Assessment of landslide susceptibility in southeast Xizang Region based on multiple models
-
摘要:
藏东南地区地质环境复杂、灾害频发，滑坡给区内工程建设和人财安全造成较大威胁。为选出藏东南地区区域滑坡预测精度较高的模型，文章通过实地调研修正滑坡点数据，结合地形地貌因子、地质因子、地表覆盖因子和诱发因子并通过主成分分析法进行因子筛选，采用频率比模型、BP神经网络模型以及两种模型耦合来进行藏东南地区区域滑坡预测，最后用ROC曲线来检验模型精度。结果表明：经过因子筛选后的频率比模型对藏东南地区预测精度最高（AUC=0.889），通过主成分分析剔除因子的模型精度高于未剔除因子模型精度且藏东南地区滑坡主要沿水系分布，多分布在雅鲁藏布江、达曲、藏曲、怒江、澜沧江、伟曲、詹曲和扎曲两侧。利用所得模型对研究区灾害进行预测，得出滑坡点均处于高易发区及易发区内，研究得出的模型可为藏东南地区工程建设提供技术参考。
Abstract:The geological environment in southeast Xizang is complicated and disasters occur frequently. Landslides pose a great threat to engineering construction and human and financial safety in the region. In order to select models with higher precision for regional landslide prediction in southeast Xizang, this paper used modified landslide point data through field investigation, combined with topographic and geomorphic factors, geological factors, land cover factors and induced factors, and screened the factors through principal component analysis. Frequency ratio models, BP neural network models, and a combination of the two models were used for regional landslides prediction in southeast Xizang. Finally, ROC curves were used to evaluate the model accuracy. The results showed that the frequency ratio model after factor selection had the highest prediction accuracy for southeast Xizang (AUC=0.889). Models with factors removed through principal component analysis had higher accuracy than those without removal, and landslides in southeast Xizang were mainly distributed along river systems, including the Yarlung Zangbo River, Daqu River, Zangqu River, Nujiang River, Lancang River, Weiqu River, Janqu River and Zhaqu River. The models were used to predict the disaster in the study area, revealing that landslide points were located in high susceptibility and susceptibility zones. The models developed in this study can provide technical reference for engineering construction in southeast Xizang.
-
Key words:
- geological hazards /
- landslide /
- frequency ratio /
- BP neural networks /
- southeast Xizang
-
-
表 1 数据来源
Table 1. Summary table of data sources
一级因子 二级因子 数据来源 类型 精度 地形因子 坡度 国家地理空间数据云（ www.gscloud.cn ）
国家地质资料数据中心（www.ngac.org.cn ）栅格 30 m 坡向 栅格 30 m 高程 栅格 30 m 地形起伏度 栅格 30 m 地质因子 地层岩性 GLi M 全球岩性数据集 栅格 30 m 地表覆盖因子 距河流距离 1∶100万全国基础地理信息数据 矢量 1∶50 000 距道路距离 矢量 1∶50 000 土地利用率 中国科学院资源环境科学与技术中心 矢量 1∶50 000 诱发因子 降雨量 栅格 30 m
下载: 导出CSV
表 2 因子相关性分析
Table 2. Factor correlation analysis
坡度 坡向 高程 地形起伏度 距河流距离 距道路距离 土地利用 降雨量 地层岩性 坡度 1 坡向 0.062 1 高程 −0.072 −0.016 1 地形起伏度 0.679** 0.077* −0.167** 1 距河流距离 −0.07 0 0.413** −0.073 1 距道路距离 0.053 0.047 −0.049 0.198** 0.162** 1 土地利用 0.007 0.026 0.073 0.053 0.057 0.186** 1 降雨量 0.149** 0.155** −0.547** 0.259** −0.228** 0.195** 0.008 1 地层岩性 0.110** 0.067 −0.353** 0.157** −0.144** 0.098* 0.051 0.295** 1 注：**在0.01级别（双尾），相关性显著；*在0.05级别（单尾），相关性显著。
下载: 导出CSV
表 3 主成分分析矩阵
Table 3. Principal component analysis matrix
成分 1 2 3 高程 −0.855 降雨量 0.748 距河流距离 −0.601 地层岩性 0.585 坡度 0.923 地形起伏度 0.890 距道路距离 0.768 土地利用 0.621 坡向
下载: 导出CSV
表 4 重大滑坡事件易发性预测
Table 4. Prediction of susceptibility for major landslide events
灾害名称 地理位置 预测易发性 贡龙滑坡 昌都市察雅县 易发区 易贡电站滑坡 林芝市波密县 易发区 达木乡滑坡 林芝市墨脱县 高易发区 通易公路滑坡 林芝市波密县 高易发去 塔林村 林芝市察隅县 易发区
下载: 导出CSV
-
[1] 张林梵,王佳运,张茂省,等. 基于BP神经网络的区域滑坡易发性评价[J]. 西北地质,2022,55(2):260 − 270. [ZHANG Linfan,WANG Jiayun,ZHANG Maosheng,et al. Evaluation of regional landslide susceptibility assessment based on BP neural network[J]. Northwestern Geology,2022,55(2):260 − 270. (in Chinese with English abstract)]
ZHANG Linfan, WANG Jiayun, ZHANG Maosheng, et al. Evaluation of regional landslide susceptibility assessment based on BP neural network［J］. Northwestern Geology, 2022, 55（2）: 260 − 270. （in Chinese with English abstract）
[2] 陶伟,孙岳. 基于GIS滑坡地质灾害易发性评价方法综述[J]. 世界有色金属,2020(21):157 − 159. [TAO Wei,SUN Yue. Review on the evaluation methods of landslide geological hazards based on GIS[J]. World Nonferrous Metals,2020(21):157 − 159. (in Chinese with English abstract)]
TAO Wei, SUN Yue. Review on the evaluation methods of landslide geological hazards based on GIS［J］. World Nonferrous Metals, 2020（21）: 157 − 159. （in Chinese with English abstract）
[3] 马啸,王念秦,李晓抗,等. 基于RF-FR模型的滑坡易发性评价——以略阳县为例[J]. 西北地质,2022,55(3):335 − 344. [MA Xiao,WANG Nianqin,LI Xiaokang,et al. Assessment of landslide susceptibility based on RF-FR model:Taking Lueyang County as an example[J]. Northwestern Geology,2022,55(3):335 − 344. (in Chinese with English abstract)]
MA Xiao, WANG Nianqin, LI Xiaokang, et al. Assessment of landslide susceptibility based on RF-FR model: Taking Lueyang County as an example［J］. Northwestern Geology, 2022, 55（3）: 335 − 344. （in Chinese with English abstract）
[4] 常志璐,黄发明,蒋水华,等. 基于多尺度分割方法的斜坡单元划分及滑坡易发性预测[J]. 工程科学与技术,2023,55(1):184 − 195. [CHANG Zhilu,HUANG Faming,JIANG Shuihua,et al. Slope unit extraction and landslide susceptibility prediction using multi-scale segmentation method[J]. Advanced Engineering Sciences,2023,55(1):184 − 195. (in Chinese with English abstract)]
CHANG Zhilu, HUANG Faming, JIANG Shuihua, et al. Slope unit extraction and landslide susceptibility prediction using multi-scale segmentation method［J］. Advanced Engineering Sciences, 2023, 55（1）: 184 − 195. （in Chinese with English abstract）
[5] 吴晶晶,江思义,吴秋菊,等. 基于GIS与BP神经网络的崩塌滑坡地质灾害易发性预测[J]. 资源信息与工程,2021,36(4):100 − 104. [WU Jingjing,JIANG Siyi,WU Qiuju,et al. Landslide geological hazard vulnerability evaluation based on GIS and BP neural network[J]. Resource Information and Engineering,2021,36(4):100 − 104. (in Chinese with English abstract)]
WU Jingjing, JIANG Siyi, WU Qiuju, et al. Landslide geological hazard vulnerability evaluation based on GIS and BP neural network［J］. Resource Information and Engineering, 2021, 36（4）: 100 − 104. （in Chinese with English abstract）
[6] 刘璐瑶,高惠瑛,李照. 基于CF与Logistic回归模型耦合的永嘉县滑坡易发性评价[J]. 中国海洋大学学报(自然科学版),2021,51(10):121 − 129. [LIU Luyao,GAO Huiying,LI Zhao. Landslide susceptibility assessment based on coupling of CF model and Logistic regression model in Yongjia County[J]. Periodical of Ocean University of China,2021,51(10):121 − 129. (in Chinese with English abstract)]
LIU Luyao, GAO Huiying, LI Zhao. Landslide susceptibility assessment based on coupling of CF model and Logistic regression model in Yongjia County［J］. Periodical of Ocean University of China, 2021, 51（10）: 121 − 129. （in Chinese with English abstract）
[7] 杨强,王高峰,丁伟翠,等. 多种组合模型的区域滑坡易发性及精度评价[J]. 自然灾害学报,2021,30(2):36 − 51. [YANG Qiang,WANG Gaofeng,DING Weicui,et al. Susceptibility and accuracy evaluation of regional landsldie based on multiple hybrid models[J]. Journal of Natural Disasters,2021,30(2):36 − 51. (in Chinese with English abstract)]
YANG Qiang, WANG Gaofeng, DING Weicui, et al. Susceptibility and accuracy evaluation of regional landsldie based on multiple hybrid models［J］. Journal of Natural Disasters, 2021, 30（2）: 36 − 51. （in Chinese with English abstract）
[8] 丛威青,潘懋,李铁锋,等. 基于GIS的滑坡、泥石流灾害危险性区划关键问题研究[J]. 地学前缘,2006,13(1):185 − 190. [CONG Weiqing,PAN Mao,LI Tiefeng,et al. Key research on landslide and debris flow hazard zonation based on GIS[J]. Earth Science Frontiers,2006,13(1):185 − 190. (in Chinese with English abstract)]
CONG Weiqing, PAN Mao, LI Tiefeng, et al. Key research on landslide and debris flow hazard zonation based on GIS［J］. Earth Science Frontiers, 2006, 13（1）: 185 − 190. （in Chinese with English abstract）
[9] 崔阳阳. 基于不同评价单元的滑坡易发性评价方法研究——以陕西省洛南县为例[D]. 西安:西安科技大学,2021. [CUI Yangyang. A comparative study on evaluation methods of landslide susceptibility based on different evaluation units[D]. Xi’an:Xi’an University of Science and Technology,2021. (in Chinese with English abstract)]
CUI Yangyang. A comparative study on evaluation methods of landslide susceptibility based on different evaluation units［D］. Xi’an: Xi’an University of Science and Technology, 2021. （in Chinese with English abstract）
[10] 邓念东,崔阳阳,郭有金. 基于频率比-随机森林模型的滑坡易发性评价[J]. 科学技术与工程,2020,20(34):13990 − 13996. [DENG Niandong,CUI Yangyang,GUO Youjin. Frequency ratio-random forest-model-based landslide susceptibility assessment[J]. Science Technology and Engineering,2020,20(34):13990 − 13996. (in Chinese with English abstract)]
DENG Niandong, CUI Yangyang, GUO Youjin. Frequency ratio-random forest-model-based landslide susceptibility assessment［J］. Science Technology and Engineering, 2020, 20（34）: 13990 − 13996. （in Chinese with English abstract）
[11] 杨云建,周学铖,何中海,等. 多时相数字孪生滑坡变形监测方法与应用研究——以金沙江白格滑坡为例[J]. 水文地质工程地质,2024,51(2):132 − 143. [YANG Yunjian, ZHOU Xuecheng, HE Zhonghai, et al. Multi-temporal digital twin method and application of landslide deformation monitoring: A case study on Baige landslide in Jinsha River[J]. Hydrogeology & Engineering Geology,2024,51(2):132 − 143. (in Chinese with English abstract)]
YANG Yunjian, ZHOU Xuecheng, HE Zhonghai, et al. Multi-temporal digital twin method and application of landslide deformation monitoring: A case study on Baige landslide in Jinsha River［J］. Hydrogeology & Engineering Geology, 2024, 51（2）: 132 − 143. （in Chinese with English abstract）
[12] 张泽方. 耦合MaxEnt模型的望谟县滑坡易发性对比研究[J]. 赤峰学院学报(自然科学版),2022,38(10):108 − 113. [ZHANG Zefang. Comparative study on landslide vulnerability in Wangmo County coupled with MaxEnt model[J]. Journal of Chifeng University (Natural Science Edition),2022,38(10):108 − 113. (in Chinese with English abstract)]
ZHANG Zefang. Comparative study on landslide vulnerability in Wangmo County coupled with MaxEnt model［J］. Journal of Chifeng University （Natural Science Edition）, 2022, 38（10）: 108 − 113. （in Chinese with English abstract）
[13] 刘明学,陈祥,杨珊妮. 基于逻辑回归模型和确定性系数的崩滑流危险性区划[J]. 工程地质学报,2014,22(6):1250 − 1256. [LIU Mingxue,CHEN Xiang,YANG Shanni. Zonation of landslide risk with logistic regression model and certainty factor[J]. Journal of Engineering Geology,2014,22(6):1250 − 1256. (in Chinese with English abstract)]
LIU Mingxue, CHEN Xiang, YANG Shanni. Zonation of landslide risk with logistic regression model and certainty factor［J］. Journal of Engineering Geology, 2014, 22（6）: 1250 − 1256. （in Chinese with English abstract）
[14] 李信,薛桂澄,夏南,等. 基于CF模型、CF-LR模型和CF-AHP模型的国家热带雨林公园地质灾害易发性研究——以海南保亭为例[J]. 现代地质,2023,37(4):1033 − 1043. [LI Xin,XUE Guicheng,XIA Nan,etal. Study on geological hazard susceptibility of national tropical rainforest Park based on CF model,CF-LR model and CF-AHP model:A case study of Baoting,Hainan Province[J]. Modern Geology,2023,37(4):1033 − 1043. (in Chinese with English abstract)]
LI Xin, XUE Guicheng, XIA Nan, etal. Study on geological hazard susceptibility of national tropical rainforest Park based on CF model, CF-LR model and CF-AHP model: A case study of Baoting, Hainan Province［J］. Modern Geology, 2023, 37（4）: 1033 − 1043. （in Chinese with English abstract）
[15] 薛正海,冯文凯,韩靖楠,等. 基于信息量及层次分析关联法和BP神经网络耦合的滑坡易发性评价[J/OL]. 桂林理工大学学报,2022:1 − 13. (2022-10-10). https://kns.cnki.net/kcms/detail/45.1375.N.20221010.1140.004.html. [XUE Zhenghai,FENG Wenkai,HAN Jingnan,et al. Landslide susceptibility evaluation based on information value and AHP correlation method coupled with BP neural network model[J/OL]. Journal of Guilin University of Technology,2022:1 − 13. (2022-10-10). https://kns.cnki.net/kcms/detail/45.1375.N.20221010.1140.004.html. (in Chinese with English abstract)]
XUE Zhenghai, FENG Wenkai, HAN Jingnan, et al. Landslide susceptibility evaluation based on information value and AHP correlation method coupled with BP neural network model［J/OL］. Journal of Guilin University of Technology, 2022: 1 − 13. （2022-10-10）. https://kns.cnki.net/kcms/detail/45.1375.N.20221010.1140.004.html. （in Chinese with English abstract）
[16] 何书,胡萌,杨志华,等. 基于模糊频率比与熵指数的滑坡易发性评价——以崇义县为例[J]. 有色金属科学与工程,2022,13(4):80 − 90. [HE Shu,HU Meng,YANG Zhihua,et al. Evaluation of landslide susceptibility based on the fuzzy frequency ratio and entropy index:A case study of Chongyi County[J]. Nonferrous Metals Science and Engineering,2022,13(4):80 − 90. (in Chinese with English abstract)]
HE Shu, HU Meng, YANG Zhihua, et al. Evaluation of landslide susceptibility based on the fuzzy frequency ratio and entropy index: A case study of Chongyi County［J］. Nonferrous Metals Science and Engineering, 2022, 13（4）: 80 − 90. （in Chinese with English abstract）
[17] 黄艳婷,郭永刚. 考虑降雨敏感度的泥石流危险性评价——以藏东南地区为例[J]. 中国地质灾害与防治学报,2023,34(1):129 − 138. [HUANG Yanting,GUO Yonggang. Debris flow risk assessment considering different rainfall sensitivity:A case study in southeast Tibet[J]. The Chinese Journal of Geological Hazard and Control,2023,34(1):129 − 138. (in Chinese with English abstract)]
HUANG Yanting, GUO Yonggang. Debris flow risk assessment considering different rainfall sensitivity: A case study in southeast Tibet［J］. The Chinese Journal of Geological Hazard and Control, 2023, 34（1）: 129 − 138. （in Chinese with English abstract）
[18] 张本浩,魏云杰,杨成生,等. 西藏然乌地区地质灾害隐患点InSAR识别与监测[J]. 中国地质灾害与防治学报,2022,33(1):18 − 26. [ZHANG Benhao,WEI Yunjie,YANG Chengsheng,et al. InSAR identification and monitoring of geological hazards in Ranwu region of Tibet[J]. The Chinese Journal of Geological Hazard and Control,2022,33(1):18 − 26. (in Chinese with English abstract)]
ZHANG Benhao, WEI Yunjie, YANG Chengsheng, et al. InSAR identification and monitoring of geological hazards in Ranwu region of Tibet［J］. The Chinese Journal of Geological Hazard and Control, 2022, 33（1）: 18 − 26. （in Chinese with English abstract）
[19] 杜国梁,杨志华,袁颖,等. 基于逻辑回归–信息量的川藏交通廊道滑坡易发性评价[J]. 水文地质工程地质,2021,48(5):102 − 111. [DU Guoliang,YANG Zhihua,YUAN Ying,et al. Landslide susceptibility mapping in the Sichuan-Tibet traffic corridor using logistic regression-information value method[J]. Hydrogeology & Engineering Geology,2021,48(5):102 − 111. (in Chinese with English abstract)]
DU Guoliang, YANG Zhihua, YUAN Ying, et al. Landslide susceptibility mapping in the Sichuan-Tibet traffic corridor using logistic regression-information value method［J］. Hydrogeology & Engineering Geology, 2021, 48（5）: 102 − 111. （in Chinese with English abstract）
[20] KHAN H,SHAFIQUE M,KHAN M A,et al. Landslide susceptibility assessment using Frequency Ratio,a case study of northern Pakistan[J]. The Egyptian Journal of Remote Sensing and Space Sciences,2019,22(1):11 − 24. doi: 10.1016/j.ejrs.2018.03.004
[21] 张海军,戚鹏程. 基于频率比和逻辑回归模型的东北地区火险制图研究[J]. 地理与地理信息科学,2012,28(5):35 − 38 + 42 + 113. [ZHANG Haijun,QI Pengcheng. Mapping fire occurrence susceptibility in Northeast China:Comparison of Frequency ratio and binary logistic regression[J]. Geography and Geo-Information Science,2012,28(5):35 − 38. (in Chinese with English abstract)]
ZHANG Haijun, QI Pengcheng. Mapping fire occurrence susceptibility in Northeast China: Comparison of Frequency ratio and binary logistic regression［J］. Geography and Geo-Information Science, 2012, 28（5）: 35 − 38. （in Chinese with English abstract）
[22] PAL S C,CHOWDHURI I. GIS-based spatial prediction of landslide susceptibility using frequency ratio model of Lachung River Basin,North Sikkim,India[J]. SN Applied Sciences,2019,1(5):416. doi: 10.1007/s42452-019-0422-7
[23] LEE S,SAMBATH T. Landslide susceptibility mapping in the Damrei Romel area,Cambodia using frequency ratio and logistic regression models[J]. Environmental Geology,2006,50(6):847 − 855. doi: 10.1007/s00254-006-0256-7
-
