):192 − 198. (in Chinese with English abstract)] doi: 10.16108/j.issn1006-7493.2009.02.013
SHI Bin, TANG Chaosheng, WANG Baojun, et al. Development and mechanism of desiccation cracking of clayey soil under different temperatures[J]. Geological Journal of China Universities, 2009, 15（2）: 192 − 198. （in Chinese with English abstract） doi: 10.16108/j.issn1006-7493.2009.02.013
-
