Seepage-heat transfer coupling process of low temperature return water injected into geothermal reservoir in carbonate rocks in Xian County, China
-
Abstract:
Fracture seepage and heat transfer in the geothermal reservoir of carbonate rocks after the reinjection of low temperature geothermal return water is a complex coupling process,which is also the frontier of geothermal production and reinjection research. Based on the research of cascade comprehensive development of geothermal resources in Beijing-Tianjin-Hebei (Xian County),the carbonate geothermal reservoir of Wumishan formation in the geothermal field in Xian County is investigated. With the development of the discrete fracture network model and the coupling model of seepage and heat transfer,the numerical solution of seepage field and temperature field with known fracture network is reached using the finite element software COMSOL,and the coupling process of seepage flow and heat in carbonate rocks is revealed. The results show that the distribution of temperature field of fractured rocks in geothermal reservoir of carbonate rocks has strong non-uniformity and anisotropy. The fracture network is interpenetrated,which constitutes the dominant channel of water conduction,and along which the fissure water moves rapidly. Under the influence of convective heat transfer and conductive heat transfer,one of the main factors to be considered in the study of thermal breakthrough is to make the cold front move forward rapidly. When the reinjection and production process continues for a long time and the temperature of the geothermal reservoir on the pumping side drops to a low level,the temperature of bedrocks is still relatively high and continues to supply heat to the fissure water,so that the temperature of the thermal reservoir on the pumping side will not decrease rapidly to the water temperature at the inlet of reinjection,but will gradually decrease after a long period of time,showing an obvious long tail effect. The distribution of fractures will affect the process of seepage and heat transfer in carbonate reservoirs,which should be considered in the study of fluid thermal coupling in carbonate reservoirs.
-
-
Table 1. Computational parameter
Name of parameter Sign Numerical value Unit Fracture Porosity εfr 0.5 - Permeability kfr 1.0×10-8 m2 Porous media Density ρs 2 800 kg/m3 Specific heat capacity at constant pressure Cp, s 920 J/(kg·K) Thermal conductivity Ks 5 W/(m·K) Porosity εs 0.25 - Permeability ks 1.0×10-14 m2 Water Density ρf 1 000 kg/m3 Thermal conductivity Kf 0.68 W/(m·K) Specific heat capacity at constant pressure Cp, f 4 200 J/(kg·K) Fluid compressibility χf 0.000 1 1/Pa Dynamic viscosity μ 0.001 Pa·s Specific heat rate γ 1 - Boundary conditions and initial conditions Temperature of reinjection side T_in 30 ℃ Pressure of reinjection side P_in 20 MPa Pressure of mining side P_out 19.5 MPa Initial temperature of reservoir T_str 90 ℃ Initial pressure of reservoir P_str 19.5 MPa Boundary conditions The upper and lower boundaries are thermally insulated and fixed without flow
下载: 导出CSV
-
CHEN Bi-guang, SONG Er-xiang, CHENG Xiao-hui. 2013. Plane-symmetrical simulation of flow and heat transport in fractured geological media: A discrete fracture model with comsol. In: Multiphysical Testing of Soils and Shales, Springer -Verlag Berlin Heidelberg: 149-154.
CHEN Bi-guang, SONG Er-xiang, CHENG Xiao-hui. 2014. A numerical method for discrete fracture network model for flow and heat transfer in two-dimensional fractured rocks. Chinese Journal of Rock Mechanics and Engineering, (33)1: 43-51. DOI: 10.13722/j.cnki.jrme.2014.01.005.
CUI Han-bo, TANG Ju-peng, JIANG Xin-tong. 2020. Influence of permeability on reservoir change during dry hot rock mining. Hydrogeology & Engineering Geology, 47(1): 171-180. DOI: 10.19637/j.cnki.2305-7068.2019.01.003.
FENG Jian-yun, ZHANG Ying, HE Zhi-liang, et al. 2019. Discussion on evaluation me-thodology of hydrothermal geothermal rese-rvoir. Journal of Groundwater Science and Engineering, 7(1): 29-41. DOI: 10.19637/j.cnki.2305-7068.2019.01.003. http://gwse.iheg.org.cn/en/article/id/412
HONG Zeng-lin, ZHANG Yin-long, ZHOU Yang. 2019. Research on the modes of occurrence and application of geothermal resources in the middle and deep layers of the piedmont area in southern Guanzhong Basin. Geology in China, 46(5): 1224-1235. DOI: 10.12029/gc20190522.
Leung CTO, Zimmerman RW. 2012. Estimating the hydraulic conductivity of two-dimensional fracture networks using network geometric properties. Transport in Porous Media, 93(3): 777-797. DOI: 10.1007/s11242-012-9982-3.
LI Ting-xin, CAI Yong-feng, LIU Yan-guang, et al. 2020. Tracer test and simulation of thermal energy storage in carbonate rocks of the Xian County geothermal field. Earth Science Frontiers, 27(1): 152-158. DOI: 10.13745/j.esf.2020.1.16.
LIN Wen-jing, LIU Zhi-ming, WANG Wan-li, et al. 2013. The assessment of geothermal resources potential of China. Geology in China, 40(1): 312-321. DOI: 10.3969/j.issn. 1000-3657.2013.01.021.
LIU Gui-hong, PU Hai, ZHAO Zhi-hong, et al. 2019. Coupled thermo-hydro-mechanical modeling on well pairs in heterogeneous porous geothermal reservoirs. Energy, 171: 631-653. DOI: 10.1016/j.energy.2019.01.022.
LIU Jiu-rong. 2013. The status of geothermal reinjection. Hydrogeology & Engineering Geology, 3: 100-104. DOI: 10.16030/j.cnki.issn.1000-3665.2003.03.025.
LIU Yan-guang, ZHU Xi, YUE Gao-fan, et al. 2015. A review of fluid flow and heat transfer in the CO2-EGS. Journal of Groundwater Science and Engineering, 3(2): 170-175. http://gwse.iheg.org.cn/en/article/id/184
LIU Yan-guang, WANG Gui-ling, YUE Gao-fan, et al. 2017a. Impact of CO2 injection rate on heat extraction at the HDR geothermal field of Zhacanggou, China. Environmental Earth Sciences 76(6): 256. DOI: 10.1007/s12665-017-6551-7.
LIU Yan-guang, LU Chuan, YUE Gao-fan, et al. 2017b. Deep geothermal fluid chemical con-stituents reconstruction of high-temperature geothermal system. Journal of Groundwater Science and Engineering, 5(2): 173-181. http://gwse.iheg.org.cn/en/article/id/271
LIU Yan-guang, WANG Gui-ling, ZHU Xi, et al. 2019a. Occurrence of geothermal resources and prospects for exploration and development in China. Energy Exploration & Exploitation, DOI: 10.1177/0144598719895820.
LIU Yan-guang, LIU Gui-hong, ZHAO Zhi-hong, et al. 2019b. Theoretical model of geothermal tail water reinjection based on an equivalent flow channel model: A case study in Xianxian, North China Plain. Energy Exploration & Exploitation, 37(2): 849-864. DOI: 10.1177/0144598718822401.
LIU Yan-guang, WANG Gui-ling, YUE Gao-fan, et al. 2019c. Comparison of enhanced geothermal system with water and CO2 as working fluid: A case study in Zhacanggou, Northeastern Xizang, China. Energy Explora-tion & Exploitation, 37(2): 736-755. DOI: 10.1177/0144598718795492.
QIN Xiang-xi, ZHANG Meng, YE Jia, et al. 2019. ORC power generation and integrated cascade utilization of mediumlow temperature geothermal resources in Cangxian Bulge Region, Hebei Province. Acta Geoscientica Sinica, 40(2): 307-313. DOI: 10.3975/cagsb. 2019.011101.
SUN Zhi-xue, XU Yi, LV Shu-huan, et al. 2016. A thermo-hydro-mechanical coupling model for numerical simulation of enhanced geothermal systems. Journal of China University of Petroleum, (40)6: 107-117. 10. DOI: 10.3969/j.issn.1673-5005.2016.06.014.
SUN Zhi-xue, ZHANG Xu, XU Yi, et al. 2017. Numerical simulation of the heat extraction in EGS with thermal-hydraulic-mechanical coupling method based on discrete fractures model. Energy, 120: 20-33. DOI: 10.1016/j.energy.2016.10.046.
WANG Xiao-xing, WU Neng-you, Zhang Ke-ni, et al. 2012. Multi-field coupling for enhanced geothermal system development. Hydrogeology & Engineering Geology, 39(2): 126-130. DOI: 10.16030/j.cnki.issn.1000-3665.2012.02.030.
WANG Gui-ling, ZHANG Wei, LIN Wen-jing, et al. 2017. Research on formation mode and development potential of geothermal re-sources in Beijing-Tianjin-Hebei Region. Geology in China, 44(6): 1074-1085. DOI: 10.12029/gc20170603.
WANG Gui-ling, ZHANG Wei, MA Feng, et al. 2018. Overview on hydrothermal and hot dry rock researches in China. China Geology, 1(2):273-285. DOI: 10.31035/cg2018021.
WANG Gui-ling, LIU Gui-hong, ZHAO Zhi-hong, et al. 2019. A robust numerical me-thod for modeling multiple wells in city-scale geothermal field based on simplified one-dimensional well model. Renewable Energy, 139: 873-894. DOI: 10.1016/j. renene. 2019.02.131.
WANG Jun-ke, ZHU Xi, LIU Yan-guang, et al. 2020. Study on earth temperature field characteristics and heat controlling factors in geothermal field of Xianxian County. China Energy and Environmental Protection, 42(1): 113-120. DOI: 10.19389/j.cnki.1003-0506.2020.01.025.
WANG Shu-fang, LIU Jiu-rong, LIN Pei, et al. 2013. A study of reinjection experiment and tracer test in a karst geothermal reservoir. Hydrogeology & Engineering Geology, 40(6): 129-133. DOI: 10.16030/j.cnki.issn.1000-3665.2013.06.025.
Zhang K, Woodbury AD. 2002. A Krylov finite element approach for multi-species con-taminant transport in discretely fractured porous media. Advances in Water Resources, 25(7): 705-721. DOI: 10.1016/S0309-1708(02)00084-2.
ZHANG Shu-guang, LI Zhi-jian, XU Yi-hong, et al. 2011. Three-dimensional numerical simulation and analysis of fluid-heat coupling heat-transfer in fractured rock mass. Rock and Soil Mechanics, (32)8: 2507-2511. DOI: 10.16285/j.rsm.2011.08.022.
ZHAO Yang-sheng, WANG Rui-feng, HU Yao-qing, et al. 2002. 3D numerical simula-tion for coupled THM of rock matrix-fra-ctured media in heat extraction in HDR. Chinese Journal of Rock Mechanics and Engineering, (21)12: 1751-1755. DOI: 10.3321/j.issn:1000-6915.2002.12.001.
ZHAO Yan-lin, WANG Wei-jun, CAO Ping, et al. 2010. Numerical implementation of discontinuities in dual media 3D model for thermo-hydro-mechanical coupling. Rock and Soil Mechanics, 31(2): 638-644. DOI: 10.16285/j.rsm.2010.02.031.
ZHAO Zhi-hong, LIU Gui-hong, TAN Xian-feng, et al. 2017. Theoretical model of geothermal tail water reinjection based on the equivalent seepage channel model. Hydrogeology & Engineering Geology, 44(3): 158-164. DOI: 10.16030/j.cnki.issn.1000-3665.2017.03.23.
ZHAO Zhi-hong, LIU Gui-hong, XU Hao-ran. 2020. A robust numerical modeling framework for coupled thermo-hydro-mechanical process in deep geoenergy engineering. Engineering Mechanics, 37(6): 1-18. DOI: 10.6052/j.issn. 1000-4750.2019.05.ST09.
-
