硫酸和硫酸铝对钡渣的无害化影响

,  ,  ,  ,  ,

文章导航 > 矿产综合利用 > 2022 > 43(5): 37-41

上一篇

下一篇

陈雁冰, 龙召凤, 李仕玉, 曾庆果, 王海峰, 王家伟. 硫酸和硫酸铝对钡渣的无害化影响[J]. 矿产综合利用, 2022, 43(5): 37-41. doi: 10.3969/j.issn.1000-6532.2022.05.007
引用本文: 陈雁冰, 龙召凤, 李仕玉, 曾庆果, 王海峰, 王家伟. 硫酸和硫酸铝对钡渣的无害化影响[J]. 矿产综合利用, 2022, 43(5): 37-41. doi: 10.3969/j.issn.1000-6532.2022.05.007
shu
Chen Yanbing, Long Zhaofeng, Li Shiyu, Zeng Qingguo, Wang Haifeng, Wang Jiawei. Harmless Effect of Sulfuric Acid and Aluminum Sulfate on Barium Slag[J]. Multipurpose Utilization of Mineral Resources, 2022, 43(5): 37-41. doi: 10.3969/j.issn.1000-6532.2022.05.007
Citation: Chen Yanbing, Long Zhaofeng, Li Shiyu, Zeng Qingguo, Wang Haifeng, Wang Jiawei. Harmless Effect of Sulfuric Acid and Aluminum Sulfate on Barium Slag[J]. Multipurpose Utilization of Mineral Resources, 2022, 43(5): 37-41. doi: 10.3969/j.issn.1000-6532.2022.05.007
shu

硫酸和硫酸铝对钡渣的无害化影响

  • 贵州大学材料与冶金学院，贵州　贵阳　550025

  • 基金项目: 国家基金（51764006、51864012）；贵州省计划项目（黔科合平台人才[2017]5788号，黔科合基础[2019]1411）；贵州省大学生创新创业训练计划项目（2018520044）
详细信息
    作者简介: 陈雁冰（1995-），女， 学生
    通讯作者: 王家伟（1980-），男，博士，教授，从事冶金工程的新工艺及固废综合处理

  • 中图分类号: TD989;X753

Harmless Effect of Sulfuric Acid and Aluminum Sulfate on Barium Slag

  • College of Materials and Metallurgy, Guizhou University, Guiyang, Guizhou, China

More Information

    摘要

  • 钡渣在《国家危险废物名录》的编号为HW47，目前仍以堆放为主，对环境造成了极大污染。针对此问题，研究了硫酸和硫酸铝对钡渣的无害化处理，考查了过量系数、水量和反应时间等因素对钡渣无害化效果的影响。研究结果表明：对100 g钡渣而言，当硫酸铝过量系数为1.5，水量为25 mL，反应时间为1.5 h时，无害化后钡渣浸出毒性测定的Ba2+浓度为93.75 mg/L，Ba2+去除率为88.97%；当硫酸铝过量系数为2.0，水量为25 mL，反应时间为2 h时，无害化后钡渣浸出毒性测定的Ba2+浓度为92.30 mg/L，Ba2+去除率为89.14%，均能达到GB 5085.3-2007对钡离子的毒性鉴别标准限值。相同条件下，硫酸铝的处理效果比硫酸的好，无害化剂的pH值越低，钡渣的无害化效果越差。

    Barium slag is numbered HW47 in the national hazardous waste list. At present, it is still mainly stacked, causing great environmental pollution. Aiming at this problem, the harmlessness of barium slag by sulfuric acid and aluminum sulfate was studied. The effects of excess coefficient, water amount and reaction time on the harmless effect of barium slag were investigated. The results show that, for 100 g barium slag, when the excess coefficient of aluminum sulfate was 1.5, the water volume was 25 ml, and the reaction time was 1.5 h, the concentration of Ba2+ was 93.75 mg/L and the removal rate of Ba2+ was 88.97%. When the excess coefficient of sulfuric acid was 2.0, the water volume was 25 mL, and the reaction time was 2 h, the concentration of Ba2+ was 92.30 mg/L and the removal rate of Ba2+ was 89.14%. Both of them could reach the limit of the toxicity identification standard for barium ion in GB 5085.3-2007. Under the same conditions, the treatment effect of aluminum sulfate was better than that of sulfuric acid, and the lower pH value of harmless agent was, the worse the harmless effect of barium slag was.

    • HTML全文
  • 加载中

  • 图 1  钡渣的XRD分析

    Figure 1.

    下载: 全尺寸图片 幻灯片

    图 2  钡渣SEM及面扫描照片

    Figure 2.

    下载: 全尺寸图片 幻灯片

    图 3  过量系数对无害化效果的影响

    Figure 3.

    下载: 全尺寸图片 幻灯片

    图 4  过量系数对Ba2+去除率的影响

    Figure 4.

    下载: 全尺寸图片 幻灯片

    图 5  水量对无害化效果的影响

    Figure 5.

    下载: 全尺寸图片 幻灯片

    图 6  水量对Ba2+去除率的影响

    Figure 6.

    下载: 全尺寸图片 幻灯片

    图 7  反应时间对无害化效果的影响

    Figure 7.

    下载: 全尺寸图片 幻灯片

    图 8  反应时间对Ba2+去除率的影响

    Figure 8.

    下载: 全尺寸图片 幻灯片

    表 1  钡渣的主要化学成分/%

    Table 1.  Main chemical components of barium slag

    BaSO4BaCO3SiO2FeOAl2O3BaSCaONa2O
    23.9537.9325.122.715.831.320.440.34
    下载: 导出CSV

    表 2  钡渣能谱分析成分/%

    Table 2.  Surface scanning results of barium slag

    CSiBa合计
    0.442.7586.81100.00
    下载: 导出CSV

    表 3  常温常压下几种钡盐的溶解度

    Table 3.  Solubility of several barium salts at room temperature and pressure

    名称碳酸钡砷酸钡铬酸钡草酸钡硫酸钡亚铁氰化钡
    溶解度/（g·100 cm-3）1.409×10-32.586×10-92.775×10-43×10-32.448×10-49.732×10-3
    下载: 导出CSV
    • 参考文献(11)
  • [1]

    温占玺. 利用含钡废渣制取氯化钡和硫酸钡[J]. 化工之友, 2001(4):38-39.

    WEN Z X. Using barium-containing waste residue to produce barium chloride and barium sulfate[J]. Friend of Chemical Industry, 2001(4):38-39.

    [2]

    刘攀. 钡渣理化性质分析表征及其资源化利用[D]. 贵阳: 贵州大学, 2015.

    LIU P. Analysis and characterization of the physical and chemical properties of barium slag and its resource utilization [D]. Guiyang: Guizhou University, 2015.

    [3]

    甘四洋, 陈彦翠, 贾韶辉, 等. 工业固体废弃物钡渣的资源化综合利用研究[J]. 建材发展导向, 2015, 13(4):36-38. doi: 10.16673/j.cnki.jcfzdx.2015.04.017

    GAN S Y, CHEN Y C, JIA S H, et al. Research on the comprehensive utilization of industrial solid waste barium slag[J]. Development Orientation of Building Materials, 2015, 13(4):36-38. doi: 10.16673/j.cnki.jcfzdx.2015.04.017

    [4]

    丁建础, 姚珺. 利用钡渣处理煤矿酸性废水的试验研究[J]. 矿业安全与环保, 2005(3):15-16+21. doi: 10.3969/j.issn.1008-4495.2005.03.006

    DING J C, YAO J. Experimental study on the treatment of coal mine acid wastewater by barium slag[J]. Mining Safety and Environmental Protection, 2005(3):15-16+21. doi: 10.3969/j.issn.1008-4495.2005.03.006

    [5]

    潘悝. 水泥生产中的钡渣利用[J]. 山东工业技术, 2018, 273(19):51. doi: 10.16640/j.cnki.37-1222/t.2018.19.036

    PAN K. Utilization of barium slag in cement production[J]. Shandong Industrial Technology, 2018, 273(19):51. doi: 10.16640/j.cnki.37-1222/t.2018.19.036

    [6]

    刘立柱, 贾韶辉, 王勇, 等. 钡渣在建材产品中的应用及其重金属固化效果研究[J]. 砖瓦, 2017(5):25-27. doi: 10.16001/j.cnki.1001-6945.2017.05.006

    LIU L Z, JIA S H, WANG Y, et al. Application of barium slag in building materials and its heavy metal solidification effect[J]. Brick and Tile, 2017(5):25-27. doi: 10.16001/j.cnki.1001-6945.2017.05.006

    [7]

    潘成昭, 吴雪柳. 钡渣在水泥混凝土面层中的应用研究[J]. 山西建筑, 2017(20):147-149. doi: 10.3969/j.issn.1009-6825.2017.20.076

    PAN C Z, WU X L. Research on the application of barium slag in cement concrete surface course[J]. Shanxi Architecture, 2017(20):147-149. doi: 10.3969/j.issn.1009-6825.2017.20.076

    [8]

    张杨, 李远勋, 刘少友, 等. 烧结温度对钡渣陶瓷砖结构和力学性能的影响[J]. 非金属矿, 2017, 40(4):40-43. doi: 10.3969/j.issn.1000-8098.2017.04.012

    ZHANG Y, LI Y X, LIU S Y, et al. Influence of sintering temperature on the structure and mechanical properties of barium slag ceramic tiles[J]. Non-metallic Minerals, 2017, 40(4):40-43. doi: 10.3969/j.issn.1000-8098.2017.04.012

    [9]

    荆小兵. 钡盐生产废渣处理技术研究[J]. 盐业与化工, 2013, 42(12):28-29. doi: 10.16570/j.cnki.issn1673-6850.2013.12.017

    JING X B. Research on waste residue treatment technology of barium salt production[J]. Salt Industry and Chemical Industry, 2013, 42(12):28-29. doi: 10.16570/j.cnki.issn1673-6850.2013.12.017

    [10]

    王海峰, 陈雁冰, 龙召凤, 等. 硫酸钠对钡渣的无害化效果研究[J]. 广州化工, 2020, 48(4):27-29+32. doi: 10.3969/j.issn.1001-9677.2020.04.014

    WANG H F, CHEN Y B, LONG Z F, et al. Research on the harmless effect of sodium sulfate on barium slag[J]. Guangzhou Chemical Industry, 2020, 48(4):27-29+32. doi: 10.3969/j.issn.1001-9677.2020.04.014

    [11]

    维基百科溶解度表, https://wenku.baidu.com/view/0e2d431f10a6f524ccbf85cb.html.

    Wikipedia solubility table, https://wenku.baidu.com/view/0e2d431f10a6f524ccbf85cb.html.
