Hydrochemistry, isotope and circulation characteristics of geothermal fluids controlled by geological structure: A case study of Yuxian Basin
-
摘要: 蔚县盆地地热资源丰富,地质构造繁杂,研究地质构造控制下的地热流体水化学、同位素及循环特征可进一步促进地热开发与利用,以及环首都县市地热温泉康养产业发展。通过结合地下水和大气降水,运用多元统计、相关性及特征系数分析,借助Piper三线图、Na-K-Mg三角图,对蔚县盆地地热流体进行研究。研究结果显示: ①地热流体中阳离子以Na+、Ca2+、Mg2+为主,阴离子以HCO3-、SO42-为主; Ca2+、Mg2+、HCO3-主要源于碳酸盐岩类矿物的溶解; ②地热流体中存在阳离子交替吸附作用,作用方向为K+、Na+进入液相,Ca2+、Mg2+进入固相,Na+与Ca2+、Mg2+处于此消彼长、相互抑制的状态; ③热储地层封闭性较差,地热流体浓缩程度和变质程度较低,受渗入水及浅表层氧化作用影响显著; 地热流体补给来源主要为大气降水,径流路径较短,水循环较快; ④热储温度为37.32~57.36 ℃,蓟县系雾迷山组热储最大循环深度为1 715~2 640 m,蓟县系高于庄组热储最大循环深度为3 291~3 337 m,均值为3 314 m。研究结果揭示了地质构造作用下水岩相互作用,对研究该地区地热流体水化学演化及动态特征具有一定意义。Abstract: Yuxian Basin has rich geothermal resources and complex geological structures. The study on the hydrochemistry, isotope and circulation characteristics of geothermal fluids controlled by geological structures can further promote the development and utilization of geothermal resources and geothermal hot spring health care industry around the capital city. By combining groundwater and atmospheric precipitation, and using multivariate statistics, correlation and characteristic coefficient analysis, the authors studied the geothermal fluid in Yuxian Basin using Piper triplex diagram and Na-K-Mg triangle diagram. The results are as follows. ① The cations in geothermal fluid are mainly Na+, Ca2+ and Mg2+, and the anions are mainly HCO3- and SO42-. Ca2+, Mg2+ and HCO3- are mainly derived from the dissolution of carbonate minerals. ② A cation alternat adsorption occurred in geothermal fluid, with the action direction of K+, Na+ into the liquid phase, and Ca2+, Mg2+ into the solid phase. Na+ and Ca2+, Mg2+ are in a state of mutual inhibition. ③ The thermal reservoir formation is poorly sealed, the concentration degree and metamorphism degree of geothermal fluid are low, indicating a significant affection by infiltration water and shallow surface oxidation. The main source of geothermal fluid recharge is atmospheric precipitation, and the runoff path is short with fast water cycle. ④ The heat storage temperature was 37.32~57.36 ℃, the maximum circulating depth of heat storage in Wumishan Formation of Jixian System was 1 715~2 640 m, and the maximum circulating depth of the heat storage in Gaoyuzhuang Formation of Jixian System was 3 291~3 337 m, with the average value of 3 314 m. The interaction between groundwater and rock under geological structure was revealed, which could provide certain guidance in studying the hydrochemical evolution and dynamic characteristics of geothermal fluid in this area.
-
Key words:
- Yuxian Basin /
- geothermal fluid /
- hydrogeochemistry /
- isotope geochemistry /
- cycle feature
-
-
[1] 王贵玲,刘彦广,朱喜,等.中国地热资源现状及发展趋势[J].地学前缘,2020,27(1):1-9.
Wang G L,Liu Y G,Zhu X,et al.The status and development trend of geothermal resources in China[J].Earth Science Frontiers,2020,27(1):1-9.
[2] 汪洋,张旭虎,蒲丛林,等.河北廊坊南部地区地热水化学特征及成因机制[J].地质通报,2022,41(9):1698-1706.
Wang Y,Zhang X H,Pu C L,et al.The hydrochemical characteristics of geothermal water and its formation in the south Langfang,Hebei Province[J].Geological Bulletin of China,2022,41(9):1698-1706.
[3] 徐世光,郭远生.地热学基础[M].北京:科学出版社,2009.Xu S G,Guo Y S.Fundamentals of Geothermal[M].Beijing:Science Press,2009.
[4] 窦斌,田红,郑君.地热工程学[M].武汉:中国地质大学出版社,2020.Dou B,Tian H,Zheng J.Geothermal Engineering[M].Wuhan:China University of Geosciences Press,2020.
[5] 汪集旸,熊亮萍,庞忠和.中低温对流型地热系统[M].北京:科学出版社,1993.Wang J Y,Xiong L P,Pang Z H.Low-Medium Temperature Geothermal System of Convective Type[M].Beijing:Science Press,1993.
[6] 牛兆轩,牛雪,张成龙,等.唐山市滨海地区地下热水水化学特征及循环深度[J].中国地质调查,2022,9(6):84-92.
Niu Z X,Niu X,Zhang C L,et al.Hydrochemical characteristics and circulation depth of geothermal water in coastal area of Tang-shan City[J].Geological Survey of China,2022,9(6):84-92.
[7] 袁利娟,张进平,何云成,等.北京市通州区地热流体水化学和同位素特征及其地热学意义[J].地质论评,2021,67(5):1545-1556.
Yuan L J,Zhang J P,He Y C,et al.Hydrochemical and isotopic characteristics of geothermal fluids in Tongzhou District,Beijing,and their geothermal significance[J].Geological Review,2021,67(5):1545-1556.
[8] 李业震. 蔚县地热地质特征及地热资源开发利用[J].中国煤田地质,2004,16(S1):72-73.
Li Y Z.Geothermal geologic features and geothermal resource exploitation in Yuxian[J].Coal Geology of China,2004,16(S1):72-73.
[9] 王国晨,夏华宗,李贝德.蔚县北洗冀地热异常区热储特征分析[J].科技视界,2016(9):261,291.Wang G C,Xia H Z,Li B D.Analysis of heat storage characteristics in Beixiji Hebei geothermal anomaly area,Yuxian County[J].Science & Technology Vision,2016(9):261,291.
[10] 周江. 蔚县盆地地热成因分析[J].煤炭科技,2019,40(5):6-10.
Zhou J.Analysis on geothermal genesis of Yuxian Basin[J].Coal Science & Technology Magazine,2019,40(5):6-10.
[11] 郝星波. 蔚县盆地地下热水赋存地质特征及开发利用前景探讨[J].地下水,2019,41(3):39-40,53.
Hao X B.Geological characteristics of underground hot water occurrence and prospect of development and utilization in Yuxian Basin[J].Ground Water,2019,41(3):39-40,53.
[12] 李泓泉,张树胜,谢明忠,等.冀西北蔚县盆地地热资源赋存特征及勘查开发方向[J].地质论评,2020,66(4):919-932.
Li H Q,Zhang S S,Xie M Z,et al.The occurrence characteristics and exploration and development direction of geothermal resources in Yuxian Basin,northwest Hebei Province[J].Geological Review,2020,66(4):919-932.
[13] 河北省地矿局国土资源勘查中心.张家口市地热资源分布规律与开发利用研究[R].2014.Hebei Province Bureau of Geology and Mineral Resources Exploration Center.Research Report on the Distribution and Exploitation of Geothermal Resources in Zhangjiakou City[R].2014.
[14] 国家能源局.NB/T 10716—2021 地热流体样品的采集与保存规范[S].北京:中国石化出版社,2021.National Energy Administration.NB/T 10716—2021 Specification for Collection and Preservation of Geothermal Fluid Samples[S].Beijing:China Petrochemical Press,2021.
[15] 张薇,王贵玲,赵佳怡,等.四川西部中高温地热流体地球化学特征及其地质意义[J].现代地质,2021,35(1):188-198.
Zhang W,Wang G L,Zhao J Y,et al.Geochemical characteristics of medium-high temperature geothermal fluids in west Sichuan and their geological implications[J].Geoscience,2021,35(1):188-198.
[16] 孙红丽,马峰,刘昭,等.西藏高温地热显示区氟分布及富集特征[J].中国环境科学,2015,35(1):251-259.
Sun H L,Ma F,Liu Z,et al.The distribution and enrichment characteristics of fluoride in geothermal active area in Tibet[J].China Environmental Science,2015,35(1):251-259.
[17] 朱喜,王贵玲,马峰,等.太行山—雄安新区蓟县系含水层水文地球化学特征及意义[J].地球科学,2021,46(7):2594-2608.
Zhu X,Wang G L,Ma F,et al.Hydrogeochemistry of geothermal waters from Taihang Mountain-Xiong’an new area and its indicating significance[J].Earth Science,2021,46(7):2594-2608.
[18] 张保建. 鲁西北地区地下热水的水文地球化学特征及形成条件研究[D].北京:中国地质大学(北京),2011.Zhang B J.Hydrogeochemical Characteristics and Formation Conditions of the Geothermal Water in Northwestern Shandong Pro-vince[D].Beijing:China University of Geosciences (Beijing),2011.
[19] 沈照理. 水文地球化学基础[M].北京:地质出版社,1986.Shen Z L.Basis of Hydrogeochemistry[M].Beijing:Geological Publishing House,1986.
[20] 江露露,隋海波,康凤新,等.鲁中隆起北缘地热区岩溶热储水化学特征及形成机理[J].中国岩溶,2023,42(5):1005-1026,1036.
Jiang L L,Sui H B,Kang F X,et al.Hydrogeochemical characteristics and formation mechanism of the karst thermal reservoir at the northern edge of the Luzhong Uplift[J].Carsologica Sinica,2023,42(5):1005-1026,1036.
[21] 赵子锐,张薇,王贵玲,等.冀中坳陷高阳地热田水文地球化学特征及其对地热成因的约束[J/OL].中国地质,(2023-08-01).http://kns.cnki.net/kcms/detail/11.1167.P.20230731.1742.006.html.
Zhao Z R,Zhang W,Wang G L,et al.Hydrogeochemical characteristics of Gaoyang geothermal field in central Hebei Depression and its constraint on geothermal genesis[J/OL].Geology of China,(2023-08-01).http://kns.cnki.net/kcms/detail/11.1167.P.20230731.1742.006.html.
[22] Craig H.Isotopic variations in meteoric waters[J].Science,1961,133(3465):1702-1703.
[23] 郑淑蕙,侯发高,倪葆龄.我国大气降水的氢氧稳定同位素研究[J].科学通报,1983,28(13):801-806.
Zheng S H,Hou F G,Ni B L.Studies on stable isotopes of hydrogen and oxygen in atmospheric precipitation in China[J].Chinese Science Bulletin,1983,28(13):801-806.
[24] 陶兰初,朱星强,马一奇,等.滇东老厂地区地热水成因:来自水化学和碳氢氧硫同位素的约束[J].沉积与特提斯地质,2023,43(2):295-310.
Tao L C,Zhu X Q,Ma Y Q,et al.Genesis of geothermal water in the Laochang area,eastern Yunnan Province:Constraints from hydrochemistry and C-H-O-S isotopes[J].Sedimentary Geology and Tethyan Geology,2023,43(2):295-310.
[25] 李泽威,袁飞,李明龙,等.水化学特征在恩施盆地地热资源调查中的指示意义[J].地质科技通报,2023,42(4):83-94,106.
Li Z W,Yuan F,Li M L,et al.Indicative significance of hydrochemical characteristics in geothermal resource investigations in the Enshi Basin[J].Bulletin of Geological Science and Technology,2023,42(4):83-94,106.
[26] 桂林冶金地质研究所同位素地质组.硫同位素地质介绍[J].地质与勘探,1974(1):24-30.
Sotope Geology Group,Guilin Institute of Metallargical Geology.Introduction of sulfur isotope geology[J].Geology and Exploration,1974(1):24-30.
[27] 宋小庆,彭钦,段启杉,等.黔东北地区地热水化学特征及起源[J].地球科学,2019,44(9):2874-2886.
Song X Q,Peng Q,Duan Q S,et al.Hydrochemistry characteristics and origin of geothermal water in northeastern Guizhou[J].Earth Science,2019,44(9):2874-2886.
[28] 徐一鸣,李傲宇,程立群,等.冀东平原馆陶组地热流体水化学成分和H-O同位素组成特征及其地质意义[J/OL].现代地质,(2023-06-08).https://doi.org/10.19657/j.geoscience.1000-8527.2023.056.
Xu Y M,Li A Y,Cheng L Q,et al.Characteristics of hydrochemical compositions and H-O isotopic compositions of geothermal fluids and their geological significance of the Guantao Formation in the Eastern Hebei Plain[J/OL].Geoscience,(2023-06-08).https://doi.org/10.19657/j.geoscience.1000-8527.2023.056.
[29] 周训,金晓媚,梁四海,等.地下水科学专论[M].2版.北京:地质出版社,2017.Zhou X,Jin X M,Liang S H,et al.Groundwater Science Monograph[M].2nd ed.Beijing:Geological Publishing House,2017.
[30] 河北省煤田地质局水文地质队.河北省蔚县1∶5万地质灾害风险调查评价报告[R].2022.Hydrogeology Team of Hebei Coal Field Geology Bureau.Investigation and Evaluation Report of 1∶50,000 Geological Disaster Risk in Yuxian County,Hebei Province[R].2022.
[31] 李洁祥,郭清海,余正艳.高温地热系统中粘土矿物形成对Na-K和K-Mg地球化学温标准确性的影响[J].地球科学,2017,42(1):142-154.
Li J X,Guo Q H,Yu Z Y.Impact of clay mineral formation in high-temperature geothermal system on accuracy of Na-K and K-Mg geothermometers[J].Earth Science,2017,42(1):142-154.
[32] Giggenbach W F.Geothermal solute equilibria.Derivation of Na-K-Mg-Ca geoindicators[J].Geochimica et Cosmochimica Acta,1988,52(12):2749-2765.
[33] 王莹,周训,于湲,等.应用地热温标估算地下热储温度[J].现代地质,2007,21(4):605-612.
Wang Y,Zhou X,Yu Y,et al.Application of geothermometers to calculation of temperature of geothermal reservoirs[J].Geoscience,2007,21(4):605-612.
[34] Fournier R O.Chemical geothermometers and mixing models for geothermal systems[J].Geothermics,1977,5(1-4):41-50.
[35] Arnórsson S.Chemical equilibria in icelandic geothermal systems-Implications for chemical geothermometry investigations[J].Geothermics,1983,12(2/3):119-128.
[36] 河北文泉水利工程有限公司.河北省蔚县暖泉古镇文化旅游开发有限公司地热勘查钻井竣工报告[R].2017.Hebei Wenquan Water Conservancy Engineering Co.,LTD.Geothermal Exploration Drilling Completion Report of Yuxian Nuanquan Guzhen Cultural Tourism Development Co.,Ltd.[R].2017.
[37] 河北省煤田地质局第四地质队.河北省蔚县麦子疃地热勘查区地热资源预可行性勘查报告[R].2020.The Fourth Geological Team of Hebei Coal Field Geology Bureau.Pre-feasibility Exploration Report of Geothermal Resources in Yuxian Geothermal Exploration Area,Hebei Province[R].2020.
[38] 张德忠,刘志刚,卢红柳,等.河北地热[M].北京:地质出版社,2013.Zhang D Z,Liu Z G,Lu H L,et al.Geothermal Energy in Hebei[M].Beijing:Geological Publishing House,2013.
-
