Potential assessment of CO2 geological storage based on injection scenario simulation: A case study in eastern Junggar Basin
-
Abstract:
Carbon Capture and Storage (CCS) is one of the effective means to deal with global warming, and saline aquifer storage is considered to be the most promising storage method. Junggar Basin, located in the northern part of Xinjiang and with a large distribution area of saline aquifer, is an effective carbon storage site. Based on well logging data and 2D seismic data, a 3D heterogeneous geological model of the Cretaceous Donggou Formation reservoir near D7 well was constructed, and dynamic simulations under two scenarios of single-well injection and multi-well injection were carried out to explore the storage potential and CO2 storage mechanism of deep saline aquifer with real geological conditions in this study. The results show that within 100 km2 of the saline aquifer of Donggou Formation in the vicinity of D7 well, the theoretical static CO2 storage is 71.967 × 106 tons (P50)①, and the maximum dynamic CO2 storage is 145.295 × 106 tons (Case2). The heterogeneity of saline aquifer has a great influence on the spatial distribution of CO2 in the reservoir. The multi-well injection scenario is conducive to the efficient utilization of reservoir space and safer for storage. Based on the results from theoretical static calculation and the dynamic simulation, the effective coefficient of CO2 storage in deep saline aquifer in the eastern part of Xinjiang is recommended to be 4.9%. This study can be applied to the engineering practice of CO2 sequestration in the deep saline aquifer in Xinjiang.
-
-
Table 1. Recommended values for
$ {E_{{\text{saline}}}} $ (DOE-NETL, 2010; Bachu, 2015)Lithology P10/% P50/% P90/% Clasolite 1.2 2.4 4.1 Dolomite 2.0 2.7 3.6 Limestone 1.3 2.0 2.8
下载: 导出CSV
Table 2. CO2 sequestration capacity based on static modelling result
P10 P50 P90 Total volume of rocks(m3) 3.255 1×1010 3.255 1×1010 3.255 1×1010 Storage volume (m3) 4.327×109 4.327×109 4.327×109 Formation temperature (℃) 66 66 66 Formation pressure (MPa) 20.6 20.6 20.6 CO2 density (kg/m3) 693 693 693 Storage capacity (million tons) 35.98 71.97 122.94
下载: 导出CSV
Table 3. The total amount of CO2 injection and its occurrence forms
CO2 Storage Amounts in Reservoir Case Million tons Percentage/% Total injection Case1 84.414 100.00 Supercritical gas 73.234 86.76 Residual trapping gas 19.813 23.47 Dissolved gas in water 11.180 13.24 Total trapping gas 31.063 36.71 Total injection Case 2 84.414 100.00 Supercritical gas 68.437 81.07 Residual trapping gas 22.063 26.14 Dissolved gas in water 15.977 18.93 Total trapping gas 38.077 45.07 Notes：The proportions of CO2 in different phases to the total injection volume in the saline aquifer are given in the table. In both scenarios, the total amount of CO2 injection is the same, and total trapping gas mainly consists of residual trapping gas + dissolved gas in saline water. The proportion of total trapping gas in Case 1 is 8.36% lower than that in Case 2, which is equivalent to 7.057 million tons of CO2. The injection mode of Case 2 has more advantages in this regard, but the storage capacity of the two scenarios is the same.
下载: 导出CSV
Table 4. Maximum dynamic storage potential of CO2 in Case 1 and Case 2
Case Total injection/Million tons Injection duration/yr Storage efficiency/% Case1 135.919 81 4.5 Case2 145.295 95 4.9
下载: 导出CSV
-
[1] Bachu S. 2015. Review of CO2 storage efficiency in deep saline aquifers. International Journal of Greenhouse Gas Control, 40: 188-202. doi: 10.1016/j.ijggc.2015.01.007
[2] Bachu S, Adams JJ. 2003. Sequestration of CO2 in geological media in response to climate change: Capacity of deep saline aquifers to sequester CO2 in solution. Energy Conversion and Management, 44(20): 3151-3175. doi: 10.1016/S0196-8904(03)00101-8
[3] Bachu S, Bonijoly D, Bradshaw J, et al. 2007. CO2 storage capacity estimation: Methodology and gaps. International Journal of Greenhouse Gas Control, 1(4): 430-443. doi: 10.1016/S1750-5836(07)00086-2
[4] CSLF(Carbon Sequestration Leadership Forum). 2005. “Phase I Final report from the task force for review and identification of standards for CO2 storage capacity measurement, prepared by the task force on CO2 storage capacity estimation for the technical group of the Carbon Sequestration Leadership Form August”. Technology Report: edition 22.
[5] CSLF(Carbon Sequestration Leadership Forum), 2007. “Estimation of CO2 storage capacity in geological media (Phase), Prepared by the task force on CO2 storage capacity estimation for the technical group of the Carbon Sequestration Leadership Form 15 June ”. Technology Report: edition 24.
[6] CSLF (Carbon Sequestration Leadership Forum), 2010. Task Force for Review and Identification of Standards for CO2 Storage Capacity Estimation.
[7] De Silva PNK, Ranjith PG. 2012. A study of methodologies for CO2 storage capacity estimation of saline aquifers. Fuel, 93: 13-27. doi: 10.1016/j.fuel.2011.07.004
[8] Diao YJ, Zhu GW, Cao H, et al. 2017. Mesoscale assessment of CO2 storage potential and geological suitability for target area selection in the Sichuan Basin. Geofluids, 2017(1): 1-17. doi: 10.1155/2017/9587872
[9] DOE-NETL. 2006. Carbon Sequestration Atlas of the United States and Canada.
[10] DOE-NETL. 2008. Carbon Sequestration Atlas of the United States and Canada, 2nd edition.
[11] DOE-NETL. 2010. Carbon Sequestration Atlas of the United State and Canada, 3rd edition.
[12] Flett M, Gurton R, Weir G. 2007. Heterogeneous saline formations for carbon dioxide disposal: Impact of varying heterogeneity on containment and trapping. Journal of Petroleum Science and Engineering, 57(1-2): 106-118. doi: 10.1016/j.petrol.2006.08.016
[13] GCCSI. THE GLOBAL STATUS OF CCS. 2016. Available on https://www.globalccsinstitute.com/ resources/publications-reports-research/the-global-status-of-ccs-2016-summary-report/.
[14] Goodman A, Hakala A, Bromhal G, et al. 2011. US DOE methodology for the development of geologic storage potential for carbon dioxide at the national and regional scale. International Journal of Greenhouse Gas Control, 5(4): 952-965. doi: 10.1016/j.ijggc.2011.03.010
[15] Guo JQ, Wen DG, Zhang SQ, et al. 2015. Potential and suitability evaluation of CO2 geological storage in major sedimentary basins of China. Acta Geological Sinica (English Edition), 89(4): 1319-1332. doi: 10.1111/1755-6724.12531
[16] He K, Zhu YS, Wang Z, et al. 2002. The Reservoir -Forming Conditions and Analyses of CretaceousExploration Prospect in the East of Junggar Basin. Journal of Xinjiang Petroleum Institute, 14(2): 6-9, 80. (in Chinese) doi: 10.3969/j.issn.1673-2677.2002.02.002
[17] IPCC. 2005. Special Report on Carbon Dioxide Capture and Storage.
[18] Jin C, Liu LT, Li YM, et al. Capacity assessment of CO2 storage in deep saline aquifers by mineral trapping and the implications for Songliao Basin, Northeast China. Energy Science & Engineering, 2017, 5(2): 81-89.
[19] Lee H, Seo J, Lee Y, et al. 2016. Regional CO2 solubility trapping potential of a deep saline aquifer in Pohang basin, Korea. Geosciences Journal, 20(4): 561-568. doi: 10.1007/s12303-015-0068-4
[20] Li PC, Zhou D, Zhang CM, et al. 2015. Assessment of the effective CO2, storage capacity in the Beibuwan Basin, offshore of southwestern PR China. International Journal of Greenhouse Gas Control, 37: 325-339. doi: 10.1016/j.ijggc.2015.03.033
[21] Li Q, Chen ZA, Zhang JT, et al. 2016. Positioning and revision of CCUS technology development in China. International Journal of Greenhouse Gas Control, 46: 282-293. doi: 10.1016/j.ijggc.2015.02.024
[22] Li Q, Wei YN, Liu G, et al. 2015. CO2-EWR: A cleaner solution for coal chemical industry in China. Journal of Cleaner Production, 103: 330-337. doi: 10.1016/j.jclepro.2014.09.073
[23] Li Q, Wei YN, Liu GZ, et al. 2014. Combination of CO2 geological storage with deep saline water recovery in western China: Insights from numerical analyses. Applied Energy, 116: 101-110. doi: 10.1016/j.apenergy.2013.11.050
[24] Li XC, Liu YF, Bai BF, et al. 2006. Ranking and screening of CO2 saline aquifer storage zones in China. Chinese Journal of Rock Mechanics and Engineering, 25(5): 963-968. (in Chinese) doi: 10.3321/j.issn:1000-6915.2006.05.015
[25] Liu DQ, Li YL, Song SY, et al. 2016. Simulation and analysis of lithology heterogeneity on CO2 geological sequestration in deep saline aquifer: A case study of the Ordos Basin. Environmental Earth Sciences, 75(11): 1-13. doi: 10.1007/s12665-016-5754-7
[26] Ma X, Li XF, Yang GD, et al. 2018. Study on Field-scale of CO2 Geological Storage Combined with Saline Water Recovery: A Case Study of East Junggar Basin of Xinjiang. Energy Procedia, 154: 36-41. doi: 10.1016/j.egypro.2018.11.007
[27] Mi ZX, Wang FG, Yang YZ, et al. 2018. Evaluation of the potentiality and suitability for CO2 geological storage in the Junggar Basin, northwestern China. International Journal of Greenhouse Gas Control. 78: 62-72.
[28] Oh J, Kim K Y, Han WS, et al. 2013. Experimental and numerical study on supercritical CO2/brine transport in a fractured rock: Implications of mass transfer, capillary pressure and storage capacity. Advances in Water Resources, 62(12): 442-453. doi: 10.1016/j.advwatres.2013.03.007
[29] Thomas MW, Stewart M, Trotz M, et al. 2012. Geochemical modeling of CO2, sequestration in deep, saline, dolomitic-limestone aquifers: Critical evaluation of thermodynamic sub-models. Chemical Geology, 306-307: 29-39. doi: 10.1016/j.chemgeo.2012.02.019
[30] Wang Y, Guo CH, Zhuang SR , et al. 2021. Major contribution to carbon neutrality by China’s geosciences and geological technologies. China Geology, 4: 329-352. doi: 10.31035/cg2021037
[31] Wen DG, Ma X, Wang LQ, et al. 2019. Combined study of static and dynamic reservoir modelling for the CO2 storage project in deep saline aquifer in Zhundong, Xinjiang, China. In 14th Greenhouse Gas Control Technologies Conference Melbourne 21-26 October 2018 (GHGT-14). Melbourne. Social Science Electronic Publishing.
[32] Wen DG, Guo JQ, Jia XF, et al. 2013. The progress of carbon dioxide geological storage research and pilot project in China. Acta Geologica Sinica, 87: 971. (in Chinese)
[33] Xu TF, Kharaka YK, Doughty C, et al. 2010. Reactive transport modeling to study changes in water chemistry induced by CO2 injection at the Frio-I Brine Pilot. Chemical Geology, 271: 153-164. doi: 10.1016/j.chemgeo.2010.01.006
[34] Yang ZJ, Xu TF, Wang FG, et al. 2019. A study on the CO2-Enhanced water recovery efficiency and reservoir pressure control strategies. Geofluids: 1-17. doi: 10.1155/2019/6053756
-
