Effect of Aerated Stirring Pretreatment on the Flotation Separation of Chalcopyrite and Pyrrhotite
-
摘要:
为提高黄铜矿浮选中脱除磁黄铁矿的效果，本文研究了通过充气搅拌预处理的方法实现黄铜矿和磁黄铁矿的有效分离。主要考查了加药顺序、搅拌时间和充气量与黄铜矿回收率的关系。研究结果表明，先加药再充气调浆搅拌的效果要好于后先充气搅拌后加药的效果；充气量的增加有助于提高黄铜矿回收率，并且气量达到2 m3/h后回收率变化平缓；搅拌0~35 min内黄铜矿回收率随搅拌时间增加而增加，35 min时回收率达到极高，然后变化趋于平缓。以上现象可能的原因是，磁黄铁矿的氧化消耗了矿浆中的氧气，从而造成矿浆中没有足够的氧来参与黄药与黄铜矿的吸附过程。矿浆中充入空气后，空气中的氧参与了磁黄铁矿的表面氧化，从而保证了矿浆中有足够的氧来参与黄药在黄铜矿表面的吸附过程，进而提高了黄铜矿的回收率。
Abstract:Aerated stirring pretreatment to achieve effective flotation separation of chalcopyrite and pyrrhotite has been studied in this paper. It is mainly investigated the relationship between the dosing sequence, mixing time and aeration rate and the recovery rate of chalcopyrite. The results of the study show that the effect of adding chemicals before aerated stirring is better than that of adding chemicals after aerated stirring; the increase of aeration rate helps to increase the recovery rate of chalcopyrite, and the recovery rate changes gentle after the rate reaches 2 m3/h ; the recovery rate of chalcopyrite increases with the increase of stirring time within 0~35 min of stirring, and the recovery rate reaches highest at 35 min and then tends to be gentle. The possible reason for the analysis of the above phenomenon is that the oxidation of pyrrhotite consumes the oxygen in the pulp, resulting in insufficient oxygen in the pulp to participate in the adsorption process of xanthate on chalcopyrite surface. After the slurry is filled with air, the oxygen in the air participates in the surface oxidation of pyrrhotite, thereby ensuring that there is enough oxygen in the slurry to participate in the adsorption process of xanthate on the surface of chalcopyrite, thereby increasing the chalcopyrite’s recovery rate.
-
Key words:
- Aeration /
- Recovery /
- Pulp /
- Absorption /
- Oxygen
-
-
表 1 矿石的主要化学成分/%
Table 1. Main chemical composition of the ore
Cu Zn Pb Sn Cd In TFe Fe2+/S2- FeO Fe2O3 SiO2 TiO2 0.16 4.43 0.0065 0.088 0.015 0.0025 22.93 6.72 20.42 0.49 30.11 0.29 Al2O3 CaO MgO MnO Na2O K2O P As S C 烧失 Ag* 6.00 10.80 4.83 0.62 0.053 0.30 0.12 0.30 6.80 0.67 4.30 12.76 *单位为g/t。
下载: 导出CSV
表 2 矿石中主要矿物的含量/%
Table 2. Content of the main minerals in the ore
黄铜矿 铜蓝 闪锌矿 磁黄
铁矿黄铁矿 锡石 褐铁矿 石英 斜长石 辉石
角闪石绿泥石 绢云母
黑云母方解石 其他 0.43 微量 7.81 10.16 0.34 0.12 0.16 3.70 13.47 8.28 40.34 9.26 5.43 0.50
下载: 导出CSV
表 3 矿石中铜的化学物相分析结果
Table 3. Results of chemical phase analysis of copper in the ore
名称 原生
硫化铜次生
硫化铜自由
氧化铜结合
氧化铜合计 含量//% 0.145 0.006 0.0012 0.0078 0.16 分布率//% 90.63 3.75 0.75 4.87 100.00
下载: 导出CSV
-
[1] 孙若凡, 刘丹, 杜钰, 等. 黄铜矿、方铅矿分离研究现状及进展[J]. 矿产综合利用, 2021(4):80-86. doi: 10.3969/j.issn.1000-6532.2021.04.012
SUN R F, LIU D, DU Y, et al. Research status and development of separation of chalcopyrite and galena[J]. Multipurpose Utilization of Mineral Resources, 2021(4):80-86. doi: 10.3969/j.issn.1000-6532.2021.04.012
[2] 邱显扬, 马先峰, 何晓娟, 等. 磁黄铁矿与黄铜矿浮选分离研究进展[J]. 矿业工程, 2011, 9(6): 29-32.
QIU X Y, MA X F, HE X J, et al. Research progress in flotation separation of pyrrhotite and chalcopyrite[J]. Mining Engineering, 2011, 9(6): 29-32.
[3] 赵清平, 蓝卓越, 童雄. 铜离子对闪锌矿、黄铁矿浮选的选择性活化机理研究[J]. 矿产综合利用, 2021(3):27-38.
ZHAO Q P, LAN Z Y, TONG X. Activation mechanism of selective flotation of spahalerite and pyrite by copper[J]. Multipurpose Utilization of Mineral Resources, 2021(3):27-38.
[4] 马先峰, 邱显扬, 何晓娟, 等. 黄铜矿与磁黄铁矿选别性质差异研究[J]. 有色金属(选矿部分), 2012(6):35-38.
MA X F, QIU X Y, HE X J, et al. Study on the difference in the separation properties of chalcopyrite and pyrrhotite[J]. Nonferrous Metals (Mineral Processing Section), 2012(6):35-38.
[5] 蔡美芳, 党志. 磁黄铁矿氧化机理及酸性矿山废水防治的研究进展[J]. 环境污染与防治, 2006(1):58-61. doi: 10.3969/j.issn.1001-3865.2006.01.018
CAI M F, DANG Z. Research progress on oxidation mechanism of pyrrhotite and prevention and control of acid mine wastewater[J]. Environmental Pollution & Control, 2006(1):58-61. doi: 10.3969/j.issn.1001-3865.2006.01.018
[6] 王双玉, 袁致涛, 刘磊, 等. 磁黄铁矿型铜铁多金属矿选矿研究进展[J]. 矿产综合利用, 2018(5):13-20. doi: 10.3969/j.issn.1000-6532.2018.05.003
WANG S Y, YUAN Z T, LIU L, et al. Research progress of pyrrhotite-type copper-iron polymetallic ore beneficiation[J]. Multipurpose Utilization of Mineral Resources, 2018(5):13-20. doi: 10.3969/j.issn.1000-6532.2018.05.003
[7] 刘能云, 邓海波, 王虹. 分离高硫磁铁矿中磁黄铁矿的研究进展[J]. 有色矿冶, 2009, 25(5):17-20. doi: 10.3969/j.issn.1007-967X.2009.05.007
LIU N Y, DENG H B, WANG H. Research progress in separating pyrrhotite from high-sulfur magnetite[J]. Nonferrous Mining and Metallurgy, 2009, 25(5):17-20. doi: 10.3969/j.issn.1007-967X.2009.05.007
-
