Experimental Study on Recovery of Super Pure Iron Concentrate from an Iron Concentrate in Sichuan
-
摘要:
四川某铁精矿中TFe品位为64.56%，杂质成分SiO2、Al2O3含量分别为5.50%和2.01%。物质组分研究表明，铁矿物主要以磁性铁形式存在，采用“阶段磨矿（再磨过程添加分散剂H01）-阶段磁选”工艺对该铁精矿进行提质降杂实验，实验可获得TFe品位为72.11%的超纯铁精矿产品，精矿中杂质成分SiO2含量为0.20%，Al2O3的含量为0.16%，酸不溶物的含量为0.28%，TFe的回收率为92.72%。
Abstract:The iron grade of a iron concentrate in Sichuan is 64.56%, and the content of SiO2 and Al2O3 is 5.50% and 2.01% respectively. Material composition research shows that iron minerals are mainly in the form of magnetic iron. The process of stage grinding and magnetic separation which added dispersant H01 in regrinding is carried out to increase iron grade and reduce silicon content. Finally, the super iron concentrate with iron grade 72.11%, SiO2 content 0.20%, Al2O3 content 0.16%, acid insoluble content 0.28%, and the iron recovery is 92.72%.
-
Key words:
- Iron concentrate /
- Stage grinding /
- Dispersant /
- Stage magnetic separation /
- Super pure iron concentrate
-
-
表 1 化学多元素分析结果/%
Table 1. Analysis results of chemistry multi-elements of the sample
TFe SiO2 Al2O3 K2O Na2O CaO MgO TS P TiO2 64.56 5.50 2.01 0.21 0.17 0.68 0.25 0.31 0.068 0.146
下载: 导出CSV
表 2 铁的物相分析结果
Table 2. Analysis results of iron phase of the sample
铁相态 含量/% 分布率/% 磁铁矿·磁黄铁矿 63.16 97.83 菱铁矿 0.15 0.23 氧化铁 0.35 0.54 硫化铁 0.90 1.40 全铁 64.56 100.00
下载: 导出CSV
表 3 -2 mm试样粒度组成及分析结果
Table 3. Result of the -2 mm particle size distribution of sample
粒级/mm 产率/% TFe品位/% TFe分布率/% +0.45 1.11 23.58 0.41 -0.45+0.25 6.39 50.41 4.99 -0.25+0.15 16.50 61.46 15.71 -0.15+0.074 30.76 64.77 30.86 -0.074+0.045 20.42 67.86 21.46 -0.045+0.038 3.35 68.84 3.57 -0.038 21.47 69.16 23.00 试样 100.00 64.56 100.00
下载: 导出CSV
表 4 粗选精矿粒度组成及分析结果
Table 4. Result of distribution of rough concentrate
粒级/mm 产率/% TFe品位/% TFe分布率/% -0.45+0.25 1.19 60.28 1.02 -0.25+0.15 6.82 67.34 6.50 -0.15+0.074 19.22 69.89 19.01 -0.074+0.045 32.36 71.19 32.61 -0.045+0.038 7.37 71.36 7.44 -0.038 33.04 71.45 33.42 合计 100.00 70.65 100.00
下载: 导出CSV
表 5 磁选全流程实验结果
Table 5. Magnetic experiment results of total procedure
产品名称 产率/% TFe品位/% TFe回收率/% 精矿1 81.57 72.14 90.98 精矿2 1.59 70.57 1.74 总铁精矿 83.16 72.11 92.72 次铁精矿（中矿1） 2.71 63.11 2.64 尾矿 9.87 13.43 2.05 中矿2 4.26 39.34 2.59 总尾矿 14.13 21.24 4.64 原 矿 100.00 64.68 100.00
下载: 导出CSV
表 6 总铁精矿化学多项分析结果/%
Table 6. Chemical composition of final iron concentrate ore
TFe SiO2 Al2O3 S Cu Zn 72.11 0.20 0.16 0.18 0.0016 0.0070 Ag Pb As P 酸不溶物 0.0064 0.0016 <0.005 <0.005 0.28
下载: 导出CSV
表 7 总铁精矿粒度组成分析结果
Table 7. Particle size distribution of final iron concentrate ore
粒级/mm 产率/% TFe
品位/%TFe
分布率/%+0.15 0.51 70.39 0.50 -0.15+0.074 23.26 71.49 23.06 -0.074+0.045 38.29 72.30 38.40 -0.045+0.038 2.24 72.29 2.24 -0.038 35.70 72.31 35.80 合计 100.00 72.11 100.00
下载: 导出CSV
-
[1] 李凤久, 尚新月, 李国峰, 等. 河北某铁矿铁精矿制备超级铁精矿试验[J]. 矿产综合利用, 2019(6):33-36. doi: 10.3969/j.issn.1000-6532.2019.06.007
LI F J, SHANG X Y, LI G F, et al. Experimental study on preparation of the super iron concentrate from an iron concentrate of an iron mine in Hebei Province[J]. Multipurpose Utilization of Mineral Resources, 2019(6):33-36. doi: 10.3969/j.issn.1000-6532.2019.06.007
[2] 宋英良, 陈中航, 辛思奇. 离心分选机在贫铁矿选别中的应用[J]. 矿产综合利用, 2019(5):140-143. doi: 10.3969/j.issn.1000-6532.2019.05.029
SONG Y L, CHEN Z H, XIN S Q. Application of centrifugal separator in poor iron ore benefication[J]. Multipurpose Utilization of Mineral Resources, 2019(5):140-143. doi: 10.3969/j.issn.1000-6532.2019.05.029
[3] 肖烈江. 阴离子捕收剂反浮选制备高纯铁精矿研究[D]. 沈阳: 东北大学, 2015.
XIAO L J. Research on the preparation of high-purity iron concentrate by reverse flotation with anionic collectors [D]. Shenyang: Northeastern University, 2015.
[4] 牛福生, 李卓林, 张晋霞, 等. 单一磁选法制备超纯铁精矿的试验研究[J]. 矿产综合利用, 2017(2):27-30. doi: 10.3969/j.issn.1000-6532.2017.02.007
NIU F S, LI Z L, ZHANG J X, et al. Experimental study on the preparation of ultra-pure iron concentrate by a single magnetic separation method[J]. Multipurpose Utilization of Mineral Resources, 2017(2):27-30. doi: 10.3969/j.issn.1000-6532.2017.02.007
[5] 刘建兵, 武改琴. 山西某区域超纯铁精矿选别试验研究[J]. 矿产综合利用, 2018(5):38-41. doi: 10.3969/j.issn.1000-6532.2018.05.008
LIU J B, WU G Q. Study on the beneficiation of ultra-pure iron concentrate in a certain area of Shanxi[J]. Multipurpose Utilization of Mineral Resources, 2018(5):38-41. doi: 10.3969/j.issn.1000-6532.2018.05.008
[6] 高斯, 黄自力, 王福坤, 等. 普通铁精矿制备超纯铁精矿试验研究[J]. 矿产综合利用, 2018(2):28-31. doi: 10.3969/j.issn.1000-6532.2018.02.007
GAO S, HUANG Z L, WANG F K, et al. Experimental research on preparation of ultra-pure iron concentrate from ordinary iron concentrate[J]. Multipurpose Utilization of Mineral Resources, 2018(2):28-31. doi: 10.3969/j.issn.1000-6532.2018.02.007
[7] 邹玄, 张晋霞, 牛福生, 等. 用河北某地磁铁矿石制备超纯铁精矿[J]. 金属矿山, 2016(7):117-120. doi: 10.3969/j.issn.1001-1250.2016.07.020
ZOU X, ZHANG J X, NIU F S, et al. Preparation of ultra-pure iron concentrate from magnetite ore in Hebei[J]. Metal Mine, 2016(7):117-120. doi: 10.3969/j.issn.1001-1250.2016.07.020
[8] 张晋霞, 牛福生, 徐之帅, 等. 用某铁精矿粉制取超纯铁精矿的选矿试验研究[J]. 金属矿山, 2009(5):73-74+87. doi: 10.3321/j.issn:1001-1250.2009.05.019
ZHANG J X, NIU F S, XU Z S, et al. Beneficiation test research on the preparation of ultra-pure iron concentrate by using certain iron concentrate powder[J]. Metal Mine, 2009(5):73-74+87. doi: 10.3321/j.issn:1001-1250.2009.05.019
[9] 高斯. 低品位铁矿选矿工艺及超纯铁精矿制备的研究[D]. 武汉: 武汉科技大学, 2018.
GAO S. Research on beneficiation technology of low-grade iron ore and preparation of ultra-pure iron concentrate [D]. Wuhan: Wuhan University of Science and Technology, 2018.
-
