Controlling factors and their geological significances of order degrees and unit-cell parameters of dolomites in the Middle Jurassic Buqu Formation in Qiangtang Basin
-
摘要: 研究羌塘盆地中侏罗统布曲组白云岩有序度和晶胞参数的特征、影响因素及地质意义。在前期对白云岩详细分类的基础上，通过X射线粉晶衍射方法进行测试，用jade 6.5软件对测试结果进行处理，获取白云石的最大晶面间距、有序度、晶胞参数等信息，探讨其影响因素及地质意义，结果表明：（1）北羌塘坳陷西南缘唢呐湖地区颗粒白云岩具低—中等的有序度，晶胞参数较为集中，可能是蒸发潟湖环境中发育的颗粒灰岩为高镁方解石，在经历埋藏过程的调整白云石化作用而成；（2）南羌塘坳陷古油藏带布曲组白云岩中，微—粉晶白云岩有序度、晶胞参数分布范围大，为灰岩在准同生阶段快速交代、在埋藏阶段重结晶形成；细晶白云岩有序度较高，晶胞参数呈正相关，发育在稳定的埋藏环境中，白云石晶体在继承先驱灰岩孔隙中自由生长而成；中—粗晶白云岩有序度最高，是在中—深埋藏阶段，经历了足够长久的白云石化作用过程，有限的空间限制了晶体的自由生长；微—粉晶白云岩→细晶白云岩→中—粗晶白云岩的有序度逐渐增高，表明稳定的埋藏过程有利于白云石向有序转化；（3）布曲组白云岩晶胞参数a、c以不同程度向理想白云石左下方偏移，说明布曲组白云岩形成以后经历了强烈的构造挤压，估算压力可达1000MPa，与晚白垩世的构造运动有关，指示南羌塘坳陷布曲组白云岩古油藏是由逆冲推覆运动造成的。Abstract: This paper discusses the characteristics, controlling factors and geological significances of the order degrees and unit cell parameters of the Middle Jurassic Buqu Formation dolomites in Qiangtang Basin. Basing on the detailed classification of dolomites in the early stage, the X-ray powder diffraction method is used to test the dolomite, and the Jade 6.5 software is used to process the test results. The maximum crystal plane spacing, order degrees, unit cell parameters and relevant information of dolomite are obtained, and the controlling factors and geological significance are discussed. The results show that: (1) The grain dolomites in Suona Lake area of the north Qiangtang Depression, which are with low to medium order degrees and concentrated unit cell parameters, develops in an evaporation lagoon environment from high magnesium calcites by the adjustment of dolomitization during the burial process; (2) To the dolomites of the Buqu Formation in the South Qiangtang Depression, the micro-powder crystalline dolomites with a large distribution range of order degrees and unit cell parameters are formed by rapid metasomatism of limestone in penesynchronous stage and recrystallization in burial stage; The fine-grained dolomites with a high degree of order and a positive correlation of unit cell parameters develop in a stable burial environment and the dolomite crystals grow freely in the pores of the inherited limestone; The medium-coarser-grained dolomite, whose degree of order is the highest, has experienced a long process of dolomitization in the middle-deep burial stage, and the narrow spaces limit the free growth of crystals. From micro-powder dolomite to fine-grain dolomite to medium-coarser-grain dolomite, the order degree of dolomites increases gradually, indicating that the stable burial process is conducive to the orderly transition of dolomites. (3) The “a” and “c” of unit cell parameters of the Buqu Formation dolomites shifted to the lower left of the ideal dolomite in different degrees, indicating that the Buqu Formation dolomites experienced a strong tectonic compression with an estimated pressure up to 1000 MPa after its formation, which is related to the tectonic movement of the late Cretaceous. It is suggested that the dolomite paleo-oil reservoir of Buqu Formation in southern Qiangtang Depression is caused by the thrust nappe tectonic movement.
-
Key words:
- Qiangtang Basin /
- Buqu Formation /
- dolomitization /
- order degree of dolomite /
- unit-cell parameters
-
-
Fuchtbauer H, 1974. Sediments and sedimentary rocks [M]//Engelhardt W V, Fuchtbauer H, Muller G. Sedimentary petrology. New York-Toronto-Sydney: Halsted Press Division, John Wiley & Sons, Inc., 303-305.
Goldsmith J R, Graf D L, 1958. Structural and compositional variations in some natural dolomites [J]. Journal of Geology, 66(6):678-693.
Goldsmith J R, Graf D L, Heard H C, 1961.Lattice constants of the calcium magnesium carbonates [J]. American Mineralogist, 46(3-4):453-459.
Goldsmith J R, Graf D L, Joensuu O I, et al., 1955.The occurrence of magnesian calcites in nature [J]. Geochimica and Cosmochimica Acta, 7(5-6): 212-228, 229-230.
Machel H G, Mountjoy Eric W, 1986. Chemistry and environments of dolomitization-A reappraisal [J]. Earth-Science Reviews, 23(3):175-222.
Machel H G, 2004. Concepts and models of dolomitization: A critical ceappraisal [J]. Geological Society London Special Publications, 235(1):7-63.
Mckenzie J A, Vasconcelos C, 2009. Dolomite mountains and the origin of the dolomite rock of which they mainly consist: Historical developments and new perspectives [J]. Sedimentology, 56(1):205-219.
Reeder R J, Markgraf S A, 1986. High-temperature crystal chemistry of dolomite [J]. American Mineralogist, 71(5):795-804.
Reeder R J, Wenk H R, 1983. Structure refinements of some thermally disordered dolomites [J]. American Mineralogist, 68(7):769-776.
Rosen M R, Miser D E, Starcher M A, et al., 1989. Formation of dolomite in the coorong region, south Australia [J]. Geochimicaet Cosmochimica Acta, 53(3):661-669.
Ross N L, Reeder R J, 1992. High-pressure structural study of dolomite and ankerite [J]. American Mineralogist, 77(3):412-421.
Warren J, 2000. Dolomite: occurrence, evolution and economically important associations [J].Earth-Science Reviews, 52(1):1-81.
Wu Z H, Hu D G, Ye P S, et al., 2004. Thrusting of the north Lhasa Block in the Tibetan plateau [J]. Acta Geologica Sinica, 78(1): 246-259.
Wu Z H, Hu D G, Ye P S, et al., 2013a. Early Cenozoic tectonics of the Tibetan plateau [J]. Acta Geologica Sinica, 87(2): 289-303.
Wu Z H, Ye P S, Barosh P J, et al., 2013b. Early Cenozoic multiple thrusts in the Tibetan plateau [J]. Journal of Geological Research: 1-12.
Wu Z H, Patrick J, Barosh, et al., 2015. Late Cretaceous tectonic framework of the Tibetan plateau [J]. Journal of Asian Earth Sciences, 114: 693-703.
Zhao Z Z, 2000. Conditions of petroleum geology of the Qiangtang Basin of the Qianghai-Tibet Plateau [J]. Acta Geologica Sinica, 74(3): 661-665.
陈文彬, 杨平, 张予杰, 等, 2006. 南羌塘盆地扎仁古油藏白云岩储层特征及成因研究[J]. 沉积与特提斯地质, 26(2):42-46.
黄翠蓉, 张光荣, 王英华, 1987. 我国部分地区白云岩岩石矿物学研究及其意义[J]. 地质论评, 33(5):449-461.
季长军, 陈程, 吴珍汉, 等, 2000. 羌塘盆地中侏罗统砂糖状白云岩流体包裹体碳-氧同位素分析及白云岩成因机制讨论[J]. 地质论评, 66(5):1186-1198.
季长军, 吴珍汉, 刘志伟, 等, 2019. 羌塘盆地逆冲推覆构造特征及油气资源效应[J]. 地质力学学报, 25(S1): 66-71.
雷怀彦，朱莲芳, 1992. 四川盆地震旦系白云岩成因研究[J]. 沉积学报, 10(2):69-78.
李鑫, 伊海生, 金峰, 等, 2018. 羌塘盆地隆鄂尼-昂达尔错古油藏带白云岩成岩特征[J]. 成都理工大学学报(自然科学版), 45(2): 142-153.
李亚林, 王成善, 伊海生, 等, 2006. 西藏北部新生代大型逆冲推覆构造域唐古拉山的隆起[J]. 地质学报, 80(8): 1118-1130, 1234.
刘池阳, 杨兴科, 魏永佩, 等, 2002. 藏北羌塘盆地西部查桑地区结构与构造特征[J]. 地质论评, 48(6):593-602.
刘集银，王自友, 1988. 白云石的晶体结构特征和X-射线研究[J]. 矿物岩石, 8(1):30-35.
刘建清,陈文彬,杨平,等,2008a. 羌塘盆地中央隆起带南侧隆额尼-昂达尔错古油藏白云岩地球化学特征及成因意义[J].岩石学报,24(6):1379-1469.
刘建清,陈文斌,杨平,等,2008b. 羌塘盆地隆额尼-昂达尔错古油藏的白云岩组构特征及铅同位素意义[J]. 地球学报,29(1):72-80.
刘建清,贾保江,杨平,等,2008c.羌塘盆地中央隆起带南侧隆额尼-昂达尔错布曲组古油藏白云岩稀土元素特征及成因意义[J].沉积学报,26(1):29-37.
刘建清,杨平,陈文彬,等,2010.羌塘盆地中央隆起带南侧隆鄂尼-昂达尔错布曲组古油藏白云岩特征及成因机制[J].地学前缘,17(1):312-321.
孙伟, 陈明, 万友利, 等, 2020. 封闭系统中的白云石化作用过程及其油气地质意义——以南羌塘坳陷中侏罗统布曲组白云岩为例[J]. 地质论评, 66(5):1217-1229.
谭富文, 张润合, 王剑, 等, 2016. 羌塘晚三叠世-早白垩世裂陷盆地基底构造[J]. 成都理工大学学报(自然科学版), 43(5):513-521.
万友利, 王剑, 付修根, 等, 2018a. 羌塘盆地南部古油藏带布曲组白云岩地球化学特征及成因机制[J]. 成都理工大学学报(自然科学版), 45(2):4-16.
万友利, 王剑, 付修根, 等, 2018b. 羌塘盆地南坳陷古油藏带中侏罗统布曲组白云岩元素地球化学特征及意义[J]. 沉积与特提斯地质, 38(2):25-37.
万友利, 王剑, 谭富文, 等, 2017. 羌塘盆地隆鄂尼-昂达尔错地区布曲组白云岩储层成因及孔隙演化特征[J]. 东北石油大学学报, 41(3):21-33.
王剑, 付修根, 沈利军, 等, 2020. 论羌塘盆地油气勘探前景[J]. 地质论评, 66(5):1091-1113.
王茂林, 周进高, 陈冬霞, 等, 2013. 白云石成因模式的研究进展及其适用性探讨[J]. 海相油气地质, 18(2):31-40.
王兴涛,张庆石,张吉,等,2000. 青藏高原中生界白云岩特征研究及成因分析[J].沉积学报, 18(4):555-559.
王泽宇, 乔占峰, 寿芳漪, 等, 2020. 塔里木盆地永安坝剖面蓬莱坝组白云岩成因与形成过程——来自有序度和晶胞参数的证据[J]. 天然气地球科学, 31(5):602-611.
吴珍汉, 刘志伟, 赵珍, 等, 2016. 羌塘盆地隆鄂尼-昂达尔错古油藏逆冲推覆构造隆升[J]. 地质学报, 90(4): 615-627.
伊海生, 陈志勇, 季长军, 等, 2014. 羌塘盆地南部地区布曲组砂糖状白云岩埋藏成因的新证据[J].岩石学报, 30(3):737-782.
伊海生, 高春文,张小青, 等, 2004. 羌塘盆地双湖地区古油藏白云岩储层的显微成岩组构特征及意义[J]. 成都理工大学学报(自然科学版), 31(6):611-615.
由雪莲, 贾文强, 徐帆, 等, 2018. 铁白云石矿物学特征及原生次生成因机制[J]. 地球科学, 43(11):4046-4055.
曾理, 万茂霞, 彭英, 2004. 白云石有序度及其在石油地质中的应用[J]. 天然气勘探与开发, 27(4):64-66.
张杰, Jones B, 潘立银, 等, 2014a. 四川盆地震旦系灯影组葡萄状白云岩成因[J]. 古地理学报, 16(5):715-725.
张杰, Jones B, 张建勇, 2014b. 不同埋藏深度交代白云石晶体结构及其对白云岩储层研究的意义[J]. 中国石油勘探, 19(3):21-28.
张杰, 寿建峰, 张天付, 等, 2014c. 白云石成因研究新方法——白云石晶体结构分析[J]. 沉积学报, 32(3):550-559.
张立强, 纪友亮, 李永铁, 等, 2001. 羌塘盆地侏罗系白云岩储层特征研究[J]. 石油实验地质, 23(4): 384-389.
张小青,伊海生,朱迎堂,等, 2005. 羌塘盆地双湖地区白云岩储集层特征研究[J].西南石油学院学报,27(5):10-13.
郑剑锋, 沈安江, 乔占峰, 等, 2013. 塔里木盆地下奥陶统蓬莱坝组白云岩成因及储层主控因素分析——以巴楚大班塔格剖面为例[J]. 岩石学报, 29(9):3223-3232.
郑剑锋, 沈安江, 乔占峰, 等, 2014. 柯坪-巴楚露头区蓬莱坝组白云岩特征及孔隙成因[J]. 石油学报, 35(4):56-64.
钟倩倩, 黄思静, 邹明亮, 等, 2009. 碳酸盐岩中白云石有序度的控制因素——来自塔河下古生界和川东北三叠系的研究[J]. 岩性油气藏, 21(3):50-55.
朱井泉，李永铁, 2000. 藏北羌塘盆地侏罗系白云岩类型、成因及油气储集特征[J]. 古地理学报, 2(4):30-41.
-
