基于综合物探的城市地下空间探测与建模

,  ,  ,  ,  ,

文章导航 > 西北地质 > 2019 > 52(2): 83-94

上一篇

下一篇

王亚辉, 张茂省, 师云超, 董英, 王锋, 于峰丹. 2019. 基于综合物探的城市地下空间探测与建模. 西北地质, 52(2): 83-94. doi: 10.19751/j.cnki.61-1149/p.2019.02.009
引用本文: 王亚辉, 张茂省, 师云超, 董英, 王锋, 于峰丹. 2019. 基于综合物探的城市地下空间探测与建模. 西北地质, 52(2): 83-94. doi: 10.19751/j.cnki.61-1149/p.2019.02.009
shu
WANG Yahui, ZHANG Maosheng, SHI Yunchao, DONG Ying, WANG Feng, YU Fengdan. 2019. Precise Detection and Modeling of Urban Underground Space Based on Integrated Geophysical Exploration. Northwestern Geology, 52(2): 83-94. doi: 10.19751/j.cnki.61-1149/p.2019.02.009
Citation: WANG Yahui, ZHANG Maosheng, SHI Yunchao, DONG Ying, WANG Feng, YU Fengdan. 2019. Precise Detection and Modeling of Urban Underground Space Based on Integrated Geophysical Exploration. Northwestern Geology, 52(2): 83-94. doi: 10.19751/j.cnki.61-1149/p.2019.02.009
shu

基于综合物探的城市地下空间探测与建模

  • 1. 陕西地矿物化探队有限公司, 陕西 西安 710043;

  • 2. 中国地质调查局西安地质调查中心/西北地质科技创新中心, 自然资源部黄土地质灾害重点实验室, 陕西 西安 710054

  • 基金项目:

    国家重点研发项目（2018YFC1504700），国家自然科学基金重点项目（41641011、41530640），中国地质调查局项目（DDT20190463、DD20160261、DD20189270）联合资助

详细信息
    作者简介: 王亚辉(1979-),男,陕西武功人,工程师,主要从事地球物理勘探应用与研究工作。E-mail:10075344@qq.com
    通讯作者: 张茂省(1962-),男,陕西咸阳人,研究员,博导,主要从事水工环地质调查与研究。E-mail:xazms@126.com

  • 中图分类号: P631

Precise Detection and Modeling of Urban Underground Space Based on Integrated Geophysical Exploration

  • 1. Shaanxi Geology and Mining Geophysical and Geochemical Exploration Team Co. Ltd., Xi'an 710043, Shaanxi, China;

  • 2. Key Laboratory for Geo-hazards in Loess Area, MNR, Xi'an Center of China Geological Survey/Northwest China Center for Geoscience Innovation, Xi'an 710054, Shaanxi, China

More Information

    摘要
  • 地下空间开发利用是解决城市诟病的有效途径，城市强干扰环境下地下空间精准探测已成为多学科交叉研究的热点，也是当前研究的难点。以大西安西咸新区为研究区，采用钻孔揭露、实验测试、多参数地球物理测井、地面地球物理勘探组合方法开展了地下空间精准探测与建模研究。通过综合地球物理勘探，获取了每层土体的多参数地球物理特征。结合钻孔揭露与实验测试资料，建立了基于钻孔资料的地面物探与测井校准与耦合，为地下空间地质结构模型赋予了物理属性。提出高密度电法、微动台阵观测和浅层地震勘探与多参数地球物理测井方法相结合，可作为城市强干扰环境下地下空间物探工作的最优方法组合。
    Underground space development and utilization is an effective way to solve urban rickets. The precise detection of underground space under strong urban interference has become a hot topic in multidisciplinary research and also serves as the difficulty of current research. Taking Xi'an-Xianyang New District as the study area, the research on accurate detection and modeling of underground space has been carried out by using borehole exposure, experimental test, multi-parameter geophysical logging and ground geophysical exploration combined method. Multi-parameter geophysical characteristics of each layer of soil have been acquired through using integrated geophysical exploration. Based on the drilling exposure and experimental test data, the ground geophysical and logging calibration and coupling have been established based on drilling data, and then the physical properties have been assigned to the underground space geological structure model. It is proposed that high-density electrical method, micro-motion array observation and shallow seismic exploration combined with multi-parameter geophysical logging method can be used as the optimal combination method for underground space geophysical exploration under strong urban interference environment.
    • HTML全文
  • 加载中
    • 参考文献(16)

  • 张茂省,王化齐,王尧,等.中国城市地质调查进展与展望[J].西北地质,2018,51(4):11-13.

    ZHANG Maosheng, WANG Huaqi, WANG Yao, et al. Progress and prospect of urban geological survey in China[J]. Northwest Geology, 2008, 51(4):11-13.

    金荣杰.智能微动勘探技术在城市地下空间地质调查中的应用[J].工程勘察,2017,12(2):19-24.

    JIN Rongjie.Application of Intelligent Micro-motion Exploration Technology in Urban Underground Space Geological Survey[J].Geotechnical Investigation& Surveying,2017,12(2):19-24.

    张茂省,董英,刘洁.论新型城镇化中的城市地质工作[J].兰州大学学报,2014,50(5):580-588.

    ZHANG Maosheng, DONG Ying, LIU Jie. Discussion of Urban Geological Work in New Urbanization[J]. Journa of Lanzhou University, 2014,50(5):580-588.

    李继军,汪启年.重磁电综合解释方法在天津城市三维地质结构调查中的应用[J].物探与化探,2007,31(5):21-26.

    LI Jijun,WANG Qinian.Application of Gravity and Magnetoelectric Comprehensive Interpretation Method in 3D Geological Structure Survey of Tianjin City[J].Geophysical and Geochemical Exploration, 2007,31(5):21-26.

    曹积飞,李红阳,李英杰,等.综合物探方法在内蒙灰山铜镍矿找矿中的应用研究[J].西北地质,2011,44(1):52-58.

    CAO Jifei,LI Hongyang,LI Yingjie, et al.Application of integrated geophysical prospecting method in prospecting Cu-Ni deposit of the Ultrabasic type in Huishan,Inner`Mongolia[J].Northwest Geology,2011, 44(1):52-58.

    张茂省.大西安城市地质调查与地下空间应用实施方案[R].西安:中国地质调查局西安地质调查中心,2016.

    ZHANG Maosheng. Large Xi'an Urban Geological Survey and Underground Space Application Implementation Plan[R]. Xi'an:Xi'an Geological Survey Center, China Geological Survey, 2016.

    程光华.中国城市地质调查丛书[M].北京:科学出版社,2013.

    CHENG Guanghua. China Urban Geological Survey Series[M]. Beijing:Science Press, 2013.

    陈麒玉,刘刚,吴冲龙,等.城市地质调查中知识驱动的多尺度三维地质模型构建方法[J].地理与地理信息科学,2016,32(4):33-37.

    CHEN Qiyu,LIU Gang,WU Chonglong, et al. Knowledge-Driven multiple scale 3D geological modeling method in urban geological survey[J].Geography and Geo-Information Science, 2016, 32(4):33-37.

    • 相关文章
  • 施引文献
  • 资源附件(0)
  • 加载中
计量
  • 文章访问数:  1555
  • PDF下载数:  853
  • 施引文献:  0
出版历程
收稿日期:  2018-12-22
修回日期:  2019-04-10
