GEOCHMICAL RECORDS OF SURFACE SEDIMENTS IN THE WESTERN BOHAI SEA
-
摘要:
对渤海西部表层沉积物44个样品20种化学组分进行了测试分析，研究了各化学组分分布特征及物质来源。Al2O3、MgO、TFe2O3、K2O、Corg、TN、Li、V和Sb等组分与细粒沉积物呈正相关，SiO2组分与粗粒沉积物呈正相关，Na2O、CaO和Ta组分与沉积物粒度无明显正或负的相关性；研究区化学组分R-型因子分析得出3种主要组合类型，以Li、CaO和TC为代表，分别代表了陆源细粒物质输入、黄河物质、黄河物质与海河物质的影响。CaO/Al2O3与K2O/Al2O3、Zr/ Al2O3与CaO/ Al2O3的离散图和Q-型聚类分析表明，渤海西部沉积物主要来源于黄河和海河，东北部沉积物受到了滦河物质的影响。
Abstract:Based on the concentrations of chemical components SiO2, Al2O3, TFe2O3, CaO, MgO, Na2O, K2O, TiO2, P2O5, MnO, Li, V, Sb, Nb, Ta、Zr, Corg, LOI, TN and TC in surface sediment samples taken from 44 stations in the west part of the Bohai Sea, the distribution pattern and material sources of the chemical components are studied. The chemical components of Al2O3, MgO, TFe2O3, K2O, Corg, TN, Li, V and Sb are positively correlated with the fine-grained sediments, while SiO2 is positively correlated with coarse-grained sediments; there are no significant positive or negative correlations between Na2O, CaO and Ta and grain sizes of sediments. R-mode cluster analysis indicates three types of combinations that are represented by Li, CaO and TC, respectively, reflecting the input of terrigenous fine-grained material, the impact of the Yellow River, and the substances from both Yellow and Haihe Rivers, respectively. Combined with scatter diagrams of CaO/Al2O3 vs.K2O/Al2O3, Zr/Al2O3vs. CaO /Al2O3 , the Q-mode cluster analysis is drawn to reveal the source of sediments in the west part of the Bohai Sea. The results suggest that the sediments of the study area mainly come from the Yellow River and Haihe River, and the sediments in the northeast part of the study area are apparently influenced by the materials from the Luanhe River.
-
Key words:
- chemical components /
- geochemistry /
- sediments /
- provenance /
- western Bohai Sea
-
-
表 1 渤海西部表层沉积物化学组分含量
Table 1. Chemical composition of surface sediments in the western Bohai Sea
化学组分 平均值 范围 变异系数 SiO2 57. 5 48. 6~74. 9 0.10 Al2O3 13. 5 9. 85~15. 3 0.11 CaO 5. 54 1 61~10. 0 0.40 MgO 2. 64 1 35~3. 13 0.16 K2O 2. 91 2. 30~3. 31 0.10 Na2O 3.53 2. 58~4. 37 0.13 TiO2 0. 68 0. 34~0. 76 0.11 P2O5 0. 17 0. 11~0. 20 0.09 MnO 0.10 0. 05~0. 23 0.34 TFe2O3 5.19 2. 60~6. 53 0.10 Corg 0.41 0. 09~0. 75 0.41 LOI 0.29 2. 64~12. 9 0.29 TN 0.06 0. 02~0. 10 0.37 TC 1.32 0. 36~2. 46 0.33 Li 43.7 20. 4~60. 9 0.27 V 83.4 40. 6~106 0.21 Sb 0.83 0. 51~1. 28 0.25 Nb 13.9 8. 9~16. 9 0.12 Ta 1.53 1 0~2. 2 0.16 Zr 211 114~425 0.30 注：SiO2、Al2O3、TFe2O3、CaO、MgO、Na2O、K2O、TiO2、P2O5、MnO、Corg、LOI、TN、TC等化学组分含量单位为% Li、V、Sb、Nb、Ta和Zr等微量元素含量单位为mg/kg。
下载: 导出CSV
表 2 渤海西部表层沉积物元素含量对比
Table 2. Correlation element contents from surface sediments in the western Bohai Sea
元素 本研究区 渤海中东部5 渤海泥[11] 中国浅海[11] 黄河[11, 12] 海河[12, 13] 溁河[12, 14] SiO2 57. 5 67. 7 56.0 63.8 53.5 57.7 74.9 A12O3 13. 5 11. 5 14. 2 11. 1 12. 5 11. 6 9. 10 CaO 5. 54 3.29 4.60 5.29 7.50 6.46 2.52 MgO 2. 64 1. 49 2.49 1. 84 2.60 1. 91 0.80 K2O 2. 91 2. 72 2.90 2.32 2. 61 2. 19 2.35 Na2O 3.53 2.23 2.49 1.99 1. 98 1. 99 3. 19 TiO2 0. 68 0. 51 0.68 0.58 0. 61 0. 57 0.22 P2O5 0. 17 0. 11 0. 11 0.09 MnO 0. 10 0. 11 0.088 0.068 0.063 0.0.4 0.040 TFe2O3 5. 19 3. 79 5.63 4.36 4.77 3. 91 2. 07 Corg 0. 41 0. 41 0. 78 0.62 Li 43.7 47 38 23 V 83.4 67.7 91 70 66 94 Sb 0.83 0.8 0.5 0.62 Nb 13. 9 16 14 15 8.6 Ta 1. 53 1. 0 0.98 1. 0 0.7 Zr 211 251 210 210 354 80 204 注：SiO2、Al2O3、TFe2O3、CaO、MgO、Na2O、K2O、TiO2、P2O5、MnO、Corg等常量元素含量单位为%; Li、V、Sb、Nb、Ta和Zr等微量元素含量单位为mg/kg。
下载: 导出CSV
表 3 渤海西部表层沉积物化学组分与沉积物类型R-型主因子负荷矩阵
Table 3. R-mode rotated factor matrices of chemical components and sediment types of surface sediment in the western Bohai Sea
元素 因子1 因子2 因子3 SiO2 -0.47 -0.84 -0.21 Al2O3 0.91 0.20 0.01 CaO -0.38 0.90 0.09 MgO 0.61 0.73 0.21 K2O 0.90 -.18 -0.21 Na2O 0.16 -0.71 0.56 TiO2 0.33 0.38 0.81 P2O5 -0.13 0.36 0.76 MnO 0.68 -0.12 0.36 TFe2O3 0.83 0.50 0.22 Corg 0.96 0.11 0.13 LOI 0.34 0.91 0.11 TN 0.97 0.04 0.13 TC 0.14 0.96 0.07 Li 0.90 0.37 0.19 V 0.74 0.60 0.27 Sb 0.52 0.69 0.15 Nb 0.29 0.11 0.88 Ta 0.12 -0.58 0.58 Zr -0.62 -0.28 0.63 砂 -0.56 -0.67 -0.38 粉砂 0.36 0.66 0.53 黏土 0.77 0.53 0.01 方差贡献/% 38.34 32.53 17.21 累积方差贡献/% 38.34 70.87 88.08
下载: 导出CSV
表 4 渤海西部表层沉积物化学组分及沉积物类型相关关系
Table 4. Correlation coefficients between chemical components and sediment type in surface sediment from the western Bohai Sea
SiO2 Al2O3 CaO MgO K2O Na2O TiO2 P2O5 MnO TFe2O3 Corg LOI TN TC Li V Sb Nb Ta Zr 砂 粉砂 黏土 SiO2 1.00 Al2O3 -0.64** 1.00 CaO -0.62** -0.16 1.00 MgO -0.96** 0.80** 0.45 ** 1.00 K2O -0.25 0.85** -0.51** 0.44** 1.00 Na2O 0.39** 0.00 -0.64** -0.33* 0.08 1.00 TiO2 -0.64** 0.51** 0.26 0.67** 0.08 0.20 1.00 P2O5 -0.39** 0.13 0. 40.** 0.41** -0.23 0.11 0.77** 1.00 MnO -0.30* 0.55** -0.29 0.37* 0.44** 0.48** 0.41 ** 0.10 1.00 TFe2O3 -0.86** 0.89** 0.14 0.92** 0.63** -0.12 0.66** 0.25 0.54** 1.00 Corg -0.59** 0.92** -0.25 0.70** 0.82** 0.15 0.48** 0.02 0. 64** 0.89** 1.00 LOI -0. 97** 0.46** 0.73 ** 0.87** 0.09 -0.49** 0.52** 0.30* 0.20 0.75 ** 0.45** 1.00 TN -0.53** 0.88** -0.31* 0.63** 0.82** 0.23 0.43 ** -0.04 0. 74** 0.85** 0.97** 0.40** 1.00 TC -0.91** 0.29 0.85** 0.78** -0.08 -0.58** 0.45 ** 0.31* 0.06 0.60** 0.26 0.97 ** 0.21 1.00 Li -0.78** 0.89** 0.01 0.85** 0.70** -0.02 0.60** 0.14 0.58** 0.98** 0.93** 0.67** 0.91** 0.49** 1.00 V -0.90** 0.79** 0.27 0.92** 0.50** -0.16 0.69** 0.31* 0.49** 0.98** 0.82** 0.83** 0.78** 0.69** 0.96** 1.00 Sb -0.85** 0.57** 0.44** 0.83** 0.29 -0.33* 0.47** 0.23 0.35* 0.80** 0.56** 0.83** 0.53** 0.74** 0.76** 0.84** 1.00 Nb -0.41 ** 0.37* 0.06 0.42** 0.07 0.42** 0.79** 0.59** 0.42** 0.49** 0.39** 0.30* 0.38* 0.21 0.48** 0.53** 0.41** 1.00 Ta 0.29 0.04 -0.48** -0.24 0.10 0.66 ** 0.23 0.04 0.27 -0.07 0.09 -0.40.** 0.13 -0.46 ** 0.01 -0.10 -0.14 0.53 ** 1.00 Zr 0.37* -0.52** 0.06 -0.44 ** -0.58** 0.42** 0.20 0.42** -0.21 -0.50** -0.52** -0.38* -0.51** -0.28 -0.53** -0.44 ** -0.47 ** 0.37* 0.45** 1.00 砂 0.87** -0.65** -0.39** -0.87** -0.26 0.18 -0.74** -0.42 ** -0.46** -0.86** -0. 64** -0.82** -0.61** -0.72** -0.82** -0.91** -0.81** -0.56** 0.11 0.34* 1.00 粉砂 -0.79** 0.47** 0.46 0.77** 0.04 -0.09 0.79 ** 0.55** 0.41 ** 0.72** 0.46** 0.75 ** 0.44 ** 0.69 ** 0.66** 0. 79** 0.71** 0.60** -0.06 -0.16 -0.95** 1.00 黏土 -0.79** 0.80** 0.17 0.83** 0.61** -0.29 0.45 ** 0.08 0.43 ** 0.90** 0.79** 0.73** 0.76** 0.60** 0.88** 0.89** 0.77** 0.33* -0.18 -0.58** -0.83** 0.61** 1.00 注:使用PASS统计软件分析**代表双侧检验在J 01水平上显著相关，*代表在0.05水平上显著相关。
下载: 导出CSV
表 5 渤海西部地球化学分区化学组分平均含量
Table 5. Mean chemical components in geochemical provinces in the western Bohai Sea
SiO2 Al2O3 CaO MgO K2O Na2O TiO2 P2O5 MnO TFe2O3 Corg LOI TN TC Li V Sb Nb Ta Zr Ⅰ区 57.9 12.6 7.00 2.55 2.65 3.44 0.68 0.18 0.089 4.66 0.37 8.18 0.04 1.43 36.6 76.8 0. 79 13.8 1.47 245 Ⅱ区 55.9 14.4 4.93 2.80 3.09 3.60 0.70 0.17 0.11 5.71 0.55 8.32 0.07 1.32 50.0 90.6 0.87 14.4 1.57 194 Ⅲ区 64.0 12.8 2.48 2.21 3.07 3.81 0.56 0.15 0.14 4.68 0.46 5.84 0.06 0.84 41.2 72.8 0.75 12.1 1.53 152 注：SiO2、Al2O3、TFe2O3、CaO、MgO、Na2O、K2O、TiO2、P2O5、MnO、Corg、LOI、TN、TC等化学组分含量单位为%; Li、V、Sb、Nb、Ta和Zr等微量元素含量单位为mg/kg
下载: 导出CSV
-
[1] 陈义兰, 吴永亭, 刘晓瑜, 等.渤海海底地形特征[J].海洋科学进展, 2013, 31(1): 75-82. doi: 10.3969/j.issn.1671-6647.2013.01.009
CHEN Yilan, WU Yongting, LIU Xiaoyu, et al. Features of seafloor topography in the Bohai Sea[J]. Advances in Marine Science, 2013, 31(1): 75-82. doi: 10.3969/j.issn.1671-6647.2013.01.009
[2] 中国科学院海洋研究所海洋地质研究室.渤海地质[M].北京: 科学出版社, 1985.
Institute of Oceanology, Chinese Academy of Sciences. Geology of the Bohai Sea[M]. Beijing: Science Press, 1985.
[3] 陈江麟, 刘文新, 刘书臻, 等.渤海表层沉积物重金属污染评价[J].海洋科学, 2004, 28(12): 16-21. doi: 10.3969/j.issn.1000-3096.2004.12.005
CHEN Jianglin, LIU Wenxin, LIU Shuzhen, et al. An evaluation on heavy metal contamination in the surface sediments in Bohai Sea[J]. Marine Sciences, 2004, 28(12): 16-21. doi: 10.3969/j.issn.1000-3096.2004.12.005
[4] 李淑媛, 刘国贤, 苗丰民.渤海沉积物中重金属分布及环境背景值[J].中国环境科学, 1994, 14(5): 370-376. doi: 10.3321/j.issn:1000-6923.1994.05.006
LI Shuyuan, LIU Guoxian, MIAO Fengmin. The distribution and environmental background values of the heavy metals in sediment of the Bohai Sea[J]. China Environmental Science, 1994, 14(5): 370-376. doi: 10.3321/j.issn:1000-6923.1994.05.006
[5] 李淑媛, 苗丰民, 赵全民, 等.辽东半岛西南及渤海中部海域表层沉积物的地球化学[J].海洋地质与第四纪地质, 2010, 30(4): 123-130. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzydsjdz201004015
LI Shuyuan, MIAO Fengmin, ZHAO Quanmin, et al. Geodchemistry of surface sediments off southwest Liaodong Peninsula and in Mid-Bohai Sea[J]. Marine Geology and Quaternary Geology, 2010, 30(4): 123-130. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzydsjdz201004015
[6] 刘彬昌, 卢中发, 张守法.渤海沉积物地球化学分区的模糊分析[J].海洋与湖沼, 1992, 23(5): 561-565.
LIU Binchang, LU Zhongfa, ZHANG Shoufa. Fuzzy analysis of geochemical divisions in sediments collected from the Bohai Sea[J]. Oceanologia et Limnologia Sinica, 1992, 23(5): 561-565.
[7] 田立柱, 裴艳东, 商志文, 等.渤海湾西部表层沉积物悬移组分元素特征及物源意义[J].海洋地质与第四纪地质, 2010, 30(1): 9-15. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzydsjdz201001002
TIAN Lizhu, PEI Yandong, SHANG Zhiwei, et al. Elements characteristics of the suspended component in surface sediments from the west Bohai Bay and the provenance implication[J]. Marine Geology and Quaternary Geology, 2010, 30(1): 9-15. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzydsjdz201001002
[8] 吕成功, 陈真.渤海表层沉积物地球化学分析[J].青岛海洋大学学报, 1993, 23(3): 9-18. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=Y2159848
LV Chengong, CHEN Zhen. Geochemical analysis of the surface sediments of the Bohai sea[J]. Journal of Ocean University of Qingdao, 1993, 23(3): 9-18. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=Y2159848
[9] 李全生, 马锡年, 沈万仁, 等.渤海湾表层沉积物中几种化学成分的研究[J].海洋科学, 1984, 8(5): 22-27. http://qdhys.ijournal.cn/hykx/ch/reader/key_query.aspx
LI Quansheng, MA Xinian, SHEN Wanren, et al. Chemical compositions of surface sediment of Bohai Bay[J]. Marine Sciences, 1984, 8(5): 22-27. http://qdhys.ijournal.cn/hykx/ch/reader/key_query.aspx
[10] 郭津年, 李健博, 吴景阳, 等.渤海沉积物中的Fe, Al, Mn的分布及某些地球化学特征的研究[J].海洋科学, 1983, 7(4): 22-25.
GUO Jinnian, LI Jianbo, WU Jingyang, et al. The distribution of Fe, Al and Mn in sediments of Bohai Sea and their certain geochemical characteristics[J]. Marine Sciences, 1983, 7(4): 22-25.
[11] 赵一阳, 鄢明才.中国浅海沉积物地球化学[M].北京:科学出版社, 1994.
ZHAO Yiyang, YAN Mingcai. Geochemistry of Sediments of the China Shelf Sea[M]. Beijing: Science Press, 1994..
[12] 刘建国, 李安春, 陈木宏, 等.全新世渤海泥质沉积物地球化学特征[J].地球化学, 2007, 36(6): 559-568. doi: 10.3321/j.issn:0379-1726.2007.06.004
LIU Jianguo, LI Anchun, CHEN Muhong, et al. Geochemical characteristics of sediments in the Bohai Sea mud area during Holocene[J]. Geochimica, 2007, 36(6): 559-568. doi: 10.3321/j.issn:0379-1726.2007.06.004
[13] 曹红英, 梁涛, 王立军, 等.近海潮间带水体及沉积物中重金属的含量及分布特征[J].环境科学, 2006, 27(1): 126-131. doi: 10.3321/j.issn:0250-3301.2006.01.024
CAO Hongying, LIANG Tao, WANG Lijun, et al. Contents and distribution characteristics of heavy metals in water and sediment of intertidalite[J]. Environmental Science, 2006, 27(1): 126-131. doi: 10.3321/j.issn:0250-3301.2006.01.024
[14] 周福根.滦河口区沉积物中元素的分布和环境的关系[J].海洋通报, 1983, 2(2): 60-70.
ZHOU Fugeng. The relations between element distribution in sediments and environments in Luanhe Estuary[J]. Marine Science Bulletin, 1983, 2(2): 60-70.
[15] 蓝先洪, 密蓓蓓, 李日辉, 等.渤海东部和黄海北部沉积物中重金属分布特征[J].中国环境科学, 2014, 34(10): 2660-2668. http://d.old.wanfangdata.com.cn/Periodical/zghjkx201410031
LAN Xianhong, MI Beibei, LI Rihui, et al. Distribution of heavy metals in surface sediments in the eastern Bohai Sea and the northern Yellow Sea[J]. China Environmental Science, 2014, 34(10): 2660-2668. http://d.old.wanfangdata.com.cn/Periodical/zghjkx201410031
[16] 张爱滨, 刘明, 廖永杰, 等.黄河沉积物向渤海湾扩散的沉积地球化学示踪[J].海洋科学进展, 2015, 33(2): 246-256. doi: 10.3969/j.issn.1671-6647.2015.02.012
ZHANG Aibin, LIU Ming, LIAO Yongjie, et al. The sedimentary geochemical trace of the Yellow River sediments diffusion in the Bohai Bay[J]. Advances in Marine Science, 2015, 33(2): 246-256. doi: 10.3969/j.issn.1671-6647.2015.02.012
[17] 董方, 刘素美, 张经.北黄海与渤海沉积物中磷形态的分布特征[J].海洋环境科学, 2001, 20(2): 18-23. doi: 10.3969/j.issn.1007-6336.2001.02.004
DONG Fang, LIU Sumei, ZHANG Jing. Phosphorus speciation in the sediments of the Bohai Sea and North Yellow Sea[J]. Marine Environmental Science, 2001, 20(2): 18-23. doi: 10.3969/j.issn.1007-6336.2001.02.004
[18] 赵保仁, 庄国文, 曹德明, 等.渤海的环流、潮余流及其对沉积物分布的影响[J].海洋与湖沼, 1995, 26(5): 466-473. doi: 10.3321/j.issn:0029-814X.1995.05.003
ZHAO Baoren, ZHUANG Guowen, CAO Deming, et al. Circulation, tidal residual currents and their effects on the sedimentations in the Bohai Sea[J]. Oceanologia et Limnologia Sinica, 1995, 26(5): 466-473. doi: 10.3321/j.issn:0029-814X.1995.05.003
[19] 施建堂.渤海湾西部的现代沉积[J].海洋通报, 1987, 6(1): 22-26.
SHI Jiantang. Modern sedimentation in the western Bohai Bay[J]. Marine Science Bulletin, 1987, 6(1): 22-26.
[20] 周永芝, 刘娟.莱州湾、渤海湾及渤海中央盆地沉积物岩芯地球化学的初步研究[J].黄渤海海洋, 1991, 9(2): 54-59.
ZHOU Yongzhi, LIU Juan. A preliminary study on geochemistry of sediment cores from Laizhou Bay, Bohai Bay and the central Basin of Bohai Sea[J]. Journal of Oceanography of Huanghai & Bohai Seas, 1991, 9(2): 54-59.
[21] 陈丽蓉, 栾作峰, 郑铁民, 等.渤海沉积物中的矿物组合及其分布特征的研究[J].海洋与湖沼, 1980, 11(1): 46-64. http://qdhys.ijournal.cn/hyyhz/ch/reader/key_query.aspx
CHEN Lirong, LUAN Zuofeng, ZHENG Tiemin, et al. Mineral assemblages and their distribution patterns in the sediments of the gulf of Bohai Sea[J]. Oceanologia et Limnologia Sinica, 1980, 11(1): 46-64. http://qdhys.ijournal.cn/hyyhz/ch/reader/key_query.aspx
[22] 刘振夏.现代滦河三角洲的影响因素和沉积物分区[J].黄渤海海洋, 1989, 7(4): 55-64.
LIU Zhenxia. The influential factors and zoning of the modern Luanhe River Delta[J]. Journal of Oceanography of huanghai & Bohai Seas, 1989, 7(4): 55-64.
[23] 邢焕政.海河口岸线演变及泥沙来源分析[J].海河水利, 2003(2): 28-30. doi: 10.3969/j.issn.1004-7328.2003.02.010
XING Huanzheng. Haihe River estuarial coastline evolvement and sediment source analysis[J]. Haihe Water Resources, 2003(2): 28-30. doi: 10.3969/j.issn.1004-7328.2003.02.010
[24] 秦蕴珊, 廖先贵.渤海湾海底沉积作用的初步探讨[J].海洋与湖沼, 1962, 4(3-4):199-207. http://qdhys.ijournal.cn/hyyhz/ch/reader/key_query.aspx
QIN Yunshan, LIAO Xiangui. A preliminary probe of sedimentation in Bohai Bay[J]. Oceanologia et Limnologia Sinica, 1962, 4(3-4): 199-207. http://qdhys.ijournal.cn/hyyhz/ch/reader/key_query.aspx
[25] 乔淑卿, 石学法, 王国庆, 等.渤海底质沉积物粒度特征及输运趋势探讨[J].海洋学报, 2010, 32(4): 139-147. CNKI:SUN:SEAC.0.2010-04-014
QIAO Shuqing, SHI Xuefa, WANG Guoqing, et al. Discussion on grain-size characteristics of seafloor sediment and transport pattern in the Bohai Sea[J]. Acta Oceanologica Sinica, 2010, 32(4): 139-147. CNKI:SUN:SEAC.0.2010-04-014
[26] Kremling K, Streu P. Saharan dust influenced trace element fluxes in deep North Atlantic Subtropical waters[J]. Deep Sea Research Part Ⅰ: Oceanographic Research Papers, 1993, 40(6): 1155-1168. doi: 10.1016/0967-0637(93)90131-L
[27] 蓝先洪.珠江三角渊第四纪沉积物TiO2/Al2O3值及其地质意义[J].台湾海峡, 1992, 11(3): 227-232.
LAN Xianhong. TiO2/Al2O3 ratio in Quaternary sediments of Zhujiang River delta and its geological significance[J]. Journal of Oceanography in Taiwan Strait, 1992, 11(3): 227-232.
[28] Hainbucher D, Hao W, Pohlmann T, et al. Variability of the Bohai Sea circulation based on model calculations[J]. Journal of Marine System, 2004, 44(3-4): 153-174. doi: 10.1016/j.jmarsys.2003.09.008
[29] 韩宗珠, 张军强, 邹昊, 等.渤海湾北部底质沉积物中黏土矿物组成与物源研究[J].中国海洋大学学报, 2011, 41(11): 95-102. doi: 10.3969/j.issn.1672-5174.2011.11.016
HAN Zongzhu, ZHANG Junqing, ZOU Hao, et al. Characteristics and provenance of clay mineral assemblage of sediments from the northern part of the Bohai Bay[J]. Periodical of Ocean University of China, 2011, 41(11): 95-102. doi: 10.3969/j.issn.1672-5174.2011.11.016
-
